Manufacturer
Sharp
Model Number
SMD2480CS
Description
24 Inch Microwave Drawer With Easy Touch
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
20A FUSE |
|
|
4X6MM SCREW |
|
|
AC CORD MOUNT ANGLE |
|
|
AIR FLOW CUSHION |
|
|
ANTENNA ASSY |
|
|
ANTENNA COVER |
|
|
AUTO DRAWER GEAR ASSY |
|
|
BACKPLATE |
|
|
BASE PLATE |
|
|
C/P REAR COVER |
|
|
CABINET SCREW/ CLEAR (ROHS) |
|
|
CANOE CLIP |
|
|
CAP NUT |
|
|
CAP NUT |
|
|
CHOKE COVER |
|
|
CONSUMER WARNING LABEL |
|
|
CONTROL PANEL ASSY |
|
|
CORD BUSHING |
|
|
CPU- DRAWER |
|
|
DHHS/GRD/CAUTION LABEL |
|
|
DOOR FRAME ASSY |
|
|
DOOR HORIZONTAL CUSHION |
|
|
DOOR PANEL ASSY |
|
|
DOOR STOPPER |
|
|
DOOR SUPPORT ANGLE A |
|
|
DOOR SUPPORT ANGLE B |
|
|
DOOR SUPPORT COVER |
|
|
DOOR VERTICAL CUSHION |
|
|
DRAWER HARNESS |
|
|
EXHAUST DUCT |
|
|
EXHAUST DUCT CUSHION |
|
|
FACEPLATE OUTERCASE COVER |
|
|
FAN MOTOR ASSY |
|
|
FAN MOTOR SUPPORT CUSHION |
|
|
HVC ASSY |
|
|
HVC BAND |
|
|
HVT CUSHION |
|
|
INDICATOR LED COVER |
|
|
INLET CUSHION |
|
|
INSTALLATION INSTRUCTIONS |
|
|
LAMP FILTER |
|
|
LATCH COVER |
|
|
LATCH HEAD L |
|
|
LATCH HEAD R |
|
|
LATCH HOOK L |
|
|
LATCH HOOK R |
|
|
LATCH SPRING |
|
|
LED CAVITY LIGHT ASSY |
|
|
LED PWB |
|
|
LED PWB HOLDER |
|
|
M3 X 10 SCREW - STEEL P-TIGHT |
|
|
M3 X 8 SCREW - TAP BINDING HEA |
|
|
M4 X 12 SCREW - COMMON (ROHS) |
|
|
M4 X 8 SCREW - T TAP TRUSS (RO |
|
|
M4 X 8 SCREW - TAP PAN HEAD |
|
|
M4-POINTED-8 |
|
|
MAG DUCT |
|
|
MAGNETRON |
|
|
MENU LABEL |
|
|
MONITOR CAUTION LABEL |
|
|
MONITOR FUSE |
|
|
NOISE FILTER UNIT |
|
|
OIL DAMPER |
|
|
OP MANUAL ASSY |
|
|
OUTER CASE CABINET |
|
|
OVEN TRAY ASSY |
|
|
OVEN/MG DM FUSE |
|
|
PARTITION AG BOTTOM |
|
|
PARTRITION AG REAR |
|
|
POWER SUPPLY CORD |
|
|
PSU HOLDER |
|
|
PSU- DRAWER |
|
|
PUSH LATCH |
|
|
RACK GEAR |
|
|
SCHEMATIC DIAGRAM |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW WITH WASHER |
|
|
SCREW WITH WASHER |
|
|
SCREW: 4MM X 8MM |
|
|
SEALER FILM |
|
|
SECONDARY INTERLOCK SWITCH / |
|
|
SENSOR ASSY |
|
|
SENSOR DUCT |
|
|
SENSOR HOLDER |
|
|
SENSOR MODULE |
|
|
SIDE ANGLE L |
|
|
SIDE ANGLE R |
|
|
SLIDE RAIL |
|
|
SPECIAL SCREW |
|
|
STIRRER MOTOR |
|
|
SW PSU HOLDER |
|
|
SW PSU- DRAWER |
|
|
TRANSFORMER |
|
|
USER CAUTION LABEL |
|
|
WAVEGUIDE COVER CLEANING LABEL |
|
|
WOOD SCREW (M4 X 20, PANHEAD) |
