Manufacturer
Samsung
Model Number
3WMD036S61P
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 0201-002394 | ADHESIVE-EPOXY;HT-1331S(SPL-K4),RED,550~ |
| 0201-001334 | ADHESIVE-SILICON;SE9187L,TRP,10 CPS,330M |
| DB94-01498G | ASSEMBLY BACK BODY |
| DB94-01529A | ASSEMBLY BEARING |
| DB94-40007A | ASSEMBLY BEARING |
| DB94-40007B | ASSEMBLY BEARING |
| DB90-12336A | ASSEMBLY CABI IN PARTS |
| DB90-12344A | ASSEMBLY CABI IN-MODULE |
| DB90-05969A | ASSEMBLY CASE-PCB |
| DB93-10943F | ASSEMBLY CONNECTOR WIRE |
| DB93-14238A | ASSEMBLY CONNECTOR WIRE-COMM |
| DB93-14039A | ASSEMBLY CONNECTOR WIRE-DC SIGNAL |
| DB93-14723A | ASSEMBLY CONNECTOR WIRE-DC SIGNAL |
| DB93-16338A | ASSEMBLY CONNECTOR WIRE-DC SIGNAL |
| DB93-09928B | ASSEMBLY CONNECTOR WIRE-EARTH |
| DB93-10798A | ASSEMBLY CONNECTOR WIRE-MOTOR |
| DB93-14203A | ASSEMBLY CONNECTOR WIRE-POWER |
| DB90-09982A | ASSEMBLY COVER CONTROL |
| DB94-08841A | ASSEMBLY DRAIN PARTS |
| DB94-08855A | ASSEMBLY DRAIN-MODULE |
| DB96-23365A | ASSEMBLY EVAP PARTS |
| DB96-10764A | ASSEMBLY EVAP SUB-REAR |
| DB96-07994A | ASSEMBLY EVAP-MAIN |
| DB96-10763E | ASSEMBLY EVAP-MAIN |
| DB96-07995A | ASSEMBLY EVAP-SUB REAR |
| DB96-09872K | ASSEMBLY EVAP-TOTAL |
| DB96-09872L | ASSEMBLY EVAP-TOTAL;MAX4,TSE,BLUE |
|
|
ASSEMBLY FAN CROSS |
| DB94-00119A | ASSEMBLY FAN CROSS |
| DB94-08849A | ASSEMBLY FAN IN PARTS |
| DB94-08861A | ASSEMBLY FAN IN-MODULE |
| DB90-03401A | ASSEMBLY HOLDER-FAN |
| DB94-00458D | ASSEMBLY HOSE DRAIN |
| DB96-03813E | ASSEMBLY INSULATION TUBE |
| DB98-29143A | ASSEMBLY LABEL BAR CODE |
| DB94-03882A | ASSEMBLY PCB AUTO |
| DB93-11439A | ASSEMBLY PCB SMD |
| DB94-00002X | ASSEMBLY PCB SMD |
| DB94-03881A | ASSEMBLY PCB SMD |
|
|
ASSEMBLY RUBBER BEARING |
| DB97-02418A | ASSEMBLY SCREW TAPPING |
| DB90-03402A | ASSEMBLY SUPPORT EVAP |
| DB95-05009E | ASSEMBLY THERMISTOR |
| DB95-05011B | ASSEMBLY THERMISTOR IN |
| DB94-01495N | ASSEMBLY TRAY DRAIN |
| DB96-11295B | ASSEMBLY TUBE EVAP OUT |
| DB96-09870E | ASSEMBLY TUBE EVAP-IN |
| DB96-23036A | ASSEMBLY TUBE EVAP-U BEND |
| DB96-10256A | ASSEMBLY TUBE U BEND |
| DB96-10257A | ASSEMBLY TUBE U BEND |
| DB93-50001A | ASSEMBLY WIRE RING SOLD |
| DB94-02043A | ASSEMBLY-CROSS FAN UNIT |
| DB97-16183A | ASSEMBLY-CUSHION-LF |
| 6902-000286 | BAG PE |
| 6902-000869 | BAG PE |
| 6902-002371 | BAG PE;HDPE,T0.015,W200,L300,T |
| 3301-002315 | BEAD-SMD;120OHM/100MHZ,3.2X1.6MM,TP,0.03 |
| DB61-03253A | BLADE-CONNECTOR LF |
| DB61-03252A | BLADE-CONNECTOR RH |
| DB61-04465A | BLADE-H |
| DB61-03254A | BLADE-V A |
| DB61-03255A | BLADE-V B |
| DB61-03208B | BODY BACK |
| DB61-03215A | BODY BACK-CUSHION |
| DB61-03232A | BRACKET-EARTH |
| DB61-03205A | BRACKET-EVAP |
| DB64-02139A | BUTTON POWER |
| 3002-001129 | BUZZER-PIEZO |
| 2401-002619 | C-AL |
| 2401-006201 | C-AL |
| 2402-000120 | C-AL, SMD |
| 2402-001145 | C-AL, SMD |
| 2402-001254 | C-AL, SMD |
| 2402-001517 | C-AL,SMD;47UF,20%,50V,TP,6.3X6.3X7.7MM, |
| 2401-004519 | C-AL;2200UF,20%,25V,TP,12.5X25MM,5MM,-40 |
| 2401-004553 | C-AL;820UF,20%,25V,TP,10X20MM,5MM,-40TO+ |
| 2203-000440 | C-CER, CHIP |
| 2203-001071 | C-CER, CHIP |
| 2203-002041 | C-CER, CHIP |
| 2203-002285 | C-CER, CHIP |
| 2203-005249 | C-CER, CHIP |
| 2203-006158 | C-CER, CHIP |
| 2203-006348 | C-CER, CHIP |
| 2203-007456 | C-CER, CHIP |
| 2203-007486 | C-CER, CHIP |
| 2203-007544 | C-CER, CHIP |
| 2203-010142 | C-CER,CHIP |
| 2203-010033 | C-CER,CHIP;220NF,10%,25V,X5R,TP,1005,T0. |
| 2201-000915 | C-CERAMIC, DISC |
| 2201-002429 | C-CERAMIC,DISC;10NF,+80-20%,2000V,Y5U,TP |
| 2201-002688 | C-CERAMIC,DISC;2.2NF,20%,400VAC,Y5U,TP,1 |
| 2202-002252 | C-CERAMIC,MLC-RADIAL;1NF,10%,1000V,R,TP, |
| 2301-002484 | C-FILM,LEAD-MPPF;470NF,10%,275VAC,BK,18X |
| 6501-000121 | CABLE TIE;DA-368,PA66,NTR,T1.5,W7.6,L0.3 |
| 6501-001106 | CABLE TIE;T1.0,W2.5,L100,BLK,NYLON66 |
| 6501-001110 | CABLE TIE;T1.2,W4.8,L200,NYLON66 |
| DB81-00607A | CABLE-TIE |
| DB61-06824A | CASE CONTROL IN |
| DB61-03648A | CASE PCB |
| DB61-07592A | CASE-BOTTOM |
| DB61-07593A | CASE-TOP |
| DB61-03857A | CLIP-DRAIN HOSE;-,STS304,T1, |
| 0204-008356 | COATING AGENT;PAS-7900,99%,80~250CPS,TRA |
| DB27-00096A | COIL CHOKE |
| DB27-00070A | COIL CHOKE;18MH,500MA,8.4X3.4MM,MN-ZN,4P |
| 3711-000177 | CONNECTOR-HEADER |
| 3711-000760 | CONNECTOR-HEADER |
| 3711-000798 | CONNECTOR-HEADER |
| 3711-003404 | CONNECTOR-HEADER |
| 3711-005223 | CONNECTOR-HEADER |
| 0102-001565 | COPPER TUBE |
| 0102-001513 | COPPER TUBE |
| 0102-001526 | COPPER TUBE , C1220T,O,6.35,0.6,ROLL, |
| 0102-001761 | COPPER TUBE;C1220T,0,9.52,0.6 |
| 0102-001548 | COPPER TUBE;C1220T,O,15.88,0.8,ROLL,- |
| 0102-001530 | COPPER TUBE;C1220T,O,7,0.41,ROLL |
| 0102-001533 | COPPER TUBE;C1220T,O,7,0.6,ROLL, |
| 0102-001534 | COPPER TUBE;C1220T,O,7,0.7,ROLL,- |
| 0102-001539 | COPPER TUBE;C1220T,O,9.5,0.7,ROLL,- |
| DB63-02689A | COVER DISPLAY |
| DB63-01759A | COVER-BEARING |
| DB63-01631A | COVER-FLARE |
| DB69-02491A | CUSHION-LF |
| DB69-02492A | CUSHION-RH |
| DB64-02515E | DECORATION-GRILLE |
| 0402-000324 | DIODE-BRIDGE |
| 0402-001192 | DIODE-RECTIFIER |
| 0402-001472 | DIODE-RECTIFIER |
|
|
DIODE-RECTIFIER |
| 0402-001741 | DIODE-RECTIFIER;S1M,1000V,1A,SMA,TP |
| 0402-000553 | DIODE-SCHOTTKY |
| 0404-001241 | DIODE-SCHOTTKY;MBR20100CT,100V,20000MA,T |
| 0401-001010 | DIODE-SWITCHING |
| 0401-001099 | DIODE-SWITCHING |
| 0406-001204 | DIODE-TVS |
| 0406-001230 | DIODE-TVS |
| 0406-001239 | DIODE-TVS |
| 0403-000461 | DIODE-ZENER |
| DB62-04004A | DISTRIBUTER AIR |
| DB60-30010B | FASTENER-NUT FLARE |
| DB60-30010D | FASTENER-NUT FLARE |
| 0505-000110 | FET-SILICON |
| DB62-04031C | FIN EVAP-B |
| DB62-02907E | FIN EVAP-B |
| DB62-05075A | FIN-EVAP MAIN |
| 0204-004665 | FLUX;KSP-70M-S,MIXTURE,NO,FLUX,13% |
| DB01-00129A | FOIL |
| 3601-001336 | FUSE-AXIAL LEAD |
| DB63-01765F | GUARD-AIR FILTER |
| DB63-03891A | GUARD-SCREEN |
| 3711-009637 | HEADER-BOARD TO BOARD;BK,STRAIGHT,1R,7P, |
| 3711-000015 | HEADER-BOARD TO CABLE |
| 3711-000296 | HEADER-BOARD TO CABLE |
| 3711-000999 | HEADER-BOARD TO CABLE |
| 3711-002001 | HEADER-BOARD TO CABLE |
| 3711-004122 | HEADER-BOARD TO CABLE |
| 3711-004236 | HEADER-BOARD TO CABLE |
| 3711-004379 | HEADER-BOARD TO CABLE |
| 3711-005405 | HEADER-BOARD TO CABLE |
| 3711-005797 | HEADER-BOARD TO CABLE |
| 3711-009174 | HEADER-BOARD TO CABLE , BOX,11P,1R,2.0MM,S |
| DB61-05216A | HOLDER SENSOR;DVM MODEL,C1220T-O,T0.55,W |
| DB61-05217A | HOLDER SENSOR;DVM MODEL,C1220T-O,T0.55,W |
| DB61-03250A | HOLDER-BODY BACK |
| DB61-03199A | HOLDER-FAN |
| DB61-03200A | HOLDER-MOTOR |
| DB61-03218B | HOLDER-PIPE |
| DB61-01097A | HOLDER-WIRE CLAMP |
| DB67-00944A | HOSE DRAIN;VIVALDI,PP,BLACK,HG-0760S,S |
| 1006-001325 | IC-BUS TRANSCEIVER |
| 0801-000393 | IC-CMOS LOGIC |
| 1103-001507 | IC-EEPROM |
| 1205-004060 | IC-INTERFACE |
| 0903-002266 | IC-MICROCONTROLLER;A34M418YLN-01,LQFP,12 |
| 1203-006759 | IC-POSI.ADJUST REG. |
| 1203-002722 | IC-POSI.FIXED REG. |
| 1203-002835 | IC-POSI.FIXED REG. |
| 1203-006245 | IC-VOL. DETECTOR |
| 1202-000104 | IC-VOLTAGE COMP. |
| 2702-001123 | INDUCTOR-RADIAL |
| 2703-004634 | INDUCTOR-SMD |
| DB62-03481F | INSULATION TUBE |
| DB62-05974A | INSULATION-HOSE;VIVALDI,PE FOAM,4,97,525 |
| DB68-03058A | LABEL BAR CODE |
| DB68-01350B | LABEL BAR CODE |
| DB68-02809A | LABEL BAR CODE |
| DB68-02988A | LABEL BAR CODE |
| DB68-11576A | LABEL BAR CODE |
| DB68-05458A | LABEL BAR CODE;AM9000H,PAPER,W17.5,L18 |
| DB98-33292A | LABEL INSTRUCTION |
| DB98-33293A | LABEL INSTRUCTION |
| DG68-01358A | LABEL INSTRUCTION;OVEN,GLOBAL,PET,W50,L2 |
| DB68-03070B | LABEL PACKING |
| DB68-03068G | LABEL RATING |
| DB98-30437A | LABEL WARNING |
| 0601-002345 | LED |
| 0601-003048 | LED |
| 0601-002679 | LED;SMD(TOP VIEW),Y-GRN,WATER CLEAR,1.2X |
| 0601-002419 | LED;SMD(TOP VIEW),YEL,WATER CLEAR,1.6X0. |
| 0609-001393 | MODULE REMOTE CONTROL |
| DB31-00332C | MOTOR FAN |
| DB31-00369D | MOTOR STEP |
| DB67-00276E | NIPPLE |
| DB67-00276B | NIPPLE;C3604,5/8-18UNF |
| DB69-03089C | PACKING ANGLE |
| DB69-01281P | PAD CUSHION |
| DB69-01779C | PAD CUSHION-IN |
| DB64-02517A | PANEL FRONT |
| DB93-11438A | PCB ASSEMBLY AUTO |
| DB93-11440A | PCB ASSEMBLY MANUAL |
| DB92-02809A | PCB ASSEMBLY SUB |
| DB92-04020A | PCB ASSEMBLY SUB |
| DB93-11009A | PCB ASSEMBLY SUB-DISPLAY |
| DB41-01192A | PCB SUB |
| DB41-01345A | PCB SUB |
| DB41-00866A | PCB SUB-DISPLAY |
| 0604-001405 | PHOTO-COUPLER;TR,200-400%,200MW,SOP,TP |
| DB60-70016A | PIN-STAPLE |
| DB61-06826A | PLATE CONTROL-MAIN |
| DB61-06825A | PLATE CONTROL-SUB |
| DB70-00775A | PLATE-EVAP JOINT |
| DB70-00774A | PLATE-EVAP MAIN |
| DB70-00776A | PLATE-EVAP SUB REAR |
| DB70-00787A | PLATE-HANGER |
| DB70-00931A | PLATE-KNOCK OUT |
| 2001-000436 | R-CARBON |
| 2007-000029 | R-CHIP |
| 2007-000052 | R-CHIP |
| 2007-000072 | R-CHIP |
| 2007-000078 | R-CHIP |
| 2007-000084 | R-CHIP |
| 2007-000090 | R-CHIP |
| 2007-000385 | R-CHIP |
| 2007-000394 | R-CHIP |
| 2007-000465 | R-CHIP |
| 2007-000467 | R-CHIP |
| 2007-000476 | R-CHIP |
| 2007-000924 | R-CHIP |
| 2007-001011 | R-CHIP |
| 2007-001297 | R-CHIP |
| 2007-001318 | R-CHIP |
| 2007-007306 | R-CHIP |
| 2007-007336 | R-CHIP |
| 2007-007587 | R-CHIP |
| 2007-007942 | R-CHIP |
| 2007-008175 | R-CHIP |
| 2007-008724 | R-CHIP |
| 2007-001051 | R-CHIP;6.04KOHM,1%,1/4W,TP,3216 |
| 2007-009149 | R-CHIP;6.8OHM,1%,1/16W,TP,1005 |
| AR36DXFUMGMULX | RAC,9.70,KW,SETIN,HP,R32 |
| 3501-001491 | RELAY-MINIATURE |
| 0103-004017 | RESIN ABS;HI-121H,NATURAL,NC0001 |
| 0103-004101 | RESIN HIPS |
| 0103-004128 | RESIN HIPS |
| 0103-003269 | RESIN HIPS;F-744/NATURAL,NATURAL,NC0001, |
| 0103-003459 | RESIN PP |
| 2802-001211 | RESONATOR-CERAMIC |
| 2802-001294 | RESONATOR-CERAMIC |
| DB73-00128A | RUBBER-BEARING |
| DB73-00181A | RUBBER-BEARING |
| DB73-00180B | RUBBER-CAP DRAIN |
| DB73-00486A | RUBBER-HOSE;VIVALDI,NBR,L19.7,SSEC,BLA |
|
|
SCREW-TAPPING |
| 6002-000474 | SCREW-TAPPING |
| 6002-000535 | SCREW-TAPPING |
|
|
SCREW-TAPPING |
| 6002-001163 | SCREW-TAPPING |
| 6002-001208 | SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
| DB62-11656B | SEAL CUTT |
| DB62-05807J | SEAL-BODY BACK |
| DB62-05062H | SEAL-BODY BACK FRONT |
| DB62-05062J | SEAL-BODY BACK UP |
| DB62-05899V | SEAL-BUTTON POWER |
| DB62-04684T | SEAL-CONTROL B |
| DB62-05062G | SEAL-EVAP UP |
| DB62-05807K | SEAL-PANEL FRONT |
| DB62-05085A | SEAL-SUPPORT EVAP |
| DB62-05058A | SEAL-TRAY LF A |
| DB62-05059A | SEAL-TRAY LF B |
| DB62-05102A | SEAL-TRAY LOW MID |
| DB62-05062C | SEAL-TRAY MID A |
| DB62-05062D | SEAL-TRAY MID B |
| DB62-05029B | SEAL-TRAY MID C |
| DB62-05060A | SEAL-TRAY RH A |
| DB62-05062A | SEAL-TRAY RH B |
| DB62-05063A | SEAL-TRAY RH C |
| DB62-05064A | SEAL-TRAY RH D |
| DB62-05061A | SEAL-TRAY RH E |
| DB62-05068A | SEAL-TRAY RH MID |
| DB62-05065B | SEAL-TRAY UP A |
| DB62-05066A | SEAL-TRAY UP B |
| DB62-05062B | SEAL-TRAY UP C |
| DB32-00241C | SENSOR HUMIDITY |
| 0406-001084 | SMG PART |
| 1203-009880 | SMG PART |
| 2007-000140 | SMG PART |
| 2007-000148 | SMG PART |
| 2007-000172 | SMG PART |
| 2007-007107 | SMG PART |
| 2007-007134 | SMG PART |
| 2007-007135 | SMG PART |
| 2007-007136 | SMG PART |
| 2007-007139 | SMG PART |
| 2007-007142 | SMG PART |
| 2007-007310 | SMG PART |
| 2007-007311 | SMG PART |
| 2007-007313 | SMG PART |
| 2007-007317 | SMG PART |
| 2007-007318 | SMG PART |
| 2007-007586 | SMG PART |
| 2007-007590 | SMG PART |
| 2007-007671 | SMG PART |
| 2007-007766 | SMG PART |
| 2007-007791 | SMG PART |
| 2007-007861 | SMG PART |
| 2007-008117 | SMG PART |
| 2203-000233 | SMG PART |
| 2203-000254 | SMG PART |
| 2203-000438 | SMG PART |
| 2203-000489 | SMG PART |
| 2203-005393 | SMG PART |
| 2203-006841 | SMG PART |
| 2203-007809 | SMG PART |
| DB26-00130D | SMG PART |
| 3710-004519 | SOCKET-BOARD TO BOARD;7P,1R,2MM,STRAIGHT |
| 0202-001338 | SOLDER-BAR |
| 0202-001976 | SOLDER-CREAM;LST-309M-K21 (PWM-118),D20~ |
| 0202-001022 | SOLDER-SILVER |
| 0202-001464 | SOLDER-SILVER;L450,91CU/1.9AG/6.95P |
| 0202-001463 | SOLDER-WIRE |
| 0202-001608 | SOLDER-WIRE FLUX |
| 0204-005794 | SOLVENT;S-1000,(CH3)2CHOH,100%,0.79 |
| DB60-00304A | SPACER-EVAP LOW |
| DB61-03207B | SPRING ETC-EVAP |
| DB81-00635A | SPRING ETC-SENSOR |
| 0101-002932 | STEEL PLATE;GI,SGCC,0.8MM,647MM,Z12,NC |
| 0101-002933 | STEEL PLATE;GI,SGCC,1,Z14,NC |
| 0101-002982 | STEEL PLATE;STAINLESS,STS304,0.3MM,NO.4 |
| 0101-003236 | STEEL PLATE;STAINLESS,STS304,1MM,1000MM, |
| DB61-03209A | SUPPORT-EVAP |
| 3404-001220 | SWITCH-TACT |
| DB02-00002A | TAPE ETC |
| DA02-00092A | TAPE ETC-OPP;BLUE,OPP,T0.08,W4 |
| DB02-00029B | TAPE ETC;RAC,OPP,0.05MM,80MM,500M,TRANSP |
| DE02-00029B | TAPE FILAMENT |
| DB72-30034F | TAPE-OPP |
| 0203-001109 | TAPE-SINGLE FACE;OPP,T0.075,W75,L800M,CL |
| DB37-00033A | TERMINAL BLOCK;DAF-4P-M,MELAMINE,300V,25 |
| 1404-001413 | THERMISTOR-NTC |
| 1404-001194 | THERMISTOR-PTC |
| 1404-001872 | THERMISTOR-PTC |
| 0506-000175 | TR-ARRAY |
| 0504-000001 | TR-DIGITAL |
| 0504-000127 | TR-DIGITAL |
| 0504-001064 | TR-DIGITAL |
| 0504-001080 | TR-DIGITAL |
| 0502-001266 | TR-POWER |
| 0501-000465 | TR-SMALL SIGNAL |
| 0501-000467 | TR-SMALL SIGNAL |
| DB26-00137A | TRANS POWER |
| DB63-01755A | TRAY DRAIN |
| DB63-01760A | TRAY-CUSHION UP |
| DB62-06660A | TUBE EVAP-OUT A |
| DB62-06660B | TUBE EVAP-OUT B |
| DB62-06660C | TUBE EVAP-OUT C |
| DB62-06660D | TUBE EVAP-OUT D |
| DB62-06660E | TUBE EVAP-OUT E |
| DB62-06660F | TUBE EVAP-OUT F |
| DB62-02348G | TUBE HAIR PIN |
| DB62-02348H | TUBE HAIR PIN |
| DB62-05793A | TUBE JUMP |
| DB62-06999A | TUBE-CU;C1220T-O,T0.25,OD7,L,ID6.3,TW0.2 |
| DB62-07332A | TUBE-PINCH |
| DB62-30369A | TUBE-U BEND |
| DB62-30368A | TUBE-U BEND;COMMON USE,C1220T-O,T0.41,OD |
| 1405-001470 | VARISTOR |
| 4709-003260 | |
| 6801-002381 | |
| DA46-01001A | |
| DB41-01539A | |
| DB63-04638A | |
| DB64-02516C | |
| DB64-02518C | |
| DB68-13026A | |
| DB68-13027A | |
| DB68-13071A | |
| DB68-13151A | |
| DB68-13152A | |
| DB69-02503G | |
| DB90-05771C | |
| DB90-09928B | |
| DB90-11882W | |
| DB91-02714A | |
| DB92-02101J | |
| DB92-05080D | |
| DB92-05773B | |
| DB92-05779B | |
| DB92-05800B | |
| DB92-05850A | |
| DB93-17392D | |
| DB93-18051A | |
| DB93-18058B | |
| DB94-10572A | |
| DB94-10573A | |
| DB96-25924Q | |
| DB97-35402B | |
| DB98-40751A | |
| DB98-40923A |
