Manufacturer
Samsung
Model Number
AQV12VBCN
Description
Split-type Air Conditioner
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| DB94-01152B | ASSEMBLY BACK BODY |
| DB98-30154A | ASSEMBLY BAR CODE BOX |
| DB94-40007B | ASSEMBLY BEARING |
| DB97-02075A | ASSEMBLY BOLT SPECIAL |
| DB94-00479A | ASSEMBLY BOSS FAN |
| DB93-04695A | ASSEMBLY CONNECTOR WIRE |
| DB93-04557A | ASSEMBLY CONNECTOR WIRE |
| DB93-04484A | ASSEMBLY CONNECTOR WIRE |
| DB93-04622A | ASSEMBLY CONNECTOR WIRE-DISPLAY |
| DB93-04367A | ASSEMBLY CONNECTOR WIRE-POWER |
| DB93-05854E | ASSEMBLY CONTROL IN |
| DB93-05854A | ASSEMBLY CONTROL IN |
| DB97-08524A | ASSEMBLY CUSHION LF |
| DB97-08525A | ASSEMBLY CUSHION RH |
| DB93-04452F | ASSEMBLY DISPLAY |
| DB96-08819A | ASSEMBLY EVAP |
| DB96-08820A | ASSEMBLY EVAP MAIN |
| DB96-04546D | ASSEMBLY EVAP SUB |
| DB96-03149A | ASSEMBLY EVAP-SUPPORT RH |
| DB94-00456A | ASSEMBLY FAN CROSS |
|
|
ASSEMBLY FILTER BIO |
| DB94-00458D | ASSEMBLY HOSE DRAIN |
| DB94-00458B | ASSEMBLY HOSE DRAIN |
| DB98-28433A | ASSEMBLY LABEL BARCODE |
| DB98-05714A | ASSEMBLY LABEL BARCODE |
| DB98-26861A | ASSEMBLY LABEL DIAGRAM IN |
| DB98-28031A | ASSEMBLY LABEL EVAP |
| DB98-28756A | ASSEMBLY LABEL KYOTO PROTOCOL |
| DB92-01087H | ASSEMBLY PANEL FRONT |
| DB97-02851C | ASSEMBLY PLATE HANGER |
| DB97-02851B | ASSEMBLY PLATE HANGER |
| DB91-00434A | ASSEMBLY POWER CORD CORE |
| DB93-04700P | ASSEMBLY REMOTE CONTROL |
|
|
ASSEMBLY RUBBER BEARING |
| DB97-02418A | ASSEMBLY SCREW TAPPING |
| DB97-02417A | ASSEMBLY SCREW TAPPING |
| DB93-04230B | ASSEMBLY SPI |
| DB98-08894A | ASSEMBLY TAPE |
| DB95-01113A | ASSEMBLY THEMISTOR-WIRE |
| DB95-01990A | ASSEMBLY THERMISTOR IN |
| DB94-01237C | ASSEMBLY TRAY DRAIN |
| DB94-01237A | ASSEMBLY TRAY DRAIN |
| DB96-03056A | ASSEMBLY TUBE EVAP IN |
| DB96-11684A | ASSEMBLY TUBE EVAP OUT |
| DB96-10973A | ASSEMBLY TUBE EVAP OUT |
| DB96-10257A | ASSEMBLY TUBE U BEND |
| DB96-10256A | ASSEMBLY TUBE U BEND |
| DB96-03214A | ASSEMBLY TUBE U-BEND |
| DB92-01202C | ASSEMBLY WINDOW MIRROR |
| DB93-50001A | ASSEMBLY WIRE RING SOLD |
| DB90-04032A | ASSY CABI IN PARTS;NEO VIVACE1,SSEC |
| DB93-04350B | ASSY CONNECTOR WIRE-PCB;AQV12FA,12K_IN |
| DB93-04485A | ASSY CONNECTOR WIRE;5,1007,26,RED,2504HP |
| DB93-04487A | ASSY CONNECTOR WIRE;5,1007,28,RED,25045H |
| DB93-04814A | ASSY CONNECTOR WIRE;FORTE1-PJT,UL1015 20 |
| DB93-06153A | ASSY CONNECTOR WIRE;USE IN-MONT BLANCPJT |
| DB93-06085A | ASSY CONTROL IN PARTS;HP,INV,E, |
| DB94-01308A | ASSY DRAIN PARTS;-,12K,SSEC |
| DB94-01172F | ASSY DRAIN PARTS;-,AS12VBANMCW |
| DB96-08811A | ASSY EVAP PARTS;NEO VIVACE 1,SSEC |
| DB94-01305A | ASSY FAN IN PARTS;12K,SSEC |
| DB90-03327K | ASSY FRAME GRILLE;NEO VIVACE,SSEC |
| DB97-08320A | ASSY MANUAL PART;-,HP,INV,E, |
| DB91-00571A | ASSY MICOM;INVERTER RAC VIVACE1 MICOM,ST |
| DB97-08781A | ASSY PACKING IN PARTS;-,NEO VIVACE1,SSEC |
| DB92-01414A | ASSY PANEL FRONT PARTS;-, |
| DB92-01226A | ASSY PANEL FRONT PARTS;-, |
| DB97-08805A | ASSY PRINT IN PARTS;-,NO, |
| DB98-28492A | ASSY-INSTALLATION MANUAL;HP,INV,E,FORTE, |
| DB98-28489M | ASSY-LABEL ENERGY;HP,INV,E,EUR,SSEC |
| DB98-28882M | ASSY-LABEL RATING IN;HP,INV,E,EUR,PVC,SS |
| DB95-01140B | ASSY-TERMINAL BLOCK;MB1-PJT,300V,25A,3P, |
| DB98-28491A | ASSY-USERS MANUAL;HP,INV,E,N,N,EUROP,VIV |
| DB98-27310A | ASSY-WARRANTY CARD;NO,E,R22,VIVACE,SSEC, |
| DB69-01414A | BAG CARRYING |
| DB69-00921A | BAG CARRYING;HDPE,T0.02,W95,L200,TRP,REC |
| 6902-000250 | BAG PE |
| 6902-000103 | BAG PE |
| DB47-90024A | BATTERY-MN |
| DB61-02908A | BLADE-H |
| DB61-01636A | BLADE-V |
| DB61-03028A | BODY BACK |
| DB64-01652A | BUTTON-POWER |
| 3002-001129 | BUZZER-PIEZO |
| 2401-003107 | C-AL |
| 2401-002300 | C-AL |
| 2401-000151 | C-AL |
| 2401-000058 | C-AL |
| 2401-000037 | C-AL |
| 2401-003518 | C-AL;6.8UF,20%,450V,GP,TP,10X16MM,5 |
| 2203-005249 | C-CER, CHIP |
| 2203-000444 | C-CER, CHIP |
| 2203-000440 | C-CER, CHIP |
| 2203-000257 | C-CER, CHIP |
| 2203-000192 | C-CER, CHIP |
| 2203-001562 | C-CERAMIC, CHIP |
| 2201-002193 | C-CERAMIC, DISC |
| 2201-000987 | C-CERAMIC, DISC |
| 2201-000983 | C-CERAMIC, DISC |
| 2202-000780 | C-CERAMIC, MLC-AXIAL |
| 2202-000173 | C-CERAMIC, MLC-AXIAL |
| 2301-001945 | C-FILM, LEAD |
|
|
C-FILM, LEAD |
| 2301-001251 | C-FILM, LEAD |
| 2301-000256 | C-FILM, LEAD-PEF |
| 2301-000141 | C-FILM, LEAD-PEF |
| 2301-001220 | C-FILM, LEAD-PPF |
| DB65-10088C | CABLE TIE |
|
|
CABLE TIE |
| DB67-00499C | CAP-SCREW |
| DB67-00942A | CAP;VIVALDI-P/J,SHP2,1,5.2,11.5,18.5, |
| DB68-02596B | CARD WARRANTY |
| DB61-02907A | CASE CONTROL |
| DB61-02907B | CASE CONTROL IN |
| DC02-10009A | CHEMICALS-LOCK SCREW |
| DB65-10074B | CLAMP-CABLE |
| DB61-03857A | CLIP-DRAIN HOSE;-,STS304,T1, |
| DB27-00017A | COIL CHOKE |
| DB39-00148A | CONNECT WIRE-EARTH;1P,UL1015AWG16,L200, |
| 3711-003404 | CONNECTOR-HEADER |
| 3711-000262 | CONNECTOR-HEADER |
| 0102-001525 | COPPER TUBE |
| 0102-001431 | COPPER TUBE;C1220T,H,OD9.52,T0.7, |
| 0102-001515 | COPPER TUBE;C1220T,O,6.35,0.7,ROLL, |
| 0102-001530 | COPPER TUBE;C1220T,O,7,0.41,ROLL |
| 0102-001531 | COPPER TUBE;C1220T,O,7,0.44,ROLL, |
| 0102-001534 | COPPER TUBE;C1220T,O,7,0.7,ROLL, |
| 0102-001537 | COPPER TUBE;C1220T,O,7.94,0.5,ROLL, |
| 0102-000252 | COPPER-TUBE |
| DB90-04485A | COVER ASSEMBLY TERMINAL |
| DB90-02167B | COVER ASSEMBLY-CONTROL IN |
| DB63-01659A | COVER PCB |
| DB63-00844C | COVER TERMINAL |
| DB63-00850A | COVER-BEARING |
| DB63-01630A | COVER-DISPLAY |
| DB63-00963A | COVER-FLARE |
| DB63-01583A | COVER-MPI |
| DB63-00844D | COVER-TERMINAL |
| DB69-00839A | CUSHION EPS-TRAY RH |
| DB69-01614A | CUSHION PAD |
| DB69-01603C | CUSHION PAD |
| DB69-01538A | CUSHION-LF |
| DB69-01539A | CUSHION-RH |
|
|
DIODE-BRIDGE |
| 0402-001427 | DIODE-RECTIFIER |
| 0402-001213 | DIODE-RECTIFIER |
|
|
DIODE-RECTIFIER |
| 0401-000005 | DIODE-SWITCHING |
| 0406-001086 | DIODE-TVS |
| 0403-001492 | DIODE-ZENER |
| 0403-001285 | DIODE-ZENER |
| 0403-000466 | DIODE-ZENER |
| 0403-000252 | DIODE-ZENER |
| DB96-09549A | EVAPERATER ASSEEMBLY TOTAL UNIT |
| DB75-00261R | EVAPORATOR-MAIN |
| DB75-00262K | EVAPORATOR-SUB |
| DB67-00394A | FAN-CROSS A |
| DB67-00395A | FAN-CROSS B |
| DB67-00396A | FAN-CROSS C |
| DB60-30010B | FASTENER-NUT FLARE |
| DB60-30010A | FASTENER-NUT FLARE |
| DB63-00615B | FILTER-CLEANER |
|
|
FILTER-DEODORIZATION |
|
|
FILTER-PRE |
| DB62-02906E | FIN EVAP-A;AQT24W6WE,A1100-H26,T0.095, |
| DB62-03337D | FIN EVAP-B |
| DB01-00129A | FOIL |
| DB61-02910A | FRAME-GRILLE;VV,HIPS,2.5,210,790,VIC |
| 3601-000263 | FUSE-CARTRIDGE |
| 3601-001209 | FUSE-RADIAL LEAD |
| 0207-001448 | GAS-NITROGEN |
| DB66-01155A | GEAR-PINION |
| DB66-01156A | GEAR-RACK |
| 3711-006040 | HEADER-BOARD TO BOARD |
| 3711-004484 | HEADER-BOARD TO CABLE |
| 3711-004379 | HEADER-BOARD TO CABLE |
| 3711-004352 | HEADER-BOARD TO CABLE |
| 3711-004067 | HEADER-BOARD TO CABLE |
| 3711-000999 | HEADER-BOARD TO CABLE |
| 3711-000941 | HEADER-BOARD TO CABLE |
| 3711-000879 | HEADER-BOARD TO CABLE |
| DB61-00924A | HOLDER-FUSE |
| DB61-01638B | HOLDER-PIPE |
| DB61-40055B | HOLDER-SENSOR |
| DB61-01097A | HOLDER-WIRE CLAMP |
| DB61-03156A | HOLDER-WIRE;VIVACE,PC,1.5,10.5,18.6,WH |
| DB67-00944A | HOSE DRAIN;VIVALDI,PP,BLACK,HG-0760S,S |
| DB09-00338A | IC MICOM |
| 1103-001175 | IC-EEPROM |
| 1203-000429 | IC-POSI.FIXED REG. |
| 1203-002545 | IC-PWM CONTROLLER |
| 1203-003334 | IC-RESET |
| 1003-001462 | IC-SOURCE DRIVER |
| 2702-001118 | INDUCTOR-RADIAL |
| DB62-03236C | INSULATION TUBE |
| DB62-04473A | INSULATION-BODY BACK;VV,EPS,72,115,635, |
| DB62-05974A | INSULATION-HOSE;VIVALDI,PE FOAM,4,97,525 |
| DB68-02809A | LABEL BAR CODE |
| DB68-02705A | LABEL BAR CODE |
| DB98-27335A | LABEL INSTRUCTION;-,PET,W35,L17, |
| DB66-01152A | LINK-GRILLE |
| DB66-01176A | LINK-SUPPORT |
| DB93-05866B | MAIN PCB ASSEMBLY |
| 0609-001204 | MODULE REMOTE CONTROL |
|
|
MOTOR FAN |
|
|
MOTOR STEP |
| DB31-00369B | MOTOR STEP |
| DB67-00276A | NIPPLE |
| DB67-60023A | NIPPLE-1/4' |
| DB67-00276B | NIPPLE;C3604,5/8-18UNF |
| DB98-15081A | PACKING CASE-IN |
| DB69-01679A | PAD-ANGLE |
| DB64-01633A | PANEL FRONT |
| DB64-01634B | PANEL-MID |
| DB93-04430A | PCB ASSEMBLY SUB |
| DB93-04256B | PCB ASSEMBLY SUB |
| DB41-00526A | PCB MAIN;VIVACE-PJT 9K/12K,CEM-3,2,1.0,T |
| DB41-00677A | PCB SUB-AC COMM;FORTE,CEM-3,2,1.0,T1.6,5 |
| DB41-00555A | PCB-MODULE;VIVACH,FR-1,REVISION 1,1.6T |
| 0604-001172 | PHOTO-COUPLER |
| 0604-001038 | PHOTO-COUPLER |
| 0604-001003 | PHOTO-COUPLER |
| DB60-70016A | PIN-STAPLE |
| DB61-01639A | PLATE-CONTROL IN;SGCC-M,T1,SSEC,SS-PJT |
| DB61-02478B | PLATE-COVER PCB |
| DB61-03819A | PLATE-COVER TERMINAL;FORTE,SGCC-M,T0.6,8 |
| DB70-00405A | PLATE-EVAP RH |
| DB70-00404A | PLATE-EVAP RH |
| DB70-00403A | PLATE-EVAP RH |
| DB70-00759A | PLATE-GRILLE;VIVACE1,SGCC-M,1,16,742,SSE |
| DB70-00534A | PLATE-HANGER |
| DB70-00532C | PLATE-HANGER LINK;VIVALDI,GI-SGCC,T0.7,4 |
| DB70-00532A | PLATE-HANGER LINK;WW-P/J,SGCC-M,T0.6,42. |
| DB70-00534B | PLATE-HANGER;GI-SGCC,T0.7,100,270.1,SSEC |
| DB63-00014A | PLUG-RUBBER |
| 2001-000793 | R-CARBON |
| 2006-001080 | R-CEMENT |
| 2006-001171 | R-CEMENT(S);200OHM,5%,7W,CB,BK,14.0X10.0 |
| 2007-000962 | R-CHIP |
| 2007-000944 | R-CHIP |
| 2007-000931 | R-CHIP |
| 2007-000872 | R-CHIP |
| 2007-000493 | R-CHIP |
|
|
R-CHIP |
| 2007-000282 | R-CHIP |
| 2007-000119 | R-CHIP |
| 2007-000109 | R-CHIP |
| 2007-000093 | R-CHIP |
| 2007-000090 | R-CHIP |
| 2007-000087 | R-CHIP |
| 2007-000084 | R-CHIP |
| 2007-000078 | R-CHIP |
| 2007-000077 | R-CHIP |
| 2007-000076 | R-CHIP |
| 2007-000030 | R-CHIP |
| 2002-001104 | R-COMPOSITION;12MOHM,5%,1/2W,AA,TP,3.4X9 |
| 2003-000685 | R-METAL OXIDE(S) |
| 2003-000656 | R-METAL OXIDE(S) |
|
|
RELAY-MINIATURE |
|
|
RELAY-POWER |
| 0103-004017 | RESIN ABS;HI-121H,NATURAL,NC0001 |
| 0103-004073 | RESIN GPPS;PG33,NATURAL,NC0001 |
| 0103-003269 | RESIN HIPS;F-744/NATURAL,NATURAL,NC0001, |
| 0103-000286 | RESIN HIPS;HR-1360,NATURAL,NC0001 |
| 0103-004092 | RESIN HIPS;PH-88,FRAME GRAY,SC-01623R |
| 0103-003326 | RESIN PA66;ZYTEL FR50,NATURAL,NC0001,GF2 |
| 0103-004069 | RESIN PC ABS;PC-510,GRAY,GY0020,N |
| 0103-003369 | RESIN PC;HF5025/INNER WHITE,INNER WHITE, |
| 0103-004065 | RESIN PC;PC-110,DAC-BK0821R |
| 0103-003378 | RESIN PET , FR530/NATURAL,NATURAL,NC0001,V |
| 0103-004042 | RESIN PMMA;IF850,SMOG,HI855M-8255 |
| 0103-004116 | RESIN POM;K300/NTR,NATURAL,NC0001,HB,N |
| 0103-003481 | RESIN PP;BJ730,WHITE,WT0054 |
| 0103-004053 | RESIN PP;M1600,NATURAL,NC0001 |
| 0103-004036 | RESIN SAN;ASG30,NATURAL,NC0001 |
| 2802-001179 | RESONATOR-CERAMIC |
| DB73-00379A | RUBBER BUTYL-EVAP |
| DB73-00181A | RUBBER-BEARING |
| DB73-00180B | RUBBER-CAP DRAIN |
| DB73-00180A | RUBBER-CAP DRAIN |
| DB73-00486A | RUBBER-HOSE;VIVALDI,NBR,L19.7,SSEC,BLA |
| DB73-00292C | RUBBER-PCB;WW2-PJ,PVC,T1.0,BLACK,V0 |
| 6001-001054 | SCREW-MACHINE |
| 6001-000929 | SCREW-MACHINE |
| 6001-000725 | SCREW-MACHINE |
|
|
SCREW-SPECIAL |
| 6002-000588 | SCREW-TAPPING |
| 6002-000536 | SCREW-TAPPING |
| 6002-000535 | SCREW-TAPPING |
| 6002-000534 | SCREW-TAPPING |
|
|
SCREW-TAPPING |
| DB62-05644B | SEAL CONTROL |
| DB62-02556A | SEAL EVAP-MID |
| DB62-02331A | SEAL-B/B REAR B;SS-PJT,FLOCKED,T1,W8,L |
| DB62-02331B | SEAL-B/B REAR C;SS-PJT,FLOCKED,T1,W8,L |
| DB62-02332A | SEAL-BODY;SS-PJT,PE FOAM,T5,W17,L632, |
| DB62-04922A | SEAL-COVER MPI;MODERATO,FLOCKED,SSEC,1,6 |
| DB62-04823A | SEAL-EVAP |
| DB62-04764F | SEAL-GRILLE UP;VIVACE,LEX FOAM,5,10,30 |
| DB62-04764B | SEAL-INSU TRAY MID A;VIVACE,FLOCKED,0. |
| DB62-01567D | SEAL-MOTOR |
| DB62-02332H | SEAL-PANEL |
| DB62-04764G | SEAL-PLATE GRILLE;FLOCKED,T0.5,W20,L35,S |
| DB62-02331T | SEAL-SUPPORT EVAP |
| DB62-02334A | SEAL-TRAY LF |
| DB62-02333A | SEAL-TRAY LF |
| DB62-02504A | SEAL-TRAY MID B;SS-PJT,FOAM PE/PU(30), |
| DB62-04771A | SEAL-TRAY MID D;VIVACE,PE FOAM,5,32,62 |
| DB62-02912M | SEAL-TRAY MID E |
| DB62-02912P | SEAL-TRAY MID F |
| DB62-02335A | SEAL-TRAY RH |
| 0202-001163 | SOLDER-SILVER |
| 0202-001022 | SOLDER-SILVER |
| DB61-03587E | SPRING ETC-EVAP;EXPORT,STS,9.8,200, |
| DB61-03845E | SPRING ETC-EVAP;RAC,STS-304,9.8,400,133, |
| DB61-03139B | SPRING ETC-GRILLE |
| DB61-03139A | SPRING ETC-GRILLE |
| DB67-60030A | SPRING-SENSOR |
| 3502-000115 | SSR |
| 0101-002929 | STEEL PLATE;GI,SGCC,0.6,Z12,NC |
| 0101-002930 | STEEL PLATE;GI,SGCC,0.7,Z12,NC |
| 0101-002932 | STEEL PLATE;GI,SGCC,0.8MM,647MM,Z12,NC |
| 0101-002933 | STEEL PLATE;GI,SGCC,1,Z14,NC |
| 0101-002935 | STEEL PLATE;GI,SGCC,1.2MM,700MM,Z14,NC |
| 0101-002960 | STEEL PLATE;PO,SPHC,2.6MM |
| 0101-003236 | STEEL PLATE;STAINLESS,STS304,1MM,1000MM, |
| DB61-01634A | SUPPORT-EVAP RH |
| 3404-001220 | SWITCH-TACT |
| DA02-00013A | TAPE ETC |
| DA02-10017J | TAPE-FILAMENT |
| 0506-000175 | TR-ARRAY |
| 0504-001064 | TR-DIGITAL |
| 0501-002296 | TR-SMALL SIGNAL |
| 0501-000534 | TR-SMALL SIGNAL |
| DB26-00015A | TRANS SWITCHING;-,JT1916-09,310V,FERRI |
| DB63-01578A | TRAY DRAIN |
| DB63-00849A | TRAY-STABILIZER |
| DB62-06486A | TUBE EVAP-IN;C1220T-0,T0.7,OD6.35,L696,S |
| DB62-06485A | TUBE EVAP-OUT A;C1220T-O,T0.6,OD9.52,L48 |
| DB62-06485B | TUBE EVAP-OUT B;C1220T-O,T0.6,OD7,L62.6, |
| DB62-06485C | TUBE EVAP-OUT C;C1220T-O,T0.6,OD7,L79.6, |
| DB62-02813A | TUBE HAIR PIN |
| DB62-02349A | TUBE HAIR PIN;SS-PJT,C1220T-0,T0.25,OD7, |
| DB62-02348A | TUBE HAIR PIN;SS-PJT,C1220T-O,T0.25,OD7, |
| DB62-02351A | TUBE JUMP |
| DB62-02328A | TUBE JUMP |
| DB62-02327A | TUBE JUMP |
| DB62-05233A | TUBE-BEND SPECIAL |
| DB62-05234A | TUBE-EVAP JUMP |
| DB62-31003C | TUBE-FLARE |
| DB62-30369A | TUBE-U BEND |
| DB62-30368A | TUBE-U BEND;COMMON USE,C1220T-O,T0.41,OD |
| 1405-000154 | VARISTOR |
| DB64-01799B | WINDOW-DISPLAY FILM |
| DB64-02054B | WINDOW-MIRROR;NEO VIVACE,PC,0.5,179.2,10 |
