Manufacturer
Samsung
Model Number
AR24KSWSJWKNCV
Description
Air Conditioner
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 0201-002668 | ADHESIVE-COM;1-2577 LOW VOC,TRANSLUCENT, |
| 0201-002354 | ADHESIVE-COM;1-2577,TRANSLUCENT,950 |
| 0201-002394 | ADHESIVE-EPOXY;HT-1331S(SPL-K4),RED,550~ |
| 0201-002081 | ADHESIVE-SIL;737,WHITE, |
| DB94-04161K | ASSEMBLY BACK BODY |
| DB94-04161H | ASSEMBLY BACK BODY |
| DB98-30154A | ASSEMBLY BAR CODE BOX |
| DB94-40007B | ASSEMBLY BEARING |
| DB92-02916A | ASSEMBLY BLADE H |
| DB90-07763C | ASSEMBLY CASE |
| DB90-08174F | ASSEMBLY CASE CONTROL ELECTRIC |
| DB93-06677A | ASSEMBLY CONNECTOR WIRE |
| DB93-04688F | ASSEMBLY CONNECTOR WIRE |
| DB93-14237A | ASSEMBLY CONNECTOR WIRE-COMM |
| DB93-15445A | ASSEMBLY CONNECTOR WIRE-DC SIGNAL |
| DB93-14221A | ASSEMBLY CONNECTOR WIRE-DC SIGNAL |
| DB93-14220A | ASSEMBLY CONNECTOR WIRE-DC SIGNAL |
| DB93-14218A | ASSEMBLY CONNECTOR WIRE-DC SIGNAL |
| DB93-14208A | ASSEMBLY CONNECTOR WIRE-DC SIGNAL |
| DB93-14207A | ASSEMBLY CONNECTOR WIRE-DC SIGNAL |
| DB93-14206A | ASSEMBLY CONNECTOR WIRE-DC SIGNAL |
| DB93-14209B | ASSEMBLY CONNECTOR WIRE-DISPLAY |
| DB93-14245A | ASSEMBLY CONNECTOR WIRE-EARTH |
| DB93-14203A | ASSEMBLY CONNECTOR WIRE-POWER |
| DB94-04183A | ASSEMBLY FAN CROSS |
| DB98-13261A | ASSEMBLY GARANTIE CARD |
| DB90-07731A | ASSEMBLY HANGER |
| DB94-00458H | ASSEMBLY HOSE DRAIN |
| DB98-29143A | ASSEMBLY LABEL BAR CODE |
| DB98-28433A | ASSEMBLY LABEL BARCODE |
| DB92-02861A | ASSEMBLY MODULE |
| DB97-24011A | ASSEMBLY PACKING-CASE PCB |
| DB92-02903B | ASSEMBLY PANEL FRONT |
| DB92-02905A | ASSEMBLY PANEL FRONT SUB |
| DB90-07796D | ASSEMBLY PLATE-CONTROL |
| DB90-07861A | ASSEMBLY PLATE-MIDDLE |
|
|
ASSEMBLY RUBBER BEARING |
| DB97-02418A | ASSEMBLY SCREW TAPPING |
| DB91-00309A | ASSEMBLY SCREW TAPPING;WW-INV,M3*2 |
|
|
ASSEMBLY THERMISTOR IN |
| DB94-04179D | ASSEMBLY TRAY DRAIN |
| DB94-04179B | ASSEMBLY TRAY DRAIN |
| DB96-18946A | ASSEMBLY TUBE EVAP IN |
| DB96-18947B | ASSEMBLY TUBE EVAP OUT |
| DB96-10257A | ASSEMBLY TUBE U BEND |
| DB96-10256A | ASSEMBLY TUBE U BEND |
| DB93-50001A | ASSEMBLY WIRE RING SOLD |
|
|
ASSEMBLY WIRELESS REMOTE CONTROL |
| DB90-07990A | ASSY CABI IN PARTS;SSEC |
| DB90-08116B | ASSY CASE PCB-DISPLAY;A3050 INV,FOR 88 D |
| DB90-07899A | ASSY CASE PCB-SUB;A3050-PJT,F-04,160MM |
| DB93-15729A | ASSY CONTROL IN PARTS;SSEC |
| DB90-07953A | ASSY COVER DISPLAY;AR18FSSSBWKNSA,ASSY |
| DB94-04473A | ASSY DRAIN PARTS;SSEC |
| DB96-19480A | ASSY EVAP MAIN-UPPER;F05,ASSY |
| DB96-18994A | ASSY EVAP MAIN;AR18FSSSBWKNSA |
| DB96-12839A | ASSY EVAP PARTS;SSEC |
| DB96-19003A | ASSY EVAP SUB-LOW;AR18FSSSBWKNSA |
| DB96-19002A | ASSY EVAP SUB-UP;AR18FSSSBWKNSA |
| DB96-19479A | ASSY EVAP SUB-UPPER;F05,ASSY |
| DB96-19001A | ASSY EVAP SUB;AR18FSSSBWKNSA |
| DB94-02966A | ASSY FAN A;WW3,SSEC |
| DB94-02935A | ASSY FAN C;JUNGFRAU,SSEC |
| DB94-02627A | ASSY FAN IN PARTS;SSEC |
| DB92-02904B | ASSY GRILLE;AR18FSSSCURNSA,ASSY,F05,GOOD |
| DB92-03727C | ASSY KIT;INDOOR,A3050-PJT,485-INV,F05,KC |
| DB98-35710A | ASSY MANUAL;SSEC |
| DB91-01704A | ASSY MICOM;15K RAC WIFI MODULE,STM-1460- |
| DB91-01755A | ASSY MICOM;16T RAC INVERTER HVPS(PM2.5)/ |
| DB97-28399A | ASSY PACKING IN PARTS;-,SSEC |
| DB92-03721A | ASSY PANEL FRONT PARTS;SSEC |
| DB94-04104A | ASSY PCB AUTO;BETTER,BEST,A3050,64*36,DB |
| DB94-06077A | ASSY PCB AUTO;INDOOR, MAIN, WIFI(SHP),A3 |
| DB94-04099A | ASSY PCB AUTO;RECEIVER,A3050,24*40,DB92- |
| DB94-04105A | ASSY PCB SMD;BETTER,BEST,A3050,64*36,DB9 |
| DB94-06078A | ASSY PCB SMD;INDOOR, MAIN, WIFI(SHP),A30 |
| DB94-04100A | ASSY PCB SMD;RECEIVER,A3050,24*40,DB92-0 |
| DB97-28675A | ASSY PRINT IN PARTS;SSEC |
| DB96-19231A | ASSY TUBE-JUMP;AR18FSSSBWKNSA,ASSY |
| DB96-15376A | ASSY U BEND-MID;AQ12UGEX,SSEC |
| 6902-000286 | BAG PE |
| 6902-002289 | BAG PE;HDPE/PE FOAM,T0.012/T0.5,W1600,L5 |
| 6902-001775 | BAG ROLL;HDPE,T0.015,W500,L495M,WHT |
| 6902-001990 | BAG ROLL;HDPE/PE FOAM,NITRON,T0.015/0.5, |
| 6922-000041 | BAND |
| 4301-000121 | BATTERY-MN |
| DB61-05844A | BLADE H-BOTTOM;A3050 F-RAC-05,ABS,HG-076 |
| DB61-05843A | BLADE H-TOP;A3050, F-RAC-05,ABS,HG-0760G |
| DB61-05846A | BLADE V |
| DB61-05870B | BODY BACK;F-RAC-05,ABS,T2.3,BLACK,NO SPI |
| 6009-001433 | BOLT-HEX |
| DB60-40022A | BOSS |
| DB60-40017A | BOSS;-, |
| DB64-03045A | BUTTON POWER |
| 3002-001139 | BUZZER-PIEZO |
| 2401-003107 | C-AL |
| 2402-001368 | C-AL, SMD |
| 2402-001145 | C-AL, SMD |
| 2402-000120 | C-AL, SMD |
| 2203-007486 | C-CER, CHIP |
| 2203-006960 | C-CER, CHIP |
| 2203-005249 | C-CER, CHIP |
| 2203-001083 | C-CER, CHIP |
| 2203-001071 | C-CER, CHIP |
| 2203-000444 | C-CER, CHIP |
| 2203-000440 | C-CER, CHIP |
| 2203-000257 | C-CER, CHIP |
| 2203-000206 | C-CER, CHIP |
| 2203-000027 | C-CER, CHIP |
| 2203-006496 | C-CER,CHIP;2.2NF,10%,50V,X7R,TP,1608,T0. |
| 2301-002032 | C-FILM, LEAD-PPF |
| DB65-10088C | CABLE TIE |
|
|
CABLE TIE |
|
|
CAP-SCREW |
| 6801-002172 | CARD-WARRANTY;A3050,EN,MOJO,216,279,8 |
| DB61-05891B | CASE CONTROL-IN;A3050,F-RAC-05,ABS,VICTO |
| DB61-05847A | CASE PCB |
| DB61-06101A | CASE PCB-LOW |
| DB61-05854A | CASE PCB-REMOTE CONTROL |
| DB61-05827A | CASE-DISPLAY |
| DB61-03857A | CLIP-DRAIN HOSE;-,STS304,T1, |
| DB63-03274A | CLIP;STS301,T0.5,GRAY METAL,1/4" |
| DB27-00102A | COIL CHOKE;1MH,2.5A,8.4X3.4MM,MN-ZN,4P,D |
| DB27-00096A | COIL CHOKE;28MH,1.5A,13X10MM,MN-ZN,4P,DI |
| 3711-003404 | CONNECTOR-HEADER |
| 3711-000998 | CONNECTOR-HEADER |
| 3711-000177 | CONNECTOR-HEADER |
| 0102-001526 | COPPER TUBE , C1220T,O,6.35,0.6,ROLL, |
| 0102-001513 | COPPER TUBE;C1220T,O,4.76,0.6,ROLL, |
| 0102-001530 | COPPER TUBE;C1220T,O,7,0.41,ROLL |
| 0102-001533 | COPPER TUBE;C1220T,O,7,0.6,ROLL, |
| 0102-001539 | COPPER TUBE;C1220T,O,9.5,0.7,ROLL, |
| 0102-001544 | COPPER-TUBE |
|
|
COVER ASSEMBLY PANEL |
| DB63-03512A | COVER EVAP |
| DB63-03510A | COVER EVAP |
| DB63-03492A | COVER MOTOR |
| DB63-03494A | COVER PANEL-SUB |
| DB63-03504B | COVER PANEL;F-RAC-05,HIPS,DA WHITE,HI630 |
| DB63-03503A | COVER PCB |
| DB63-01067A | COVER-FLARE |
| DB63-03547A | COVER-SENSOR;A3050,PA66,T1.2,NATURAL,A20 |
| DB63-03581A | COVER;A3050 F05 DLX,PET+GF30%,W65.6,L92, |
| DB69-02961A | CUSHION-LEFT;A3050 F-RAC-05,EPS,W374,L34 |
| DB69-02960A | CUSHION-RIGHT;A3050 F-RAC-05,EPS,W374,L3 |
| DB64-02998A | DECO-GRILLE;A3050, F-RAC-05, GOOD 1,PMMA |
| 0402-001741 | DIODE-RECTIFIER;S1M,1000V,1A,SMA,TP |
| 0406-001204 | DIODE-TVS |
| 0406-001005 | DIODE-TVS |
| 0403-000258 | DIODE-ZENER |
| DB62-04004A | DISTRIBUTER AIR;BRASS,29.8MM,5 HOLE |
| DB75-00577A | EVAP-MAIN;AR18FSSSBWKNSA,2,10,840,H-FIN, |
| DB75-00578A | EVAP-SUB;AR18FSSSBWKNSA,2,6,840,H-FIN,FP |
| DB75-00580A | EVAP-UP;AR18FSSSBWKNSA,1,4,840,H-FIN,FP1 |
| DB75-00579A | EVAP-UP;AR18FSSSBWKNSA,1,8,840,H-FIN,FP1 |
| DB96-19009B | EVAPERATER ASSEEMBLY TOTAL UNIT |
| DB67-01117A | FAN A;WW3, JSF2,SAN+GF30%,ASG30,BLACK, |
| DB67-01110A | FAN B;JUNGFRAU,SAN+GF30%,ASG30,OD106.5 |
| DB60-30010D | FASTENER-NUT FLARE |
| DB60-30010A | FASTENER-NUT FLARE |
| DB63-03731A | FILTER AIR-PRE |
| DB62-11647A | FIN COND;A1100 |
| DB62-11647C | FIN COND;A1100,H,1.3,NGS |
| DB62-02907E | FIN EVAP-B |
| DB62-11642A | FIN EVAP;A1100-H26 |
| 0204-004665 | FLUX;KSP-70M-S,MIXTURE,NO,FLUX,13% |
| DB01-00129A | FOIL |
| 3601-001765 | FUSE-RADIAL LEAD , 250V,3.15A,TIME-LAG,THE |
| 0205-001271 | GREASE;PL-50,40~150C |
| DB64-02997D | GRILLE INLET |
| DB63-03665A | GUARD-SCREEN;A3050 F-RAC-05,MSWR,T1,BLAC |
| DB61-05872A | GUIDE BLADE |
| DB61-05900A | HANGER-LINK |
| DB61-05898A | HANGER-MAIN;A3050 COMMON,GI-SGCC,T0.6 |
| 3711-005098 | HEADER-BOARD TO CABLE |
| 3711-004379 | HEADER-BOARD TO CABLE |
| 3711-004236 | HEADER-BOARD TO CABLE |
| 3711-004122 | HEADER-BOARD TO CABLE |
| 3711-004067 | HEADER-BOARD TO CABLE |
| 3711-003942 | HEADER-BOARD TO CABLE |
| 3711-003845 | HEADER-BOARD TO CABLE |
| 3711-002001 | HEADER-BOARD TO CABLE |
| 3711-000999 | HEADER-BOARD TO CABLE |
| 3711-000941 | HEADER-BOARD TO CABLE |
| 3711-000296 | HEADER-BOARD TO CABLE |
| 3711-000203 | HEADER-BOARD TO CABLE |
| 3711-000024 | HEADER-BOARD TO CABLE |
| 3711-005096 | HEADER-BOARD TO CABLE;BK,STRAIGHT,1R,5P, |
| 3711-005097 | HEADER-BOARD TO CABLE;BOX,5P,1R,2MM,STRA |
| DB61-05849A | HOLDER |
| DB61-06078A | HOLDER EVAP-SUB;A3050-PJT,PVC,BLACK,LF-G |
| DB61-05851A | HOLDER EVAP;A3050, F-RAC-05,ABS,BLACK, |
| DB61-06122A | HOLDER LED;A3050,ABS,T2,BLACK,HB,HF700,2 |
| DB61-03132A | HOLDER-BLADE OUT |
| DB61-05852A | HOLDER-PIPE;F-RAC-05,HIPS,2,87.2,132.2,N |
| DB61-40055B | HOLDER-SENSOR |
| DB61-01717A | HOLDER-SENSOR |
| DB61-00854A | HOLDER-SENSOR;AVMCH052B10,C1220T-O,T0.55 |
| DB61-05871A | HOLDER-WIRE;A3050,ABS,T2.5,W16,L40.8,BLA |
| DB67-00944A | HOSE DRAIN;VIVALDI,PP,BLACK,HG-0760S,S |
| 1006-001325 | IC-BUS TRANSCEIVER |
| 0801-000393 | IC-CMOS LOGIC |
| 1003-002078 | IC-LED DRIVER |
| 0903-001864 | IC-MICROCONTROLLER;HART-M310,QFP,100P,20 |
| 1203-007526 | IC-POSI.FIXED REG.;7815,D-PAK/TO252,3P,6 |
| 1203-006245 | IC-VOL. DETECTOR |
| 1202-000104 | IC-VOLTAGE COMP. |
| DB62-03481F | INSULATION TUBE;EPE,7,49,1120,SKY BLUE |
| DB62-05974A | INSULATION-HOSE;VIVALDI,PE FOAM,4,97,525 |
| DB62-03481H | INSULATION-PIPE;PE FOAM,T7,L1000,GRA |
| DB68-02809A | LABEL BAR CODE |
| DB98-32618A | LABEL BAR CODE;-,ALL (WIFI MODEL),ART, |
| DB68-05458A | LABEL BAR CODE;AM9000H,PAPER,W17.5,L18 |
| DB68-04014A | LABEL DIAGRAM;A3050,ART,60,160,STD#4,INV |
| DB98-33293A | LABEL INSTRUCTION;-,ART,15,5,H |
| DB98-33292A | LABEL INSTRUCTION;ART,5,15,H/P,INV |
| DB68-03068C | LABEL PRINT;PET,W55,L170,SILVER,LABEL RA |
| DB68-04028C | LABEL RATING;SWL-CQ51,EU,PET,52,28,A3050 |
| DB68-02813A | LABEL WARNING |
| DB68-01350A | LABEL-BAR CODE |
| DB07-00188A | LED DISPLAY;7S,2D,29MM*23MM*13.5MM,WHT,P |
| 0601-003285 | LED;ROUND,WHT,WHT CLEAR,D3.1,3.9X5.4MM,1 |
| DB66-01750A | LINK BLADE-A |
| DB66-01729A | LINK BLADE-A |
| DB66-01730A | LINK BLADE-B |
| DB92-02873F | MAIN PCB ASSEMBLY |
| DB68-03934A | MANUAL INSTALL;AR*FSSS*SA,SA,EN,MOJO,W25 |
| DB68-05637A | MANUAL USERS & INSTALL;AR24KSWSJWK/CV,CV |
| DB68-05638A | MANUAL USERS;AR24KSWSJWK/CV,CV,NEWS PAPE |
| 0609-001377 | MODULE REMOCON;VERTICAL,5.85MM,BK |
| DB31-00637A | MOTOR BLDC FAN |
| DB31-00369D | MOTOR STEP |
| DB67-00276A | NIPPLE |
| DB67-00276E | NIPPLE;C3604,7/8-18UNF |
| DB69-02966K | PACKING CASE;A3050_F-RAC-05,CB,DW2,L376, |
| DB69-02969A | PAD CUSHION;F-RAC-05,EPS,T25,W370,L500, |
| DB69-02969D | PAD CUSHION;F-RAC-05,SIDE,EPS,T18,W420,L |
| DB64-02996A | PANEL FRONT;A3050 F-RAC-05,ABS,HRABS-RS, |
| DB92-02877A | PCB ASSEMBLY DISPLAY |
|
|
PCB ASSEMBLY SUB |
| DB41-01225A | PCB DISPLAY;FR-4,2L,T1.6,64*36,12,BETTER |
| DB41-01221A | PCB MAIN;FR-4,2LAYER,98.5*120,STD#4,INDO |
| DB41-01222A | PCB SUB;FR-1,1L,T1.6,24*40,24,RECEIVER,1 |
| 0604-001002 | PHOTO-COUPLER |
| DB61-05961A | PLATE CONTROL LEFT |
| DB61-06079A | PLATE CONTROL MIDDLE |
| DB61-05960A | PLATE CONTROL RIGHT |
| DB61-05812A | PLATE CONTROL SUB |
| DB61-05965A | PLATE CONTROL UP |
| DB61-06160A | PLATE CONTROL-SUB;A3050 KCV,GI-SGCC,T1 |
| DB61-05842A | PLATE EVAP-LOW;A3050 F-RAC-05,GI-SGCC,T0 |
| DB61-05855A | PLATE EVAP-MIDDLE;A3050 F-RAC-05,GI-SGCC |
| DB61-05841A | PLATE EVAP-UP;A3050 F-RAC-05,GI-SGCC,T0. |
| DB70-10532A | PLATE-BOSS;APN-SM402,CR-SPCC,T1 |
| 2007-009922 | R-CHIP |
| 2007-001433 | R-CHIP |
| 2007-000979 | R-CHIP |
| 2007-000939 | R-CHIP |
| 2007-000924 | R-CHIP |
| 2007-000583 | R-CHIP |
| 2007-000475 | R-CHIP |
| 2007-000455 | R-CHIP |
| 2007-000385 | R-CHIP |
| 2007-000303 | R-CHIP |
|
|
R-CHIP |
| 2007-000130 | R-CHIP |
| 2007-000116 | R-CHIP |
| 2007-000090 | R-CHIP |
| 2007-000087 | R-CHIP |
| 2007-000084 | R-CHIP |
| 2007-000078 | R-CHIP |
| 2007-000076 | R-CHIP |
| 2007-000029 | R-CHIP |
| 2802-001211 | RESONATOR-CERAMIC |
| DB67-01428A | RUBBER PLUG;A3050,SIR,505,WHITE |
| DB73-00181A | RUBBER-BEARING |
| DB73-00180B | RUBBER-CAP DRAIN |
|
|
SCREW-SPECIAL |
|
|
SCREW-TAPPING |
| 6002-000536 | SCREW-TAPPING |
| 6002-000535 | SCREW-TAPPING |
|
|
SCREW-TAPPING |
| 6002-000231 | SCREW-TAPPING |
| DB62-11676A | SEAL BODY-BASE;PE FOAM,T3,W45,L57 |
| DB62-11670A | SEAL CONTROL-A;PVC,T1,W52,L95,NONFLAMMAB |
| DB62-11671A | SEAL CONTROL-B;PVC,T1,W104,132,NONFLAMMA |
| DB62-11537A | SEAL CUSHION-BODY;EPS,PKF-401XS |
| DB62-11640G | SEAL CUTT |
| DB62-11639B | SEAL CUTT;EPDM,T3,W10 |
| DB62-11640F | SEAL CUTT;FLOCKED,T0.5,W15 |
| DB62-11668C | SEAL CUTT;FOAM PE+FOAM PU,SSEC:T3+T5,TSE |
| DB62-11637Q | SEAL CUTT;PE FOAM,T10,W15,NONFLAMMABLE |
| DB62-11637D | SEAL CUTT;PE FOAM,T3,W15 |
| DB62-11637S | SEAL CUTT;PE FOAM,T5,W50,DARK GRAY, |
| DB62-11641K | SEAL CUTT;PU FOAM,T3,W15 |
| DB62-11641W | SEAL CUTT;PU FOAM,T3,W5 |
| DB62-11656D | SEAL CUTT;PVC,T1,W70 |
| DB62-11639C | SEAL CUTT;WA54M8750AV/A4,EPDM,HB,HB,BL |
| DB62-11693A | SEAL DRAIN;PE FOAM,T3,W60,96,NONFLAMMABL |
| DB62-11779A | SEAL-CASE PCB;PE FOAM,T3,W40 |
| DB62-00707A | SEAL-DISPALY COVER A;-,FOAM-LEX+AL,FOA |
| DB62-11626A | SEAL-DISPALY COVER B;LEX FOAM,T3,W35,HB |
| DB62-11627A | SEAL-DISPALY COVER C;LEX FOAM,T3,HB |
| DB62-11661A | SEAL-DISPALY COVER;PE FOAM,T3,W63,L55 |
| DB62-11348V | SEAL-DISPLAY COVER D;LEX FOAM,T2,W35,L35 |
| DB62-11585A | SEAL-PANEL FRONT;PE FOAM,T3,115,190,NONF |
| DB62-11659A | SEAL-TRAY LEFT D;PE FOAM,T3,L64.1,HB |
| DB62-11666A | SEAL-TRAY LEFT E;FLOCKED,T0.5,W47.3,NONF |
| DB62-11580A | SEAL-TRAY LF C;PE FOAM,T5,L224,HB |
| DB62-11581A | SEAL-TRAY RH A;PE FOAM,T3,L58.3,HB |
| DB62-11583A | SEAL-TRAY TOP;PE FOAM,T3,47.5,922.0,NONF |
| DB63-03553D | SHEET-CONTROL;AR12FSSSBWKNSA,AL,T0.07,22 |
| DB63-03553F | SHEET-CONTROL;AR12FSSSBWKXSA,AL,T0.07 |
| DB63-03553H | SHEET-CONTROL;AR24FSSSBWKNSA,AL,T0.07 |
| 0202-001933 | SOLDER-CREAM;LFM-48W TM-HP,D20~38UM,96.5 |
| 0202-001022 | SOLDER-SILVER |
| 0202-001464 | SOLDER-SILVER;L450,91CU/1.9AG/6.95P |
| 0202-001463 | SOLDER-WIRE |
| 0202-001608 | SOLDER-WIRE FLUX |
| DB61-03845F | SPRING ETC-EVAP;RAC,STS-304,13.4,610,610 |
| DB67-60030A | SPRING-SENSOR |
| 0101-002929 | STEEL PLATE;GI,SGCC,0.6,Z12,NC |
| 0101-002932 | STEEL PLATE;GI,SGCC,0.8MM,647MM,Z12,NC |
| 0101-003236 | STEEL PLATE;STAINLESS,STS304,1MM,1000MM, |
| DB70-01013A | STEEL-EVAP UPPER;JUNGFRAU,GI-SGCC,T0.8,W |
| DB61-05963A | SUPPORT-CONTROL |
| 3404-001220 | SWITCH-TACT |
| DB02-00003A | TAPE ETC;ALL MODEL,PET,T0.1,W7,L40,METAL |
| DB02-00029B | TAPE ETC;RAC,OPP,0.05MM,80MM,500M,TRANSP |
| 0203-001512 | TAPE-DOUBLE FACE;3M-A-25-9448,T0.64,W15, |
| DA02-10017J | TAPE-FILAMENT |
| DB65-00326D | TERMINAL BLOCK |
| 1404-001194 | THERMISTOR-PTC |
| 0506-000175 | TR-ARRAY |
| 0504-001080 | TR-DIGITAL |
| 0502-000245 | TR-POWER |
| 0501-000465 | TR-SMALL SIGNAL |
| 0501-000362 | TR-SMALL SIGNAL |
| DB63-03502A | TRAY DRAIN |
| DB62-04534A | TUBE COND-JUMP |
| DB62-02348R | TUBE HAIR PIN;A3050 PJT,C1220T-0,T0.25,O |
| DB62-11578A | TUBE JUMP;AR18FSSSBWKNSA,C1220T-O,T0.6,O |
| DB62-06999A | TUBE-CU;C1220T-O,T0.25,OD7,L,ID6.3,TW0.2 |
| DB62-31003C | TUBE-FLARE |
| DB62-30369A | TUBE-U BEND |
| DB62-10916A | TUBE-U BEND MID;AQ12UGEX,C1220T-O,T0.6,O |
| DB62-30368A | TUBE-U BEND;COMMON USE,C1220T-O,T0.41,OD |
| 1405-001239 | VARISTOR;680V,560VDC,6000A,17X10MM,TP,11 |
| 4709-002355 | W-LAN MODULE;SWL-CQ51/AC,QCA4531,IEEE802 |
| DB64-02999A | WINDOW DISPLAY;A3050,F-RAC-05,PC,T1.2,30 |
