Manufacturer
Samsung
Model Number
AVXDUH110CE
Description
Air Conditioner
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| DB97-19364B | ACCESSORY ASSEMBLY-DUCT |
| DB97-03726D | ACCESSORY ASSEMBLY-DUCT |
| DB97-03726B | ACCESSORY ASSEMBLY-DUCT |
| 0201-002394 | ADHESIVE-EPOXY;HT-1331S(SPL-K4),RED,550~ |
| 0201-002081 | ADHESIVE-SIL;737,WHITE, |
| 0102-001603 | ALUMINUM INGOT;ALDC8 |
| DB97-03499C | ASSEMBLY BAG SHEET |
| DB97-03499A | ASSEMBLY BAG SHEET |
| DB97-03751B | ASSEMBLY BAND MOTOR |
| DB97-03751A | ASSEMBLY BAND MOTOR |
| DB98-30154A | ASSEMBLY BAR CODE BOX |
| DB90-05651B | ASSEMBLY BRACKET MOTOR |
| DB90-02408B | ASSEMBLY BRACKET OUTLET PART |
| DB90-02408A | ASSEMBLY BRACKET OUTLET PART |
| DB90-02402A | ASSEMBLY CABI FRONT |
| DB90-02407A | ASSEMBLY CABI SIDE-LF |
| DB90-02406A | ASSEMBLY CABI SIDE-RH |
| DB90-03110B | ASSEMBLY CABINET-BOTTOM BLOWER |
| DB90-02409E | ASSEMBLY CABINET-BOTTOM DRAIN |
| DB90-02409C | ASSEMBLY CABINET-BOTTOM DRAIN |
| DB90-02409B | ASSEMBLY CABINET-BOTTOM DRAIN |
| DB90-03109D | ASSEMBLY CABINET-TOP |
| DB90-03109B | ASSEMBLY CABINET-TOP |
| DB90-03109A | ASSEMBLY CABINET-TOP |
| DB90-06679B | ASSEMBLY CASE-BLOWER UPPER |
| DB90-05177B | ASSEMBLY CASE-BLOWER UPPER |
| DB90-01992B | ASSEMBLY CASE-CONTROL |
| DB93-03524A | ASSEMBLY CONNECTOR WIRE-SSR |
| DB93-05578C | ASSEMBLY CONTROL IN |
| DB94-02001C | ASSEMBLY DRAIN PAN |
| DB91-00346A | ASSEMBLY DRAIN PAN |
| DB94-03287A | ASSEMBLY DRAIN-HOSE JOINT |
| DB96-11489A | ASSEMBLY EVAP |
| DB96-07234A | ASSEMBLY EVAP-UNIT |
| DB98-13261A | ASSEMBLY GARANTIE CARD |
| DB98-29143A | ASSEMBLY LABEL BAR CODE |
| DB98-28433A | ASSEMBLY LABEL BARCODE |
| DB98-25271B | ASSEMBLY LABEL CAUTION DIP |
| DB98-25289A | ASSEMBLY LABEL DIAGRAM |
| DB97-03721A | ASSEMBLY PACKING SCREW |
| DB97-10869E | ASSEMBLY PACKING-CASE IN |
| DB98-27123B | ASSEMBLY PAD INSTALL |
| DB98-27123A | ASSEMBLY PAD INSTALL |
| DB98-13260A | ASSEMBLY REGISTRATION CARD |
| DB91-00309A | ASSEMBLY SCREW TAPPING;WW-INV,M3*2 |
| DB97-02682A | ASSEMBLY SCREW TAPTITLE |
| DB97-14454A | ASSEMBLY SEAL-PIPE COVER |
| DB95-01983B | ASSEMBLY THERMISTOR IN |
| DB95-01987B | ASSEMBLY THERMISTOR-EVAP |
| DB96-07228A | ASSEMBLY TUBE EVAP IN |
| DB96-10257A | ASSEMBLY TUBE U BEND |
| DB96-10256A | ASSEMBLY TUBE U BEND |
| DB96-07232A | ASSEMBLY TUBE-COLLECTOR |
| DB93-50001A | ASSEMBLY WIRE RING SOLD |
| DB97-05553A | ASSY ACCESSORY IN PARTS;HP,11.2KW,N, |
| DB90-03104A | ASSY CABI IN PARTS;AVXDUH112EA,SSEC |
| DB93-08323A | ASSY CONTROL IN PARTS;AVXDUH100 110 145C |
| DB93-05578B | ASSY CONTROL IN;SAC,DUCT |
| DB94-02101A | ASSY DRAIN PARTS;-,N,DH090EAS,SS |
| DB94-00951A | ASSY DRAIN PARTS;-,R22,DH42BTA,S |
| DB94-00758B | ASSY DRAIN-HOSE JOINT;200,DUCT,SSEC |
| DB94-00758A | ASSY DRAIN-HOSE JOINT;250,SLIM DUCT3,SSE |
| DB96-07229A | ASSY EVAP PARTS;AVXDUH112EA,SSEC |
| DB94-01543B | ASSY FAN IN PARTS;AVXDUHT40CA,TRANE SSEC |
| DB90-06701A | ASSY HOLDER-CLAMP;CH140EAMC,SSEC |
| DB90-02064A | ASSY HOLDER-DRAIN PIPE;SLIM DUCT 1,SSEC |
| DB97-12785A | ASSY MANUAL;AVXDUH100CE,DVM PLUS3 MSP DU |
| DB91-00921C | ASSY MICOM;DVM_INV DUCT (2WAY, MINI-4WAY |
| DB91-00921B | ASSY MICOM;USA PLUS3_DUCT (2WAY, MINI-4W |
| DB91-00921A | ASSY MICOM;USA PLUS3_DUCT (2WAY, MINI-4W |
| DB97-11094A | ASSY PACKING IN PARTS;INVERTOR,CH070EAV1 |
| DB97-20958A | ASSY PACKING IN PARTS;MA1 E |
| DB97-19083E | ASSY PACKING-BOTTOM;MA0/MA1,SSEC,S-4,113 |
| DB97-19083T | ASSY PACKING-BOTTOM;MA1_KO_EN_CN |
| DB97-18619A | ASSY PACKING-UP;MA1,D-3 |
| DB94-03790Y | ASSY PCB AUTO;DB93-08296B |
| DB94-03790Z | ASSY PCB MANUAL;DB93-08296B |
| DB94-03790X | ASSY PCB SMD;DB93-08296B |
| DB97-12790B | ASSY PRINT IN PARTS;AVXDUH110CE,DVM PLUS |
| DB97-14454B | ASSY SEAL-PIPE COVER;DUCT,ASSY SEAL PIPE |
| DB90-02075B | ASSY-BRACKET OUTLET;DC42BTVA/UMG |
| DB90-02075A | ASSY-BRACKET OUTLET;DH42BTA,SSEC |
| DB98-31760A | ASSY-INSTALLATION MANUAL;AVXDUH100CE ETC |
| DB98-30799A | ASSY-INSTALLATION MANUAL;AVXDUH100CE,SSE |
| DB98-30800A | ASSY-INSTRUCTION MANUAL;AVXDUH100CE,SSEC |
| DB98-33052A | ASSY-INSTRUCTION MANUAL;DUCT TYPE,AMERIC |
| DB98-25271C | ASSY-LABEL CAUTION DIP;HP,AMERICAN DUCT |
| DB98-27584A | ASSY-LABEL CAUTION;HP,INV,FOR KCV CONTRO |
| DB98-32332A | ASSY-LABEL CAUTION;SSEC,TOWER |
| DB98-30819Q | ASSY-LABEL RATING IN;AVXDUH110CE,SILVER |
| 6902-000103 | BAG PE |
| 6922-000041 | BAND |
| DB72-00743A | BAND-MOTOR LOW |
| DB72-00742A | BAND-MOTOR UP |
| DB67-00583B | BLOWER |
| 6009-001074 | BOLT-HEX |
| DB60-20011A | BOLT-SPECIAL |
| DB61-02314A | BOSS-FAN;MH020FDEZ,ALDC12,L35,2 |
| DB61-02373A | BRACKET CONTROL;DUCT 60K,SGCC-M,T1,20,40 |
| DB61-02331A | BRACKET MOTOR |
| DB61-02374A | BRACKET-FILTER |
| DB61-04889A | BRACKET-FILTER;SLIM DUCT,SGCC-M,1.0 |
| DB61-02439B | BRACKET-OUTLET A;DC42BTVA/UMG,GI-SGCC,T0 |
| DB61-02439A | BRACKET-OUTLET A;MA1,SGCC-M,T1.0,918,245 |
| 2401-002216 | C-AL |
| 2401-000711 | C-AL |
| 2401-000037 | C-AL |
| 2203-000444 | C-CER, CHIP |
| 2203-000257 | C-CER, CHIP |
| 2203-000192 | C-CER, CHIP |
| 2203-001562 | C-CERAMIC, CHIP |
| 2301-001959 | C-FILM, LEAD |
| 2301-001220 | C-FILM, LEAD-PPF |
| DB64-01399A | CABINET FRONT;MA1,GI-SGCC,T1.5,318,1146, |
| DB64-01403B | CABINET-BOTTOM BLOWER;GI-SGCC,T0.8, |
| DB64-01402B | CABINET-BOTTOM DRAIN;GI-SGCC,T0.8, |
| DB64-01400A | CABINET-SIDE LF;DH42BTA,GI-SGCC,T1,S |
| DB64-01401A | CABINET-SIDE RH;MA1,GI-SGCC,T1,SSEC |
| DB64-01398A | CABINET-TOP;DH42BTA,GI-SGCC,T1,SSEC |
| DB65-10088C | CABLE TIE |
| DB67-01188A | CAP-HOSE A;CH140EAMC,PVC,P-1000,GRAY,SSE |
| DB67-01189A | CAP-HOSE B;CH140EAMC,LS170,P-1000,GRAY,S |
| DB67-00602A | CAP-HOSE;SLIM DUCT-3,LS170,SSEC |
| DB63-10374B | CAP-TUBE |
| DB67-00942A | CAP;VIVALDI-P/J,SHP2,1,5.2,11.5,18.5, |
| DB68-40091A | CARD-REGISTRATION |
| DB61-02333B | CASE BLOWER-BOTTOM |
| DB61-02333A | CASE BLOWER-BOTTOM |
| DB61-02332B | CASE BLOWER-UPPER |
| DB61-02332A | CASE BLOWER-UPPER |
| DB61-02377B | CASE CONTROL;MA,GI-SGCC,T0.7, |
| DB61-05156A | CASE PCB |
| DB61-02287B | CASE PCB |
| DB61-02287C | CASE PCB;DUCT,HIPS,T2.5,215*120,70,I BLA |
| DB39-01106A | CBF-C/W VENTILATOR;AVMME036EZC, |
| DC02-10009A | CHEMICALS-LOCK SCREW |
| DB61-04522A | CLIP-DRAIN BAND;AVMEH035EA3,STS304,SSEC |
| DB27-00033A | COIL CHOKE |
| DB61-02434A | CONNECT WIRE |
| DB39-01107A | CONNECT WIRE-POWER |
| DB39-01106C | CONNECT WIRE-POWER&COMMUNICATION |
| DB39-01106B | CONNECT WIRE-POWER&COMMUNICATION |
| DB39-01106D | CONNECT WIRE-POWER&COMMUNICATION;MH023/0 |
| DB39-01108B | CONNECT WIRE-VENTILATOR&WATER HEATER |
| DB39-01108A | CONNECT WIRE-VENTILATOR&WATER HEATER |
| 3711-003406 | CONNECTOR-HEADER |
| 3711-003405 | CONNECTOR-HEADER |
| 3711-003404 | CONNECTOR-HEADER |
| 3711-000997 | CONNECTOR-HEADER |
| 3711-000940 | CONNECTOR-HEADER |
| 3711-000798 | CONNECTOR-HEADER |
| 3711-000796 | CONNECTOR-HEADER |
| 3711-000262 | CONNECTOR-HEADER |
| 3711-000177 | CONNECTOR-HEADER |
| 3711-000176 | CONNECTOR-HEADER |
| 0102-001525 | COPPER TUBE |
| 0102-001526 | COPPER TUBE , C1220T,O,6.35,0.6,ROLL, |
| 0102-001548 | COPPER TUBE;C1220T,O,15.88,0.8,ROLL, |
| 0102-001549 | COPPER TUBE;C1220T,O,15.88,1,ROLL, |
| 0102-001530 | COPPER TUBE;C1220T,O,7,0.41,ROLL |
| 0102-001533 | COPPER TUBE;C1220T,O,7,0.6,ROLL, |
| 0102-001534 | COPPER TUBE;C1220T,O,7,0.7,ROLL, |
| 0102-001537 | COPPER TUBE;C1220T,O,7.94,0.5,ROLL, |
| 0102-001538 | COPPER TUBE;C1220T,O,7.94,0.7,ROLL, |
| 0102-001539 | COPPER TUBE;C1220T,O,9.5,0.7,ROLL, |
| 0102-001542 | COPPER TUBE;C1220T,O,9.52,0.7,ROLL, |
| 0102-000252 | COPPER-TUBE |
| DB31-40005A | CORE ROTOR |
| DB90-02404B | COVER ASSEMBLY PIPE |
| DB90-02404A | COVER ASSEMBLY-PIPE |
| DB63-01296A | COVER-CONTROL |
| DB63-02115A | COVER-HOLE |
| DB63-01463B | COVER-PIPE;DC36ETSA/SGE,GI-SGCC,T1, |
| DB63-01463A | COVER-PIPE;MA1,SGCC-M,T1.0,54,183.3, |
| DB69-02762A | CUSHION-BOTTOM IN;MA-2,EPS,W572,L490,H90 |
| DB69-01379A | CUSHION-LEFT |
| DB69-01281L | CUSHION-MID |
| DB69-01281K | CUSHION-MID |
| DB69-01380A | CUSHION-RIGHT |
| DB69-02763A | CUSHION-TOP IN;MA-2,EPS,W578,L508,H82.5, |
|
|
DIODE-BRIDGE |
|
|
DIODE-RECTIFIER |
|
|
DIODE-SWITCHING |
| 0406-001204 | DIODE-TVS |
| DB62-03692A | DISTRIBUTER AIR;SLIM DUCT 1,C1220T-O,T0. |
| DB67-00617A | DRAIN |
| DB75-00346A | EVAPORATOR |
| DB60-30010D | FASTENER-NUT FLARE |
| DB60-30010B | FASTENER-NUT FLARE |
| DB63-01299B | FILTER-PRE |
| DB62-04145A | FIN-FOIL EVAP;MA1,A1100,T0.095,38.1,295. |
| 0204-002606 | FLUX |
| DB01-00129A | FOIL |
| 3601-001308 | FUSE |
| 3601-000414 | FUSE-CARTRIDGE |
| DB63-00237A | GROMMET-HANGER |
| 3711-005716 | HEADER-BOARD TO CABLE |
| 3711-003845 | HEADER-BOARD TO CABLE |
| 3711-003407 | HEADER-BOARD TO CABLE |
| 3711-002855 | HEADER-BOARD TO CABLE |
| 3711-001000 | HEADER-BOARD TO CABLE |
| 3711-000939 | HEADER-BOARD TO CABLE |
| 3711-000880 | HEADER-BOARD TO CABLE |
| 3711-000794 | HEADER-BOARD TO CABLE |
| 3711-000203 | HEADER-BOARD TO CABLE |
| 3711-000178 | HEADER-BOARD TO CABLE |
| 3711-000024 | HEADER-BOARD TO CABLE |
| 3711-000015 | HEADER-BOARD TO CABLE |
| DB62-03085A | HEAT SINK |
| DB61-00924A | HOLDER-FUSE |
| DB61-02431A | HOLDER-GASKET;-,GI-SGCC,T3,12.4,22.4, |
| DB61-03876A | HOLDER-MOTOR |
| DB61-40251A | HOLDER-SENSOR |
|
|
HOLDER-SENSOR |
| DB61-00854A | HOLDER-SENSOR;AVMCH052B10,C1220T-O,T0.55 |
| DB61-01282A | HOLDER-SIDE CABI |
| DB61-03149A | HOLDER-WIRE |
| DB61-00250A | HOLDER-WIRE CLAMP |
| DB67-01191A | HOSE DRAIN;CH140EAMC,PVC,BLACK,GRAY,SSEC |
| DB67-00601B | HOSE DRAIN;DUCT,PVC,30.5,41.5,100,GRAY,S |
| DB67-00601A | HOSE-DRAIN;SLIM DUCT-3,PVC,T2.0, |
| DB09-00338A | IC MICOM |
| 1006-001325 | IC-BUS TRANSCEIVER |
| 0801-000393 | IC-CMOS LOGIC |
| 1103-001228 | IC-EEPROM |
| 1103-001175 | IC-EEPROM |
| 1006-001371 | IC-LINE TRANSCEIVER |
| 1203-000274 | IC-POSI.FIXED REG. |
| 1203-000243 | IC-POSI.FIXED REG. |
| 1203-003334 | IC-RESET |
| DB62-04103A | INSULATION DRAIN-IN;MA1,PE,T3.0,105,980, |
| DB62-04091B | INSULATION-CABI BLOWER A;MA1,PE+PUR FOAM |
| DB62-04108A | INSULATION-CABI BLOWER B;MA1,FLOCKED,T1. |
| DB62-04108B | INSULATION-CABI BLOWER C;MA1 DUCT,FLOCKE |
| DB62-04108C | INSULATION-CABI BLOWER D;MA1 DUCT,FLOCKE |
| DB62-04091A | INSULATION-CABI BOTTOM DRAIN;MA1,PE+PUR |
| DB62-04874B | INSULATION-CABI OUT BOTTOM;PU FOAM,T8,W2 |
| DB62-04874A | INSULATION-CABI OUT UP;PU FOAM,T8,W220,L |
| DB62-04271A | INSULATION-CABI TOP A;MA1 DUCT,FLOCKED,T |
| DB62-04271B | INSULATION-CABI TOP B;MA1 DUCT,FLOCKED,T |
| DB62-04271C | INSULATION-CABI TOP C;MA1 DUCT,FLOCKED,T |
| DB62-04875A | INSULATION-CABI TOP MID;PU FOAM,T10,W150 |
| DB62-04090A | INSULATION-CABI TOP;MA1,PUR FOAM,T10,457 |
| DB62-04318S | INSULATION-COVER BAND;CH140EAMC,EPDM,T5, |
| DB62-04318T | INSULATION-COVER DRAIN OUT;CH140EAMC,EDP |
| DB62-04094A | INSULATION-COVER PIPE;MA1,PUR FOAM,T10,3 |
| DB62-03566A | INSULATION-DARAIN PIPE;DH60FTA,FOAM-PE,T |
| DB72-00143G | INSULATION-DRAIN |
| DB62-11028A | INSULATION-DRAIN HOSE;CH140EAMC,PE FOAM, |
| DB62-03440H | INSULATION-DRAIN IN;AVMEH035EA3,FORM-PE, |
| DB62-03440N | INSULATION-DRAIN IN;DUCT,FOAM-PE,10,PI 5 |
| DB62-03439N | INSULATION-DRAIN OUT;MA & SLM DUCT,EPDM, |
| DB62-04105A | INSULATION-DRAIN-OUT A;MA1,PE FOAM,T3.0, |
| DB62-04105B | INSULATION-DRAIN-OUT B;MA1,PE FOAM,T3.0, |
| DB62-04104A | INSULATION-DRAIN-OUT C;MA1,PE FOAM,T3.0, |
| DB62-03566B | INSULATION-DRAIN-PIPE;SLIM 1 2 3,EPDM,5, |
| DB62-04091C | INSULATION-FRONT A;MA1,PUR FOAM,T10,10,1 |
| DB62-04091D | INSULATION-FRONT B;MA1,PUR FOAM,T10,10,2 |
| DB62-04089A | INSULATION-FRONT C;MA1,PUR FOAM,T10,311, |
| DB62-11028B | INSULATION-HOSE A;CH070EAMC,PE FOAM,SSEC |
| DB62-11028C | INSULATION-HOSE B;PE FOAM,3,MB9500,SSEC |
| DB62-11028E | INSULATION-HOSE D;PE FOAM,10,150,MB9500, |
| DB72-00143E | INSULATION-INSTALL INLET |
| DB62-03439J | INSULATION-OUT;-,EPDM,T5,200,230, |
| DB62-04092A | INSULATION-OUTLET A;MA1,FLOCKED,T1.0,18, |
| DB62-04092B | INSULATION-OUTLET B;MA1,FLOCKED,T1.0,18, |
| DB62-03440D | INSULATION-PIPE IN |
| DB62-03440C | INSULATION-PIPE IN |
| DB62-03439D | INSULATION-PIPE OUT |
| DB62-03439C | INSULATION-PIPE OUT |
| DB62-03439K | INSULATION-PIPE OUT 3/8;DH070EAV1,PUR FO |
| DB62-03439L | INSULATION-PIPE OUT;DH070EAV1,PUR FOAM,1 |
| DB62-04087A | INSULATION-SIDE LF;PE FOAM/PU FOAM,T13,W |
| DB62-04093A | INSULATION-SIDE RH A;PE FOAM/PP FOAM,T13 |
| DB62-04088A | INSULATION-SIDE RH B;MA1,PUR FOAM,T20,14 |
| DB62-11028F | INSULATION-TUBE OUT;PE FOAM,10,200,GRA |
| DB68-02809A | LABEL BAR CODE |
| DB68-03065A | LABEL BAR CODE;PET,45,15,E-PASS |
| DB98-33749A | LABEL CAUTION;-,ART,W148,L210,ZH+EN+KO |
| DB98-05725B | LABEL INSTRUCTION |
| DB98-32334A | LABEL INSTRUCTION;-,PET,57,8,S |
| DB68-02813A | LABEL WARNING |
| DB68-02856B | LABEL WARNING-B |
| DB98-31132A | LABEL WARNING;-,PET,WW1,WB |
| DB68-01350A | LABEL-BAR CODE |
| DB68-02885A | LABEL-CAUTION BLOWER |
| DB68-02878A | LABEL-TEST |
| 0601-001377 | LED |
| 0601-001375 | LED |
| 0601-001373 | LED |
| DB93-08296B | MAIN PCB ASSEMBLY-IN |
|
|
MOTOR CIRCUIT |
| DB67-60003A | NIPPLE |
| DB67-60023B | NIPPLE;W-PJT,MBS,25.5,5/8-18UNF |
| 0205-001027 | OIL-SILICON |
| DB69-02412V | PACKING CASE BOTTOM;MA1_KO_EN_CN,CB,SW3, |
| DB69-01800C | PACKING CASE-IN;DC36BTSA/UMG,CB,MA1,403, |
| DB69-02749A | PACKING CASE;MA1,CB,DW3,L585,W1410,H363, |
| DB69-02412E | PACKING-BOTTOM;MA0,MA1,CB,T3,1388,572,92 |
| DB69-02774A | PAD CUSHION;DH125EZVAC,EPS,T30,W572,L300 |
| DB41-00364A | PBA LOGIC BOARD;MINIDVM_SLIMDUCT_CHI,FR- |
| DB60-70016A | PIN-STAPLE |
| DB61-02441A | PLATE-EVAP LF |
| DB61-02441C | PLATE-EVAP LF;MA1,STS430,T1 |
| DB61-02442A | PLATE-EVAP RH |
| DB61-02442C | PLATE-EVAP RH;MA1,STS430,T1 |
| 2007-001071 | R-CHIP |
| 2007-001067 | R-CHIP |
| 2007-000938 | R-CHIP |
| 2007-000931 | R-CHIP |
| 2007-000872 | R-CHIP |
| 2007-000766 | R-CHIP |
| 2007-000686 | R-CHIP |
| 2007-000613 | R-CHIP |
| 2007-000477 | R-CHIP |
| 2007-000468 | R-CHIP |
| 2007-000300 | R-CHIP |
| 2007-000023 | R-CHIP |
| 3501-001248 | RELAY-MINIATURE |
|
|
RELAY-MINIATURE |
| 0103-004028 | RESIN ABS;ABSG10/NATURAL,NATURAL,NC0001, |
| 0103-004086 | RESIN HIPS;PH-88,HURRICANE,SC-03101R,N |
| 0103-003376 | RESIN LDPE;MB9500,NATURAL,NC0001,N |
| 0103-002637 | RESIN PA66;NY66/NATURAL,NATURAL,NC0001,N |
| 0103-004069 | RESIN PC ABS;PC-510,GRAY,GY0020,N |
| 0103-003480 | RESIN PP;BJ730/NC0001,NATURAL,NC0001,N |
| 0103-004165 | RESIN PP;TB53,BLACK,BK0001,TD30%,N |
| 0103-004034 | RESIN SAN;ASG20,NATURAL,NC0001,GF20%,N |
| 0103-002713 | RESIN-PVC |
| 2802-001179 | RESONATOR-CERAMIC |
| DB81-00614A | RING;STS304 D2.0, |
| DB73-00270A | RUBBER-COVER WIRE B |
|
|
SCREW-SPECIAL |
| 6002-000560 | SCREW-TAPPING |
| 6002-000536 | SCREW-TAPPING |
| 6002-000527 | SCREW-TAPPING |
| 6002-000440 | SCREW-TAPPING |
|
|
SCREW-TAPPING |
| 6002-000234 | SCREW-TAPPING |
| 6002-000231 | SCREW-TAPPING |
|
|
SCREW-TAPPING |
| DB62-06034A | SEAL-DRAIN PAN A;UH090EAS,EPDM,10,50,5 |
| DB62-06034G | SEAL-DRAIN PAN D;DH090EAS,EPDM,T10,980 |
| DB62-06034U | SEAL-EEV;-,SLOW REBOUND EPDM VO,T3,W20 |
| 0202-001459 | SOLDER-CREAM |
| 0202-001163 | SOLDER-SILVER |
| 0202-001022 | SOLDER-SILVER |
| 0202-001464 | SOLDER-SILVER;L450,91CU/1.9AG/6.95P |
| 0202-001463 | SOLDER-WIRE |
| 0202-001608 | SOLDER-WIRE FLUX |
| DB67-60030A | SPRING-SENSOR |
| 3502-001035 | SSR |
| 3502-001027 | SSR |
| 0101-002929 | STEEL PLATE;GI,SGCC,0.6,Z12,NC |
| 0101-002932 | STEEL PLATE;GI,SGCC,0.8MM,647MM,Z12,NC |
| 0101-002933 | STEEL PLATE;GI,SGCC,1,Z14,NC |
| 0101-002935 | STEEL PLATE;GI,SGCC,1.2MM,700MM,Z14,NC |
| 0101-003199 | STEEL PLATE;GI,SGCC,1.5,Z14,NC |
| 0101-002940 | STEEL PLATE;GI,SGCC,2,Z14,NC |
| 0101-003173 | STEEL PLATE;GI,SGCC,2.5,Z18,NC |
| 0101-003170 | STEEL PLATE;GI,SGCC,3MM,180MM,Z18,NC |
| DB34-00009A | SWITCH-DIGITAL |
| 3407-000121 | SWITCH-DIP |
| 3406-001106 | SWITCH-ROTARY;24VDC,15MA,10,L14MM |
| DA02-00013A | TAPE ETC |
| DB02-00045B | TAPE ETC-PVC;NS1004PXEA,PVC,0.15MM,25,26 |
| DB02-00045A | TAPE ETC-PVC;NS1004PXEA,PVC,0.15MM,25,30 |
| DB02-00029B | TAPE ETC;RAC,OPP,0.05MM,80MM,500M,TRANSP |
| DA02-10017J | TAPE-FILAMENT |
| DB65-00105M | TERMINAL BLOCK |
| DB65-00105L | TERMINAL BLOCK |
| 0506-000175 | TR-ARRAY |
| 0504-000001 | TR-DIGITAL |
| 0501-002296 | TR-SMALL SIGNAL |
| 0501-000534 | TR-SMALL SIGNAL |
| DB26-00107A | TRANS POWER |
| DB26-00095A | TRANS POWER |
| DB62-03445D | TUBE HAIR PIN;MA1 DUCT,C1220T-O,0.25,OD7 |
| DB62-07219C | TUBE-BONET;C1220T-0,0.7,7.94,65 |
| DB62-07043K | TUBE-CAP;C1220T-O,ID15.88 |
| DB62-07219K | TUBE-COLLECTOR;C1220T-0,T1,OD15.88,461, |
| DB62-06999A | TUBE-CU;C1220T-O,T0.25,OD7,L,ID6.3,TW0.2 |
| DB62-07219A | TUBE-EXPAN IN;C1220T-0,0.7,9.52,144 |
| DB62-07219B | TUBE-EXPAN OUT;C1220T-0,0.7,9.52,214 |
| DB62-00541C | TUBE-FILTER;AVMCC052EA0,C1220T-H,T1,OD19 |
| DB62-07219M | TUBE-OUTLET A;C1220T-0,T0.7,OD7,72 |
| DB62-07219N | TUBE-OUTLET B;C1220T-0,T0.7,OD7,81.5, |
| DB62-07219D | TUBE-PATH A;C1220T-0,0.7,4.76,211 |
| DB62-07219E | TUBE-PATH B;C1220T-0,0.7,4.76,164 |
| DB62-07219F | TUBE-PATH C;C1220T-0,0.7,4.76,157 |
| DB62-07219G | TUBE-PATH D;C1220T-0,0.7,4.76,173 |
| DB62-07219H | TUBE-PATH E;C1220T-0,0.7,4.76,168 |
| DB62-07219J | TUBE-PATH F;C1220T-0,0.7,4.76,173 |
| DB62-07332A | TUBE-PINCH;EVAP,C1220T-O,T0.6,OD6.35,L70 |
| DB62-30369A | TUBE-U BEND |
| DB62-30368A | TUBE-U BEND;COMMON USE,C1220T-O,T0.41,OD |
| DB62-04068A | VALVE COIL EXPAN |
| DB62-04066A | VALVE EXPAN |
| 1405-000160 | VARISTOR |
| 1405-000154 | VARISTOR |
| DB68-01675A | WARRANTY CARD |
