Manufacturer
Samsung
Model Number
CLX-8540ND
Description
Color Laser Multi-function Printer
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| JC66-01689A | ACTUATOR-DUPLEX;SCX-6555N,PC,T2,BLK |
| JC66-01474A | ACTUATOR-EXIT;CLX-8380ND/XAA,PC,1.5T,V0, |
| JC66-01803A | ACTUATOR-GATE;SCX-6555N,PC,BLK |
| JC66-01688A | ACTUATOR-REGI;SCX-6555N,PC,T2,BLK |
| JC66-01691A | ACTUATOR-REVERSE;SCX-6555N,PC,T2,BLK |
| JC66-01690A | ACTUATOR-SCAN;SCX-6555N,PC,T2,BLK |
| 0201-001006 | ADHESIVE-AA;#7452,TRP |
| JB72-00764A | BAND;SCX-1110/XRX,POM,WHT |
|
|
BATTERY-LI;3V,220MAH,CR2032,20X3.2MM,CON |
| 3301-000344 | BEAD-RADIAL;200OHM,3.5X0.6X6.5MM,7000MA, |
| 3301-001495 | BEAD-SMD;120OHM,2012,2500MA,TP,115OHM/10 |
| 3301-001655 | BEAD-SMD;33OHM,3216,3000MA,TP,16OHM/39MH |
| 3301-001067 | BEAD-SMD;600OHM,1608 |
| 3301-001594 | BEAD-SMD;90OHM,2.0*1.2*1.3MM,TP,-,- |
|
|
BEARING-BALL;6705ZZ,ID25.0,OD32.0,L4,CWB |
|
|
BEARING-BALL;688ZZ,ID8,OD16,L5,SUJ2 |
| 6601-001389 | BEARING-BALL;L-1280ZZH P0P25LY13,ID8,OD1 |
| 6601-001580 | BEARING-BALL;MR106-2RS,ID6,OD10,L3,EC3 4 |
| 6602-001581 | BELT-TIMING GEAR;40S2M168,RUBBER,T1.36,L |
| 6602-001090 | BELT-TIMING GEAR;FIBER GLASS,T3.2,942.85 |
| 6602-001092 | BELT-TIMING GEAR;RUBBER,T1.36,40S2M338,3 |
| JC61-03528A | BLADE-CLEANING ACR;CLX-8380ND/XAA,FLOCKI |
| JC61-03317A | BRACKET-ADJUST SKEW;SCX-6445N,SECC,T1.0 |
| JC61-02040A | BRACKET-DEVE FRONT;CLX-8380ND/XAA,SECC,T |
| JC61-02043A | BRACKET-DEVE REAR;CLX-8380ND/XAA,SECC,T1 |
| JC61-02057A | BRACKET-FINISHER REAR;CLX-8380ND/XAA,SEC |
| JC61-02042A | BRACKET-FUSER DRIVE;CLX-8380ND/XAA,SECC, |
| JC61-02204A | BRACKET-HOLDER BAND;CLX-8380ND/XAA,STS 3 |
| JC61-02023A | BRACKET-HOLDER LSU;CLX-8380ND/XAA,SECC,T |
| JC61-02496A | BRACKET-HOLDER MOTOR;CLX-8380ND/XAA,SECC |
| JC61-02060A | BRACKET-HOLDER OPC;CLX-8380ND/XAA,SECC,T |
| JC61-02205A | BRACKET-HOLDER SPRING;CLX-8380ND/XAA,SEC |
| JC61-02002A | BRACKET-INLET;CLX-8380ND/XAA,SECC,T1.0 |
| JC61-02167A | BRACKET-LSU CLEANING;CLX-8380ND/XAA,SECC |
| JC61-02038A | BRACKET-MAIN DRIVE FR;CLX-8380ND/XAA,SEC |
| JC61-02039A | BRACKET-MAIN DRIVE RR;CLX-8380ND/XAA,SEC |
| JC61-02091A | BRACKET-OPE GROUND;CLX-8380ND/XAA,SECC,T |
| JC61-02147A | BRACKET-PUSHER LSU;CLX-8380ND/XAA,SECC,T |
| JC61-02059A | BRACKET-SCAN SUP F;CLX-8380ND/XAA,SECC,T |
| JC61-01999A | BRACKET-SCAN SUP REAR;CLX-8380ND/XAA,SEC |
| JC61-02093A | BRACKET-SHIELD SMPS;CLX-8380ND/XAA,SECC, |
| JC61-02144A | BRACKET-SMPS LOWER;CLX-8380ND/XAA,SECC,T |
| JC61-02145A | BRACKET-SMPS UPPER;CLX-8380ND/XAA,SECC,T |
| JC61-02058A | BRACKET-SUPPORT REAR;CLX-8380ND/XAA,SECC |
| JC61-02041A | BRACKET-T1 ENGAGE;CLX-8380ND/XAA,SECC,T1 |
| JC61-02754A | BRACKET-WHITE BAR;CLX-8380ND,SECC,1.0,27 |
| JC67-00055A | BRUSH-ANTISTATIC 531P;SF-531P,AL+THUNDER |
| JC67-00125A | BRUSH-EXIT;SCX-6345N/XRX,AL0.4T, SUS FIB |
| JC61-00424A | BUSH-4;ML-9400W,BEARING,?4,NTR |
| JC61-01686A | BUSH-4D_FE;SCX-6345N,SBF2118,?4,?5.93,3. |
| JC61-00884A | BUSH-6_D(L);SCX-6320F,BRONZE POWDER(KAB- |
| JC61-00423A | BUSH-6_D;ML-9400W,BEARING,?6,NTR |
| JC61-00426A | BUSH-8/5;ML-9400W,BEARING,?8,OD12.0,L6.0 |
| JC61-00699A | BUSH-D6/L4;CLP-500,FE+CU+ZN-SLEARATE,?6, |
| JC61-01428A | BUSH-DRY;SCX-6345N/XRX,BRONZE SINTERED(K |
| JC61-00984A | BUSH-M-D8 L5;CLP-510,POM(M90-44),?8,?11. |
|
|
BUSH-M_ADF CLUTCH;SCX-6320F,PPS,7,11.85, |
| 3002-000185 | BUZZER-MAGNETIC;85DB,5V,40MA,2.4KHZ,BK |
| 2402-001042 | C-AL,SMD;100UF,20%,16V,GP,TP,6.6X6.6X5.4 |
| 2402-001086 | C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3 |
| 2402-001049 | C-AL,SMD;10UF,20%,16V,GP,TP,3.3X3.3X5.4 |
| 2402-000204 | C-AL,SMD;10UF,20%,16V,WT,TP,4.3X4.3X5.4 |
| 2402-001178 | C-AL,SMD;10UF,20%,16V,WT,TP,4.3X4.3X5.8M |
| 2402-000117 | C-AL,SMD;10UF,20%,35V,GP,TP,5.3X5.3X5.4 |
| 2402-000209 | C-AL,SMD;22UF,20%,16V,WT,TP,5.3X5.3MM |
| 2402-001106 | C-AL,SMD;33UF,20%,50V,WT,TP,8.3X8.3X6.3M |
| 2402-000008 | C-AL,SMD;47UF,20%,16V,GP,TP,6.6X6.6X5.4 |
| 2402-001155 | C-AL,SMD;47UF,20%,16V,WT,TP,6.3X5.2MM |
| 2401-000207 | C-AL;100UF,20%,50V,WT,TP,8X12,5 |
| 2401-000480 | C-AL;10UF,20%,50V,GP,TP,5X11,5 |
| 2401-002395 | C-AL;22UF,20%,25V,WT,TP,5X11,5 |
| 2401-000962 | C-AL;22UF,20%,50V,GP,TP,5X11,5 |
| 2401-002300 | C-AL;47UF,20%,50V,GP,TP,6.3X11,5MM |
| 2203-005105 | C-CER,CHIP;.68NF,5%,50V,C0G,TP,1608 |
| 2203-000384 | C-CER,CHIP;0.015NF,5%,50V,C0G,TP,1608,0. |
| 2203-000426 | C-CER,CHIP;0.018NF,5%,50V,C0G,1608 |
| 2203-000041 | C-CER,CHIP;0.01NF,0.25PF,50V,C0G,TP,1608 |
| 2203-000626 | C-CER,CHIP;0.022NF,5%,50V,C0G,1608 |
| 2203-000627 | C-CER,CHIP;0.022NF,5%,50V,C0G,TP,1005 |
| 2203-001408 | C-CER,CHIP;0.27NF,5%,50V,NP0,1608 |
| 2203-000783 | C-CER,CHIP;0.33NF,5%,50V,C0G,1608 |
| 2203-001656 | C-CER,CHIP;0.47NF,5%,50V,NP0,1608 |
| 2203-000140 | C-CER,CHIP;1.5NF,10%,50V,X7R,1608 |
| 2203-005819 | C-CER,CHIP;1000NF,+80-20%,16V,Y5V,TP,160 |
| 2203-005617 | C-CER,CHIP;1000NF,+80-20%,50V,Y5V,TP,201 |
| 2203-006348 | C-CER,CHIP;1000NF,10%,25V,X5R,TP,1608,0. |
| 2203-002709 | C-CER,CHIP;100NF,+80-20%,16V,Y5V,1005 |
| 2203-000192 | C-CER,CHIP;100NF,+80-20%,50V,Y5V,TP,2012 |
| 2203-006158 | C-CER,CHIP;100NF,10%,16V,X7R,TP,1005,0.5 |
| 2203-005249 | C-CER,CHIP;100NF,10%,50V,X7R,TP,1608 |
| 2203-000206 | C-CER,CHIP;100NF,10%,50V,X7R,TP,2012 |
| 2203-000257 | C-CER,CHIP;10NF,10%,50V,X7R,TP,1608 |
| 2203-000440 | C-CER,CHIP;1NF,10,50V,X7R,TP,1608 |
| 2203-006320 | C-CER,CHIP;2200NF,10%,16V,X7R,TP,2012 |
| 2203-002392 | C-CER,CHIP;220NF,+80-20%,50V,Y5V,2012 |
| 2203-005384 | C-CER,CHIP;4700NF,+80-20%,10V,Y5V,TP,201 |
| 2203-000975 | C-CER,CHIP;47NF,10%,25V,X7R,TP,1608,- |
| 6502-001130 | CABLE CLAMP;DACS-3N,14*5,NYLON66,BLACK |
| 6502-000132 | CABLE CLAMP;DAWS-1NE,ID11,L21.0,NTR,NYLO |
| 6502-001093 | CABLE CLAMP;DAWS-3NE,ID11*L34.8,NYLON66, |
| 6501-000004 | CABLE TIE;DA-80,T1,W2.5,L80,NTR,NYLON66 |
| JC66-01532A | CAM-TR ENGAGE;CLX-8380ND/XAA,POM,BLK |
| JC67-00422A | CAP-ACR SENSOR;CLX-8385ND,PC+SAN-GF40,2. |
| JC67-00234A | CAP-SIDE LOWER;CLX-8380ND/XAA,ABS(HB),2. |
| JC67-00236A | CAP-SIDE UPPER;CLX-8380ND/XAA,ABS(HB),2. |
| JC67-00284A | CAP-TONER L;SCX-6555N,PP,1.0,33,6,BLK |
|
|
CARTRIDGE-TRANSFER;CLX-8380ND/XAA,SEC,-, |
| JC39-00114A | CBF HARNESS-BRUSH GND;ML-7050,UL1007,300 |
| JC39-00509A | CBF HARNESS-GND ZENER;SCX-4521F,UL1007,1 |
| JC39-00507A | CBF HARNESS-GND1;CLP-600,CBF HARNESS,UL1 |
| JC39-00508A | CBF HARNESS-GND2;CLP-600,CBF HARNESS,UL1 |
| JB39-00103A | CBF HARNESS-LIU GND;SCX-1110F,WIRE,UL100 |
| JC39-00496A | CBF HARNESS-LSU_GND;CLP-300,WIRE HARNESS |
|
|
CBF IF-USB;ML-6100,4,UL2725,1800 +/- 50, |
| 3903-000296 | CBF-POWER CORD;DT,US,EP3,IEC320 C13,125/ |
| JC66-01837A | CLUTCH-2.5K Z24;CLX-8380ND/XAA,POM+METAL |
|
|
CLUTCH-2.5K Z24;SCX-6555N,POM+METAL,2.5K |
| JC66-00994B | CLUTCH-5K Z32;CLX-8380ND/XAA,POM+METAL,5 |
|
|
CLUTCH-5K Z32;SCX-6345N/XRX,POM+METAL,5K |
|
|
CLUTCH-P_ONE WAY;SCX-6345N/XRX,OWC612GXR |
| 3709-001372 | CONNECTOR-CARD EDGE;200P,0.6MM,SMD,AUF,S |
| 3708-002121 | CONNECTOR-FPC/FFC/PIC;40P,1MM,SMD-S,SN,N |
| 3708-001741 | CONNECTOR-FPC/FFC/PIC;6P,1MM,STRAIGHT,SN |
| 3711-006437 | CONNECTOR-HEADER;BOX,15P,1R,1.5MM,STRAIG |
| 3711-006761 | CONNECTOR-HEADER;BOX,4P,1R,2MM,SMD-A,SN, |
| 3711-006454 | CONNECTOR-HEADER;BOX,7P,1R,1.27MM,STRAIG |
| 3711-002349 | CONNECTOR-HEADER;BOX,7P,1R,2MM,STRAIGHT, |
| 3711-006576 | CONNECTOR-HEADER;NO WALL,4P,1R,6MM,SMD-S |
| JC67-00424A | COUPLER-OPC DRIVE;CLX-8385ND,PA66+CF40,1 |
| JC67-00423A | COUPLER-ROLLER REGI;CLX-8385ND,FE -SINTE |
| JC67-00126A | COUPLER-TORQUELIMITER;SCX-6345N/XRX,OTLV |
| JC63-01544A | COVER-BAND;CLX-8380ND/XAA,ABS,T2.0,VIOLE |
| JC63-01362A | COVER-CCD CABLE;CLX-8380ND/XAA,ABS,T2.0, |
| JC63-01363A | COVER-CONNECTOR;CLX-8380ND/XAA,PC,T2.0,5 |
| JC63-00765B | COVER-CONNECTOR;SCX-6345N,ABS,5.3,55.0,7 |
| JC63-01451A | COVER-EXIT BOTTOM;CLX-8330ND/XAA,HIPS,T2 |
| JC63-01452A | COVER-EXIT REAR;CLX-8330ND/XAA,HIPS,T 2. |
| JC63-01360A | COVER-FAN SMPS;CLX-8380ND/XAA,PC,T2.0,5V |
| JC63-02488A | COVER-FILTER SIDE;CLX-8385ND,ABS HF-0660 |
| JC63-01611A | COVER-FRONT;SCX-6555N,HIPS,T2.5,VIOLET S |
| JC63-01412A | COVER-LEVER SLIDE;CLX-8380ND/XAA,POM,T3. |
| JC63-00192C | COVER-MAIN REAR DUMMY;SCX-6322DN,HIPS,13 |
| JC63-01458A | COVER-MAIN REAR LOWER;CLX-8330ND/XAA,HIP |
| JC63-01453A | COVER-PANEL MFP;CLX-8330ND/XAA,HIPS,T 3, |
| JC63-01637A | COVER-REAR;SCX-6555N,HIPS,T2.5,VIOLET SM |
| JC63-01454A | COVER-SIDE_LEFT;CLX-8330ND/XAA,PC/ABS,T |
| JC63-01358A | COVER-TERMINAL ITB;CLX-8380ND/XAA,ABS,V0 |
| 2801-000111 | CRYSTAL-SMD;0.032768MHZ,20PPM,28-AAW,12. |
| 2801-004181 | CRYSTAL-SMD;20MHZ,50PPM,28-AAN,16PF,30OH |
| 0402-001212 | DIODE-RECTIFIER;SS26,60V,2A,SMB,TP |
| 0404-001084 | DIODE-SCHOTTKY;BAT54A,30V,200MA,SOT-23,T |
| 0404-000112 | DIODE-SCHOTTKY;RB420D,40V,100MA,SOT-23,T |
| 0407-000123 | DIODE-SWITCHING;DAN202K,80V,100MA,SOT-23 |
| 0407-000122 | DIODE-SWITCHING;KDS226,80V,100MA,SOT-23, |
| 0401-000116 | DIODE-SWITCHING;MMSD914T1,100V,200MA,SOD |
| JC93-00201A | DRIVE FUSER;CLX-8385ND,SEC |
| JC93-00200A | DRIVE MAIN;CLX-8385ND,SEC |
| JC93-00099A | DRIVE MAIN;CLX-8385ND/XAA,SEC |
| JC93-00199A | DRIVE-DEVE;CLX-8385ND,SEC |
| JC93-00098A | DRIVE-DEVE;CLX-8385ND/XAA,SEC |
| JC93-00100A | DRIVE;CLX-8385ND/XAA,SEC |
|
|
DUPLEX-COVER FILTER;CLX-8385ND/XAA,SEC |
| JC90-00957A | DUPLEX;CLX-8385ND/XAA,SEC |
| JC96-04579A | ELA HOU-BOTTLE BASE;CLX-8380ND/XAA,SEC |
| JC96-04857A | ELA HOU-COVER JAM;SCX-6555N,SEC,-,-,- |
| JC96-04862A | ELA HOU-COVER OPEN;SCX-6555N,SEC,-,-,-,- |
| JC96-04859A | ELA HOU-DADF MOTOR;SCX-6555N,SEC,-,-,-,- |
| JC96-04858A | ELA HOU-DADF SUB;SCX-6555N,SEC,-,-,-,- |
| JC96-04855A | ELA HOU-DADF;SCX-6555N,SEC,-,-,-,- |
| JC96-04860A | ELA HOU-DUPLEX MOTOR;SCX-6555N,SEC,-,-,- |
| JC96-04536A | ELA HOU-DUPLEX;CLX-8380ND/XAA,SEC,-,DUPL |
| JC96-04748A | ELA HOU-EXIT;CLX-8380ND/XAA,-,-,-,- |
| JC96-04542A | ELA HOU-GUIDE EXIT;CLX-8380ND/XAA,SEC,-, |
| JC96-04600A | ELA HOU-GUIDE REGI;CLX-8380ND/XAA,SEC,-, |
| JC96-04861A | ELA HOU-GUIDE SCAN;SCX-6555N,SEC,-,-,-,- |
|
|
ELA HOU-MP PICK UP;SCX-6345N/XRX,-,-,MP |
| JC96-04774A | ELA HOU-MP;CLX-8380ND/XAA,-,-,-,- |
| JC96-03749B | ELA HOU-SOLENOID DP;CLX-8380ND/XAA,-,KOR |
| JC96-04562A | ELA UNIT-BASE PLATE R;CLX-8380ND/XAA,SEC |
| JC96-04936A | ELA UNIT-BASE RIGHT;CLX-8380ND/XAA,SEC,- |
| JC96-04338A | ELA UNIT-CCDM HIGH;ADVANCED-COLOR,EPIN,C |
| JC96-04747A | ELA UNIT-COVER BAND;CLX-8380ND/XAA,-,-,- |
| JC96-04558A | ELA UNIT-COVER OPEN;CLX-8380ND/XAA,SEC,- |
| JC96-02127B | ELA UNIT-CST SENSOR;CLX-8380ND/XAA,SEC,- |
| JC96-04568A | ELA UNIT-DRIVE FUSER;CLX-8380ND/XAA,SEC, |
| JC96-04560A | ELA UNIT-FRAME UPPER;CLX-8380ND/XAA,SEC, |
|
|
ELA UNIT-FUSER LV;CLX-8380ND/XAA,SEC,-,1 |
| JC96-04555A | ELA UNIT-HOLDER LSU;CLX-8380ND/XAA,SEC,- |
| JC96-04573A | ELA UNIT-HOLDER OPC;CLX-8380ND/XAA,SEC |
| JC96-05203A | ELA UNIT-HOLDER_HVPS;CLX-8380ND/XAA,-,-, |
| JC96-04581A | ELA UNIT-HV DEVE;CLX-8380ND/XAA,SEC |
| JC96-04561A | ELA UNIT-HV ITB;CLX-8380ND/XAA,SEC,-,-,- |
| JC96-04578A | ELA UNIT-HV TR;CLX-8380ND/XAA,SEC,-,T2,- |
| JC96-04746A | ELA UNIT-LEVER;CLX-8380ND/XAA,-,KOREA,-, |
| JC96-04559A | ELA UNIT-LSU CLEANING;CLX-8380ND/XAA,SEC |
| JC96-04520A | ELA UNIT-LSU;CLX-8330N,-,TANDEM,A4,600DP |
| JC96-04554A | ELA UNIT-PICK UP;CLX-8380ND/XAA,SEC,KORE |
| JC96-04570A | ELA UNIT-PLATE UPPER;CLX-8380ND/XAA,SEC, |
| JC96-04547A | ELA UNIT-PUSHER LSU;CLX-8380ND/XAA,SEC,- |
| JC96-04548A | ELA UNIT-SCAN LOWER;CLX-8380ND/XAA,SEC,- |
| JC96-04958A | ELA UNIT-SCAN MOTOR;CLX-8380ND/XAA,SEC,- |
| JC96-04569A | ELA UNIT-SCAN UPPER;CLX-8380ND/XAA,SEC,- |
| JC96-04550A | ELA UNIT-SCANNER;CLX-8380ND/XAA,SEC,-,-, |
| JC96-04552A | ELA UNIT-SIZE SENSOR;CLX-8380ND/XAA,SEC, |
| JC96-04749A | ELA UNIT-SMPS UPPER;CLX-8380ND/XAA,-,-,- |
| JC96-05204A | ELA UNIT-SUPPORT REAR;CLX-8380ND/XAA,SEC |
| JC96-05048A | ELA UNIT-WASTE_SENSOR;CLX_8380ND,SEC,SEC |
| JC96-04564A | ELA UNIT-WTB MOTOR;CLX-8380ND/XAA,SEC |
| JC31-00086A | FAN-DC;CLX-8380ND/XAA,PBT+GF,UL10272 AWG |
|
|
FAN-DC;CLX-8380ND/XAA,UL10272 AWG#26,AMP |
| JC31-00087A | FAN;CLX-8380ND/XAA,PBT+GF,UL10272 AWG#26 |
|
|
FDB-MULTI_TRIAC V1;CLX-8330N,AC/AC,1300W |
| JC63-02050A | FELT-ITB;CLX-8380ND,DOUBLE RACHEL FABRIC |
|
|
FIXER-M_E RING 4PI;SCX-6345N/XRX,POM,T1. |
| JC39-00941A | FLAT CABLE-APS_FFC;SCX-6555N,6P,410MM,AW |
| JC61-40001A | FOOT-ML80;ML-80,NBR,GRAY |
| JC61-01411B | FRAME-CASSETTE;SCX-6345N,HIPS,HB,VIOLET |
| JC93-00102A | FRAME-LOWER;CLX-8385ND/XAA,SEC |
| JC61-02024A | FRAME-MAIN LOWER;CLX-8380ND/XAA,PC+G/F 2 |
| JC61-02132A | FRAME-MAIN UPPER;CLX-8380ND/XAA,PC+GF 20 |
| JC61-01351B | FRAME-MP LOWER;SCX-6345N,ABS,HB,VIOLET S |
| JC61-01352B | FRAME-MP TOP;SCX-6345N,ABS,HB,VIOLET SMO |
| JC93-00103A | FRAME-REGI;CLX-8385ND/XAA,SEC |
| JC93-00095A | FRAME;CLX-8385ND/XAA,SEC |
| JB66-00104A | GEAR-ADF IDLE 34;SCX-1110F,POM,0.6,34,20 |
| JC66-00320A | GEAR-AUGER;SCX-5100,POM M90-44,0.6,24,14 |
| JC66-01480A | GEAR-CLEANING ITB;CLX-8380ND/XAA,POM,1,2 |
| JC66-01667A | GEAR-CLUTCH;SCX-6555N,POM,0.6,28,NTR,SPU |
| JC66-00565A | GEAR-DADF24(A);SCX-6320F,POM M90-44,1,Z2 |
| JC66-01496A | GEAR-DEVE DRIVE;CLX-8380ND/XAA,POM,M0.8, |
| JC66-01495A | GEAR-DEVE IDLE;CLX-8380ND/XAA,POM,M0.8,Z |
| JC66-01494A | GEAR-DEVE RDCN BK;CLX-8380ND/XAA,POM,M0. |
| JC66-01497A | GEAR-DEVE RDCN COLOR;CLX-8380ND/XAA,POM, |
| JC66-01571A | GEAR-EXIT RDCN A;CLX-8380ND/XAA,POM,M0.5 |
| JC66-01572A | GEAR-EXIT RDCN B;CLX-8380ND/XAA,POM,M1.0 |
| JC66-01644A | GEAR-FEED IDLE B;CLX-8380ND/XAA,POM,M1.0 |
| JC66-01490A | GEAR-FEED IDLE;CLX-8380ND/XAA,POM,M1.0/M |
| JC66-01570A | GEAR-FUSER IDLE;CLX-8380ND/XAA,POM,M1.0, |
| JC66-01569A | GEAR-FUSER RDCN A;CLX-8380ND/XAA,POM,M0. |
| JC66-01499A | GEAR-FUSER RDCN B;CLX-8380ND/XAA,POM,M1. |
| JC66-01405A | GEAR-FUSER;CLP-660,PPS+GF,1.0,25,BROWN,? |
| JB66-00083A | GEAR-IDLE;SCX-1110/XRX,POM M90-44,0.5,31 |
| JC66-01489A | GEAR-ITB DRIVE;CLX-8380ND/XAA,POM,M0.5,Z |
| JC66-01527A | GEAR-LSU CLEANING;CLX-8380ND/XAA,POM,M0. |
| JC66-00473B | GEAR-M-DEVE IDEL Z51;CLP-500,POM,0.8,Z51 |
| JC66-01642A | GEAR-MP RDCN A;CLX-8380ND/XAA,POM,M1.0/M |
| JC66-01643A | GEAR-MP RDCN B;CLX-8380ND/XAA,POM,M1.0/M |
| JC66-01806A | GEAR-MULTI ROLLER;SCX-6555N,POM,0.6,51,N |
| JC66-00991A | GEAR-M_DUPLEX IDLE;SCX-6345N/XRX,POM,1,3 |
| JC66-00997A | GEAR-M_EXIT IDLE C;SCX-6345N/XRX,POM,A:1 |
| JC66-01018A | GEAR-M_EXIT LOWER;SCX-6345N/XRX,POM,0.8, |
| JC66-01017A | GEAR-M_EXIT UPPER;SCX-6345N/XRX,POM,0.8, |
| JC66-01012A | GEAR-M_EXIT;SCX-6345N/XRX,POM,1,15,W10,B |
| JC66-00974A | GEAR-M_FORWARD;SCX-6345N/XRX,POM,1,31,H9 |
| JC66-00940A | GEAR-M_IDLE PU;SCX-6345N/XRX,POM,0.7,22, |
| JC66-00955A | GEAR-M_LIFT COUPLING;SCX-6345N/XRX,POM,1 |
| JC66-00954A | GEAR-M_LIFTING;SCX-6345N/XRX,POM,1.5,46, |
| JC66-00941A | GEAR-M_ONE WAY;SCX-6345N/XRX,POM,0.7,21, |
| JC66-00973A | GEAR-M_PICKUP IDLE B;SCX-6345N/XRX,POM,A |
| JC66-01020A | GEAR-M_PINION 24;SCX-6345N/XRX,POM,1,24, |
|
|
GEAR-M_PU JOINT;SCX-6345N/XRX,POM,0.7,21 |
| JC66-00975A | GEAR-M_RETARD;SCX-6345N/XRX,POM,0.6,57,H |
| JC66-01683A | GEAR-ONE WAY DADF;SCX-6555N,POM,0.6,42,N |
| JC66-01492A | GEAR-OPC DRIVE;CLX-8380ND/XAA,POM,M0.5,Z |
| JC66-01493A | GEAR-OPC IDLE;CLX-8380ND/XAA,POM,M0.5,Z4 |
| JB66-00105A | GEAR-PICK UP 26;SCX-1110F,POM,0.6,26,15. |
| JB66-00102A | GEAR-PICK UP IDEL 38;SCX-1110F,POM,0.6,3 |
| JC66-01676A | GEAR-PICKUP DRIVE;SCX-6555N,POM,1,25,BLK |
| JC66-01645A | GEAR-PICKUP RDCN A;CLX-8380ND/XAA,POM,M1 |
| JG66-40003A | GEAR-PINION;SF4000,POM,1,Z16,WHT |
| JC66-00530A | GEAR-REDUCTION73/37;SCX-6320F,POM M90-44 |
| JC66-02543A | GEAR-REGI IDLE_R;CLX-8385ND,POM,1.0,32,W |
| JC66-01491A | GEAR-REGI RDCN;CLX-8380ND/XAA,POM,M0.5/M |
| JC66-01675A | GEAR-ROLLER DRIVE;SCX-6555N,POM,0.6,42,N |
| JC66-01478A | GEAR-SENSOR ITB;CLX-8380ND/XAA,POM,1,22, |
| JC66-01479A | GEAR-TENSION ITB;CLX-8380ND/XAA,POM,1,24 |
| JC66-01867A | GEAR-TIMING;CLX-8380ND/XAA,POM,M0.5,57,W |
| JC66-01502A | GEAR-TR ENGAGE A;CLX-8380ND/XAA,POM,M0.6 |
| JC66-01488A | GEAR-TR ENGAGE B;CLX-8380ND/XAA,POM,M0.7 |
| JC66-01503A | GEAR-TR ITB ENGAGE A;CLX-8380ND/XAA,POM, |
| JC66-01498A | GEAR-TR ITB ENGAGE B;CLX-8380ND/XAA,POM, |
| JC01-00016A | GLASS-SCAN HEATING;388*271.5,T3.2 |
| JC74-00019A | GLASS;238.4*19*2.8,SCX-5100,GLASS,CLEAR |
| JC63-01388A | GROUND-FEED ROLLER;CLX-8380ND/XAA,C5210P |
| JC63-01448A | GROUND-FUSER HV;CLX-8380ND/XAA,C5210P,T0 |
| JC63-01389A | GROUND-FUSER;CLX-8380ND/XAA,C5210P,T0.2 |
| JC63-01515A | GROUND-MAIN DRIVE;CLX-8380ND/XAA,C5210P, |
| JC63-01390A | GROUND-OPE REAR;CLX-8380ND/XAA,C5210P,T0 |
| JC63-00794A | GROUND-P-PAPER SIZE;SCX-6345N/XRX,PHOSPH |
| JC63-00833A | GROUND-P-SHAFT RETARD;SCX-6345N/XRX,PHOS |
| JC61-02347A | GUIDE-EXTENSIONPLATEN;SCX-6555N,ABS,T2.5 |
| JC61-01297A | GUIDE-M_FEED IDLE MP;SCX-6345N/XRX,ABS , |
|
|
GUIDE-M_PICKUP DOC;SCX-6345N/XRX,PC+ABS, |
| JC61-01299A | GUIDE-M_UPPER PICK UP;SCX-6345N/XRX,PC A |
| JC61-01413A | GUIDE-P-SIDE LEFT;SCX-6345N/XRX,SECC,T1. |
| JC61-02065A | GUIDE-RAIL FEED F;CLX-8380ND/XAA,ABS,BLK |
| JC61-02066A | GUIDE-RAIL FEED R;CLX-8380ND/XAA,ABS,BLK |
| JC61-02062A | GUIDE-RAIL LSU;CLX-8380ND/XAA,HIPS,BLK,P |
| JC61-02094A | GUIDE-RAIL MAIN;CLX-8380ND/XAA,ABS,BLACK |
| JC39-01213A | HARNESS-ACR;CLX-8385ND,UL 10272,20,525MM |
| JC39-00708A | HARNESS-BASE DUPL CLT;CLX-8380ND,UL10272 |
| JC39-00691A | HARNESS-BLDC_ITB&T2;CLX-8380ND,UL10272,1 |
| JC39-00815A | HARNESS-CCD_FFC;SCX-6555N,40P,680MM,WHT, |
| JC39-00709A | HARNESS-DUPLEX;CLX-8380ND,UL10272,11P/3P |
| JC39-00801A | HARNESS-DUPLEX_SEN;SCX-6555N,UL10272,9P/ |
| JC39-00707A | HARNESS-FAN&FUSER&HVPS;CLX-8380ND,UL1027 |
| JC39-00806A | HARNESS-FEED_MTR;SCX-6555N,UL10272,10P,2 |
| JC39-00747A | HARNESS-FUSER FU;CLX8380ND,UL3398,4P,75M |
| JC39-01236A | HARNESS-HVPS_SMALL;CLX-8385ND,UL10272,14 |
| JC39-00701A | HARNESS-LSU CLEAN MOT/SENS;CLX-8380ND,UL |
| JC39-00730A | HARNESS-LSU&P_MT;CLX-8380ND,UL10272,32P/ |
| JC39-00702A | HARNESS-MP SPK;CLX-8380ND,UL10272,2,3,4, |
| JC39-00715A | HARNESS-MP_CLT;CLX-8380ND,UL10272,4P/3P/ |
| JC39-00793A | HARNESS-NEAR_SEN;RUSHMORE,UL10272,3P,75M |
| JC39-00705A | HARNESS-REGI;CLX-8380ND,UL10272,6P/3P/3P |
| JC39-00753A | HARNESS-SATA_POWER;SCX-6555N,FLAT,UL1061 |
| JC39-00754A | HARNESS-SATA_SIGNAL;SCX-6555N,FLAT,UL272 |
| JC39-00719A | HARNESS-SCF EMPTY;CLX-8380ND,UL10272,8P/ |
| JC39-00748A | HARNESS-SMPS;CLX-8380ND,UL1061/UN10272,8 |
|
|
HDD;160G,HTS545016B9A300,512BYTES,5400RP |
| JC59-00032A | HDD;250G,HTS543225A7A384/HM250HI,S63,H16 |
| 3711-000178 | HEADER-BOARD TO CABLE;1WALL,2P,1R,3.96MM |
| 3711-000198 | HEADER-BOARD TO CABLE;1WALL,3P,1R,2.5MM, |
| 3711-000255 | HEADER-BOARD TO CABLE;1WALL,5P,1R,2.5MM, |
| 3711-000296 | HEADER-BOARD TO CABLE;1WALL,6P,1R,3.96MM |
| 3711-006435 | HEADER-BOARD TO CABLE;BOX,10P,1R,1.5MM,S |
| 3711-006436 | HEADER-BOARD TO CABLE;BOX,11P,1R,1.5MM,S |
| 3711-006501 | HEADER-BOARD TO CABLE;BOX,12P,1R,1.5MM,S |
| 3711-003340 | HEADER-BOARD TO CABLE;BOX,16P,2R,2MM,STR |
| 3711-006444 | HEADER-BOARD TO CABLE;BOX,34P,2R,1.5MM,S |
| 3711-000862 | HEADER-BOARD TO CABLE;BOX,3P,1R,1.25MM,S |
| 3711-006431 | HEADER-BOARD TO CABLE;BOX,4P,1R,1.5MM,ST |
| 3711-006432 | HEADER-BOARD TO CABLE;BOX,5P,1R,1.5MM,ST |
| 3711-006433 | HEADER-BOARD TO CABLE;BOX,6P,1R,1.5MM,ST |
| 3711-005912 | HEADER-BOARD TO CABLE;BOX,6P,1R,2.54MM,S |
| 3711-002809 | HEADER-BOARD TO CABLE;BOX,8P,1R,2MM,STRA |
| JC61-00729A | HINGE-M-HOUSING;SCX-6320F,DELRIN 100P,WH |
| JC61-03509A | HOLDER-ACR SENSOR;CLX-8385ND,ABS+GF20,2. |
| JC61-02073A | HOLDER-ACTUATOR EXIT;CLX-8380ND/XAA,PC,1 |
| JC61-02007A | HOLDER-COUPLING DEVE;CLX-8380ND/XAA,PC |
| JC61-02005A | HOLDER-COUPLING ITB;CLX-8380ND/XAA,PC |
| JC61-02146A | HOLDER-COVER SENSOR;CLX-8380ND/XAA,ABS,T |
| JC61-02675A | HOLDER-HARNESS SIDE;CLX-8380ND/XAA,HIPS, |
| JC61-02033A | HOLDER-HARNESS;CLX-8380ND/XAA,ABS,T2.0,B |
| JC61-01422A | HOLDER-M_ACT READY;SCX-6345N/XRX,PC,T2,W |
| JC61-01335A | HOLDER-M_ACTUATOR DP;SCX-6345N/XRX,PC,T1 |
| JC61-01288A | HOLDER-M_IDLE ONE WAY;SCX-6345N/XRX,POM, |
| JC61-01406A | HOLDER-M_LIU;SCX-6345N/XRX,ABS,T2.5,W80, |
| JC61-02706A | HOLDER-OPC COUPLING;CLX-8380ND/XAA,STEEL |
| JC61-02034A | HOLDER-SAW;CLX-8380ND/XAA,PC,BLK,NH-1035 |
| JC61-02006A | HOLDER-SENSOR GEAR;CLX-8380ND/XAA,ABS |
| JC61-03508A | HOLDER-SHAFT REGI;CLX-8385ND,ABS+GF,2.5T |
| JC61-01341B | HOUSING-BASE RIGHT;SCX-6345N/XRX,ABS,3.0 |
| JC61-02032A | HOUSING-CAP SPRING;CLX-8380ND/XAA,P0M,T1 |
| JC61-02421A | HOUSING-FEED ROLLER;SCX-6555N,ABS,BLACK |
| JC61-01343A | HOUSING-M_SIZE SENSOR;SCX-6345N/XRX,ABS, |
| JC61-02028A | HOUSING-TERMINAL ITB;CLX-8380ND/XAA,ABS, |
| JC44-00181A | HVPS;24V,21.6V~27.6V,MAX 1KV,MAX-3KV,600 |
| JC44-00141A | HVPS;24V,21.6V~27.6V,MAX 5KV,MAX-2KV |
| JC13-00044A | IC ASIC-CIP6;CIP6,CLX-9350,496P,3.3V,0TO |
| JC13-00020A | IC ASIC-ENGINE CONTROL;LPEC1,CLP-500,128 |
| JC13-00027A | IC ASIC-JUPITER4E;S4FD004X01-E080,ML-152 |
| 1001-000170 | IC-ANALOG SWITCH;MC14051BD,SPDT CMOS,SOP |
| 1001-000171 | IC-ANALOG SWITCH;MC14053BD,SPDT CMOS,SOP |
| 1201-000105 | IC-AUDIO AMP;34119,SOP,8P,150MIL,SINGLE, |
| 1205-002339 | IC-CLOCK GENERATOR;CY25811SC,SOIC,8P,150 |
| 0803-003263 | IC-CMOS LOGIC;74LCX07,HEX BUFFER,SOIC,14 |
| 0801-002403 | IC-CMOS LOGIC;74LCX08,AND GATE,TSSOP,14P |
| 0801-002379 | IC-CMOS LOGIC;74LCX16245,TRANSCEIVER,TSS |
| 0801-002095 | IC-CMOS LOGIC;74LCX245,TRANSCEIVER,TSSOP |
| 0801-002326 | IC-CMOS LOGIC;74LCX32,OR GATE,TSSOP,14,1 |
| 0801-000794 | IC-CMOS LOGIC;7S08,AND GATE,SC-70,5P,2.0 |
| 0801-002143 | IC-CMOS LOGIC;7S32,OR GATE,SOT-23,5P,63M |
| 1203-003739 | IC-DC/DC CONVERTER;MVPG31,DFN,12P,4X3MM, |
| 1105-001652 | IC-DDR SDRAM;K4H511638,DDR,512MBIT,32MX1 |
| 1105-002040 | IC-DDR2 SDRAM;K4T1G084Q,DDR2,1GBIT,128MX |
| 1105-001718 | IC-DDR2 SDRAM;K4T1G164Q,DDR2,1GBIT,64MX1 |
| 1105-001390 | IC-DRAM;K4S641632,SDR,64MBIT,4MX16BIT,TS |
| 1103-001279 | IC-EEPROM;24C32,32KBIT,4KX8,SOP,8P,5X4MM |
| 1006-001250 | IC-LINE DRIVER;DS90LV017A,SOIC,8P,150MIL |
| 0903-001411 | IC-MICROCONTROLLER;S3F443FX,LQFP,64P,12X |
| 1003-001732 | IC-MOTOR DRIVER;A3953SLBTR,SOIC,16P,10.1 |
| 1003-001535 | IC-MOTOR DRIVER;A3977SLP,TSSOP,28P,9.6X4 |
| 1003-001848 | IC-MOTOR DRIVER;SLA7066M-LF2102,ZIP,21P, |
| 1107-001286 | IC-NOR FLASH;29LV160,16MBIT,2MX8/1MX16,T |
| 1203-003700 | IC-POSI.ADJUST REG.;LD1117ADT-R,DPAK,3P, |
| 1203-001455 | IC-POSI.FIXED REG.;1117,DPAK,3P,265MIL,P |
| 1203-002454 | IC-POSI.FIXED REG.;1117,TO-252,3P,257MIL |
| 1203-000259 | IC-POSI.FIXED REG.;7818,TO-220IS,3P,-,PL |
| 1203-002560 | IC-POSI.FIXED REG.;NJM7805,TO-220F,3P,-, |
| 1203-005228 | IC-PWM CONTROLLER;FAN5333,SOT-23,5P,2.9X |
| 1203-005382 | IC-PWM CONTROLLER;ISL8014IRZ-T,QFN,16P,4 |
| 1206-001026 | IC-TIMEKEEPER;M41T00M6TR,SOP,8P,150MIL,P |
| 0904-002093 | IC-USC;ISP1761BE,32BIT,LQFP,128P,20X14MM |
| 0904-002329 | IC-USC;USB2514B,QFN,36P,6.0X6.0X0.5MM,24 |
| 1202-000164 | IC-VOLTAGE COMP.;393,SOP,8P,150MIL,DUAL, |
| JB70-00168A | ICT-PIN ADF;SCX-1110F,STS303,L10.0,D2.0 |
| 2703-002539 | INDUCTOR-SMD;6.8UH,20%,6965 |
| JC70-00195A | IPR-BRACKET SENSOR;ML-7250,SECC,1.0T |
| JC70-00239A | IPR-CHANNEL BASE FRAME;SCX-5100,SECC,T1. |
| JC70-10232D | IPR-E-PLATE SAW(MCK2);SCX-6320F,SUS304CS |
| JC70-11028A | IPR-GROUND TOP;ML-6000,SUS304CSP3/4H,T0. |
| JC70-00218A | IPR-GUARD C/O S/W;SCX-5100,SUS301CSP,0.2 |
| JB70-00148A | IPR-HOLDER GLASS;SCX-1110/XRX,SUS304,12* |
| JC70-00064A | IPR-PIN ROLLER EXIT;SUS304,SF-5100,L23,P |
| JC70-00192A | IPR-PLATE SENSOR;ML-7250,SUS301,0.2T |
| 3722-002591 | JACK-MODULAR;8P/8C,N,ANGLE,N,AU,1PORT |
| 3722-001051 | JACK-USB;4P/1C,AU,BLK,ANGLE,A TYPE |
| 3722-002303 | JACK-USB;4P/1C,AU30U,BLK,ANGLE,B TYPE |
| JC66-01452A | JOINT-COUPLING OPC;CLX-8380ND/XAA,FE+ST |
| JC66-00976A | JOINT-M_RETARD;SCX-6345N/XRX,POM,T1.2,18 |
| JC64-00288B | KEY-HOOK;CLX-8385ND,ABS,70*20*15,HB,LEAD |
| JC64-00287B | KEY-JOB_STATUS;CLX-8385ND,ABS,16*22*9,HB |
| JC64-00239F | KEY-M_TEL;CLX-8385ND,ABS,60.2*66.1*14.5, |
| JC64-00335B | KEY-POWER;CLX-8385ND,ABS,25*25*10,LEAD G |
| JC64-00289A | KEY-STOP;SCX-6345N,HIPS HB,25*25*10,HB,S |
| JB68-00916A | LABEL RATING-BLANK;SF-340,SEC,TETRON,0.0 |
| JC68-01584A | LABEL(P)-BLANK 90*25;CLP-510,SEE,ART 100 |
| JC68-10932A | LABEL(P)-BLANK(ML);ML-85,ART,G100,WHT,CO |
| JC68-00780A | LABEL(P)-CAUTION PRINTING;COMMON,WHITE P |
| JB68-00073A | LABEL(R)-BAR CODE;SF-3000,PY,T0.5,6.5,34 |
| JC68-00573A | LABEL(R)-BARCODE;ML-4500,PET,T0.05,20MM, |
| JC68-01621A | LABEL(R)-MAX FILL;SCX-6345N/XRX,XEROX,PC |
| 4713-001224 | LAMP-HALOGEN;115V,1200W,13X9.8X288MM |
| JC66-02071A | LATCH-BOX;CLX-6200FX,PP,1.8,81.7,68.4,WH |
| JC66-00958A | LATCH-M_ARM FRT;SCX-6345N/XRX,POM,T1.5,3 |
| 0601-001226 | LED;SMD(TOP VIEW),RED,1.2X0.8MM,660NM,1. |
| JC61-01391A | LEG-M LIMIT STACKING;SCX-6345N/XRX,PC,BL |
| JC61-01435A | LEG-M_ACT READY DP;SCX-6345N/XRX,PC,V0,B |
| JC61-01336A | LEG-M_ACTUATOR DUPLEX;SCX-6345N/XRX,PC,V |
| JC67-00209A | LENS-STATUS;SCX-6345N,PMMA,MILKY WHITE,1 |
| JC66-01523A | LEVER-LOCKER;CLX-8380ND/XAA,ABS,HB,VIOLE |
| JC66-00959A | LEVER-M_ARM FRICTION;SCX-6345N/XRX,POM M |
| JC66-01516A | LEVER-OPC SMALL;CLX-8380ND/XAA,PC,T3.0,V |
|
|
LOCKER-M_FRONT;SCX-6345N/XRX,POM,BLACK,H |
| JC64-00199A | LOCKER-M_REAR;SCX-6345N/XRX,POM,BLACK,HB |
| JC98-01134A | MAINLINE;CLX-8385ND/XAA,SEC |
| JC97-01088A | MEA RACK-BUSHING AGI;ML-6000,SEC,KOR,POM |
| JC97-02704A | MEA UNIT-ACT READY;SCX-6345N,XEROX,GB,-, |
| JC97-02935A | MEA UNIT-BLADE ITB;CLX-8380ND/XAA,SEC,IT |
|
|
MEA UNIT-CASSETTE;SCX-6345N/XRX,SEC,-,CA |
| JC97-03449A | MEA UNIT-COVER FRONT;CLX-8380ND/XAA,SEC, |
| JC97-02946A | MEA UNIT-COVER INNER;CLX-8380ND/XAA,SEC, |
| JC97-02989A | MEA UNIT-COVER REAR;CLX-8380ND,-,-,SEC,- |
| JC97-02258B | MEA UNIT-COVER TOP;SCX-6345N/XRX,SEC,-,C |
| JC97-02274B | MEA UNIT-COVER UPPER;SCX-6345N/XRX,SEC,- |
| JC97-02944A | MEA UNIT-DUCT TONER;CLX-8380ND/XAA |
| JC97-02950A | MEA UNIT-DUMMY UPPER;CLX-8380ND/XAA,SEC |
| JC97-03269A | MEA UNIT-EXIT DUPLEX;CLX-8380ND/XAA,-,-, |
|
|
MEA UNIT-F DR;SCX-6345N/XRX,XEROX,-,F DR |
| JC97-02705A | MEA UNIT-FEED IDLE MP;SCX-6345N,XEROX,-, |
| JC97-03450A | MEA UNIT-FRONT OPC;CLX-8380ND/XAA,SEC |
|
|
MEA UNIT-HINGE RM;SCX-6555N,SEC,-,-,- |
|
|
MEA UNIT-HINGE;SCX-6345N/XRX,XEROX,-,HIN |
| JC97-02276A | MEA UNIT-HOLDER HDD;SCX-6345N/XRX,XEROX, |
|
|
MEA UNIT-HOLDER PAD;SCX-6345N/XRX,XEROX, |
| JC97-02836A | MEA UNIT-LIFTING GEAR;SCX-6345N,SEC,-,-, |
| JC97-03477A | MEA UNIT-PLATE OPE;CLX-8330N,SEE,-,-,-,- |
| JC97-02290A | MEA UNIT-RETARD;SCX-6345N/XRX,XEROX,-,RE |
|
|
MEA UNIT-ROLLER PU;SCX-6345N/XRX,XEROX,- |
| JC97-02951A | MEA UNIT-SHUTTER WTB;CLX-8380ND/XAA,SEC |
|
|
MEA UNIT-TONER DRIVE;CLX-8380ND/XAA,SECC |
| JC97-02934A | MEA UNIT-TR;CLX-8380ND/XAA,SEC,SESK,-,-, |
|
|
MEA UNIT-TRAY;SCX-6345N/XRX,SEC,-,TRAY,- |
| JC97-03219A | MEA-COVER PLATEN SUB;SCX-6555N,SEC,-,-,- |
| JC97-03095A | MEA-EXIT;SCX-6555N,SEC,-,-,- |
| JC97-03119A | MEA-FEED ROLLER;SCX-6555N,SEC,-,-,-,- |
| JC97-03096A | MEA-GUIDE PICKUP;SCX-6555N,SEC,-,-,-,- |
|
|
MEA-HOLDER ADF RUBBER;SCX-6555N,SEC,-,-, |
|
|
MEA-PICK UP;SCX-6555N,SEC,-,-,-,- |
| JC97-03098A | MEA-TX STACKER;SCX-6555N,SEC,-,-,-,- |
|
|
MEC-ADF ROLLER ASSY;SCX-1110F/XRX,XEROX, |
|
|
MEC-BRUSH ANTISTATIC;ML-6060A,SEC,NTR |
|
|
MEC-PICK UP ROLLER ASSY;SCX-1110F/XRX,XE |
|
|
MOTOR BLDC;2220 RPM,1400GF.CM,DC24V,2.1A |
| JC31-00074A | MOTOR BLDC;50M843C100,2235 RPM,DC24V,2.8 |
| JC31-00094A | MOTOR DC;HF283LG,DC24V,CLX-8380ND/XAA,79 |
|
|
MOTOR DC;NF213G-1020515,DC24V,CLX-8380ND |
| JC31-00045A | MOTOR GEARED-P LIFT;2.1RPM,1.5N.M,1/1513 |
| JC31-00033B | MOTOR STEP;17PM-J342-G4VS,CLX-8380ND/XAA |
| JC31-00102A | MOTOR STEP;M42SP-13NK,SCX-6555N,0.6A,200 |
| JC31-00077A | MOTOR STEP;M42SP-4NK,CLX-8380ND/XAA,0.6A |
| JC31-00098A | MOTOR STEP;STP-43D3006,SCX-6555N,1.2A,42 |
| JC97-03713A | OPE-COVER;CLX-8385ND,SEE,SEE |
| JC97-03808A | OPE-DUMMY;CLX-8385ND/XAA,SEC,FRENCH |
| JC97-03714A | OPE-PANEL;CLX-8385ND,SEE(FRENCH),ABS |
| JC97-03714B | OPE-PANEL;CLX-8385ND,SEE(SPANISH) |
| JC97-03807A | OPE-PANEL;CLX-8385ND/XAA,SEC,SPANISH |
| JC67-00122A | OTHER MECHA-M GATE DP;SCX-6345N/XRX,PC+G |
|
|
PAD-GUIDE PICKUP;SCX-6555N,CB,T0.9,W19*L |
|
|
PAD-MP(PLUS);EPU,SCX-5315F,0.9T,W31*L11. |
| JC92-01913A | PBA SUB-CASSETTE;CLX-8380ND,SEC,SEC,CASS |
| JC92-01888A | PBA SUB-DEVE_CRUM_IF;CLX-8380ND,SEC,SEC, |
| JC92-01885A | PBA SUB-FINISHER IF;CLX-8380ND,SEC,SEC,F |
| JC92-01886A | PBA SUB-ITB_CRUM_IF;CLX-8380ND,SEC,SEC,I |
|
|
PBA SUB-KEY;CLX-8380,SEC,SEC,OPE_KEY,FR- |
| JC92-01928A | PBA SUB-KEY_SUB;CLX-8380,SEC,SEC,OPE_KEY |
| JC92-02005A | PBA SUB-MOTOR_SENSOR;CLX-8380,SEC,SEC,MO |
| JC92-01884A | PBA SUB-SCAN_IF;CLX-8380ND,SEC,SEC,SCAN_ |
| JC92-01887A | PBA SUB-TB_CRUM_IF;CLX-8380ND,SEC,SEC,TB |
| JC92-02009A | PBA-APS_IF;SCX-6555N,SEC,EXPORT,-,-,-,30 |
| JC92-01942A | PBA-DADF;SCX-6555N,SEC,EXPORT,-,-,-,135X |
| JC92-02195A | PBA-ENGINE;CLX-8385ND,SEC,ENGINE,FR-4,4L |
| JC92-01959A | PBA-ERASER;CLX-8380ND,SEC,SEC,ERASER,-,- |
| JC92-02192A | PBA-MAIN;CLX-8385ND,SEC,VIDEO,FR-4,6L |
| JC92-02045H | PBA-OPE;CLX-8385ND,SEC,OPE |
| JC92-02196A | PBA-RAM DIMM;CLX-8385ND,SEC,DDR2 DIMM X1 |
| 0603-001021 | PHOTO TR;NPN,20V,5V,20MA,75MW,TP |
| 0604-001370 | PHOTO-INTERRUPTER;CIRCUIT,BULK |
| 0604-001230 | PHOTO-INTERRUPTER;OPIC,BK |
|
|
PHOTO-INTERRUPTER;TR,75MW,BGA,TR |
|
|
PHOTO-INTERRUPTER;TR,90%,150MW,DIP-4,BK |
| 6043-001115 | PIN-PARALLEL(KEY);A,OD2.0,L14.0,ZPC(YEL) |
| JC61-01322A | PLATE-P-LEVER;SCX-6345N/XRX,SECC,T1.6,40 |
| JC72-01248A | PMO-ACTUATOR DOC;SCX-6320F,ABS+GF10%,HB, |
|
|
PMO-ACTUATOR LENGTH;SCX-6322DN,ABS+GF10% |
| JB72-00821A | PMO-ADF COLAR;SCX-1110F,POM,NTR |
| JC72-41191A | PMO-BEARING SHAFT;ML-6000,POM,WHT,M90-44 |
| JC72-41050A | PMO-BUSHING AGITATOR;ML-7000,POM(M90-44) |
| JC72-01215A | PMO-COVER DEV SPRING CAP;CLP-500,POM,WHI |
| JF72-41354A | PMO-GEAR PINION;CF4500,POM,NTR+WHT(DELRI |
| JC72-00444A | PMO-HOLDER COLLIMATOR;ML-1710,PC,TRANSPA |
| JC72-00755A | PMO-LEVER SENSOR;SCX-5100,POM,HB,BLK |
| JB72-00845A | PMO-PICK UP CLUTCH SUB;SCX-1110F,POM(DE8 |
| JB72-00763A | PMO-PULLEY;SCX-1110/XRX,POM,WHT |
| JC72-00744A | PMO-SHAFT PICK UP;SCX-5150,ABS,BLK,HB |
| JB72-00822A | PMO-SLEEVE ADF;SCX-1110F,POM,BLK |
| JB72-00823A | PMO-SLEEVE PICK UP;SCX-1110F,POM,BLK |
| JC72-00766A | PMO-TIE STOPPER;SCX-5100,NYLON66,NTR |
| JC66-00971A | PULLEY-M_DUPLEX;SCX-6345N/XRX,POM,HB,BLA |
| 2007-008433 | R-CHIP;0.33OHM,1%,1W,TP,6432 |
| 2007-000033 | R-CHIP;0OHM,5%,1/4W,TP,3216 |
| 2007-000029 | R-CHIP;0OHM,5%,1/8W,TP,2012 |
| 2007-000122 | R-CHIP;1.2KOHM,5%,1/10W,TP,1608 |
| 2007-000239 | R-CHIP;1.5KOHM,1%,1/10W,TP,1608 |
| 2007-000123 | R-CHIP;1.5KOHM,5%,1/10W,TP,1608 |
| 2007-000079 | R-CHIP;1.8KOHM,5%,1/10W,TP,1608 |
| 2007-000102 | R-CHIP;100KOHM,5%,1/10W,TP,1608 |
| 2007-000287 | R-CHIP;100OHM,1%,1/10W,TP,1608 |
| 2007-000074 | R-CHIP;100OHM,5%,1/10W,TP,1608 |
| 2007-000293 | R-CHIP;100OHM,5%,1/4W,TP,3216 |
| 2007-000052 | R-CHIP;10KOHM,1%,1/10W,TP,1608 |
| 2007-000090 | R-CHIP;10KOHM,5%,1/10W,TP,1608 |
| 2007-000305 | R-CHIP;10MOHM,5%,1/10W,TP,1608 |
| 2007-000309 | R-CHIP;10OHM,5%,1/10W,TP,1608 |
| 2007-008426 | R-CHIP;12.4KOHM,1%,1/10W,TP,1608 |
| 2007-000116 | R-CHIP;120OHM,5%,1/10W,TP,1608 |
| 2007-000091 | R-CHIP;12KOHM,5%,1/10W,TP,1608 |
| 2007-007521 | R-CHIP;14.7KOHM,1%,1/10W,TP,1608 |
| 2007-008567 | R-CHIP;15.4KOHM,1%,1/10W,TP,1608 |
| 2007-000104 | R-CHIP;150KOHM,5%,1/10W,TP,1608 |
| 2007-000402 | R-CHIP;150OHM,5%,1/10W,TP,1608 |
| 2007-000403 | R-CHIP;150OHM,5%,1/4W,TP,3216 |
| 2007-000067 | R-CHIP;15KOHM,1%,1/10W,TP,1608 |
| 2007-000092 | R-CHIP;15KOHM,5%,1/10W,TP,1608 |
| 2007-007937 | R-CHIP;17.4KOHM,1%,1/10W,TP,1608 |
| 2007-008505 | R-CHIP;17.8KOHM,1%,1/10W,TP,1608 |
| 2007-008105 | R-CHIP;18.2OHM,1%,1/10W,TP,1608 |
| 2007-000078 | R-CHIP;1KOHM,5%,1/10W,TP,1608 |
| 2007-000475 | R-CHIP;1MOHM,1%,1/10W,TP,1608 |
| 2007-002425 | R-CHIP;1OHM,5%,1/10W,TP,1608 |
| 2007-000124 | R-CHIP;2.2KOHM,5%,1/10W,TP,1608 |
| 2007-000105 | R-CHIP;200KOHM,5%,1/10W,TP,1608 |
| 2007-000093 | R-CHIP;20KOHM,5%,1/10W,TP,1608 |
| 2007-000075 | R-CHIP;220OHM,5%,1/10W,TP,1608 |
| 2007-000094 | R-CHIP;22KOHM,5%,1/10W,TP,1608 |
| 2007-000071 | R-CHIP;22OHM,5%,1/10W,TP,1608 |
| 2007-000616 | R-CHIP;24KOHM,5%,1/10W,TP,1608 |
| 2007-000129 | R-CHIP;27KOHM,5%,1/10W,TP,1608 |
|
|
R-CHIP;2KOHM,5%,1/10W,TP,1608 |
| 2007-007550 | R-CHIP;3.16KOHM,1%,1/10W,TP,1608 |
| 2007-000082 | R-CHIP;3.3KOHM,5%,1/10W,TP,1608 |
| 2007-007525 | R-CHIP;3.4KOHM,1%,1/10W,TP,1608 |
| 2007-000704 | R-CHIP;3.6KOHM,5%,1/10W,TP,1608 |
| 2007-000125 | R-CHIP;3.9KOHM,5%,1/10W,TP,1608 |
| 2007-002910 | R-CHIP;30.1KOHM,1%,1/10W,TP,1608 |
| 2007-000729 | R-CHIP;300OHM,5%,1/10W,TP,1608 |
| 2007-007008 | R-CHIP;300OHM,5%,1/16W,TP,1005 |
| 2007-000096 | R-CHIP;30KOHM,5%,1/10W,TP,1608 |
| 2007-000133 | R-CHIP;330KOHM,5%,1/10W,TP,1608 |
| 2007-000113 | R-CHIP;33OHM,5%,1/10W,TP,1608 |
| 2007-000783 | R-CHIP;33OHM,5%,1/4W,TP,3216 |
| 2007-000118 | R-CHIP;390OHM,5%,1/10W,TP,1608 |
| 2007-000083 | R-CHIP;3KOHM,5%,1/10W,TP,1608 |
| 2007-002987 | R-CHIP;4.75KOHM,1%,1/10W,TP,1608 |
| 2007-000084 | R-CHIP;4.7KOHM,5%,1/10W,TP,1608 |
| 2007-000875 | R-CHIP;4.7KOHM,5%,1/4W,TP,3216 |
| 2007-000882 | R-CHIP;4.7OHM,5%,1/10W,TP,1608 |
| 2007-009777 | R-CHIP;4.99KOHM,1%,1/16W,TP,1005 |
| 2007-009363 | R-CHIP;40.2KOHM,1%,1/16W,TP,1005 |
| 2007-000107 | R-CHIP;470KOHM,5%,1/10W,TP,1608 |
| 2007-000077 | R-CHIP;470OHM,5%,1/10W,TP,1608 |
| 2007-002916 | R-CHIP;475KOHM,1%,1/10W,TP,1608 |
| 2007-008293 | R-CHIP;475OHM,1%,1/16W,TP,1005 |
| 2007-000939 | R-CHIP;47KOHM,1%,1/10W,TP,1608 |
| 2007-000097 | R-CHIP;47KOHM,5%,1/10W,TP,1608 |
| 2007-000072 | R-CHIP;47OHM,5%,1/10W,TP,1608 |
| 2007-007226 | R-CHIP;49.9OHM,1%,1/10W,TP,1608 |
| 2007-008298 | R-CHIP;49.9OHM,1%,1/16W,TP,1005 |
| 2007-000965 | R-CHIP;5.1KOHM,5%,1/10W,TP,1608 |
| 2007-000144 | R-CHIP;5.1KOHM,5%,1/16W,TP,1005 |
| 2007-000086 | R-CHIP;5.6KOHM,5%,1/10W,TP,1608 |
| 2007-008133 | R-CHIP;56.2KOHM,1%,1/10W,TP,1608 |
| 2007-000119 | R-CHIP;560OHM,5%,1/10W,TP,1608 |
| 2007-000098 | R-CHIP;56KOHM,5%,1/10W,TP,1608 |
| 2007-008473 | R-CHIP;59KOHM,1%,1/10W,TP,1608 |
| 2007-007222 | R-CHIP;6.04KOHM,1%,1/10W,TP,1608 |
| 2007-008112 | R-CHIP;68.1OHM,1%,1/10W,TP,1608 |
| 2007-000120 | R-CHIP;680OHM,5%,1/10W,TP,1608 |
| 2007-001134 | R-CHIP;68OHM,5%,1/10W,TP,1608 |
| 2007-001139 | R-CHIP;7.5KOHM,1%,1/10W,TP,1608 |
| 2007-007238 | R-CHIP;8.25KOHM,1%,1/10W,TP,1608 |
| 2007-001179 | R-CHIP;8.2KOHM,5%,1/10W,TP,1608 |
| 2007-000121 | R-CHIP;820OHM,5%,1/10W,TP,1608 |
| 2008-000166 | R-FUSIBLE;56OHM,5%,1/4W,AA,TP,2.6X6.7MM |
| 2011-001011 | R-NETWORK;10KOHM,5%,1/16W,L,CHIP,8P,TP,3 |
| 2011-001264 | R-NETWORK;10OHM,5%,1/16W,L,CHIP,8P,TP,2. |
| 2011-001482 | R-NETWORK;1KOHM,5%,1/16W,L,CHIP-V,8P,TP, |
| 2011-001262 | R-NETWORK;22OHM,5%,1/16W,L,CHIP,8P,TP,2. |
| 2011-001261 | R-NETWORK;33OHM,5%,1/16W,L,CHIP,8P,TP,2. |
| 2011-001396 | R-NETWORK;4.7KOHM,5%,1/16W,L,CHIP,8P,TP, |
| 2011-001474 | R-NETWORK;47OHM,5%,1/16W,L,CHIP,8P,TP,2. |
| 2011-001346 | R-NETWORK;68OHM,5%,1/16W,L,CHIP,8P,TP,2. |
| 3501-001312 | RELAY-POWER;5V,540MW,10000MA,1FORMA,15MS |
| 3501-001053 | RELAY-POWER;5VDC,530MW,10000MA,1FORMA,15 |
| 6044-000159 | RING-C;ID3,OD7,T0.6,PASS,STSC |
| 6044-000121 | RING-E;ID2,OD5,T0.4,PASS,STSC |
| 6044-000125 | RING-E;ID4,OD9,T0.6,STSC |
| 6044-000231 | RING-E;ID5.0,OD11.0,T0.6,PASS,STS304 |
| 6044-000129 | RING-E;ID6,OD12,T0.8,ZPC,STSC |
| 6041-000210 | RIVET-FH;D3.2,L8,ANODIZING,AL |
|
|
RMO-ADF RUBBER;SCX-1110F,SILICON RUBBER, |
| JC73-40902A | RMO-SEAL AGITATOR;ML-7000,SANTOPRENE,NTR |
| JC66-00970A | ROLLER-DUPLEX READY;SCX-6345N/XRX,SUM22+ |
| JC66-01508A | ROLLER-DUPLEX;CLX-8380ND/XAA,SUM22(NI PL |
| JC66-01507A | ROLLER-FEED DUPLEX;CLX-8380ND/XAA,SUM22( |
| JC66-01410B | ROLLER-FUSER;CLX-8380ND/XAA,SI-RUBBER,?2 |
| JC66-01411A | ROLLER-HEAT;CLP-660,STKM11A,?18,249 |
| JC66-00764A | ROLLER-IDLE FEED;CLP-600,POM,OD13.0,ID3. |
| JC66-01019A | ROLLER-M EXIT DP IDLE;SCX-6345N/XRX,POM, |
|
|
ROLLER-M IDLE JF;SCX-6345N/XRX,POM+PFPE, |
| JC66-01812A | ROLLER-MP FEED;CLX-8380ND/XAA,SUM22(NI P |
| JC66-01412A | ROLLER-PRESSURE;CLP-660,SI-RUBBER,?29,25 |
| JC66-02432A | ROLLER-REGI DRIVE;CLX-8385ND,SUM+EPDM,8, |
| JC66-01506A | ROLLER-REGI IDLE;CLX-8380ND/XAA,SUM 22L, |
| JC66-01505A | ROLLER-TRANSFER;CLX-8380ND/XAA,SUM22+ECO |
| JC72-20902A | ROLLER;ML-5000A,TEFLON,WHT |
|
|
RPR-PAD CASSETTE;ML-1510,URETHANE SPONGE |
| JC73-00079A | RPR-SEAL SIDE;SCX-5100,URETHANE FOAM,NTR |
| JC73-00266A | RUBBER-ADF ROLLER;SCX-6555N,EPDM+IR,OD25 |
| JC73-00215A | RUBBER-DAMPER HDD;SCX-6345N/XRX,EPDM,7.5 |
| JC73-00268A | RUBBER-FEED;SCX-6555N,EPDM,OD50,BLK,70C |
| JC73-00235A | RUBBER-GUIDE MP;SCX-6345N/XRX,NBB,38*28. |
| JC73-00267A | RUBBER-PICKUP ROLLER;SCX-6555N,EPDM+IR,O |
| JC73-00216A | RUBBER-ROLLER PU;SCX-6345N/XRX,EPDM+IR 3 |
| 6502-001132 | SADDLE;CS4N,11.6X8.8,NYLON66,BLACK |
| 6001-000130 | SCREW-MACHINE;BH,+,M3,L6,ZPC(WHT),SWRCH1 |
| 6006-001193 | SCREW-MACHINE;PH,+,WSP,M3,L10,ZPC(WHT),S |
| 6002-000440 | SCREW-TAPPING;PWH,+,2,M3,L8,ZPC(BLK),SWR |
|
|
SCREW-TAPTYPE;BH,+,-,B,M3,L12,ZPC(BLK),S |
| 6003-000261 | SCREW-TAPTYPE;BH,+,-,B,M3,L6,ZPC(WHT),SW |
|
|
SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW |
|
|
SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SW |
| 6003-001474 | SCREW-TAPTYPE;BH,+,B,M3,L30,ZPC(WHT),SWR |
|
|
SCREW-TAPTYPE;BH,+,B,M4,L16,NI PLT,SWRCH |
| 6003-000301 | SCREW-TAPTYPE;BH,+,S,M4,L6,ZPC(WHT),SWRC |
|
|
SCREW-TAPTYPE;FH,+,B,M3,L8,ZPC(BLK),SWRC |
| 6002-000308 | SCREW-TAPTYPE;PH,+,-,B,M2.6,L6,ZPC(WHT), |
| 6006-001078 | SCREW-TAPTYPE;PH,+,WSP,B,M3,L10,ZPC(WHT) |
| 6003-000264 | SCREW-TAPTYPE;PWH,+,-,B,M3,L6,ZPC(WHT),S |
| 6003-000266 | SCREW-TAPTYPE;PWH,+,-,S,M3,L6,ZPC(WHT),S |
| 6003-000267 | SCREW-TAPTYPE;PWH,+,-,S,M3,L8,ZPC(WHT),S |
| 6003-000196 | SCREW-TAPTYPE;PWH,+,B,M3,L10,NI PLT,SWRC |
| JC62-00492A | SEAL-COVER CCD;CLX-8380ND/XAA,URETHAN FO |
| JC62-00499A | SEAL-SCAN_LOWER;CLX-8380ND/XAA,URETHAN F |
| JC32-00012A | SENSOR-CTD;GP2Y40011K0F,0 ~ 60,4.5 ~ 5.5 |
| JC32-00006A | SENSOR-CTD;YA-HA16,CLP-660,0~60C,+5V5%, |
| JC32-00005A | SENSOR-HUMIDITY;CHS-CSC-20,CLP-660,0~50C |
| JC66-01460A | SHAFT-DEVE DRIVE;CLX-8380ND/XAA,SUM24L,F |
| JC66-02544A | SHAFT-FEED DRIVE_R;CLX-8385ND,SUM22,8 |
| JC70-40914A | SHAFT-ICT-PIN P/UP SHAFT;ML-5000A,SUM24L |
| JC66-02566A | SHAFT-IDLE ROLLER;SCX-6445N,SUM22,221,4 |
| JC66-01457A | SHAFT-ITB DRIVE;CLX-8380ND/XAA,SUM24L,F8 |
| JC66-02439A | SHAFT-OPC DRIVE;CLX-8385ND/XAA,SUM22,8 |
| JC66-01795A | SHAFT-OPC HINGE L;CLX-8380ND/XAA,SUM22,3 |
|
|
SHAFT-PLATE LEVER;SCX-6345N/XRX,SUM22 NI |
| JC66-02431A | SHAFT-REGI DRIVE;CLX-8385ND,SUM22,8 |
| JC66-00662A | SHAFT-REGI;SCX-6320F,SUM24L,47.5,PI 6.0 |
| JC66-00937A | SHAFT-RETARD S;SCX-6345N/XRX,SUM22 NI,22 |
| JC66-01461A | SHAFT-T1 ENGAGE DRIVE;CLX-8380ND/XAA,SUM |
| JC66-01458A | SHAFT-T2 ENGAGE DRIVE;CLX-8380ND/XAA,SUM |
| JC66-00939A | SHAFT;SCX-6345N/XRX,SUS303,L8,OD2,NTR |
| JC63-00074A | SHEET-DUMMY UPPER;SCX-5312F,PET SHEET,0. |
| JC01-00036A | SHEET-FILM LCD;SCX-5128F,PET,0.075T,TRAS |
| JC63-00186A | SHEET-GUIDE ADF;SCX-6320F,PET,0.125,37,2 |
| JC63-01852A | SHEET-GUIDE FILM;CLX-8380ND/XAA,PET,0.18 |
| JC63-01400A | SHEET-GUIDE PAPER FR;CLX-8380ND/XAA,PET, |
| JC63-01496A | SHEET-GUIDE REGI;CLX-8380ND/XAA,PET,0.12 |
|
|
SHEET-GUIDE RETARD;SCX-6345N/XRX,PET,0.1 |
| JC63-01876A | SHEET-SCAN_LOWER_L;CLX-8380ND/XAA,PC,T0. |
| JC63-01875A | SHEET-SCAN_LOWER_S;CLX-8380ND/XAA,PC,T0. |
| JC63-00810A | SHEET-WHITE BAR;SCX-6345N/XRX,PET,0.075, |
| JC72-00751A | SHEET;SCX-5100,SPONGE+SHEET,217.5*357.5, |
| JC63-01404A | SHIELD-SMPS_UPPER;CLX-8380ND/XAA,SECC,T0 |
| JC44-00149A | SMPS-V1;CLX-8330N,PSP-TYPE6-V1,SMPS,350W |
| JC33-00029A | SOLENOID-DUPLEX;CLX-8380ND/XAA,24V,45O,2 |
| JC33-00032A | SOLENOID-PICK UP;SCX-6555N,24V,80O,36.5* |
| 3001-002207 | SPEAKER;0.3W,8OHM,81DB,400HZ,50X16.4MM |
| JC72-01407A | SPONGE-FAN SUB;CLX-8380ND/XAA,POLYURETHA |
| JC72-01483A | SPONGE-OPEN LOWER;SCX-6555N/XAA,POLYURET |
| JC72-01484A | SPONGE-OPEN UPPER A;SCX-6555N/XAA,POLYUR |
| JC72-01485A | SPONGE-OPEN UPPER B;SCX-6555N/XAA,POLYUR |
| JC72-01542A | SPONGE-SIDE FAN;SCX-6255N,PORON,2.0T,10, |
| JC61-70959B | SPRING ETC--FEED;ML-5200A,SUS 304 WPB,F0 |
| JB61-70904A | SPRING ETC-CLUTCH;AMUNDSEN,SWRS82A,D11.4 |
| JC61-70928A | SPRING ETC-DEV_R;ML-7000,D0.6,5.6,L18.5, |
| JC61-02514A | SPRING ETC-DOCU;CLX-6240FX,SUS304,0.25,5 |
| JC61-01563A | SPRING ETC-DUP IDLE;SCX-6345N/XRX,SUS304 |
| JC61-70950A | SPRING ETC-EXTENSION;ML-5000A,SUS304WPB |
| JC61-70930A | SPRING ETC-HV SMALL;ML-5000A,PI0.3,L12.5 |
| JC61-02097A | SPRING ETC-ITB;CLX-8380ND/XAA,SWP-B,0.7, |
| JC61-00483A | SPRING ETC-KNOCKUP,MP;SCX-5100,SUS304-WP |
| JC61-00479A | SPRING ETC-LOCKER TORSION;SCX-5100,SUS30 |
| JC61-00387A | SPRING ETC-PAD;ML-9400W,SUS304WPB,PI0.5, |
|
|
SPRING ETC-PICKUP;SCX-5100,SUS304-WPB,PI |
| JC61-70910A | SPRING ETC-RAIL;ML-165,SUS304 WPB,D5.4,L |
| JB61-00074A | SPRING ETC-SCAN STOPPER (CC2-F);SCX-1110 |
| JC61-02098A | SPRING ETC-SLIDE;CLX-8380ND/XAA,SWP-B,0. |
| JC61-70915A | SPRING ETC-SOLENOID DP;ML-165,SUS304-WPB |
|
|
SPRING ETC-TORSION DOC (CC2-F);SCX-1110F |
| JC61-00486A | SPRING ETC-TORSION;SCX-5100,SUS304WPB,0. |
| JC61-70906A | SPRING ETC-TR_R;ML-165,SUS304WPB,PI0.5,O |
| JC61-00548A | SPRING ETC-WHITE BAR;SCX-5312F,SUS304WPB |
| 6107-000117 | SPRING-CS;PI0.7,D12.4,L29,DEGRE,STS304-W |
|
|
SPRING-CS;SUS304,PI0.5,D6.7,L17.5,ID6.2, |
| 6107-000014 | SPRING-CS;SUS304-WPB,PI0.55,D6.9,L14 |
| 6107-001342 | SPRING-CS;SUS304-WPB,PI1.0,D8.0,L23.4,ID |
| 6107-001219 | SPRING-CS;SWOSC-V,PI3.2,D12.4,L55.8,ID9. |
| 6107-001343 | SPRING-CS;SWP,3-ZINC PLATING(YELLOW),PI0 |
| 6107-001194 | SPRING-CS;SWP-B,BLK,PI0.9,D6.95,L20,ID6. |
| 6107-001337 | SPRING-CS;SWP-B,PI0.5,D5.9,L33,ID5.4,OD6 |
| 6107-001334 | SPRING-CS;SWP-B,PI0.55,D8.45,L16.25,ID7. |
| 6107-001344 | SPRING-CS;SWPB,PI0.8,D5.1,L90,ID4.3,OD5. |
|
|
SPRING-ES;SUS304-WPB,NTR,PI0.32,D3.88,L1 |
| 6107-001258 | SPRING-ES;SUS304-WPB,PI0.55,D4.25,L37.5, |
| 6107-001324 | SPRING-ES;SUS304-WPB,PI0.6,D4.1,L24.8,ID |
| 6107-001259 | SPRING-ES;SWP-B,PI0.35,D4.25,L33.8,ID3.9 |
| 6107-001155 | SPRING-ES;SWP-B,PI0.55,L25,OD4.4 |
| 6107-001399 | SPRING-ES;SWPB,PI0.45,D4.65,L20.5,ID4.2, |
| 6107-001340 | SPRING-TS;SUS304,PI0.7,ID15.1 |
| 6107-001375 | SPRING-TS;SUS304,PI0.8,D9.48,L12,ID8.68, |
| 6107-001326 | SPRING-TS;SUS304WPB,PI0.7,28.54,ID15.3 |
| 6107-001327 | SPRING-TS;SUS304WPB,PI0.8,D7.4,T0.8,ID6. |
| 6107-001540 | SPRING-TS;SWP B,PI0.5,D3.55,L12.93/6.5,W |
|
|
STOPPER-M-FAN80;ML-2150,ABS HB,26.4,BLAC |
| JC61-00832B | STOPPER-M_KNOCK UP;CLP-510,HIPS HB,24,VI |
| JC61-02673A | SUPPORT-ACTUATOR;CLX-8380ND/XAA,TEFLON[P |
| JC61-02096A | SUPPORT-LEVER FRONT;CLX-8380ND/XAA,POM,T |
| 3404-000165 | SWITCH-TACT;12V,50MA,160GF,6X6X5,SPST |
| 3404-001222 | SWITCH-TACT;12VDC,50MA,160GF,6X6X5.0MM,S |
| 0203-000007 | TAPE-FILAMENT;T0.15,L55M,TRP,FILAMENT |
| 0203-001100 | TAPE-OPP MASKING;OPP/W75/CLR,T0.075,W75, |
| JC65-00028A | TERMINAL-HV DEVE A;CLX-8380ND/XAA,SUS304 |
| JC65-00029A | TERMINAL-HV TR;CLX-8380ND/XAA,SUS304WPB, |
| JC65-00012A | TERMINAL-S_IDLE;SCX-6345N/XRX,SUS304WPB, |
|
|
THERMISTOR-NTC ASSY;10KOHM,3435K,3MW/C |
| 1404-001065 | THERMISTOR-PTC;0.11OHM,13.2VAC,40A,1.5A, |
| 0506-001069 | TR-ARRAY;MBT3904DW1T1,NPN,DUAL,150MW,SOT |
| 0502-001258 | TR-POWER;FJT44,NPN,SOT-223,TP,40-200 |
| 0502-000245 | TR-POWER;KSB1151-Y,PNP,1300MW,TO-126,160 |
| 0502-001048 | TR-POWER;KSD1691,NPN,1.3W,TO-126,BK,160 |
| 0504-000144 | TR-SMALL SIGNAL;2SC1008,NPN,800MW,TO-92, |
| 0501-000342 | TR-SMALL SIGNAL;KSC1623-Y,NPN,200MW,SOT- |
| 0501-000457 | TR-SMALL SIGNAL;MMBT2222A/KST2222A,NPN,3 |
| 0501-000462 | TR-SMALL SIGNAL;MMBT2907A,PNP,350MW,SOT- |
| JC63-00447E | TRAY-M-ASF_FOLDER;ML-3051ND,HIPS,2.5,235 |
| 6031-001255 | WASHER-PLAIN;NYLON,CUTTING,ID5,OD9,T0.5, |
| 6031-000023 | WASHER-PLAIN;POLY,ID5.9,OD10.0,T0.5,BLK |
| 6031-000019 | WASHER-PLAIN;POLY,ID6.1,OD8.5,T0.1,BLK |
| 6031-001584 | WASHER-PLAIN;POLYSLIDER,ID4,OD7,T0.5,BLA |
