Manufacturer
Samsung
Model Number
DW90F89T0USRAA
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| DD98-01134D | |
| DD98-01021B | |
| DD97-00881A | |
| DD97-00880A | |
| DD97-00489Q | |
| DD69-00147C | |
| DD66-00146B | |
| DD61-00877A | |
| DD61-00876A | |
| DD61-00742J | |
| DD63-00336B | ABSORBER SPONGE , DW9900M,PE FOAM,T5,WHITE |
| DD63-00319A | ABSORBER-FRAME |
| DD63-00320B | ABSORBER-FRAME , DW9900R,FELT,T15,LIGHT WA |
| 0201-001982 | ADHESIVE-SIL;TSE3854DS-W,WHITE,2.2,MIL-A |
|
|
ASSEMBLY CASE BRAKE;DW9900R,COMMON |
| DD98-01020A | ASSEMBLY CORNER(F/R) , DW9900H,COMMON |
| DD97-00750A | ASSEMBLY COVER BASE;DW5000C |
| DD97-00256C | ASSEMBLY COVER DOOR SWITCH;DW8700B |
| DD97-00653A | ASSEMBLY COVER DRY |
| DD98-01021A | ASSEMBLY CUSHION TOP , DW9900H,COMMON |
| DD97-00764A | ASSEMBLY DOOR INNER;DW5000C,INNER DOOR+SHEET |
| DD97-00489K | ASSEMBLY DOOR-OUTER |
| DD93-01022A | ASSEMBLY DUCT DRY-HEATER |
| DD93-01023A | ASSEMBLY DUCT DRY-THERMOSTAT |
| DD97-00499C | ASSEMBLY FRAME FRONT;DW9900R,COMMO |
| DD97-00627F | ASSEMBLY GUIDE WATER-MODULE;DW8700B,COMMON |
| DC94-02705A | ASSEMBLY HEAT SINK 2 , SEINE,230V/50HZ,SEINE,2 |
| DD97-00662A | ASSEMBLY HOSE DRAIN;DW8700B |
|
|
ASSEMBLY HOSE DRAIN;DW9900R,PP+TPE |
| DD97-00236A | ASSEMBLY HOUSING UPPER , DW9900H,COMMON |
| DD96-00057B | ASSEMBLY LAMP LED;FR-4,WHITE,45MA, 47OHM,DC5 |
| DD93-01025B | ASSEMBLY MOTOR BLDC;DW8700B-PJ |
| DD97-00509B | ASSEMBLY ROTOR UPPER , DW7000B,COMMON |
| 6902-001827 | BAG PE , LDPE,T0.05,W120,L140,TRP,NONE,0 |
| 6902-003459 | BAG PE;HDPE,MAKER : G WORLD,T0.015,W250, |
| 6902-000336 | BAG ZIPPER |
| 6922-000009 | BAND PP |
| 3301-002113 | BEAD-SMD;470 OHM/100MHZ 470 OHM/100MHZ,2 |
|
|
BOLT-HEX |
|
|
BRACKET 3RD-RAIL;DW9900R,STS304,T0.8,POL |
| DD61-00626A | BRACKET DOOR , DW9000M,PP,BLACK,RECYCLE |
| DD61-00424A | BRACKET DUCT-MIDDLE , DW9900H,STS304,T0.4, |
| DD61-00305B | BRACKET DUCT-UP , DW9900H,STS304,T0.6 |
|
|
BRACKET HOSE |
|
|
BRACKET INSTALL |
|
|
BRACKET RAIL |
|
|
BRACKET RAIL-LEFT;DW9900R,DW8000R,STS304 |
|
|
BRACKET RAIL-RIGHT;DW9900R,DW8000R,STS30 |
| DD61-00593B | BUSH |
| 2402-001145 | C-AL, SMD |
| 2402-001268 | C-AL, SMD |
| 2402-001303 | C-AL, SMD |
| 2401-004519 | C-AL;2200UF,20%,25V,TP,12.5X25MM,5MM,-40 |
| 2401-006198 | C-AL;470UF,20%,250V,WT,BK,25.4X30MM,10MM |
| 2203-002285 | C-CER, CHIP |
| 2203-005642 | C-CER, CHIP |
| 2203-007456 | C-CER, CHIP |
| 2203-007544 | C-CER, CHIP |
| 2203-008315 | C-CER, CHIP |
| 2203-010142 | C-CER,CHIP |
| 2203-010033 | C-CER,CHIP;220NF,10%,25V,X5R,TP,1005,T0. |
| 2201-000332 | C-CERAMIC, DISC |
| 2201-000915 | C-CERAMIC, DISC |
| 2201-002689 | C-CERAMIC,DISC;10NF,+80-20%,250VAC,Y5V,T |
| 2201-002690 | C-CERAMIC,DISC;2.2NF,20%,400VAC,Y5U,TP,1 |
| 2301-001899 | C-FILM, LEAD |
| 2301-002011 | C-FILM,LEAD-PPF;2.2NF,5%,630V,TP,13X11X6 |
| DD61-00541B | CAP , DW7000B,POM,HB,F20-03,CLEAR GRAY, |
|
|
CAP DOOR GUIDE |
|
|
CAP OUTLET DRY |
| DD67-00208A | CAP-HEATFAN INNER , DW7000B,PP+GLF15%, |
| DD67-00207A | CAP-HEATFAN OUTER |
| DD61-00281A | CASE GEAR |
| DD61-00516A | CASE SWITCH DOOR , DW9000H,PP,NATURAL,P700 |
| DC02-10009A | CHEMICALS-LOCK SCREW |
|
|
CLAMPER HOSE |
| DD65-00001N | CLAMPER HOSE |
| 0204-009273 | COATING AGENT;DS8802FL,50~60%,300CPS,TRA |
| 3711-000260 | CONNECTOR-HEADER |
| 3711-000262 | CONNECTOR-HEADER |
| 3711-000744 | CONNECTOR-HEADER |
|
|
COVER ASSEMBLY PLINTH |
| DD63-00375A | COVER CIRCULATION PUMP;DW8700B,PP+TD30%, |
| DD63-00271A | COVER DOOR SWITCH , DW9000H,PP,NATURAL,P70 |
| DD63-00376A | COVER DRAIN PUMP;DW8700B,PP+TD30%,-,-,CL |
| DC63-01432C | COVER FILTER |
| DD63-00385B | COVER FILTER-BOTTOM;DW8700B,PP+TD30%,-,- |
| DD63-00388A | COVER FILTER;DW8700B,PP+TD30%,-,-,CLEAR |
| DD63-00215B | COVER FRONT;STS304,T0.4 |
| DD63-00373A | COVER NOZZLE , DW7000B,PP+TD30%,CLEAR |
|
|
COVER PLINTH |
|
|
COVER POWER-LOW |
|
|
COVER POWER-UP |
|
|
COVER TUB EDGE (LEFT) |
|
|
COVER TUB EDGE (RIGHT) |
|
|
COVER WIRE |
| DD63-00326B | COVER WIRE |
| DD63-00372A | COVER-FAN , DW7000B,PP+TD30%,CLEAR GRA |
| DD63-00371A | COVER-ROTOR LOW UP , DW7000B,STS304,T0.4, |
| DD63-00151A | COVER-WIRE HARNESS DOOR |
| DD69-00052B | CUSHION BASKET , DW9000H,EPS,W32,L50,H100, |
| DD69-00051A | CUSHION BASKET , GALA-E,COMMON,EPS,W50,H65 |
| DD69-00067A | CUSHION CORNER-FRONT , DW9900H,EPS,W344,L9 |
| DD69-00068A | CUSHION CORNER-REAR , DW9900H,EPS,W210,L97 |
| DD63-00221B | CUSHION DUCT (LEFT) |
| DD69-00066A | CUSHION-TOP , DW9900H,EPS,W657,L740,H104, |
| DD66-00198A | DAMPER RUBBER |
| 0402-001224 | DIODE-BRIDGE |
| 0402-001192 | DIODE-RECTIFIER |
| 0402-001472 | DIODE-RECTIFIER |
|
|
DIODE-RECTIFIER |
| 0402-001741 | DIODE-RECTIFIER;S1M,1000V,1A,SMA,TP |
| 0404-001250 | DIODE-SCHOTTKY |
| 0404-001991 | DIODE-SCHOTTKY;MBR20200CD,200V,20000MA,T |
| 0401-000132 | DIODE-SWITCHING |
| 0401-001099 | DIODE-SWITCHING |
| 0406-001239 | DIODE-TVS |
| 0406-001865 | DIODE-TVS;SMBJ17CA,18.9V,20.9V,5MAV,100A |
| 0403-000461 | DIODE-ZENER |
| 0403-001164 | DIODE-ZENER |
| DD59-01005B | DISPENSER;DW8700B,DACOR,US,PP,EPDM,DC12V |
| DD64-00225B | DOOR OUTER |
| DD67-00209A | DUCT DRY-LOW |
| DD67-00210A | DUCT DRY-UP |
| DD67-00224A | DUCT POWER-LOW;PP+TD30%,-,-,PTN960,CLEAR |
| DD67-00225A | DUCT POWER-UP;PP+TD30%,-,-,PTN960,CLEAR |
| DD60-00007A | ELBOW HOSE;TPE,RH40 |
| 0505-000110 | FET-SILICON |
| 0505-001943 | FET-SILICON;FDN342P,P,20V,2A,0.08OHM,0.5 |
| DD01-01023A | FILM-PET , PET,T0.2,W150,L180,NATURAL,N |
| DD01-01002A | FILM-PROTECTION , GALA-E,COMMON,PET,T0.05, |
| DD63-00384A | FILTER COARSE;DW8700B,PP+TD30%,-,CLEAR G |
| DD29-00009A | FILTER EMI |
| DD63-00387A | FILTER FINE;DW8700B,STS304,T0.4,-,-,-,-, |
| DD63-00383A | FILTER MICRO;DW8700B,PP+TD30%,-,CLEAR GR |
| DD61-00775A | FIXER RUBBER-LOW LEFT;DW8700B,EPDM,BLA |
| DD61-00776A | FIXER RUBBER-LOW RIGHT;DW8700B,EPDM,BL |
| DD61-00777A | FIXER RUBBER-UP LEFT;DW8700B,EPDM,LIGH |
| DD61-00778A | FIXER RUBBER-UP RIGHT;DW8700B,EPDM,LIG |
| 0204-004665 | FLUX;KSP-70M-S,MIXTURE,NO,FLUX,13% |
|
|
FOOT BUILT IN |
|
|
FOOT FREE STANDING |
| DD61-00578A | FRAME FRONT , DW9900M,GI-SGCC,T0.5 |
| 3601-001731 | FUSE-AXIAL LEAD |
| 3601-001927 | FUSE-AXIAL LEAD;250V,2A,TIME-LAG,CERAMIC |
|
|
GASKET-BRAKE |
|
|
GEAR HELICAL |
|
|
GEAR WORM |
| 0205-001197 | GREASE-SILICON , TSK550,WHT TRANSLUCENT |
| DD61-00671A | GUIDE CUFF D;DW9900R,POM,F20-03,BLACK |
| DD61-00682A | GUIDE FRAME FRONT |
|
|
GUIDE HINGE |
| DD64-00188A | HANDLE PIN |
| 3711-000833 | HEADER-BOARD TO CABLE |
| 3711-000999 | HEADER-BOARD TO CABLE |
| 3711-001084 | HEADER-BOARD TO CABLE |
| 3711-003844 | HEADER-BOARD TO CABLE |
| 3711-004236 | HEADER-BOARD TO CABLE |
| 3711-005221 | HEADER-BOARD TO CABLE |
| 3711-009393 | HEADER-BOARD TO CABLE;BOX,24P,2R,2.0MM,S |
| 3711-009395 | HEADER-BOARD TO CABLE;BOX,28P,2R,2.0MM,S |
| DC62-00243A | HEAT SINK |
| DD47-00013A | HEATER |
| DD61-00618B | HOLDER , DW7000B,POM,CLEAR GRAY,HB,F20 |
| DD61-00185A | HOLDER BOLT |
| DD61-00820A | HOLDER DUCT-MIDDLE;DW8700B,PP+TD20%,CL |
| DD61-00592B | HOLDER DUCT-UP |
| DD61-00518B | HOLDER HOSE |
| DD61-00598A | HOLDER HOSE-OUTLET |
|
|
HOLDER RAIL |
| DD61-00742E | HOLDER ROPE DOOR;DW5000C,POM,T2.5,VITALI |
| DD61-00656A | HOLDER ROTOR |
| DD61-00693A | HOLDER ROTOR , DW7000B,POM,T1.5,NATURAL,F2 |
| DD61-00591B | HOLDER ROTOR-UP |
| DD61-00449A | HOLDER SEAL DOOR , DW9900H,PP,BLACK,EP649N |
| DD61-00698A | HOLDER SENSOR , DW7000B,STS304,T0.4, |
| DD61-00472B | HOLDER TINE-LOW;DW8700B,POM,CLEAR GRAY |
| DD61-00681B | HOLDER TINE-UP |
| DD61-00621B | HOLDER-TUB LIGHT;DW8700B,PP+GLF15%,NAT |
| DD67-00123A | HOSE DRAIN OUT , TPE,W/T70 |
| DD67-00212A | HOSE PUMP |
| DD67-00168A | HOSE PUMP , DW9900M,PP,ID21,HS90,LIGHT WAR |
| DD67-00214A | HOSE PUMP-OUT;DW8700B,EPDM,ID29.6,T2.5,H |
| DD67-00217A | HOSE WATER;DW8700B,EPDM,ID10.7,T3.1,HS65 |
| DD61-00669A | HOUSING-LEFT , DW8000R,GI-SGCC,T0.35 |
| 1202-001090 | IC VOLTAGE COMP. |
| 1203-009429 | IC-DC/DC CONVERTER;SYU812C1,SOT23-6,6P,3 |
| 1103-001564 | IC-EEPROM |
| 0903-002197 | IC-MICROCONTROLLER;HART-I910Z,LQFP,64P,1 |
| 1201-000166 | IC-OP AMP |
| 1203-006759 | IC-POSI.ADJUST REG. |
| 1203-002722 | IC-POSI.FIXED REG. |
| 1203-002835 | IC-POSI.FIXED REG. |
| 1203-009428 | IC-PWM CONTROLLER;ICE5QR1680BG,DSO-12,12 |
| 1203-006245 | IC-VOL. DETECTOR |
| 1203-004967 | IC-VOL. DETECTOR;KIA7042AT,TSM,3P,2.9X1. |
| DD66-00180A | IMPELLER SENSOR FLOW |
| 2703-004724 | INDUCTOR-SMD |
| DC68-02060A | LABEL BAR CODE |
| DD68-00150K | LABEL INSTRUCTION , DW9900H,PET,W60,L50 |
| DD68-00216A | LABEL INSTRUCTION , DW9900RM,DW8000R, DW99 |
| 6812-000145 | LABEL INTEGRATION QR;PET,LAMINATE COATED |
| DD68-00098C | LABEL RATING , DW9900H,PET,W160,L20,WHITE |
| DD68-00020A | LABEL WARNING , DW9900H,ART,W220,L28,FRAME |
| DD68-00019A | LABEL WARNING , DW9900R,ART,W60,L85,LAMINA |
| DC68-02173A | LABEL-PACKING |
| DC07-00149A | LCD;57.09X30.1MM,20TO+70C,3.3V,30TO+80 |
| 0601-002679 | LED;SMD(TOP VIEW),Y-GRN,WATER CLEAR,1.2X |
| DD66-00148A | LEVER ARM , DW9000H,POM,F20-03,NATURAL |
|
|
LEVER DOOR |
| DD66-00147A | LEVER LINK(C) , DW9000H,POM,F20-03,NATURAL |
| DD61-00597A | MAGNET |
| DD68-00206C | MANUAL INSTALL , DW8000R,US,EN+MES+CFR,MOJ |
|
|
MOTOR AC DRIVE |
| DD31-00024C | MOTOR BLDC FAN |
| DD31-00016B | MOTOR BLDC PUMP;BD15-3C,2800-3 |
| DC60-50153A | NUT HEX |
| 6021-000258 | NUT-HEXAGON |
| 0205-001027 | OIL-SILICON |
| DD69-00072B | PACKING ANGLE , DW9900H,PAPER,44,44,725,SE |
| DD69-00072A | PACKING ANGLE , DW9900H,PAPER,57,57,635,SE |
| DD69-00073A | PACKING CASE TOP , DW9900,CB,SW2,L743,W65 |
| DD69-00136A | PACKING SHEET , BUILT-IN,PP,T0.15,W100,L66 |
| DD69-00128A | PAD BOTTOM , DW9900M,PP,T0.15,W700,L740, |
| DD69-00075A | PAD PACKING , DW9900H,PAPER,T5.0,W40,L80, |
| 0604-001405 | PHOTO-COUPLER;TR,200-400%,200MW,SOP,TP |
| DD62-00169A | PIPE PUMP , DW9900R,POM,NATURAL,NATURAL,F2 |
| DD61-00796A | PLATE BASE;DW5000C,PP,-,BLACK,-,-,RM60 |
| 1003-002536 | POWER MODULE , 600V,4A,DIP,IGCM04G60HA,24, |
| 2007-000033 | R-CHIP |
| 2007-000279 | R-CHIP |
| 2007-000312 | R-CHIP |
| 2007-000394 | R-CHIP |
| 2007-000451 | R-CHIP |
| 2007-000476 | R-CHIP |
| 2007-000490 | R-CHIP |
| 2007-000496 | R-CHIP |
| 2007-000537 | R-CHIP |
| 2007-000571 | R-CHIP |
| 2007-000668 | R-CHIP |
| 2007-000718 | R-CHIP |
| 2007-000930 | R-CHIP |
| 2007-001162 | R-CHIP |
| 2007-001297 | R-CHIP |
| 2007-001654 | R-CHIP |
| 2007-007306 | R-CHIP |
| 2007-007321 | R-CHIP |
| 2007-007942 | R-CHIP |
| 2007-008304 | R-CHIP |
| 2007-008779 | R-CHIP |
| 2007-008791 | R-CHIP |
| 2007-012404 | R-CHIP , 0.2OHM,1%,2W,TP,6432,T0.7 |
| 2007-010245 | R-CHIP;0.01OHM,1%,2W,TP,6432 |
| 2007-007386 | R-CHIP;2OHM,1%,1/4W,TP,3216 |
| 2007-000764 | R-CHIP;330OHM,1%,1/4W,TP,3216 |
| 2007-012278 | R-CHIP;3MOHM,1%,1/4W,TP,3216,T0.55 |
| 3501-001306 | RELAY-MINIATURE;12VDC,3000MA,1FORMA,10MS |
|
|
RELAY-POWER |
|
|
RELAY-POWER |
| 3501-001291 | RELAY-POWER , 12V,0.4W,5000MA,1FORMC,10MS, |
| 0103-008912 | RESIN EPS;S-450/NTR,NATURAL,NC0001,N |
| 0103-001533 | RESIN PP;BJ500,NATURAL,NC0001 |
| 2802-001211 | RESONATOR-CERAMIC |
| 6041-001066 | RIVET , -,STS304,O3.2,L8, |
| DD66-00020A | ROLLER HINGE |
| DD66-00078A | ROLLER-3RD TUB |
| DD66-00203B | ROLLER-RAIL UP , DW7000B,POM,OD12.6,CLEAR |
| DD66-00185B | ROTOR-UP LOW , DW7000B,PP+TD30%,TB53,CLEAR |
| DD66-00186B | ROTOR-UP UP , DW7000B,PP+TD30%,TB53,CLEAR |
| DD67-00189B | RUBBER SKIRT;DW9900R,DW8000R,DW9900M,EPD |
| 6002-001435 | SCREW TAPPING |
| 6001-000516 | SCREW-MACHINE |
| 6001-002698 | SCREW-MACHINE , FH,TORX,M5,L16,PASS,STS304 |
|
|
SCREW-SPECIAL |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
| 6002-000413 | SCREW-TAPPING |
| 6002-000536 | SCREW-TAPPING |
|
|
SCREW-TAPPING |
| 6002-001018 | SCREW-TAPPING |
|
|
SCREW-TAPPING |
| 6002-001257 | SCREW-TAPPING;SWRCH18A,ZPC(WHT),L30,M4,P |
| DD62-00170A | SEAL DUCT DRY |
| DD62-00193A | SEAL HOLDER DUCT-MIDDLE;DW8700B_US,EPDM, |
|
|
SEAL SOIL SENSOR |
| DD62-00097E | SEAL TUB PACKING;DW5000C,TPV,-,SA7-35NE, |
|
|
SEAL TUB;DW9900R,EPDM,INNER BLACK |
| DD62-00109A | SEAL-BRACKER RAIL;DMT800/DMT400,EPDM,BLA |
| DD62-00171A | SEAL-THERMISTOR |
| DD62-00172A | SEAL-THERMOSTAT , DW7000B,EPDM,EPDM 60 |
| DC32-00024A | SENSOR TEMP;PLR3TM-K441-S63,PIPE LENGTH |
| DD32-00007A | SENSOR-FLOW |
| DD66-00149A | SHAFT , DW9000H,POM,INNER GRAY,F20-03,F20- |
| DD66-00146A | SHAFT BASKET |
| DD66-00111A | SHAFT HINGE , DW9900H,SWRCH10A |
| DD66-00122B | SHAFT ROD ADJUSTER FOOT , DW9900M,SWRCH10A |
| DD66-00204A | SHAFT ROLLER , DW9900R,STS304,L23,OD4,T4 |
| 0201-003987 | SMG PART |
| 0903-002307 | SMG PART |
| 2007-007132 | SMG PART |
| 2007-007136 | SMG PART |
| 2007-007137 | SMG PART |
| 2007-007139 | SMG PART |
| 2007-007142 | SMG PART |
| 2007-007308 | SMG PART |
| 2007-007311 | SMG PART |
| 2007-007312 | SMG PART |
| 2007-007313 | SMG PART |
| 2007-007314 | SMG PART |
| 2007-007316 | SMG PART |
| 2007-007317 | SMG PART |
| 2007-007318 | SMG PART |
| 2007-007319 | SMG PART |
| 2007-007334 | SMG PART |
| 2007-007538 | SMG PART |
| 2007-007586 | SMG PART |
| 2007-007588 | SMG PART |
| 2007-007589 | SMG PART |
| 2007-007627 | SMG PART |
| 2007-007671 | SMG PART |
| 2007-007766 | SMG PART |
| 2007-007791 | SMG PART |
| 2007-007861 | SMG PART |
| 2203-000438 | SMG PART |
| 2203-000489 | SMG PART |
| 2203-000585 | SMG PART |
| 2203-000995 | SMG PART |
| 2203-006841 | SMG PART |
| 2203-007392 | SMG PART |
| 2203-007795 | SMG PART |
| 2203-007809 | SMG PART |
| 2203-008462 | SMG PART |
| DC26-00056C | SMG PART |
| DD31-00011C | SMG PART |
| DD47-00015A | SMG PART |
| DD61-00474B | SMG PART |
| DD61-00635A | SMG PART |
| DD61-00639A | SMG PART |
| DD61-00702A | SMG PART |
| DD61-00703A | SMG PART |
| DD61-00704A | SMG PART |
| DD61-00705A | SMG PART |
| DD61-00711A | SMG PART |
| DD61-00747A | SMG PART |
| DD61-00760B | SMG PART |
| DD61-00800A | SMG PART |
| DD61-00801A | SMG PART |
| DD61-00802A | SMG PART |
| DD61-00803A | SMG PART |
| DD62-00158A | SMG PART |
| DD62-00174A | SMG PART |
| DD62-00175A | SMG PART |
| DD62-00177A | SMG PART |
| DD62-00178A | SMG PART |
| DD62-00184A | SMG PART |
| DD62-00185A | SMG PART |
| DD62-00192A | SMG PART |
| DD63-00313B | SMG PART |
| DD63-00340A | SMG PART |
| DD63-00395A | SMG PART |
| DD63-00417F | SMG PART |
| DD63-00428A | SMG PART |
| DD63-00433A | SMG PART |
| DD63-00434A | SMG PART |
| DD63-00441A | SMG PART |
| DD64-00267A | SMG PART |
| DD64-00272A | SMG PART |
| DD66-00089B | SMG PART |
| DD66-00218A | SMG PART |
| DD66-00219A | SMG PART |
| DD66-00234A | SMG PART |
| DD67-00258A | SMG PART |
| DD67-00260A | SMG PART |
| DD67-00262A | SMG PART |
| DD67-00263A | SMG PART |
| DD68-00114A | SMG PART |
| DD68-00185E | SMG PART |
| DD69-00115A | SMG PART |
| DD69-00116B | SMG PART |
| DD69-00165A | SMG PART |
| DD69-00168A | SMG PART |
| DD69-00172B | SMG PART |
| DD92-00088A | SMG PART |
| DD97-00689A | SMG PART |
| DD97-00695A | SMG PART |
| DD97-00758A | SMG PART |
| DD98-01051F | SMG PART |
| DD98-01133A | SMG PART |
| DD98-01134A | SMG PART |
| 0202-001933 | SOLDER-CREAM;LFM-48W TM-HP,D20~38UM,96.5 |
| 0202-001463 | SOLDER-WIRE |
| 0202-001608 | SOLDER-WIRE FLUX |
| DD60-00009A | SPACER HEATER |
| 3001-002875 | SPEAKER;8OHM,82DB,350HZ,60.5X40X10.5MM,2 |
| DD61-00761A | SPRING ETC DOOR;DW8700B,PW-2,2.0MM,OD19. |
| 3502-001180 | SSR , DC6V,0.3A,30TO+85C,0.05A,AC600V,3V |
| DD61-00731A | SUPPORT CUP-HOLDER;DW8700B,POM,T3,HB,F20 |
|
|
SWITCH DOOR |
|
|
SWITCH-MICRO |
| DE02-00029B | TAPE FILAMENT |
| DD02-01003A | TAPE OPP , OPP,T0.075,W48,L100,CLEAR |
| 0203-006612 | TAPE-DOUBLE FACE , NO.4920,T0.4,W10,L520,W |
| 0203-001524 | TAPE-DOUBLE FACE , NONWOVEN,S830G,T0.14,W4 |
| 0203-001607 | TAPE-OPP MASKING |
| 0203-006665 | TAPE-OPP MASKING |
| DE02-00030A | TAPE-SCOTCHPAR |
| 0203-007184 | TAPE-SINGLE FACE;PO,T0.07,W50,L100M,CLEA |
| 1404-001481 | THERMISTOR-NTC , 5OHM,7A,3100K,25MWC,20MM, |
| CALL_1-800-SAMSUNG | THERMISTOR-PTC |
| 1404-001872 | THERMISTOR-PTC |
| DD47-00012A | THERMOSTAT , AC125/250V,15/7.5A,85C3C,70C |
| DD47-00011A | THERMOSTAT , AC125/250V,15/7.5A,95C3C,0C, |
| 0506-000175 | TR-ARRAY |
| 0504-001008 | TR-DIGITAL |
| 0504-001080 | TR-DIGITAL |
| 0502-001266 | TR-POWER |
| 0501-000465 | TR-SMALL SIGNAL |
| 0501-000467 | TR-SMALL SIGNAL |
| DD64-00151D | TRIM SIDE;DW5000C,PP,EP649N,BLACK,-,TPV |
| DD64-00150A | TRIM-LOW |
| DD62-00079A | VALVE CHECK |
| DD62-00176A | VALVE DISTRIBUTER;DW8700B,POM,NATURAL,-, |
|
|
WIRE HARNESS-LEAKAGE |
| DA46-01001A | |
| DA92-01837A | |
| DD01-01036A | |
| DD02-01004A | |
| DD07-00024A | |
| DD32-00012A | |
| DD33-01003A | |
| DD41-00020C | |
| DD61-00510B | |
| DD61-00526C | |
| DD61-00617D | |
| DD61-00657C | |
| DD61-00660D | |
| DD61-00688B | |
| DD61-00691B | |
| DD61-00696B | |
| DD61-00745B | |
| DD61-00746B | |
| DD61-00804B | |
| DD61-00823B | |
| DD61-00824B | |
| DD61-00825B | |
| DD61-00826B | |
| DD61-00832A | |
| DD61-00833A | |
| DD61-00835A | |
| DD61-00836A | |
| DD61-00837A | |
| DD61-00838A | |
| DD61-00839A | |
| DD61-00843A | |
| DD61-00844A | |
| DD61-00845A | |
| DD61-00846A | |
| DD61-00848A | |
| DD61-00861A | |
| DD61-00862A | |
| DD61-00867A | |
| DD61-00868A | |
| DD62-00156B | |
| DD62-00188C | |
| DD62-00188H | |
| DD62-00194A | |
| DD63-00250B | |
| DD63-00370B | |
| DD63-00419C | |
| DD63-00454A | |
| DD63-00455A | |
| DD63-00456A | |
| DD63-00457A | |
| DD63-00459A | |
| DD63-00466A | |
| DD63-00467A | |
| DD63-00473A | |
| DD64-00156C | |
| DD64-00230C | |
| DD64-00231C | |
| DD64-00266C | |
| DD64-00283C | |
| DD64-00285A | |
| DD64-00286A | |
| DD64-00287A | |
| DD64-00288A | |
| DD64-00289A | |
| DD64-00290A | |
| DD64-00291A | |
| DD64-00301A | |
| DD66-00210B | |
| DD66-00211B | |
| DD66-00212B | |
| DD66-00214C | |
| DD66-00215C | |
| DD66-00241B | |
| DD66-00242B | |
| DD66-00246A | |
| DD66-00247A | |
| DD66-00248A | |
| DD66-00249A | |
| DD66-00250A | |
| DD67-00187B | |
| DD67-00188B | |
| DD67-00213F | |
| DD67-00275A | |
| DD67-00276A | |
| DD67-00277A | |
| DD67-00278A | |
| DD67-00280A | |
| DD67-00281A | |
| DD67-00282A | |
| DD67-00283A | |
| DD67-00284A | |
| DD67-00285A | |
| DD67-00286A | |
| DD67-00287A | |
| DD67-00296A | |
| DD68-00152Q | |
| DD68-00245C | |
| DD68-00261C | |
| DD90-00673B | |
| DD90-00676B | |
| DD90-00677F | |
| DD90-00703C | |
| DD90-00704B | |
| DD91-00002A | |
| DD91-00008A | |
| DD92-00093M | |
| DD92-00113A | |
| DD92-00115A | |
| DD93-01021F | |
| DD93-01024C | |
| DD93-01028L | |
| DD93-01032A | |
| DD93-01034A | |
| DD93-01036A | |
| DD93-01037A | |
| DD94-01241B | |
| DD94-01315B | |
| DD94-01316A | |
| DD94-01317A | |
| DD97-00567E | |
| DD97-00646E | |
| DD97-00649C | |
| DD97-00657D | |
| DD97-00660E | |
| DD97-00699B | |
| DD97-00735G | |
| DD97-00741B | |
| DD97-00742B | |
| DD97-00743B | |
| DD97-00745C | |
| DD97-00746B | |
| DD97-00749D | |
| DD97-00752E | |
| DD97-00753D | |
| DD97-00754C | |
| DD97-00755B | |
| DD97-00756C | |
| DD97-00757C | |
| DD97-00777B | |
| DD97-00797M | |
| DD97-00801B | |
| DD97-00802B | |
| DD97-00812A | |
| DD97-00813A | |
| DD97-00815A | |
| DD97-00816A | |
| DD97-00818A | |
| DD97-00819A | |
| DD97-00827B | |
| DD97-00830B | |
| DD97-00833C | |
| DD97-00839C | |
| DD97-00844A | |
| DD97-00848A | |
| DD97-00849A | |
| DD97-00852A | |
| DD97-00854B | |
| DD97-00857A | |
| DD97-00858A | |
| DD97-00859A | |
| DD97-00872A | |
| DD97-00873A | |
| DD97-00874A | |
| DD97-00875A | |
| DD97-00876A | |
| DD98-01137E | |
| DD98-01143D |
