Model Image
Manufacturer

Samsung

Model Number

EH052CAV

Description

Slim Ducted Type Air Conditioner

Interactive Exploded View

Parts List

Part Number Description
DB97-03726C ACCESSORY ASSEMBLY-DUCT
0201-002394 ADHESIVE-EPOXY;HT-1331S(SPL-K4),RED,550~
0201-002081 ADHESIVE-SIL;737,WHITE,
0102-001603 ALUMINUM INGOT;ALDC8
DB97-03499B ASSEMBLY BAG SHEET
DB97-03800B ASSEMBLY BAND MOTOR
DB97-03800A ASSEMBLY BAND MOTOR
DB98-30154A ASSEMBLY BAR CODE BOX
DB90-04279A ASSEMBLY BASE-CUSHION
DB90-03400A ASSEMBLY BASE-CUSHION C
DB94-40007A ASSEMBLY BEARING
DB90-07701A ASSEMBLY BRACKET MOTOR
DB97-03796A ASSEMBLY BRACKET OUTLET
DB90-03158A ASSEMBLY BRACKET OUTLET PART
DB90-05790A ASSEMBLY CABI SIDE RH
DB90-05314C ASSEMBLY CABI TOP
DB90-02160D ASSEMBLY CABINET-BASE
DB90-02160A ASSEMBLY CABINET-BASE
DB90-01951A ASSEMBLY CABINET-SIDE RH
DB90-02161A ASSEMBLY CABINET-TOP EVAP
DB90-01948B ASSEMBLY CASE BLOWER BOTTOM
DB90-01948A ASSEMBLY CASE BLOWER BOTTOM
DB90-01947C ASSEMBLY CASE BLOWER UPPER
DB90-01947A ASSEMBLY CASE BLOWER UPPER
DB93-09157C ASSEMBLY CONNECTOR WIRE-COMM
DB93-09129C ASSEMBLY CONNECTOR WIRE-POWER
DB93-09129B ASSEMBLY CONNECTOR WIRE-POWER
DB93-09129A ASSEMBLY CONNECTOR WIRE-POWER
DB93-05227B ASSEMBLY CONTROL IN
DB96-04902A ASSEMBLY COUPLER
DB97-03791A ASSEMBLY CUSHION BASE B
DB94-06964B ASSEMBLY DRAIN HOSE
DB94-02004A ASSEMBLY DRAIN PAN
DB91-01343A ASSEMBLY DRAIN PAN
DB96-11493B ASSEMBLY EVAP
DB96-05115B ASSEMBLY EVAP-UNIT
DB98-13261A ASSEMBLY GARANTIE CARD
DB98-27564A ASSEMBLY INSTALLATION MANUAL
DB98-28433A ASSEMBLY LABEL BARCODE
DB91-00625A ASSEMBLY MIC
DB94-00759A DB94-00759A ASSEMBLY MOLD BEARING
DB97-03721A ASSEMBLY PACKING SCREW
DB97-10615C ASSEMBLY PACKING-CASE
DB97-04095B ASSEMBLY PAD INSTALL A
DB97-04095A ASSEMBLY PAD INSTALL A
DB94-00809C ASSEMBLY PARTITION
DB94-00809B ASSEMBLY PARTITION
DB94-00809A ASSEMBLY PARTITION
DB98-13260A ASSEMBLY REGISTRATION CARD
DB91-00309A ASSEMBLY SCREW TAPPING;WW-INV,M3*2
DB97-14454A ASSEMBLY SEAL-PIPE COVER
DB98-27578A ASSEMBLY SERVICE MANUAL
DB90-01978A ASSEMBLY SUPPORT EVAP LF
DB90-01946A ASSEMBLY SUPPORT EVAP RH
DB96-10257A ASSEMBLY TUBE U BEND
DB96-10256A ASSEMBLY TUBE U BEND
DB98-27565A ASSEMBLY USERS MANUAL
DB93-50001A ASSEMBLY WIRE RING SOLD
DB97-06347A ASSY ACCESSORY IN PARTS;HP,EH0
DB97-33768D ASSY ACCESSORY PARTS;AM024KNLDCH/AZ,SLIM
DB94-00688A ASSY BOSS-FAN;MH020FDEZ,SSEC
DB90-03302A ASSY CABI IN PARTS;EH070CAV,SSEC
DB90-01941B ASSY CASE-CONTROL;AVMDSC040B1,SSEC,ASSY
DB93-05194A ASSY CONTROL IN PARTS;HP,208-230V,
DB93-09644B ASSY CONTROL IN;HP,NO,ASSY,SSEC-CAC
DB97-19775A ASSY CUSHION BOTTOM IN;ASSY
DB97-14506A ASSY CUSHION TOP IN;SSEC,SLIM DUCT,ASSY
DB94-01442A ASSY DRAIN PARTS;-,R410A,EH070CA
DB94-00758A ASSY DRAIN-HOSE JOINT;250,SLIM DUCT3,SSE
DB96-07769A ASSY EVAP PARTS;EH052CAV,SSEC
DB96-05122A ASSY EVAP-SUB;EH070EZMC,
DB94-01443A ASSY FAN IN PARTS;EH070CAV,SSEC
DB90-06701B ASSY HOLDER-CLAMP;CH140EAMC,SSEC
DB90-02064A ASSY HOLDER-DRAIN PIPE;SLIM DUCT 1,SSEC
DB97-06414B ASSY MANUAL;EH070CAV,SSEC
DB97-03793B ASSY PACKING IN PARTS;-,N,N,DW3,N,R410A,
DB97-19083N ASSY PACKING-BOTTOM;SLIM 2_KO_CN_EN
DB97-14313F ASSY PACKING-UP;SLIM2,CL175/S125/S150/S1
DB94-03794A ASSY PCB AUTO;DB93-09057B
DB94-03795A ASSY PCB MANUAL;DB93-09057B
DB94-03793A ASSY PCB SMD;DB93-09057B
DB90-07979A ASSY PLATE-LEFT;SLIM DUCT
DB97-06356A ASSY PRINT IN PARTS;-,HP,208-230V,
DB97-14454B ASSY SEAL-PIPE COVER;DUCT,ASSY SEAL PIPE
DB97-14454D ASSY SEAL-PIPE COVER;DUCT,BLK&WHITE,PU+P
DB96-05113B ASSY TUBE EVAP IN;EH052/070EAV,SSEC
DB96-05114B ASSY TUBE EVAP OUT;EH052EAV,SSEC
DB96-21696B ASSY TUBE-DISTRIBUTOR;RAC(NEO FORTE,A305
DB98-25943L ASSY-CARD ENERGY GUIDE;HP,ENGLISH,ENGLIS
DB97-15923A ASSY-CUSHION CABI SIDE RH;DC18ETSA/SGE
DB97-19312A ASSY-CUSHION DRAIN;SLIM 2,SLIM 2
DB98-31633A ASSY-DIP LABEL CAUTION;HP,NO,R22,MH035FE
DB98-32519A ASSY-INSTALLATION MANUAL;EH035CAV,SSEC,E
DB98-29517A ASSY-INSTRUCTION MANUAL;HP,T,36K/48K,R41
DB98-32332A ASSY-LABEL CAUTION;SSEC,TOWER
DB98-27576B ASSY-LABEL RATING IN;HP,18,000/20,500 BT
DB97-03714B ASSY-NUT;HP,INV,SLIM DUCT 1,SSEC
DB97-03714A ASSY-NUT;HP,INV,SLIM DUCT 1,SSEC
DB98-32170A ASSY-SIMPLE MANUAL;MWR-WH01,PAPER,12LANG
6902-000103 BAG PE
6902-002020 BAG PE;HDPE,T0.02,W200,L350,TRP,RECYCLE+
6902-002333 BAG PE;LDPE,T0.03,W300,L400,TRP,RECYCLE+
6922-000041 BAND
DB72-00745A BAND-MOTOR LOW;DUCT 1,SGCC-M,T2,11,70
DB72-00744A BAND-MOTOR UP;DUCT 1,SGCC-M,T2,11,70
DB61-03642A BASE-CUSHION A;SLIM DUCT3,EPS,NATURAL,
DB61-03204A BASE-CUSHION C;EH035EAV,EPS,NATURAL,
DB67-00576A BLOWER
DB67-00565A BLOWER
DB60-20011A BOLT-SPECIAL
DB61-02341A BOSS-FAN IN;AVMME036EZC,AL,SSEC
DB61-02342A BOSS-FAN OUT;AVMME036EZC,AL,SSEC
DB61-02314A BOSS-FAN;MH020FDEZ,ALDC12,L35,2
DB61-02282A BRACKET MOTOR
DB61-02643A BRACKET-FILTER
DB61-02321A BRACKET-OUTLET A
DB61-02276A BRACKET-OUTLET B;MH020FDEZ,SGCC-M,T0.8,
DB61-02322A BRACKET-OUTLET SUB
2401-002216 C-AL
2401-000711 C-AL
2401-000037 C-AL
2203-000444 C-CER, CHIP
2203-000257 C-CER, CHIP
2203-000192 C-CER, CHIP
2203-001562 C-CERAMIC, CHIP
2301-001913 2301-001913 C-FILM, LEAD-OTHER
2301-001220 C-FILM, LEAD-PPF
DB64-01344A CABINET-BASE;EH070EZMC,GI-SGCC,T1,SS
DB64-01324B CABINET-SIDE LF
DB64-01325A CABINET-SIDE RH
DB64-02527C CABINET-SIDE RH;SLIM S,GI-SGCC,T0.8
DB64-01346A CABINET-TOP EVAP;DH24BTA/UMG,GI-SGCC,T0.
DB64-01345A CABINET-TOP MOTOR
DB65-10088C CABLE TIE
6501-001052 CABLE TIE
6501-001108 CABLE TIE;T1.2,W3.6,L146,BLK,NYLON66
6501-001110 CABLE TIE;T1.2,W4.8,L200,NYLON66
DB67-00581A CAP-BEARING
DB67-00602A CAP-HOSE;SLIM DUCT-3,LS170,SSEC
DB67-00942A CAP;VIVALDI-P/J,SHP2,1,5.2,11.5,18.5,
DB68-40091A CARD-REGISTRATION
6801-002246 CARD-WARRANTY;USA,EN,MOJO,W216,L280,8P,C
DB61-02284A CASE BLOWER-BOTTOM
DB61-02284B CASE BLOWER-BOTTOM;SLIM DUCT,HIPS,T2,L21
DB61-02283A CASE BLOWER-UPPER
DB61-02283B CASE BLOWER-UPPER;SLIM DUCT,HIPS,T2,L205
DB61-02285B CASE CONTROL;AVMDSC040B1,SGCC-M,T0.8,218
DB61-05156A CASE PCB
DB61-02287B CASE PCB
DC02-10009A CHEMICALS-LOCK SCREW
DB61-02349A CLIP-BRUSH
DB61-04505A CLIP-BRUSH;SLIM DUCT,PA66,2.5,NATURAL,10
DB61-04522A CLIP-DRAIN BAND;AVMEH035EA3,STS304,SSEC
DB61-02365A CLIP-WIRE
DB27-00032A COIL CHOKE
DB39-01107A CONNECT WIRE-POWER
DB39-01106C CONNECT WIRE-POWER&COMMUNICATION
DB39-01106B CONNECT WIRE-POWER&COMMUNICATION
DB39-01106D CONNECT WIRE-POWER&COMMUNICATION;MH023/0
DB39-01108B CONNECT WIRE-VENTILATOR&WATER HEATER
DB39-01108A CONNECT WIRE-VENTILATOR&WATER HEATER
3711-003406 CONNECTOR-HEADER
3711-003405 CONNECTOR-HEADER
3711-003404 CONNECTOR-HEADER
3711-000940 CONNECTOR-HEADER
3711-000796 CONNECTOR-HEADER
3711-000262 CONNECTOR-HEADER
3711-000177 CONNECTOR-HEADER
3711-000176 CONNECTOR-HEADER
0102-001526 COPPER TUBE , C1220T,O,6.35,0.6,ROLL,
0102-001515 COPPER TUBE;C1220T,O,6.35,0.7,ROLL,
0102-001530 COPPER TUBE;C1220T,O,7,0.41,ROLL
0102-001537 COPPER TUBE;C1220T,O,7.94,0.5,ROLL,
0102-000252 COPPER-TUBE
DB67-00582A COUPLER-SHAFT RUBBER;EH140EZMC,RUBBER IN
DB90-02101A COVER ASSEMBLY-CONTROL
DB90-01950A COVER ASSEMBLY-DRAIN PUMP
DB90-09638A COVER ASSEMBLY-PIPE
DB90-01938A COVER ASSEMBLY-PIPE
DB63-01262A COVER BEARING-MOLD;EH140EZMC,NBR,L30.2
DB63-01235A COVER PIPE
DB63-01237A COVER-CONTROL
DB63-00309A COVER-DRAIN PUMP
DB63-00360C COVER-FLARE
DB63-02115A COVER-HOLE
DB63-02699B COVER-PIPE;SLIM S,GI-SGCC,T0.8,
DB69-01167A CUSHION (LEFT)
DB69-01166A CUSHION (RIGHT)
DB69-01188B CUSHION-BASE B;EH070EZMC,EPS,
DB69-02789A CUSHION-BOTTOM IN;SLIM DUCT 1/2/S,EPS,W6
DB63-02698A CUSHION-CABI SIDE RH;DC18ETSA/SGE,EPS,PK
DB69-01281J CUSHION-MID
DB69-01281H CUSHION-MID
DB69-02788A CUSHION-TOP IN;SLIM DUCT 1/2/S,EPS,W692.
0402-001298 0402-001298 DIODE-BRIDGE
0402-000137 0402-000137 DIODE-RECTIFIER
0401-000133 0401-000133 DIODE-SWITCHING
0406-001204 DIODE-TVS
DB62-04309C DISTRIBUTER AIR;UH070EZM1C,C1220T-O,1.0,
DB67-00663A DRAIN PAN
DB60-30010C FASTENER-NUT FLARE
DB60-30010A FASTENER-NUT FLARE
DB63-03098A FILTER-PRE
DB62-03801A FIN-FOIL;A3102,L231,D7,H,1.5,NGS,
DB62-03684A FIN-FOIL;A3102,L231,D7,H,1.5,NGS,
0204-004665 FLUX;KSP-70M-S,MIXTURE,NO,FLUX,13%
DB01-00129A FOIL
DB01-00069H FOIL-NEO GREEN
3601-001308 FUSE
3601-000263 FUSE-CARTRIDGE
0207-001448 GAS-NITROGEN
0205-000178 GREASE-SILICON
DB63-00237A GROMMET-HANGER
DB61-02286A GUIDE-CONTROL;MH020FDEZ,SGCC-M,T0.8,
DB61-02274A HANGER-PLATE
3711-005716 HEADER-BOARD TO CABLE
3711-003845 HEADER-BOARD TO CABLE
3711-003407 HEADER-BOARD TO CABLE
3711-000939 HEADER-BOARD TO CABLE
3711-000880 HEADER-BOARD TO CABLE
3711-000794 HEADER-BOARD TO CABLE
3711-000203 HEADER-BOARD TO CABLE
3711-000178 HEADER-BOARD TO CABLE
DB62-03085A HEAT SINK
DB61-00924A HOLDER-FUSE
DB61-02431A HOLDER-GASKET;-,GI-SGCC,T3,12.4,22.4,
DB61-03882A HOLDER-MOTOR;DUCT,GI-SGCC,T2,24,117,
DB61-40055A DB61-40055A HOLDER-SENSOR
DB61-03149A HOLDER-WIRE
DB67-01609A HOSE DRAIN;DUCT,4WAY,PVC,L160,BLACK,
DB67-00601A HOSE-DRAIN;SLIM DUCT-3,PVC,T2.0,
DB09-00338A IC MICOM
1006-001325 IC-BUS TRANSCEIVER
0801-000393 IC-CMOS LOGIC
1103-001228 IC-EEPROM
1103-001175 IC-EEPROM
1006-001371 IC-LINE TRANSCEIVER
1203-000274 IC-POSI.FIXED REG.
1203-000243 IC-POSI.FIXED REG.
1203-003334 IC-RESET
DB62-03418A INSULATION CABI- SIDE RH FRONT;-,FLOCKED
DB62-04262A INSULATION DRAIN-SIDE D;DC24BTV,PU,T15,W
DB62-03419M INSULATION- CASE BOTTOM;PUR FOAM,T3,130,
DB62-11071A INSULATION-CABI;PE FOAM,T3,150,165,DAR
DB62-03419B INSULATION-CABINET BASE;PUR FOAM,T5,40,7
DB62-09268A INSULATION-CABINET RH;DC18ETSA1/SGE,PE+P
DB62-03419N INSULATION-CASE UPPER;-,FOAM PE,T3,60,20
DB62-04318S INSULATION-COVER BAND;CH140EAMC,EPDM,T5,
DB62-01559A INSULATION-COVER DRAIN
DB62-04318T INSULATION-COVER DRAIN OUT;CH140EAMC,EDP
DB62-03559K INSULATION-COVER DRAIN PUMP;DC18ETSA/SGE
DB62-03559L INSULATION-COVER PIPE B;DC18ETSA/SGE,PE+
DB62-03419X INSULATION-COVER PIPE IN A;DC24BTVA,FOAM
DB62-03416A INSULATION-COVER PIPE IN;-,FOAM-PE,T10,
DB62-03690A INSULATION-COVER PIPE OUT;-,T25,70.0,9
DB62-09269A INSULATION-COVER PIPE;DC18ETSA/SGE,PE+PU
DB62-03559P INSULATION-COVER;PU FOAM,15,30,100,BLA
DB62-03419Y INSULATION-CUSHION BASE B;EH035EAV,PUR F
DB62-03559M INSULATION-CUSHION CABI SIDE RH A;DC18ET
DB62-03559N INSULATION-CUSHION CABI SIDE RH B;DC18ET
DB62-03419W INSULATION-CUSHION;SLIM DUCT 2,PUR FOAM,
DB62-03566A INSULATION-DARAIN PIPE;DH60FTA,FOAM-PE,T
DB62-04212A INSULATION-DARAIN SIDE A;DC24BTVX/UMG,PE
DB62-04213A INSULATION-DARAIN SIDE B;DC24BTVX/UMG,PE
DB62-04211C INSULATION-DARAIN TOP;DC24BTVX/UMG,FOAM-
DB62-03440H INSULATION-DRAIN IN;AVMEH035EA3,FORM-PE,
DB62-04295F INSULATION-DRAIN LOW;SLIM DUCT,FOAM-PE,9
DB62-03439H INSULATION-DRAIN OUT;-,EDPM,T5,250,270,
DB62-03419F INSULATION-DRAIN PAN CORNER;EPDM,T3,40,4
DB62-05936D INSULATION-DRAIN PAN;SLIM DUCT,EPDM,T5,3
DB62-03438A INSULATION-DRAIN PUMP HOLE;-,FOAM-PE,T10
DB62-04247A INSULATION-DRAIN SIDE C;DC24BTVA/UMG,30F
DB62-11146A INSULATION-DRAIN-PIPE;SLIM S,PE FOAM,T3,
DB62-04526A INSULATION-FRAME;AF1-PJT,PUR FOAM,T5,W12
DB62-11028D INSULATION-HOSE C;PE FOAM,10,150,MB9500,
DB62-11028E INSULATION-HOSE D;PE FOAM,10,150,MB9500,
DB62-11028M INSULATION-HOSE;PE FOAM,T10,L180,GRA
DB62-11028N INSULATION-HOSE;PE FOAM,T3,L45,GRAY,
DB62-11028L INSULATION-HOSE;PE FOAM,T5,L114,GRAY
DB72-00143E INSULATION-INSTALL INLET
DB72-00143D INSULATION-INSTALL OUTLET
DB62-03439J INSULATION-OUT;-,EPDM,T5,200,230,
DB62-04932A INSULATION-OUTLET B;-,PBT,T1,W12,L146,
DB62-04956A INSULATION-PARTITION SIDE;CH070EAMC,PUR
DB62-03440J INSULATION-PIPE IN
DB62-03440D INSULATION-PIPE IN
DB62-03440C INSULATION-PIPE IN
DB62-03439D INSULATION-PIPE OUT
DB62-03439C INSULATION-PIPE OUT
DB62-03439K INSULATION-PIPE OUT 3/8;DH070EAV1,PUR FO
DB62-03439L INSULATION-PIPE OUT;DH070EAV1,PUR FOAM,1
DB62-03439M INSULATION-PIPE OUT;PU FOAM,10,50,125,
DB62-03419D INSULATION-PLATE EVAP LF
DB62-03419J INSULATION-SIDE LF;PUR FOAM,T3,15,620,
DB62-03419K INSULATION-SIDE RH A;-,FOAM PU,T3,10,165
DB62-03419L INSULATION-SIDE RH B;-,FOAM PU,T3,5,120,
DB62-03446A INSULATION-SUPPORT EVAP LF;AVMME036EZC,F
DB62-08699A INSULATION-SUPPORT EVAP PLATE;EH071EZVAC
DB62-03419C INSULATION-SUPPORT EVAP RH;PUR FOAM,T3,5
DB62-03798A INSULATION-TOP EVAP;-,LEX FOAM,T3,60,110
DB68-02809A LABEL BAR CODE
DB68-11576A LABEL BAR CODE;AM9000A,EU,ART,W15,L15,QR
DB68-05458A LABEL BAR CODE;AM9000H,PAPER,W17.5,L18
DB68-02851E LABEL CAUTION
DB68-01975A LABEL CAUTION
DB98-33749A LABEL CAUTION;-,ART,W148,L210,ZH+EN+KO
DB98-32768A LABEL CAUTION;SLIM DUCT,GLOBAL,PET,W100,
DB68-03042A LABEL DIAGRAM
DB98-32334A LABEL INSTRUCTION;-,PET,57,8,S
DB68-03068C LABEL PRINT;PET,W55,L170,SILVER,LABEL RA
DB68-02813A LABEL WARNING
DB68-02856B LABEL WARNING-B
DB98-31132A LABEL WARNING;-,PET,WW1,WB
DB68-01350A LABEL-BAR CODE
DB68-02878A LABEL-TEST
0601-001377 LED
0601-001375 LED
0601-001373 LED
DB93-03213G MAIN PCB ASSEMBLY
DB93-09057B DB93-09057B MAIN PCB ASSEMBLY-IN
DB31-00314C DB31-00314C MOTOR BLOWER
DB61-02501A MOUNT-TIE
DB67-60023A NIPPLE-1/4'
DB67-00183F NIPPLE;AS-T1010,C3604,1/2"
DB67-00276F NIPPLE;C3604,3/4-16UNF
DB69-03089F PACKING ANGLE;ALL MODEL,PAPER,T4,W35,H35
DB69-02412Q PACKING CASE BOTTOM;SLIM2_KO_CN_EN,CB,SW
DB97-03996C PACKING CASE-IN
DB69-02748F PACKING CASE;SLIM2,CB,DW2,L700,W1342,H24
6902-002029 PACKING SHEET;ALL,HDPE,T0.02,W1500,L1500
DB69-02774B PAD CUSHION;EH071EZVAC,EPS,T30,W686,L300
DB67-00579A PARTITION;EH070EZMC,GI-SGCC,T1.2
DB67-00579B PARTITION;SLIM DUCT,GI-SGCC,T1.2,
DB41-00364A PBA LOGIC BOARD;MINIDVM_SLIMDUCT_CHI,FR-
DB60-70016A PIN-STAPLE
DB81-02330A PIPE-SLIMDUCT;ABS,T920,NATURAL
DB61-02278A PLATE-EVAP LF
DB61-02278B PLATE-EVAP LF;SLIM DUCT 1,STS430,T0.8
DB61-02279A PLATE-EVAP RH
DB61-02279B PLATE-EVAP RH;SLIM DUCT 1,STS430,T0.8
DB61-06121A PLATE-LOW;AVXDSHT07CA,GI-SGCC,T0.8,W14.4
2007-001071 R-CHIP
2007-001067 R-CHIP
2007-000938 R-CHIP
2007-000931 R-CHIP
2007-000872 R-CHIP
2007-000766 R-CHIP
2007-000686 R-CHIP
2007-000613 R-CHIP
2007-000477 R-CHIP
2007-000468 R-CHIP
2007-000300 R-CHIP
2007-000023 R-CHIP
3501-001248 RELAY-MINIATURE
3501-001154 3501-001154 RELAY-MINIATURE
0103-004028 RESIN ABS;ABSG10/NATURAL,NATURAL,NC0001,
0103-004031 RESIN ABS;ABSPC100,BLACK,BK0003
0103-004017 RESIN ABS;HI-121H,NATURAL,NC0001
0103-003376 RESIN LDPE;MB9500,NATURAL,NC0001,N
0103-003325 RESIN PA66;FR50/BK0001,BLACK,BK0001,V-0,
0103-004069 RESIN PC ABS;PC-510,GRAY,GY0020,N
0103-004055 RESIN PP;MT42,NATURAL,NC0001,TD20%,N
0103-004034 RESIN SAN;ASG20,NATURAL,NC0001,GF20%,N
0103-002713 RESIN-PVC
2802-001179 RESONATOR-CERAMIC
DB81-00614A RING;STS304 D2.0,
DB73-00461G RUBBER-BUTYL
DB73-00294A RUBBER-COVER CONTROL;AVMEH035EA3,NBR,45*
DB73-00269A RUBBER-COVER WIRE A;MH020FDEZ,RUBBER,OD
DB73-00270A RUBBER-COVER WIRE B
DB73-00285A RUBBER-SHAFT
6009-001001 6009-001001 SCREW-SPECIAL
6002-000630 6002-000630 SCREW-TAPPING
6002-000560 SCREW-TAPPING
6002-000536 SCREW-TAPPING
6002-000527 SCREW-TAPPING
6002-000239 6002-000239 SCREW-TAPPING
6002-000213 6002-000213 SCREW-TAPPING
DB62-04933A SEAL BRACKET-OUTLET;-,NONWOVEN,T1,W14,
DB62-12257A SEAL BRACKET-OUTLET;NONWOVEN,T1,W12,HB
DB62-12258A SEAL CABI-SIDE RIGHT;NONWOVEN,T1,W100,HB
DB62-12255A SEAL COVER-PIPE;NONWOVEN,T1,W140,HB
DB62-04877E SEAL-CASE UPPER;PU FOAM,3,60,200
DB62-04877D SEAL-DRAIN RIB;SLIM DUCT,FOAM-PU,5,48,
DB92-01734A SHAFT
DB66-00956A SHAFT-COUPLER;BIG-CEILING,ALDC12,
0202-001976 SOLDER-CREAM;LST-309M-K21 (PWM-118),D20~
0202-001163 SOLDER-SILVER
0202-001022 SOLDER-SILVER
0202-001464 SOLDER-SILVER;L450,91CU/1.9AG/6.95P
0202-001463 SOLDER-WIRE
0202-001608 SOLDER-WIRE FLUX
DB67-60030A SPRING-SENSOR
3502-001026 SSR
3502-001040 SSR;12V,3A,1MS,1MS,9.6-14.4V,264V
0101-002928 STEEL PLATE
0101-002932 STEEL PLATE;GI,SGCC,0.8MM,647MM,Z12,NC
0101-002933 STEEL PLATE;GI,SGCC,1,Z14,NC
0101-002935 STEEL PLATE;GI,SGCC,1.2MM,700MM,Z14,NC
0101-002940 STEEL PLATE;GI,SGCC,2,Z14,NC
0101-002982 STEEL PLATE;STAINLESS,STS304,0.3MM,NO.4
DB61-02280A SUPPORT-EVAP LF;MH020FDEZ,SGCC,T0.8
DB61-02281A SUPPORT-EVAP RH;MH020FDEZ,SGCC,T0.8
DB34-00009A SWITCH-DIGITAL
3407-000121 SWITCH-DIP
3406-001106 SWITCH-ROTARY;24VDC,15MA,10,L14MM
DA02-00013A TAPE ETC
DB02-00045B TAPE ETC-PVC;NS1004PXEA,PVC,0.15MM,25,26
DB02-00045A TAPE ETC-PVC;NS1004PXEA,PVC,0.15MM,25,30
DB02-00029B TAPE ETC;RAC,OPP,0.05MM,80MM,500M,TRANSP
DA02-10017J TAPE-FILAMENT
DB65-00105M TERMINAL BLOCK
DB65-00105L TERMINAL BLOCK
DB95-01983A THERMISTOR-IN
0506-000175 TR-ARRAY
0504-000001 TR-DIGITAL
0501-002296 TR-SMALL SIGNAL
0501-000534 TR-SMALL SIGNAL
DB26-00080A TRANS POWER
DB62-02813A TUBE HAIR PIN
DB62-03445B TUBE HAIR PIN;DH24BTA,C1220T-O,T0.25,7,1
DB62-03986A TUBE-BONNET;CASSETTE,C1220T-O,T0.7,OD6.3
DB62-06999A TUBE-CU;C1220T-O,T0.25,OD7,L,ID6.3,TW0.2
DB62-31003C TUBE-FLARE
DB62-30369A TUBE-U BEND
DB62-30368A TUBE-U BEND;COMMON USE,C1220T-O,T0.41,OD
1405-000154 VARISTOR
DB68-01675A WARRANTY CARD
DB71-00133A WIRE-SADDLE
Main Menu x
