Manufacturer
Samsung
Model Number
HG28NE473AFXZA
Description
Led Tv(h),hg28ne473af,28,united States,
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ASSEMBLY BOARD P-JOG SWITCH & |
|
|
ASSEMBLY CABLE P-FFC |
| BN96-30338B | ASSEMBLY SPEAKER P |
| BH69-00418A | BAG PE-WRAPPING FILM |
|
|
BEAD-SMD |
| 3301-001404 | BEAD-SMD |
| 3301-001364 | BEAD-SMD |
| 2402-001268 | C-AL,SMD |
| 2203-008315 | C-CER,CHIP |
| 2203-008096 | C-CER,CHIP |
| 2203-007513 | C-CER,CHIP |
| 2203-007306 | C-CER,CHIP |
| 2203-007233 | C-CER,CHIP |
| 2203-007176 | C-CER,CHIP |
| 2203-007132 | C-CER,CHIP |
| 2203-006348 | C-CER,CHIP |
|
|
C-CER,CHIP |
| 2203-006158 | C-CER,CHIP |
| 2203-006126 | C-CER,CHIP |
| 2203-006048 | C-CER,CHIP |
| 2203-005968 | C-CER,CHIP |
| 2203-005659 | C-CER,CHIP |
| 2203-005249 | C-CER,CHIP |
| 2203-005083 | C-CER,CHIP |
| 2203-002711 | C-CER,CHIP |
| 2203-002285 | C-CER,CHIP |
| 2203-000627 | C-CER,CHIP |
| 2409-001168 | C-EDL |
| 3903-000576 | CBF-POWER CORD |
| 3719-001755 | CONNECTOR-ACCESSORY |
| 3708-001150 | CONNECTOR-FPC/FFC/PIC |
| 3701-001856 | CONNECTOR-HDMI |
| 3701-001967 | CONNECTOR-HDMI;19P,A,FEMALE,AU |
| 2801-004813 | CRYSTAL-SMD |
| 2801-003773 | CRYSTAL-SMD |
| 2801-000258 | CRYSTAL-SMD |
|
|
DC VSS-LED TV PD BD |
| 0404-001404 | DIODE-SCHOTTKY |
| 0404-001307 | DIODE-SCHOTTKY |
| 0401-001099 | DIODE-SWITCHING |
| 0401-001056 | DIODE-SWITCHING |
| 0401-000116 | DIODE-SWITCHING |
| 0406-001635 | DIODE-TVS |
| 0406-001271 | DIODE-TVS |
| 0403-001407 | DIODE-ZENER |
| BN73-00024D | ELEMENT-SILICON/RUBBER |
| 0505-003397 | FET-SILICON |
| 0505-003205 | FET-SILICON |
| 0505-002560 | FET-SILICON |
|
|
FUSE-SURFACE MOUNT |
|
|
HEADER-BOARD TO CABLE |
| 3711-008521 | HEADER-BOARD TO CABLE |
| 3711-008131 | HEADER-BOARD TO CABLE |
| 1201-003690 | IC-AUDIO AMP |
| 1205-003201 | IC-BUS SWITCH |
| 0801-002780 | IC-CMOS LOGIC |
| 0801-002630 | IC-CMOS LOGIC |
| 0801-002564 | IC-CMOS LOGIC |
| 1203-000404 | IC-DC/DC CONVERTER |
| 1204-003354 | IC-DEMODULATOR |
| 1103-001561 | IC-EEPROM |
| 1103-001531 | IC-EEPROM |
| 1006-001266 | IC-LINE TRANSCEIVER |
| 0903-001879 | IC-MICROCONTROLLER |
| 1107-002048 | IC-NAND FLASH |
| 1107-002226 | IC-NOR FLASH |
| 1203-006138 | IC-POSI.ADJUST REG. |
| 0909-001032 | IC-REAL TIME CLOCK |
| 1203-006017 | IC-VOL. DETECTOR |
| 1203-004364 | IC-VOL. DETECTOR |
| 1203-004363 | IC-VOL. DETECTOR |
| 2703-003930 | INDUCTOR-SMD |
| 2703-003790 | INDUCTOR-SMD |
| 2703-000158 | INDUCTOR-SMD |
| 3722-003667 | JACK-PHONE |
| 3722-003617 | JACK-PHONE |
|
|
JACK-USB |
| BN68-00513A | LABEL-E, PASS |
| BN07-01386A | LCD-PANEL |
|
|
LEAD CONNECTOR |
| BN39-01884C | LEAD CONNECTOR |
| BN39-01873D | LEAD CONNECTOR |
| 2806-001308 | OSCILLATOR-VCXO |
| BN69-00391Y | PAD-ANGLE |
| 2007-010304 | R-CHIP |
| 2007-009753 | R-CHIP |
| 2007-008779 | R-CHIP |
| 2007-007463 | R-CHIP |
| 2007-001168 | R-CHIP |
| 2007-000950 | R-CHIP |
| 2007-000929 | R-CHIP |
| 2007-000701 | R-CHIP |
| 2007-000504 | R-CHIP |
| 2007-000475 | R-CHIP |
| 2007-000312 | R-CHIP |
| 2007-000231 | R-CHIP |
| 2007-000219 | R-CHIP |
| 2007-000120 | R-CHIP |
| 2011-001449 | R-NETWORK |
| 2011-001396 | R-NETWORK |
| 2011-001264 | R-NETWORK |
| 2011-001262 | R-NETWORK |
| 2011-000515 | R-NETWORK |
|
|
SCREW-MACHINE |
|
|
SCREW-MACHINE |
|
|
SCREW-TAPTYPE |
|
|
SCREW-TAPTYPE |
| BN60-00162H | SPACER-FOAM |
| 0501-000445 | TR-SMALL SIGNAL |
| BN26-00069A | TRANS PULSE |
| 1405-001382 | VARISTOR |
|
|
VARISTOR |
