Manufacturer
Samsung
Model Number
HLT5675SX
Description
56-inch Slim 720p Dlp Hdtv
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| BP96-01792A | ASSY BOARD P-RMC;HLT5075S,CT5000-5030A,R |
| BP96-00547P | ASSY BOARD P-TERMINAL JACK;HLT5075S,GCK0 |
|
|
ASSY COLOR WHEEL P;K620,SVC |
| BP96-01737A | ASSY COVER P-FRONT;56K6(SLIM),ABS+PMMA,H |
| BP96-01743A | ASSY COVER P-REAR BOTTOM;K6(LAMP),PS,V0, |
| BP96-01734A | ASSY COVER P-REAR;56K6/K8,PS,V0,BK500,NO |
|
|
ASSY DMD BOARD P;K620,SVC |
|
|
ASSY LAMP P;K520,PHILIPS 120W,E22,SVC |
| BP96-01799A | ASSY MISC-DETECOTR S/W;HLS4676,L64E |
| BP96-01831A | ASSY PCB MAIN;HLT5075SX/XAA,L64F |
|
|
ASSY PCB MISC-KEY CONTROL;HLT5075SX/XAA |
| BP96-01861A | ASSY PCB MISC-LED;HLT5675SX/XAA,CATTLEYA |
|
|
ASSY SPEAKER P;8OHM,HORN TYPE,10W,1100/4 |
| BP39-00106C | CBF SIGNAL-DVI(D);HLP5063WX,24P/24P,2027 |
|
|
DLP;1290X720/HD5,0.45",TYPE X NON APERTU |
| BP31-00022B | FAN-DC;G8025S12B2-AE-WS,K520 |
|
|
FAN;G6015S12B2-BA-WS,K520 |
|
|
GLASS-COLOR WHEEL;AIR,GLASS,T0.7,COPAL V |
|
|
LAMP-BALLAST;EUC 132D P/41I,65MM,160MM |
|
|
LAMP;UHP 120W/132W 1.0,E22,65*70,LL |
| BP67-00320A | MIRROR-FRONT;56K6,GLASS,1160!?600!?654!? |
| BP59-00099A | MODULE-RF SPLITTER;UMX-NT-057,2INPUT 1OU |
|
|
POWER CORD |
|
|
REMOTE CONTROL |
| BP67-00304A | SCREEN FRESNEL;K620,MS,1262MM X 720MM, 5 |
| BP67-00305A | SCREEN LENTI;K620,PET,MS,1262MM X 720MM |
|
|
SMPS-DLP TV;PN082DPS-VF(A),AC/DC,90V-132 |
| BP40-00001A | TUNER;DTVS305CV201A,DTVS305CV201A,ATSC/N |
