Manufacturer
Samsung
Model Number
LC27JG50QQNXZA
Description
27-inch Jg50 Wqhd Monitor
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 0201-001457 | ADHESIVE-AA |
|
|
ASSEMBLY BOARD P-FUNCTION JOG |
| BN96-42023C | ASSEMBLY CHASSIS FRONT P |
| BN96-47106A | ASSEMBLY COVER P-CLEAN BACK TE |
| BN96-47104A | ASSEMBLY COVER P-REAR |
| BN96-42212B | ASSEMBLY FRAME P MIDDLE |
| BN96-47038A | ASSEMBLY LED BAR P |
| BN96-41990A | ASSEMBLY OPEN CELL |
| BN94-13220A | ASSEMBLY PCB MAIN |
|
|
ASSEMBLY STAND P-COVER BODY |
|
|
ASSEMBLY STAND P-COVER NECK |
| BN96-39762C | ASSEMBLY STAND P-COVER TOP |
| BN94-11861C | ASSY PCB FUNCTION |
| 6902-000609 | BAG ROLL |
| BN64-02286E | BUTTON-FUNCTION |
| 3701-001670 | CONNECTOR-DISPLAY PORT |
| 3701-001967 | CONNECTOR-HDMI |
| BN63-17827A | COVER-CLEAN BACK TERMINAL |
| BN63-02183L | COVER-SHEET |
| BN63-02183C | COVER-SHEET |
| BN63-17828A | COVER-TERMINAL SIDE |
|
|
DC VSS(A) |
| BN96-38748P | FFC CABLE |
| BN67-00327J | FOOT-RUBBER |
| 3601-001926 | FUSE-SURFACE MOUNT |
| BN63-12151A | GASKET-EMI |
| BN39-01997C | HDMI CABLE |
| 3711-008646 | HEADER BOARD TO CABLE |
|
|
HEADER-BOARD TO CABLE |
| 3711-005872 | HEADER-BOARD TO CABLE |
| BP61-00495C | HOLDER-CARE |
|
|
HOLDER-STAND |
| BN64-03890C | INLAY |
|
|
JACK-DC POWER |
| 3722-003216 | JACK-PHONE |
| BN68-07667A | LABEL |
| BN68-03920C | LABEL BOX |
| BN68-00513F | LABEL-AMS |
| BH68-40364A | LABEL-BLANK |
| AK68-02233C | LABEL-RATING |
| BN68-01570A | LABEL-RATING |
| BN68-04551A | LABEL-TWO DIMENSIONAL CODE |
| BN68-00129A | LABELSHIPPING |
| BN39-01878E | LEAD CONNECTOR-SUB ASSEMBLY |
| BN68-04972G | LEAFLET-REGULATORY GUIDE |
| BN68-03677A | LEAFLET-WARRANTY |
| BN68-00226M | MANUAL FLYER-WARRANTY |
| BN69-17053D | PACKING ANGLE |
| BN41-02578B | PCB-FUNCTION |
| BN95-04362F | PRODUCT LCD DP |
| BN95-05245A | PRODUCT LCD-SDC |
|
|
SCREW-MACHINE |
|
|
SCREW-MACHINE |
| 6001-002685 | SCREW-MACHINE |
|
|
SCREW-TAPTYPE |
|
|
SCREW-TAPTYPE |
|
|
SCREW-TAPTYPE |
|
|
SCREW-TAPTYPE |
|
|
SCREW-TAPTYPE |
| BN63-10945B | SHEET-PROTECTION COVER |
| 0202-001919 | SOLDER-CREAM |
| 0202-001608 | SOLDER-WIRE FLUX |
|
|
SPRING ETC-STAND |
| BN61-02932E | STUD-PEM |
| 3404-001490 | SWITCH-TACT |
| BN02-00043Y | TAPE SINGLE FACE |
| BN02-00043T | TAPE SINGLE FACE |
| BN74-00008D | TAPE-SINGLE FACE |
| BN02-00352E | TAPE-SINGLE FACE |
| 0203-001598 | TAPE-SINGLE FACE |
| BN69-11504A | WRAP VINYL |
