Model Image
Manufacturer

Samsung

Model Number

LH82QEREBGCXZA

Description

82 Inch 4k Led Tv

Interactive Exploded View

Parts List

Part Number Description
BN81-16406A A/S-IC DRIVER SOURCE;IC DRIVER SOURCE,LJ
BN96-48730B ASSY BOARD P-FUNCTION TACT;QE82R,CT20SH0
BN96-49697A ASSY COVER P-REAR;82QER,PC+ABS+ED20%,5VB
BN96-40152A ASSY HOLDER P-CABLE;65KS7500,ABS,BK0007,
BN96-48378A ASSY LED BAR P;19Y_RU8K_82INCH_EDGE_LED
BN94-14787A ASSY PCB MAIN;QER
BN96-45632S ASSY SPEAKER P-FRONT;TV-SPK,QER,6OHM,10W
6902-003159 BAG ROLL;HDPE/PE FOAM,T0.015/T0.5,W2000,
4301-000121 BATTERY-MN;1.5V,R03,10.5X44.5M,7.5G,AAA
3301-002039 3301-002039 BEAD-SMD;26OHM/100MHZ,1.6X0.8MM,TP,7MOHM
BN61-13557K BRACKET-WIRE;55KS7000,SW-C,T1,SILVER,ZIN
BN61-13557G BRACKET-WIRE;55KS7000,SW-C,T1,SILVER,ZIN
BN61-13557F BRACKET-WIRE;55KS7000,SW-C,T1,SILVER,ZIN
2203-006048 C-CER,CHIP;100NF,10%,10V,X7R,TP,1005,T0.
2203-006158 C-CER,CHIP;100NF,10%,16V,X7R,TP,1005,T0.
2203-002711 C-CER,CHIP;100NF,10%,25V,X7R,TP,1608,-55
2203-007544 C-CER,CHIP;100NF,10%,50V,X7R,TP,1005,T0.
2203-005249 C-CER,CHIP;100NF,10%,50V,X7R,TP,1608,-55
2203-002285 C-CER,CHIP;10NF,10%,50V,X7R,TP,1005,-55T
2203-007513 C-CER,CHIP;10UF,10%,10V,X5R,TP,1608,T0.8
2203-007176 C-CER,CHIP;10UF,10%,16V,X5R,TP,2012,T1.2
2203-007306 C-CER,CHIP;10UF,10%,25V,X5R,TP,2012,T1.2
2203-007423 C-CER,CHIP;10UF,10%,35V,X7R,TP,3216,-55T
2203-006348 C-CER,CHIP;1UF,10%,25V,X5R,TP,1608,T0.8,
2203-006698 C-CER,CHIP;1UF,10%,25V,X7R,TP,1608,T0.8,
2203-005918 C-CER,CHIP;1UF,10%,6.3V,X7R,TP,1608,T0.8
2203-008096 C-CER,CHIP;2.2UF,10%,50V,X5R,TP,2012,T1.
2203-005083 C-CER,CHIP;220NF,10%,50V,X7R,TP,1608,T0.
2203-005642 C-CER,CHIP;220PF,5%,50V,C0G,TP,1005,T0.5
2203-000627 C-CER,CHIP;22PF,5%,50V,C0G,TP,1005,-55TO
2203-008315 C-CER,CHIP;22UF,20%,25V,X5R,TP,2012,T1.2
2203-005968 C-CER,CHIP;4.7NF,10%,50V,X7R,TP,1005,T0.
2203-006377 C-CER,CHIP;4.7UF,10%,25V,X5R,TP,2012,-55
2203-006844 C-CER,CHIP;470NF,10%,10V,X5R,TP,1005,-55
2203-001428 C-CER,CHIP;470NF,10%,50V,X7R,TP,2012,-55
2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005,T0.5
2203-000998 C-CER,CHIP;47PF,5%,50V,C0G,TP,1608,T0.8,
2409-001168 C-EDL;200000UF,3.3V,0.01MA,TP,6.8X11.3MM
2409-001240 C-ORGANIC,SMD;33UF,20%,25V,LR,TP,7343
2409-001191 C-ORGANIC,SMD;47UF,20%,20V,TP,7343(1.9T)
6801-001760 CARD INFORMATION;MEXICO,SPANISH,W/P,W215
3701-001967 CONNECTOR-HDMI;19P,A,FEMALE,AU,0.5MM,BLK
3711-007975 3711-007975 CONNECTOR-HEADER;BOX,10P,1R,1.25MM,SMD-A
2801-003773 CRYSTAL-SMD;12MHZ,30PPM,28-AAN,20PF,50OH
2801-004021 CRYSTAL-SMD;24.576MHZ,20PPM,28-AAN,12PF,
BN44-01006A DC VSS-PD BOARD;F82E8_RHS,AC/DC,305W,AC1
0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200MA,SOT-23,
0404-001953 DIODE-SCHOTTKY;MBRA340F-HAF,40V,3000MA,S
0404-001640 DIODE-SCHOTTKY;SS1060HEWS,60V,1000MA,SOD
0404-001976 DIODE-SCHOTTKY;SV540,40V,5000MA,TO-277,T
0401-001099 DIODE-SWITCHING;1N4148WS,75V,150MA,SOD-3
0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO
0406-001786 DIODE-TVS;PJEC5V0V6TM,5V,7V,8V,0.1MAV,9V
0406-001778 DIODE-TVS;PUSB3FR4,6V,9V,0.2MAV,0.7VPA,0
0406-001718 DIODE-TVS;SMF36A,40V,44.2V,3.8MAV,1.25VP
0403-001797 DIODE-ZENER;NZH3V0B,2.85~3.15V,500MW,SOD
0505-003397 FET-SILICON;2N7002K,N,60V,0.38A,1.19OHM,
0505-002917 FET-SILICON;AO3406,N,30V,3.6A,1.4W,SOT-2
0505-003507 FET-SILICON;AO3424,N,30V,3.8A,1.4W,SOT-2
0505-002560 FET-SILICON;AO6415,P,20V,-3.3A,0.15OHM,1
0505-003620 FET-SILICON;AOD4286,N,100V,14A,55.5MOHM,
0505-003752 FET-SILICON;AONR21321,P,30V,50A,0.035OHM
0505-002598 FET-SILICON;AP2317GN,P,20V,-4.2A,0.052OH
0505-003205 FET-SILICON;DMG4435SSS-13,P,30V,-7.3A,1.
BN96-39820H BN96-39820H FFC CABLE;65/75NU8000,FOLD,L500,96P,-
BN96-39903C BN96-39903C FFC CABLE;65/75NU8000,FOLD,L650,96P,-
3601-001376 3601-001376 FUSE-SURFACE MOUNT;32V,3A,FAST-ACTING,HI
BN39-01545B BN39-01545B GENDER CABLE;PROTON,3P,200,UL2547,BLK,ST
3711-007803 HEADER-BOARD TO CABLE;BOX,12P,1R,1.25MM,
3711-008859 HEADER-BOARD TO CABLE;BOX,12P,2R,2MM,ANG
3711-008098 HEADER-BOARD TO CABLE;BOX,20P,1R,1.25MM,
3711-008131 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5MM,AN
1001-001680 IC-ANALOG MULTIPLEX;TC7SB3157CFU,CMOS,US
1001-001545 IC-ANALOG MULTIPLEX;TS3USB221ERSER,R-PQF
1201-003690 IC-AUDIO AMP;TAS5747PHPR,QFP,48P,DUAL,PL
0801-002780 IC-CMOS LOGIC;74LVC1G17,SCHMITT-TRIGGER
0801-002628 IC-CMOS LOGIC;7SZ08,2-INPUT AND GATE,SC-
1301-002160 IC-CPLD;SLG4P4190VTR,TQFN20,20P,3X2MM,21
1203-009197 IC-DC/DC CONVERTER;RT6203E,SOP-8,8P,5X4X
1203-009194 IC-DC/DC CONVERTER;SYD104IADC,TSOT23-6,6
1203-008920 IC-DC/DC CONVERTER;SYD105ADC,TSOT23,6P,2
1203-009193 IC-DC/DC CONVERTER;SYD113IADC,TSOT23-6,6
1203-009198 IC-DC/DC CONVERTER;TPS549A20,VQFN-CLIP,2
1203-009063 IC-DC/DC CONVERTER;VPM2SM,QFN,56P,7X7X0.
1105-002992 IC-DDR4 SDRAM;MT53E256M32D2DS-053 WT:B,L
1105-002989 IC-DDR4 SDRAM;MT53E384M32D2DS-053 WT:E,L
1204-003775 IC-DECODER;SDP1803,FCBGA,929P,31X31X2.19
1006-001509 IC-DRIVER/RECEIVER;MAX3222ECPWR,TSSOP,20
1107-002590 IC-EMMC;KLM8G1GETF-B041007,8GBYTE,64GBX1
1205-005952 IC-LCD CONTROLLER;SE18S01-NT,PBGA,202P,1
1003-003029 IC-LEVEL DRIVER;VLS3GM,QFN,40P,6X6X0.9MM
1107-002226 IC-NOR FLASH;W25Q40CLSSIP,4MBIT,SOIC,8P,
1201-004217 IC-OP AMP;TLV9062,SOP,ST,8P,DUAL,PLASTIC
1203-009186 IC-POSI.ADJUST REG.;TLV759P01PDRVR,TP,6P
1209-002183 1209-002183 IC-SENSOR;S-5851AAA-M6T1U,SOT,6Z30,2.9X1
1205-005519 IC-SWITCH;ET20163,SOT23-5,5P,2.95X3.02MM
1205-005749 IC-SWITCH;G2897KD1U,TDFN2X3-14,14P,2X3MM
1203-009188 IC-VOL. DETECTOR;G623F11U,TP,8P,4.9X6X1.
2703-003713 INDUCTOR-SMD;1.5UH,20%,7366,T3,0.015OHM,
2703-005376 INDUCTOR-SMD;10UH,20%,10.7X10MM,T3.8,0.0
2703-003862 INDUCTOR-SMD;10UH,20%,6060,0.065OHM,1900
2703-005193 INDUCTOR-SMD;2.2UH,20%,6060,T4.5,0.024OH
2703-003747 INDUCTOR-SMD;22UH,20%,6060,0.135OHM,1300
2703-005194 INDUCTOR-SMD;3.3UH,20%,6060,T4.5,0.03OHM
2703-004724 INDUCTOR-SMD;8.2UH,20%,5050,T4,0.072OHM,
3722-003199 JACK-MODULAR;8P/8C,Y,ANGLE,NONE,AU,1PORT
3722-003216 JACK-PHONE;1P/7C,AU,BLK,SMD-A,3.6PI,10.2
3722-003667 JACK-PHONE;1P/7C,NI+SN,BLK,STRAIGHT,3.6P
3722-003248 JACK-USB;4P/1C,BLK,STRAIGHT,A,2.0,14.6X1
3722-003457 3722-003457 JACK-USB;4P/1C,NI,BLK,ANGLE,A,2.0,13.1X1
BN39-02217F BN39-02217F LEAD CONNECTOR-POWER;70KU6000,UL21016,12
BN39-02465A LEAD CONNECTOR-SUB ASSY;49, 55 Q70,UL214
BN39-02457B LEAD CONNECTOR-SUB ASSY;Q70,UL21016,12P,
BN59-01314A BN59-01314A NETWORK-WLAN CLIENT;WCP730M,78.3X29.3X7.
3903-001132 3903-001132 POWER CORD-DT;USA,2P-F,125V,7A,BLK,L3000
BN95-05764A PRODUCT LCD-SDC;CY-NR082FGLVZH/V,QER,BAS
2007-008596 R-CHIP;0.1OHM,1%,1/4W,TP,3216
2007-008779 R-CHIP;0OHM,1%,1/16W,TP,1005,T0.05,GENER
2007-009322 R-CHIP;1.3KOHM,1%,1/16W,TP,1005
2007-000052 R-CHIP;10KOHM,1%,1/10W,TP,1608
2007-002899 R-CHIP;10OHM,1%,1/10W,TP,1608
2007-000343 R-CHIP;120OHM,1%,1/10W,TP,1608
2007-000078 R-CHIP;1KOHM,5%,1/10W,TP,1608
2007-007992 R-CHIP;1OHM,1%,1/10W,TP,1608
2007-002906 R-CHIP;200KOHM,1%,1/10W,TP,1608
2007-007767 R-CHIP;200OHM,1%,1/16W,TP,1005
2007-000066 R-CHIP;20KOHM,1%,1/10W,TP,1608
2007-007520 R-CHIP;20OHM,1%,1/10W,TP,1608
2007-007008 R-CHIP;300OHM,5%,1/16W,TP,1005,T0.35
2007-008175 R-CHIP;330OHM,1%,1/16W,TP,1005
2007-000772 R-CHIP;33KOHM,1%,1/10W,TP,1608,T0.45
2007-000779 R-CHIP;33OHM,1%,1/10W,TP,1608
2007-008294 R-CHIP;33OHM,1%,1/16W,TP,1005,T0.35
2007-008298 R-CHIP;49.9OHM,1%,1/16W,TP,1005,T0.35
2007-000979 R-CHIP;5.6KOHM,1%,1/10W,TP,1608
2007-007736 R-CHIP;510KOHM,1%,1/10W,TP,1608
2007-001125 R-CHIP;68KOHM,1%,1/10W,TP,1608
2011-001587 R-NETWORK;100OHM,5%,1/16W,L,CHIP,4P,TP,1
2011-001448 R-NETWORK;10OHM,5%,1/16W,L,4P,TP,1.0X1.0
2011-001264 R-NETWORK;10OHM,5%,1/16W,L,CHIP,8P,TP,2.
2011-001527 R-NETWORK;4.7KOHM,5%,1/16W,L,CHIP,4P,TP,
BN59-01180A BN59-01180A REMOCON-TV;2013 LFD,SAMSUNG,44KEY,3V,14Y
6001-003016 6001-003016 SCREW-MACHINE;PWH,+,M3,L5.0,ZPC(WHT),SWR
3407-000183 SWITCH-DIP;50V,100MA,SLIDE,STANDARD
0504-000126 TR-DIGITAL;KSR1101,NPN,200MW,4.7K/4.7K,S
0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150MW,SOT
1405-001381 VARISTOR;11V,8VDC,30A,1608,TP,25V,500PF
1405-001382 VARISTOR;24.5V,16VDC,120A,2012,TP,42V,40
1405-001271 1405-001271 VARISTOR;35V,20VDC,5A,1005,TP,100V,10PF
1405-001232 VARISTOR;6.4V,5.6VDC,30A,1608,TP,19V,200
