Manufacturer
Samsung
Model Number
LU32J590UQNXZA
Description
32-inch Uj590 Uhd Monitor
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| BN81-01918A | A/S-RESIN;EPS,SG-302 |
| BN96-39758A | ASSEMBLY BOARD P-FUNCTION JOG |
| BN94-07238T | ASSEMBLY PCB FUNCTION-BN96-397 |
| BN94-12191N | ASSEMBLY PCB MAIN |
| BN97-09080K | ASSEMBLY SMD , CF39,BN96-39758 |
| BN96-46465A | ASSEMBLY STAND P-COVER NECK |
| BN96-54483A | ASSEMBLY STAND P-COVER TOP |
|
|
ASSEMBLY STAND P-COVER TOP |
| 6902-000001 | BAG AIR |
| 6902-000379 | BAG AIR |
| 6902-000519 | BAG PE |
| 6902-000476 | BAG PE |
| 6902-000110 | BAG PE |
| 6902-002963 | BAG PE , HDPE/PE FOAM,T0.015/T |
| 6902-002784 | BAG PE , HDPE/PE FOAM,T0.015/T |
| BH69-00418A | BAG PE-WRAPPING FILM |
| 6902-003676 | BAG ROLL |
| 6902-000609 | BAG ROLL |
| 6902-003713 | BAG ROLL , HDPE/PE FOAM,T0.015 |
| 6902-002594 | BAG ROLL , HDPE/PE FOAM,T0.015 |
| 6902-002380 | BAG ROLL;HDPE/PE FOAM+HDPE,T0. |
| BN63-06461A | BAG ROLL;HDPE/PE FOAM,T0.5/T0. |
| 6902-000604 | BAG WRAPPING |
| 6902-000258 | BAG ZIPPER |
| 6922-000003 | BAND |
| 6922-000421 | BAND;PP,T0.8,W18,L2300,TRP,REC |
| 3301-001404 | BEAD-SMD |
| 3301-001560 | BEAD-SMD |
|
|
BEAD-SMD |
| BN61-13638A | BRACKET-STAND TOP;27CF398,HGI, |
| BN61-08997A | BRACKET-VESA , EGI-SECC,T0.8,N |
| BN64-03398A | BUTTON-CONTROL |
| BN64-03400A | BUTTON-FUNCTION |
| 2402-001408 | C-AL, SMD |
| 2203-008315 | C-CER, CHIP |
| 2203-000257 | C-CER, CHIP |
| 2203-000440 | C-CER, CHIP |
| 2203-000575 | C-CER, CHIP |
| 2203-000627 | C-CER, CHIP |
| 2203-001103 | C-CER, CHIP |
| 2203-002285 | C-CER, CHIP |
| 2203-005083 | C-CER, CHIP |
| 2203-005194 | C-CER, CHIP |
| 2203-005249 | C-CER, CHIP |
| 2203-006048 | C-CER, CHIP |
| 2203-006126 | C-CER, CHIP |
| 2203-006158 | C-CER, CHIP |
| 2203-006348 | C-CER, CHIP |
| 2203-006698 | C-CER, CHIP |
| 2203-007176 | C-CER, CHIP |
| 2203-007306 | C-CER, CHIP |
| 2203-007486 | C-CER, CHIP |
| 2203-007513 | C-CER, CHIP |
| 2203-007544 | C-CER, CHIP |
| 2203-008412 | C-CER,CHIP |
| 2203-006824 | C-CER,CHIP;4.7UF,10%,10V,X5R,T |
| 2409-001191 | C-ORGANIC, SMD |
| 2409-001129 | C-POLYMER, CHIP |
| 3701-001670 | CONNECTOR-DISPLAY PORT |
|
|
CONNECTOR-FPC/FFC/PIC |
| 3701-001967 | CONNECTOR-HDMI |
| BN96-46448A | COVER ASSEMBLY P-FRONT |
| BN96-46449A | COVER ASSEMBLY P-REAR |
| BN63-02183B | COVER-SHEET |
| BN63-02183L | COVER-SHEET |
| BN63-15486A | COVER-STAND BOTTOM;27CF398,ABS |
| 2801-003773 | CRYSTAL-SMD |
|
|
DC VSS(A) |
| 0404-001307 | DIODE-SCHOTTKY |
| 0404-001595 | DIODE-SCHOTTKY |
| 0401-001056 | DIODE-SWITCHING |
| 0401-001099 | DIODE-SWITCHING |
| 0406-001438 | DIODE-TVS |
| 0406-001635 | DIODE-TVS |
| 0403-001382 | DIODE-ZENER |
| 0403-001411 | DIODE-ZENER |
| 0403-001779 | DIODE-ZENER |
| 0403-001900 | DIODE-ZENER |
| 0403-001976 | DIODE-ZENER , MM3Z6V2B,6.06~6. |
| 0403-001783 | DIODE-ZENER;BZB84-C6V2,5.8~6.6 |
| 0505-002560 | FET-SILICON |
| 0505-003391 | FET-SILICON |
| 0505-003397 | FET-SILICON |
| BN96-38748N | FFC CABLE |
| BN67-00327S | FOOT-RUBBER |
| 3601-001926 | FUSE-SURFACE MOUNT |
| BN63-00520A | GASKET |
| BP63-00835A | GASKET-EMI |
| AA63-01141C | GASKET-EMI |
| BN63-07349A | GASKET-EMI;EMI SHIELDING,FABRI |
| BN63-03996B | GASKET-EMI;LE40F86BDX,FABRIC,T |
| BN74-00120A | GREASE , LUBTECH P 90B,GREASE |
| BN39-01997C | HDMI CABLE |
| 3711-008646 | HEADER BOARD TO CABLE |
| 3711-005872 | HEADER-BOARD TO CABLE |
|
|
HEADER-BOARD TO CABLE |
| BP61-00495C | HOLDER-CARE |
|
|
HOLDER-STAND |
|
|
HOLDER-STAND |
| BN61-13332A | HOLDER-STAND , CF390,POM,WHITE |
| 1105-003109 | IC DDR2 SDRAM |
| 1107-002547 | IC NOR FLASH |
| 1203-008027 | IC-BACKLIGHT DRIVER , SLC5014R |
| 1205-003201 | IC-BUS SWITCH |
| 1203-008921 | IC-DC/DC CONVERTER |
| 1203-008082 | IC-DC/DC CONVERTER |
| 1203-008118 | IC-DC/DC CONVERTER |
| 1203-009193 | IC-DC/DC CONVERTER;SYD113IADC, |
| 1203-008063 | IC-DC/DC CONVERTER;TPS54540DDA |
| 1204-003657 | IC-DECODER |
| 1103-001564 | IC-EEPROM |
| 1103-001583 | IC-EEPROM;BR24T02FJ-WGE2,2KBIT |
| 1103-001646 | IC-EEPROM;M24C02-RMN6T,2KBIT,X |
| 1203-009643 | IC-POSI.ADJUST REG.;ET5A0ADJY2 |
| 1203-006118 | IC-POSI.FIXED REG. |
| 1203-007151 | IC-PWM CONTROLLER |
| 1205-004704 | IC-SWITCH |
| 2703-005194 | INDUCTOR-SMD |
| 2703-003713 | INDUCTOR-SMD |
| 2703-003719 | INDUCTOR-SMD |
| 2703-003867 | INDUCTOR-SMD |
| 2703-004145 | INDUCTOR-SMD , 2.2UH,20%,7066, |
| 2703-004575 | INDUCTOR-SMD;22UH,20%,16X15MM, |
| BN64-03890C | INLAY;27CJG5,PS,T0.3,W51,L125, |
|
|
JACK-DC POWER |
| 3722-003216 | JACK-PHONE |
| BN46-00700A | KEY CODE-CERTIFICATION;CHG70,2 |
| BN68-12374A | LABEL BAR CODE , ALL,THERMAL P |
| BN68-03920C | LABEL BOX |
| BH68-00634A | LABEL BOX-00 |
| BN68-03920A | LABEL BOX;ALL,ART,W100,L75,W/W |
| BH68-00697A | LABEL BOX;ALL,ART,W60,L100,WHT |
| BN68-04746A | LABEL ETC;ALL,PET,W25.4,L9.53, |
| BN68-00513F | LABEL-AMS;ALL MONITOR,WW,ART,W |
| BH68-40364A | LABEL-BLANK |
| BN68-05603A | LABEL-E PASS;ART,W/W,90G |
| BN68-00513A | LABEL-E, PASS |
| BN68-01870A | LABEL-MISC;MOJO,W10,L30 |
| BN68-01570A | LABEL-RATING |
| BN68-07103D | LABEL-RATING;ALL,WW,PP,T0.1,W9 |
| BN68-07103B | LABEL-RATING;MONITOR,WW,PE,T0. |
| BN68-05603E | LABEL-RESIN;ART,W8,L50,UL LABE |
| AA68-00364B | LABEL-SERIAL |
| BN68-04169A | LABEL-SMD;SBB,22,10,WHITE |
| BN68-06922R | LABEL-STICKER;MONITOR,ART,W50, |
| BN68-04551A | LABEL-TWO DIMENSIONAL CODE;PAP |
| BN68-07667A | LABEL;ALL,ART,W80,L75,WIN10,90 |
| BN68-00129A | LABELSHIPPING |
| BN07-01589B | LCD-PANEL;M315DJJ-K30 C2,CMV5J |
| BN39-02408A | LEAD CONNECTOR-BLU |
| BN39-01878P | LEAD CONNECTOR-SUB ASSEMBLY |
| BN68-04972H | LEAFLET-REGULATORY GUIDE;LFD/L |
| BN68-04972G | LEAFLET-REGULATORY GUIDE;LFD/L |
| BN68-15181A | LEAFLET-SAFETY GUIDE;MONITOR,Z |
| BN68-03677A | LEAFLET-WARRANTY;QR,1YEAR,US,M |
| 0601-001896 | LED |
| BN67-00559A | LENS-LED |
| AA61-30009A | LOCKER-BAND, CLIP |
| BN94-13067A | MAIN PCB ASSEMBLY |
| BN68-00226M | MANUAL FLYER-WARRANTY |
| BN69-17053D | PACKING ANGLE;ALL,PAPER,T3,W20 |
| BN69-17053P | PACKING ANGLE;ALL,PAPER,T3,W22 |
| BN69-09401A | PACKING ANGLE;ALL,PAPER,YELLOW |
| BN69-24708A | PACKING ROLL , LDPE,T0.05,W280 |
| BH69-00457B | PACKING-PAD |
| BH69-00376C | PACKING-PALLET |
| BN73-00024G | PAD GAP-THERMAL;SB240,SILICON, |
| BN69-02240G | PALLET-WOODEN , LF19PP,WOOD,W9 |
| BN41-02522A | PCB-FUNCTION , CF770,FR-4,2L,T |
| 2007-007306 | R-CHIP |
| 2007-001206 | R-CHIP |
| 2007-000708 | R-CHIP |
| 2007-000239 | R-CHIP |
| 2007-000219 | R-CHIP |
| 2007-000029 | R-CHIP |
| 2007-000052 | R-CHIP |
| 2007-000060 | R-CHIP |
| 2007-000071 | R-CHIP |
| 2007-000082 | R-CHIP |
| 2007-000084 | R-CHIP |
| 2007-000090 | R-CHIP |
| 2007-000102 | R-CHIP |
| 2007-000109 | R-CHIP |
| 2007-000127 | R-CHIP |
| 2007-000134 | R-CHIP |
| 2007-000309 | R-CHIP |
| 2007-000536 | R-CHIP |
| 2007-000602 | R-CHIP |
| 2007-000755 | R-CHIP |
| 2007-000910 | R-CHIP |
| 2007-000939 | R-CHIP |
| 2007-000962 | R-CHIP |
| 2007-001007 | R-CHIP |
| 2007-002906 | R-CHIP |
| 2007-007049 | R-CHIP |
| 2007-007668 | R-CHIP |
| 2007-008067 | R-CHIP |
| 2007-008121 | R-CHIP |
| 2007-008269 | R-CHIP |
| 2007-008294 | R-CHIP |
| 2007-008766 | R-CHIP |
| 2007-008779 | R-CHIP |
| 2007-008807 | R-CHIP |
| 0103-010866 | RESIN ABS PMMA;SF-0950/K24313, |
| 0103-004609 | RESIN ABS;HF-0680U,K21294,BK00 |
| 0103-010861 | RESIN ABS;HF-0680U/K24313,DARK |
| 0103-005036 | RESIN PC;SC-1220R/ENP,TRANSPAR |
| 0103-009674 | RESIN POM , F20-03/WT0069,WHIT |
| 6003-000264 | SCREW-TAPTYPE |
|
|
SCREW-TAPTYPE |
|
|
SCREW-TAPTYPE |
|
|
SCREW-TAPTYPE |
|
|
SCREW-TAPTYPE |
| BN61-12346A | SCREW-TAPTYPE;SWRCH18A,ZPC(BLK),L8,M4,FH |
| BN63-02183E | SHEET-PROTECTION COVER |
| BN63-17418N | SHEET-PROTECTION COVER;QTQ60F, |
| BN63-07229G | SHEET-PROTECTION COVER;ROSE70 |
| BN97-13649A | SMG PART |
| BN69-21424F | SMG PART |
| BN69-17053Y | SMG PART |
| BN68-20411A | SMG PART |
| BN68-15181C | SMG PART |
| BN68-12929A | SMG PART |
| BN68-09371G | SMG PART |
| BN60-00231D | SMG PART |
| 2703-003149 | SMG PART |
| 2203-007270 | SMG PART |
| 2203-007269 | SMG PART |
| 2203-007240 | SMG PART |
| 2203-006890 | SMG PART |
| 2203-006838 | SMG PART |
| 2203-006562 | SMG PART |
| 2203-006474 | SMG PART |
| 2203-006427 | SMG PART |
| 2203-003019 | SMG PART |
| 2203-000995 | SMG PART |
| 2203-000812 | SMG PART |
| 2203-000714 | SMG PART |
| 2203-000585 | SMG PART |
| 2203-000489 | SMG PART |
| 2203-000438 | SMG PART |
| 2203-000359 | SMG PART |
| 2203-000233 | SMG PART |
| 2007-009117 | SMG PART |
| 2007-008672 | SMG PART |
| 2007-008137 | SMG PART |
| 2007-008117 | SMG PART |
| 2007-007588 | SMG PART |
| 2007-007491 | SMG PART |
| 2007-007488 | SMG PART |
| 2007-007470 | SMG PART |
| 2007-007318 | SMG PART |
| 2007-007312 | SMG PART |
| 2007-007310 | SMG PART |
| 2007-007308 | SMG PART |
| 2007-007139 | SMG PART |
| 2007-007138 | SMG PART |
| 2007-001292 | SMG PART |
| 2007-000539 | SMG PART |
| 2007-000173 | SMG PART |
| 2007-000172 | SMG PART |
| 2007-000171 | SMG PART |
| 2007-000165 | SMG PART |
| 2007-000162 | SMG PART |
| 2007-000159 | SMG PART |
| 2007-000157 | SMG PART |
| 2007-000148 | SMG PART |
| 2007-000143 | SMG PART |
| 2007-000140 | SMG PART |
| 2007-000138 | SMG PART |
| 2007-000137 | SMG PART |
| 2007-000070 | SMG PART |
| 1105-002660 | SMG PART |
| 0601-003922 | SMG PART |
| 0404-001089 | SMG PART |
| 0103-012665 | SMG PART |
| 0103-012086 | SMG PART |
| 0103-004631 | SMG PART |
| 0202-001976 | SOLDER-CREAM;LST-309M-K21 (PWM |
| 0202-001919 | SOLDER-CREAM;M705-GRN360-K2-VT |
| 0202-001830 | SOLDER-CREAM;PFM-48W LT-SH,D20 |
| 0202-001608 | SOLDER-WIRE FLUX |
| BN60-00162G | SPACER-FOAM |
| BN61-13319A | SPRING ETC-PLATE , SF350/SF390 |
| BN61-04216A | SPRING ETC-STAND |
| 0101-003397 | STEEL PLATE , EGI,SECC,T0.8,E2 |
| BN61-02932E | STUD-PEM |
| 3404-001490 | SWITCH-TACT |
| 0203-001100 | TAPE-OPP |
| 0203-001269 | TAPE-OPP MASKING |
| BN02-00102K | TAPE-SINGLE FACE;FILAMENT,T0.1 |
| 0203-006894 | TAPE-SINGLE FACE;OPP,3M, #3675 |
| BN02-00319A | TAPE-SINGLE FACE;OPP,T0.05,W60 |
| BN74-00008D | TAPE-SINGLE FACE;OPP,T0.05,W75 |
| BN02-00102B | TAPE-SINGLE FACE;OPP,T0.15,W25 |
| BN74-00053G | TAPE-SINGLE FACE;PAPER,3M2307, |
| 0501-000445 | TR-SMALL SIGNAL |
| 1405-001185 | VARISTOR |
|
|
VARISTOR |
| BN69-11504A | WRAP VINYL;LDPE,T0.018,W500,L1 |
