Manufacturer
Samsung
Model Number
ME18H704SFB
Description
1.8 Cu. Ft. Over-the-range Microwave
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| DE42-10018E | ANTENNA-CERAMIC;16 X 12 X 10 |
| DE99-00234A | ASSY ANODE;MGT-RHN, |
| DE94-02906C | ASSY BASE BOTTOM;ME18H704SF,EGI-SECC |
| DE94-02379C | ASSY BASE PLATE;SMH2117,SPP,T0.6,ED COAT |
|
|
ASSY BODY LATCH;SMH2177, JVM 1950,ML1-MD |
| DE99-00237A | ASSY CATHODE;MGT-RHN, |
| DE94-03162A | ASSY CONTROL PANEL;ME18H704SFB,BLACK,PC |
| DE94-02367B | ASSY COVER MOTOR;59285042,SECC,T0.6,CANA |
|
|
ASSY COVER-FRONT;GE MD4, PREMIUM,SPP,T0. |
|
|
ASSY DOOR E;SMH7175,,COATING |
| DE94-03159A | ASSY DOOR;ME18H704SFB,BLACK,PC |
| DE94-02372A | ASSY DUCT EXHAUST;85052,SGCC,T0.5,SEARS |
|
|
ASSY DUCT UPPER;85053,SECC,T0.4,MHC4, LA |
|
|
ASSY GUIDE ROLLER;3RD-1.0 CMO,,PI15 |
|
|
ASSY HANDLE;SMH1816B,PC,BLK,ML1-MD4,BETT |
|
|
ASSY HARD WARE;SMH1611B/XAA,SS MD-3 |
|
|
ASSY HOLDER-NUT;OTR6,SK5(T0.5) + S10C |
|
|
ASSY HVC;SMH7175,,0.91UF HVC, |
|
|
ASSY MGT |
|
|
ASSY NOISE FILTER;SN-UF12E,250V/20A,250V |
| DE99-00235A | ASSY OUTPUT;MGT-RHN, |
|
|
ASSY PCB MAIN;ME18H704SFS,ME7000HA_1.8,1 |
|
|
ASSY STIRRER;85053,MHC-4,ALP T0.6,SEARS |
|
|
ASSY THERMOSTAT;JVM-1750DP,164D5312G013, |
| DE96-01047A | ASSY WIRE HARNESS-DISPLAY;ME18H704,120V/ |
|
|
ASSY WIRE HARNESS-EARTH;OTR6ALLMODEL,120 |
|
|
ASSY WIRE HARNESS-MAIN;ME18H704,120V/60H |
|
|
ASSY WIRE HARNESS-POWER;ME21F707MJT,120V |
|
|
ASSY WIRE HARNESS-SENSOR;SMH7185WG/XAA,1 |
|
|
ASSY-BOTTOM LATCH;SMH1927,PBT,ML1-MD4, O |
| DE92-90242D | ASSY-HOOD DAMPER;JVM-1870,JVM250BL OTR |
| DE99-00224A | ASSY-ROD END;MGT-RHN,7.5*43.8 |
|
|
BADGE LOGO INLET;NI,T0.08,W9.19,L65,BLAC |
|
|
BLADE-FAN;MODULAR4,PP |
|
|
BOLT-FLAT;MSWR,L100,UNF1/4 |
|
|
BOLT-HEX;M6,L50,ZPC(WHT),SWRCH18A,HH HEA |
|
|
BOLT-TOGGLE;MSWR,W3/16X75,MSWR |
| DE61-00162A | BRACKET EARTH;JVM-1860,EGI-SECC,T0.5,W39 |
| DE61-00115A | BRACKET-HVC;SMH7175,EGI-SECC,T0.5 |
|
|
BRACKET-TCO;GI-SGCC,T0.8 |
|
|
BUTTON-LOCKING;JVM1950, PVM1970, PVM2170 |
| 2401-000842 | C-AL;220UF,20%,25V,WT,TP,8X11.5MM,5MM |
| 2401-001838 | C-AL;470UF,20%,25V,WT,TP,10X16MM,5MM |
| 2401-000040 | C-AL;47UF,20%,250V,WT,TP,12.5X25MM,5 |
| 2203-000335 | C-CER,CHIP;0.012NF,5%,50V,C0G,2012 |
| 2203-007306 | C-CER,CHIP;10000NF,10%,25V,X5R,TP,2012,T |
| 2203-006960 | C-CER,CHIP;1000NF,10%,50V,X7R,TP,2012 |
| 2203-000206 | C-CER,CHIP;100NF,10%,50V,X7R,TP,2012,T0. |
| 2203-000260 | C-CER,CHIP;10NF,10%,50V,X7R,TP,2012 |
| 2203-000444 | C-CER,CHIP;1NF,10%,50V,X7R,TP,2012,T1.2 |
| 2201-000987 | C-CERAMIC,DISC;2.2NF,20%,400V,Y5U,BK,12. |
|
|
C-FILM,LEAD;10,25TO+70,220V,+10~-5,38X2 |
|
|
C-OIL HIGH VOLTAGE;910NF,2100V,BK,34X54X |
| 6502-001056 | CABLE CLAMP;DAWH-2NC,ID18.5,NYLON6/6,NTR |
| DE73-00019A | CHOKE-RING;H-6,SPCCT-1/4H,T0.25X26X26,NI |
|
|
COUPLER;MMV1163,SPS,MODULAR-3 |
| DE63-00660A | COVER CONNECTOR;MODULAR4,PP,T2,HB,NATURA |
|
|
COVER DAMPER;JVM-1870,MICA SHEET,0.22,68 |
| DE63-00657B | COVER FRONT;GE MD4,CR-SPP,T0.6 |
|
|
COVER LAMP;MODULAR4,EGI-SECC,T0.4 |
|
|
COVER MGT;SMH1927,PP,NATURAL,MT44 (BLACK |
|
|
COVER STIRRER;SMH1927,PP,DARK GREY,ML1 M |
| DE71-00120B | COVER-COOKTOP LAMP;JVM-1860,EGI-SECC,T0. |
|
|
DAMPER-MAIN;EGI-SECC,T0.5 |
|
|
DIODE-BRIDGE;DF06S,600V,1A,SMD-4,TP |
|
|
DIODE-H.V;MWO,2CL4512H/CL04-12A,500MA,12 |
|
|
DIODE-RECTIFIER;US1M,1000V,1A,SMA,TP |
| 0404-001595 | DIODE-SCHOTTKY;B2100,100V,2000MA,SMB,TP |
| 0401-001010 | DIODE-SWITCHING;1N4148W,75V,150MA,400MW, |
| 0403-000258 | DIODE-ZENER;BZX84C5V6,5.2~6V,225MW,SOT-2 |
| 0403-000499 | DIODE-ZENER;MMSZ5230B,5%,500MW,SOD-123,T |
|
|
DOOR C;ME21F707MJT,PP,T1.5,HB,TB53,NATUR |
|
|
DOOR-CAP;MHC4,PP, |
|
|
DOOR-KEY;MODULAR-2,POM,BLK, |
|
|
DUCT-REAR;MODULAR4,EGI-SECC,T0.4 |
|
|
FILTER AIR;SMH7175,AL,T2.0,W150,L340 |
|
|
FILTER-CHARCOAL;SMH7175,ACTIVATED CARBON |
| DE63-20015A | GASKET-R.F;MGT-ALL,BRASS,T2,OD39,ID16.8, |
|
|
GLASS-COOK TOP LAMP;JVM-1860,GLASS,T3.2, |
|
|
GRILLE;SMH1927,PC,W613.8,L79.8,HB,GE BLA |
| DE61-01297A | GUIDE-VENT AIR;MODULAR4,PP |
| 3711-004143 | HEADER-BOARD TO CABLE;BOX,2P/3P,1R,5MM,S |
| 3711-004379 | HEADER-BOARD TO CABLE;BOX,4P,1R,2MM,STRA |
| 3711-003843 | HEADER-BOARD TO CABLE;BOX,8P,1R,2MM,STRA |
| DE62-30032A | HEAT SINK-S1;AL6063,W15,L25.5,WHITE |
|
|
HOLDER FILTER;ME18H704SF,PBT+GF,T3,BLACK |
| DE61-01300A | HOLDER LAMP;MODULAR4,EGI-SECC,T0.4 |
|
|
HOLDER RACK;GE MD4, PREMIUM,POLYSULFONE, |
|
|
HOLDER-SENSOR;POM,NATURAL,HB,K300 |
|
|
HOLDER-STIRRER;MD3,SPS, |
| DE61-00164A | HOLDER-WIRE;OTR8,PP,NATURAL,HB |
| 1103-001183 | IC-EEPROM;24C04,4KBIT,512X8,SOP,8P,5X4MM |
| 1201-001125 | IC-OP AMP;75S01,SOP,5P,63MIL,SINGLE,100D |
| 1203-006245 | IC-VOL. DETECTOR;KIA7033AT,TSM,3P,2.9X1. |
| DE47-00032D | LAMP SOCKET-HALOGEN;250V,UL SPEC,CERAMIC |
| CALL_1-800-SAMSUNG | LAMP SOCKET;250V,UL SPEC,PF,PHENOL,E17,1 |
|
|
LAMP-HALOGEN;120V,20W,NTR,130LM,12X40,9. |
|
|
LAMP-INCANDESCENT;130V,40W,NTR,25X73MM,2 |
|
|
LATCH BODY;JVM1950, PVM1940, PVM2170,PP, |
| DG66-00024A | LATCH-INLET;STEAM_JUPITER,POM |
|
|
LED DISPLAY;7S,4D,HL-LED1045SB-C201-1,74 |
|
|
LEVER SWITCH-LOWER;OTR6,POM,F20-03,NATUR |
| DE73-90014A | MAGNET-CATHODE;FERRITE,T13.1,PMF-2BB |
|
|
MOTOR AC DRIVE;SSM-16HR,8,21V,60HZ,3RPM, |
|
|
MOTOR AC FAN;SMF-U2070B,2,120V,60HZ,25W, |
|
|
MOTOR AC VENTILATION;SMV-U460B,2POLE,120 |
| DE60-30022A | NUT TOGGLE;ZPC,ZPC2 |
|
|
PANEL OUTER;SMH1816B/XAA,EGI-SECC,T0.4, |
| DE62-20011B | PIPE-EXHAUST;MGT-RHN,C1020BD-H,L7,OD12,L |
|
|
PLATE-MOUNTING;GE 1.6 NEW APPEARANCE,GI- |
|
|
POWER CORD-AT;SJT 3X14AWG 105C,GRY,US3S, |
| 2007-000033 | R-CHIP;0OHM,5%,1/4W,TP,3216 |
| 2007-000029 | R-CHIP;0OHM,5%,1/8W,TP,2012 |
| 2007-000285 | R-CHIP;100KOHM,5%,1/4W,TP,3216 |
| 2007-000282 | R-CHIP;100KOHM,5%,1/8W,TP,2012 |
| 2007-000293 | R-CHIP;100OHM,5%,1/4W,TP,3216 |
|
|
R-CHIP;100OHM,5%,1/8W,TP,2012 |
| 2007-000300 | R-CHIP;10KOHM,5%,1/8W,TP,2012 |
| 2007-000355 | R-CHIP;12KOHM,5%,1/8W,TP,2012 |
| 2007-000465 | R-CHIP;1KOHM,1%,1/8W,TP,2012 |
| 2007-000468 | R-CHIP;1KOHM,5%,1/8W,TP,2012 |
| 2007-000532 | R-CHIP;200KOHM,5%,1/8W,TP,2012 |
| 2007-000671 | R-CHIP;2KOHM,5%,1/8W,TP,2012 |
| 2007-000931 | R-CHIP;470OHM,5%,1/8W,TP,2012 |
| 2007-000941 | R-CHIP;47KOHM,5%,1/8W,TP,2012 |
|
|
RACK WIRE;85052, 85053, 85059,MSWR-SWRM, |
| 3501-001324 | RELAY-POWER;12.0V,16000MA,1FORMA,6.5MS,1 |
|
|
SCREW-A;TH,M4,L10,ZPC(WHT),SWRCH18A,2 |
|
|
SCREW-TAPPING;FH,2S,M4,L12,ZPC(BLK),SW |
| DE60-10051A | SCREW-TAPPING;PH,M4,L6,ZPC(WHT),SWRCH1 |
|
|
SCREW-TAPPING;PH,NO,2,M3,L6,ZPC(WHT),S |
|
|
SCREW-TAPPING;PH,NO,2S,M3,L8,ZPC(WHT), |
| 6002-001237 | SCREW-TAPPING;PWH,2,M3,L12,ZPC(WHT),SW |
|
|
SCREW-TAPPING;PWH,2S,M5,L9,SWRCH18 |
| DE60-10067A | SCREW-TAPPING;TH,NO,2,M4,L8,ZPC(BLK),S |
| 6002-000643 | SCREW-TAPPING;TH,NO,2S,M4,L10,ZPC(WHT) |
|
|
SCREW-TAPPING;TH,WT,2,M4,L10,ZPC(WHT), |
| DE81-01903A | SCREW-TAPTYPE;FH,TORX,M4,L16,ZPC(BLK),SW |
|
|
SENSOR GAS;TGS-880, |
| DE71-80022A | SHIELD-TOP;MGT-ALL,MO,T1.95,OD7.5,ID1.74 |
| DE61-01443A | SPRING ETC;HSWR-SWRH,PI 0.6,PI 9.6,PI 10 |
| DE61-00086A | SPRING-KEY;HSWR-SWRH,PI0.95,,D8.35,L47 |
|
|
SUPPORT PCB;PA66 |
| DE34-00427A | SWITCH MEMBRANE;ME18H704SFB,PC,120V,200- |
|
|
SWITCH-MICRO;125/250VAC,16A,200GF,SPST-N |
|
|
SWITCH-MICRO;125/250VAC,16A,200GF,SPST-N |
|
|
THERMOSTAT;AC125-250V,15/10A,140C,0C,GE- |
|
|
THERMOSTAT;AC125/250V,15/10A,120C,0C,VER |
|
|
THERMOSTAT;AC125/250V,15/10A,150C,60C,AC |
|
|
THERMOSTAT;AC125/250V,15/10A,40C,70C,VER |
| 0506-000175 | TR-ARRAY;2003,NPN,7,1000MW,SOP-16,TP,100 |
| 0504-001080 | TR-DIGITAL;KRC246S,NPN,200MW,2.2K/10KOHM |
|
|
TRANS H.V;SHV-U1870D,120V,2545,2385V/3.4 |
|
|
TRAY COOKING;85059,GLASS,T6 |
| DE62-20026A | TUBE-CU;C1020T-H,T0.7,OD18.6,L1800,ILLUS |
| DE62-20025A | TUBE-CU;C1020T-H,T0.725,OD15.35,L1800,IL |
| 1405-000154 | VARISTOR;560V,460VDC,4500A,17.5X7.5MM,BK |
| DE64-00766A | WINDOW-DISPLAY;SMH7175,SAN,T2,HB,CR-5381 |
| DE66-00123A | WIRE-SADDLE;JE620/610BF/WF,PA66,,,,, |
