Model Image
Manufacturer

Samsung

Model Number

ML2550

Description

Ml-2550 Monochrome Laser Printer

Interactive Exploded View

Parts List

Part Number Description
6902-000183 BAG PE: LDPE,T0.05,L400,W320,TRP,8,2,PE M
JC71-00042A BAR-P_CROSS BOTTOM: ML-2060,SECC T1.0,-
JC66-10902A JC66-10902A BEARING-H/R L: ML-165,PPS(RBA313),ID26.2,
JC66-10202A BEARING-PICK UP: ML-80,POM,-,-
JC66-10901A JC66-10901A BEARING-PRESSURE/R: ML-165,PPS,5,14.8
JC69-00454N BOX(P)-MAIN(SEE): ML-2550/SEE,DW,A-1,500,
JC61-00623A BRACKET-P-EXIT: ML-2060,SECC,1.2,77,85,
JC61-00617A BRACKET-P-FUSER: ML-2060,SECC,T1.2,-,
JC61-00622A BRACKET-P-MAIN: ML-2060,SECC,1.6,163,123,
JC61-00755A BRACKET-P-SHAFT MP: ML-2060,SECC,1.2,-,
JC61-00679A BRACKET-P_DUMMY CTRL: ML-2060,SECC,0.6,
JC70-00195A BRACKET-SENSOR: ML-7250,SECC,1.0T,-,-
JC61-00845A BUSH-M-EXIT: ML-2550,POM,5,7,7,WHITE,-
JC61-00665A BUSH-M-FEED, DUP: ML-2060,POM, SW01,4.1,7
JC61-00653A BUSH-M-FINGER,F: ML-2060,POM(M90-44),-,
JC61-00615A JC61-00615A BUSH-M-HR_R: ML-2060,PPS,-,BLK,-
JC61-00657A BUSH-M-RETAINER: ML-2060,POM,-,-,-
JC61-00652A BUSH-M-RETARD: ML-2060,POM(M90-44),-,
JC61-00668A BUSH-M-ROLLER REGI L: ML-2060,POM(M90-44)
JC61-00669A BUSH-M-ROLLER REGI U: ML-2060,POM(M90-44)
JC64-00043A BUTTON-M-POWER: ML-2060,ABS,V0,-
2401-000880 C-AL
2402-000176 C-AL,SMD: 10UF,20%,16V,GP,5353,1.4MM,TP
2401-000042 C-AL: 100UF,20%,16V,GP,6.3X7MM,2.5MM
2203-000426 C-CERAMIC,CHIP
2203-000783 C-CERAMIC,CHIP
2203-000998 C-CERAMIC,CHIP
2203-000257 C-CERAMIC,CHIP: 10NF,10%,50V,X7R,1608,T
2203-000384 C-CERAMIC,CHIP: 15PF,5%,50V,CH,1608,TP
2203-000440 C-CERAMIC,CHIP: 1NF,10%,50V,X7R,1608,TP
2203-000491 C-CERAMIC,CHIP: 2.2NF,10%,50V,X7R,1608,
2203-002392 C-CERAMIC,CHIP: 220NF,+80-20%,50V,Y5V,TP,
2203-000626 C-CERAMIC,CHIP: 22PF,5%,50V,CH,1608,TP
2203-001683 C-CERAMIC,CHIP: 68PF,5%,50V,CH,1608,1.6MM
2201-000119 C-CERAMIC,DISC: 100NF,+80-20%,50V,Y5V,8X5
6501-000004 CABLE_TIE: DA-80,NONE,T1,W2.5,L80,NTR,NYL
JC66-00452A CAM-M-PICK UP MP: ML-2060,POM,-,NTR,-
JC67-00039A CAP-M-GEAR: ML-2060,POM,-,BLK,-
JC67-00037A CAP-M-GUIDE SIDE,L: ML-2060,ABS,-,BLK
JC67-00034A CAP-M-SENSOR: ML-2060,ABS,2.5,-,-
JC67-00036A CAP-M-WIRE PTL LOWER: ML-2060,POM,-,B
JC67-00035A CAP-M-WIRE PTL UPPER: ML-2060,POM,-,B
JC67-00047A CAP-M_BUSHING ACTUATOR: ML-2060,POM,-,-
JC67-00038A CAP-P_BUSHING REGI LOWER: ML-2060,SUS,T0.
JC39-00259A CBF HARNESS-CONNECTOR: ML-2150,CBF,UL 106
JC39-00258A CBF HARNESS-COVER OPEN: ML-2150,CBF,UL 10
JB39-00017A CBF HARNESS-EARTH (TX MOTOR): SF-3100,CBF
JC39-00254A CBF HARNESS-EXIT: ML-2150,CBF,UL 1061,3PI
JC39-00279A CBF HARNESS-FUSER: ML-2150,CBF,UL 3122,2P
JC39-00247A CBF HARNESS-HVPS: ML-2150,CBF,UL 1007,4PI
JC39-00246A CBF HARNESS-INLET: ML-2150,CBF,UL 1617 /
JC39-00249A CBF HARNESS-LCD: ML-2150,WIRE,UL2878 ,8PI
JC39-00257A CBF HARNESS-MAIN MOTOR: ML-2150,CBF,UL 10
JC39-00157A CBF HARNESS-MOTOR: ML-1650,WIRE HARNESS,U
JC39-00256A CBF HARNESS-MP EMPTY: ML-2150,CBF,UL 1061
JC39-00205A CBF HARNESS-MPF JOINT: ML-3550,UL1061AWG2
JB39-40532A CBF HARNESS-OPE: SF3000,CBF,UL1007,100,Y/
JB39-00128A CBF HARNESS-P1284 FG: SF-430,UL1007,#18,1
JC39-00251A CBF HARNESS-PANEL: ML-2150,CBF,UL 1061,6P
JC39-00181A CBF HARNESS-PTL: SCX-5100,WIRE HARNESS,UL
JC39-00250A CBF HARNESS-SCF EMPTY: ML-2150,CBF,UL 106
JC39-00261A CBF HARNESS-SENSOR: ML-2150,CBF,UL 1061,4
JC39-00253A CBF HARNESS-SMPS: ML-2150,CBF,UL 1061,24P
JC39-00255A CBF HARNESS-THRMISTOR: ML-2150,CBF,UL 106
JC39-00298A CBF HARNESS-TONER_SEN: ML-2550,CBF,UL 106
JC39-40511A CBF-HARNESS: ML-80,JUMPER,AWG22,52MM,SILV
3903-000042 3903-000042 CBF-POWER CORD: M2511,250/250V,10-16/10A,
JC61-40001A COM,FOOT-RUBBER: CR70,BLK
3711-002813 CONNECTOR-HEADER: BOX,12P,1R,2MM,STRAIGHT
3711-003204 CONNECTOR-HEADER: BOX,24P,2R,2MM,STRAIGHT
3711-000826 CONNECTOR-HEADER: BOX,2P,1R,2MM,ANGLE,SN
3711-003968 CONNECTOR-HEADER: BOX,3P,1R,2.5MM,STRAIGH
3711-000906 CONNECTOR-HEADER: BOX,3P,1R,2MM,ANGLE,SN
3711-005861 CONNECTOR-HEADER: BOX,40P,2R,0.8MM,SMD-S,
3711-000967 CONNECTOR-HEADER: BOX,4P,1R,2MM,ANGLE,SN
3711-002809 CONNECTOR-HEADER: BOX,8P,1R,2MM,STRAIGHT,
3702-001121 CONNECTOR-RIBBON: 60P,MALE,STRAIGHT,AUF
3301-000317 CORE-FERRITE BEAD: AB,2X1.25X0.9MM,-
JC63-00122A COVER-M-FRAME EXIT: ML-2060,ABS,2.5,-,V
JC63-00118A COVER-M-FRONT INNER: ML-2060,ABS,-,VO
JC63-00110A COVER-M-FUSER: ML-2060,PET+GF30%+MD,-,-
JC63-00127A COVER-M-MP: ML-2060,ABS,-,V0,SEC,C872
JC63-00116A COVER-M-OPEN: ML-2060,ABS,-,V0,-,-
JC63-00120A COVER-M-REAR: ML-2060,ABS,-,V0,-,-
JC63-00115A COVER-M-RIGHT: ML-2060,ABS,-,V0,-,-
JC63-00119V COVER-M_TOP: ML-2550,ABS ,2.5,-,V0,USA,
JC63-00256A COVER-WINDOW: ML-2150,PVC FILM,T0.15,78MM
JC69-00396A CUSHION-MAIN: ML-2060,EPS,60,478,514,220,
0407-000122 DIODE-ARRAY: 1SS226,80V,300MA,C2-3,SOT-23
0407-000101 DIODE-ARRAY: DA204K,20V,100MA,C2-3,SOT-2
0402-000129 DIODE-RECTIFIER: 1N4003,200V,1A,DO-41
0404-000112 DIODE-SCHOTTKY: RB420D,25V,100MA,SOT-23,T
0401-000005 DIODE-SWITCHING: 1N4148,100V,200MA,500MW,
0403-000433 DIODE-ZENER: ZPU150,150V,130-165V,1.3W,DO
JC96-02127A ELA HOU-CST SENSOR HAWK16: ML-7250,XEROX,
JC96-01772A ELA HOU-VARISTOR: ML-6060,NEC/SEC,110/220
JC96-02845A ELA UNIT-CASSETTE(550): ML-2150,SEC,110
JC96-02679A ELA UNIT-COVER MP: ML-2060A,SEC,220V,-,
JC96-02697A ELA UNIT-COVER RIGHT: ML-2060,SEC,220V,
JC96-02696T ELA UNIT-COVER TOP: ML-2550 ,SEC,USA,110V
JC96-02627G ELA UNIT-FRAME BASE: ML-2550,SEC,220V,-
JC96-01730A JC96-01730A ELA UNIT-HOLDER TR L: ML-6060A,SAMSUNG,SE
JC96-01729A ELA UNIT-HOLDER TR R: ML-6060A,SAMSUNG,SE
JC96-02680A ELA UNIT-KNOCKUP MP: ML-2060A,SEC,220V,
JC96-02857A ELA UNIT-MOTOR EXIT CARDINAL2: ML-2550,XE
JC96-02725B ELA UNIT-MOTOR MAIN CAR 25: ML-2550,XEROX
JC96-02683A JC96-02683A ELA UNIT-PICK UP: ML-2060,SEC,220V,-,
JC96-02681A ELA UNIT-PICKUP MP: ML-2060,SEC,220V,-,
JC96-03666A ELA UNIT-REGI: ML-2150,SAMSUNG,KOR,-,
JC96-02682A ELA UNIT-RETARD: ML-2060,SEC,220V,-,-
JC96-02686A JC96-02686A ELA UNIT-ROLLER P/UP MP: ML-2060,SEC,220V
JC71-00039A ELECTRODE-P-FU_M: ML-2060,T0.6,6,L72,C521
JC71-00040A ELECTRODE-P-FU_R: ML-2060,T0.6,6,L72,C521
JC71-00041A ELECTRODE-P_FU_L: ML-2060,T0.6,6,L90,C521
JC31-00027B FAN-DC CARDINAL: AD0424LS-C50,ML-2550,-
JC31-00029A FAN-DC: AD0824MS-A70GL(TR),ML-2150,P.B.T,
2901-001178 FILTER-EMI SMD: 25V,2A,100000PF,2X1.25X
JG61-40001A FOOT: SF4000,CR,3,BLK
JC61-00677A FRAME-M-BASE: ML-2060,ABS,-,BLK,-,-
JC61-00642A FRAME-M-CASSETTE: ML-2060,HIPS,HB,BLACK
JC61-00683A FRAME-M-HOLDER PAD: ML-2060,ABS,HB,BLAC
JC61-00676A FRAME-M-LSU LOWER: ML-2060,ABS,-,BLK,
JC61-00641A FRAME-M-PICKUP: ML-2060,PC,-,BLACK,-,
JC61-00640A FRAME-M-RETARD: ML-2060,PC,-,BLACK,-,
JC61-00621A FRAME-P-FUSER: ML-2060,SECC T1.2,-,-,
JC66-40911A GEAR-DP,IDLE: ML-165,POM(NW-02),WHT,M1,Z2
JC66-00415A GEAR-DUPLEX IDLE: ML-2060,M90-44,1.0,23,3
JC66-00422A GEAR-DUPLEX: ML-2060,M90-44,1.0,19,9,NTR,
JC66-40211B GEAR-EXIT/U,ID: ML-1605,POM,BLK,-
JC66-40209A GEAR-EXIT: ML-80,POM,BLK,-
JC66-40913B GEAR-FUSER 7300: ML-7300,PPS, OFL4036,1,3
JC66-00418A GEAR-FUSER IDLE: ML-2060,SW-01,1.0,29,8,N
JC66-00340A JC66-00340A GEAR-HUB CLUTCH: SCX-5100,POM,M0.8,Z13,
JC66-00426A JC66-00426A GEAR-IDLE 23: ML-2060,PPS,1.0,23,8,NTR,25
JC66-00425A JC66-00425A GEAR-IDLE 33: ML-2060,M90-44,1.0,33,8,NTR
JC66-00674A GEAR-M-EXIT Z17: ML-2550,M90-44,1.0,17,
JC66-00413A GEAR-MP DRV: ML-2060,M90-44,0.8,45,7.5,NT
JC66-00424A GEAR-MP HOLDER_CAM: ML-2060,M90-44,0.8,37
JC66-00423A GEAR-MP PICK_UP: ML-2060,M90-44,0.8,37,20
JC66-00644A GEAR-OPC DRV INNER: ML-2150,M90-44,0.5,53
JC66-00645A GEAR-OPC DRV OUTER: ML-2150,M90-44,0.8,31
JC66-00533A GEAR-PICK_UP CAM: ML-2060,M90-44,0.8,29,1
JC66-00412A GEAR-PICK_UP DRV: ML-2060,SW-01,0.8,59,10
JG66-40003A GEAR-PINION: SF4000,POM,WHT,M1,Z16
JC66-00414A GEAR-RDCN DUPLEX: ML-2060,SW-01,0.8/1.0,1
JC66-00419A GEAR-RDCN EXIT: ML-2060,M90-44,0.5/1.0,53
JC66-00409A GEAR-RDCN FEED: ML-2060,SW-01,0.8,33/23,1
JC66-00416A GEAR-RDCN FUSER IN: ML-2060,M90-44,0.5,79
JC66-00417A JC66-00417A GEAR-RDCN FUSER OUT: ML-2060,M90-44,1.0,2
JC66-00405A GEAR-RDCN OPC: ML-2060,M90-44,0.5,61/26,1
JC66-00411A GEAR-RDCN PICK_UP: ML-2060,M90-44,0.8,63/
JC66-00407A GEAR-RDCN REGI: ML-2060,SW-01,0.5/0.8,59/
JC66-00410A GEAR-RDCN RETARD: ML-2060,SW-01,0.8,27/19
JC66-00408A GEAR-REGI IDLE: ML-2060,M90-44,0.8,29,15,
JC66-00420A GEAR-REGI Z25: ML-2060,M90-44,0.8,25,5.6,
JC66-00039A GEAR-TR29: ML-6060A,POM,BLK,0.6,29
JC61-00658A GUIDE-M-DUPLEX: ML-2060,PC,-,BLK,-
JC61-00644A GUIDE-M-EXTENSION CST: ML-2060,HIPS,HB,
JC61-00655A GUIDE-M-HANDLE: ML-2060,ABS,V0,-,IVOR
JC61-00704A GUIDE-M-INNER CST: ML-2060,HIPS,HB,-,
JC61-00664A GUIDE-M-LEFT, DUP: ML-2060,HIPS, HB,2.0,4
JC61-00267B GUIDE-M-LOCK A: ML-2150,ABS,HB,-,C750
JC61-00648A GUIDE-M-PAPER SIZE: ML-2060,POM,-,WHT
JC61-00646A GUIDE-M-REAR: ML-2060,HIPS,HB,-,IVORY
JC61-00620A GUIDE-M-REAR: ML-2060,PET+GF30%+MD,-,
JC61-00662A GUIDE-M-RIGHT, DUP: ML-2060,ABS, V0,2.0,5
JC61-00645A GUIDE-M-SIDE LOCK: ML-2060,ABS,HB,-,B
JC61-00801A GUIDE-M_FRONT: ML-2150,PET+GF30%+MD,-,-
JC61-00661A GUIDE-P-BOTTOM, DUP: ML-2060,SECC,0.8,248
JC61-00660A GUIDE-P-FRONT, DUP: ML-2060,SECC,0.8,76,2
JC61-00751A GUIDE-P-REAR PAPER CST: ML-2060,SUS-301,0
JC61-00691A GUIDE-PLATE PAPER: ML-2060,SECC,T0.6,-,
JC61-00674A GUIDE-P_REGI LOWER: ML-2060,SECC,1.2,-,
JC61-00670A GUIDE-P_REGI PLATE: ML-2060,SECC,1.2,-,
JC61-00675A GUIDE-P_REGI UPPER: ML-2060,SECC,1.2,-,
JC61-00678A GUIDE-P_TRANSFER: ML-2060,SECC,0.6,-,
JC61-00666A HINGE-M-FRONT GUIDE, DUP: ML-2060,POM, HB
JC61-00829A JC61-00829A HOLDER-BEARING EXIT F/DOWN: SCX-4216F,POM
JC61-00673A HOLDER-M-BUSHING EXIT: ML-2060,POM,-,
JC61-00671A HOLDER-M-BUSHING TX: ML-2060,POM,-,BL
JC61-00785A HOLDER-M-IDLE ROLLER: ML-2150,PC,-,BL
JC61-00639A HOLDER-M-INDICATOR: ML-2060,ABS,-,BLK
JC61-00684A JC61-00684A HOLDER-M-PAD: ML-2060,ABS,-,BLK,-
JC61-00705A HOLDER-M-PICKUP MP: ML-2060,ABS,-,BLK
JC61-00638A HOLDER-M-RETARD: ML-2060,ABS,-,BLK,V0
JC61-00672A HOLDER-M-SENSOR: ML-2060,HIPS,-,BLK,-
JC61-00637A HOUSING-M-FEED: ML-2060,ABS,-,BLK,V0
JC61-00685A HOUSING-M-PICK UP MP: ML-2060,ABS,-,B
JC61-00635A JC61-00635A HOUSING-M-RETARD: ML-2060,ABS,-,BLK,V
JB13-00004A IC ASIC-OPE: SF-3100,HT48C5,SSOP,48P,16.1
JC13-00028A IC ASIC-SPGPV3: SPGPV3,ML-2550_VE,496PIN,
1205-002339 IC-CLOCK GENERATOR: CY25811SC,SOIC,8P,150
0801-000205 IC-CMOS LOGIC: 4050,BUFFER,SOP,16P,150MIL
0801-002446 IC-CMOS LOGIC: 74LCX14,SCHMITT INVERTER,T
1105-001357 IC-DRAM: K4S281632,2MX16X4BIT,TSOP(II),54
1103-001183 IC-EEPROM: 24C04,512X8BIT,SOP,8P,150MIL,-
1107-001549 IC-FLASH MEMORY: K9F5616U0C,16MX16BIT,TSO
1006-001224 IC-LINE TRANSCEIVER: 74LVX161284,TSSOP,48
1003-001535 IC-MOTOR DRIVER: A3977SLP,TSSOP,28P,9.6X4
1203-000001 IC-POSI.ADJUST REG.: 7805,TO-220,3P,PLA
1203-003700 IC-POSI.ADJUST REG.: LD1117ADT-R,DPAK,3P,
0904-001989 IC-USC: ISP1582BS,HVQFN56,56P,8X8X0.85M
1202-000164 IC-VOLTAGE COMP.: 393,SOP,8P,150MIL,DUAL,
JC70-00327A ICT-STUD DRV GEAR, DUP: ML-2060,SWCH10181
JC70-00457A ICT-STUD PAPER GUIDE, DP: ML-2150,SUS 303
JC70-20901A JC70-20901A IEX-SHAFT IDLE,F/UP: ML-5000A,SUS304,PI1.
JC64-00041A INDICATOR-M-EMPTY: ML-2060,HIPS,RED,HB,
JC70-00467A IPR-GND-P-PAPER_SIZE: ML-2550,SUS,0.2,-
JC70-00325A IPR-P-FINGER LEFT: ML-2060,SPCC,T1.2,
JC70-00326A IPR-P-FINGER RIGHT: ML-2060,SPCC,T1.2,-
JC70-00192A IPR-PLATE SENSOR: ML-7250,SUS301,0.2T,-
JC70-00336A IPR-P_GND SOLENOIDE FEED: ML-2060,SUS,0
JC70-00328A IPR-P_GROUND GUIDE TR: ML-2060,SUS,0.2,
JC70-00330A IPR-P_GROUND MOTOR MAIN2: ML-2060,SUS,0
JC70-00332A IPR-P_GROUND OPC: ML-2060,SUS,0.2,-,-
JC70-00339A IPR-P_GROUND PLATE PAPER: ML-2060,SUS,0
JC70-00333A IPR-P_GROUND REGI ROLLER: ML-2060,SUS,0
JC70-00334A IPR-P_GROUND SCF MAIN: ML-2060,SUS,0.2,
JC70-10961A IPR-TERMINAL FU: ML-165,C5210P,T0.3,-
3722-001101 JACK-USB: 4P/2C,8.38MM,AU,IVR,#22-28
JC64-00045A KEY-M-BUTTON: ML-2060,ABS,V0,-,-
JC64-00044A KEY-M-DUPLEX: ML-2060,ACRYL,-,NATURAL,-
JC64-00046A KEY-M-ON LINE: ML-2060,ACRYL,-,NATURAL,
JC64-00047A KEY-M-SAVE MODE: ML-2060,ACRYL,-,NATURA
JC64-00042A KNOB-M-REAR: ML-2060,ABS,-,-,IVORY,
JC47-00010A LAMP-PTL: 90-20-210-167,ML-2150,4.1 X 9.4
JC07-00005A LCD-PANEL: VHC1625SLYC9-1,ML-2150,16X2,36
0601-000353 LED
0601-000161 LED: ROUND,GRN,5MM,570NM
JC66-00443A LEVER-M-OPEN, DUP: ML-2060,PC,2.5,12,40,-
JC97-01034A JC97-01034A MEA RACK-EXIT ROLLER: ML-1605,SUMSUNG,KOR
JC97-01692A MEA UNIT- ROLLER CLEAN: ML-2060,SAMSUNG,-
JC97-02361A MEA UNIT-COVER REAR: ML-2150,SEC,USA,-,
JC97-01714B MEA UNIT-DUPLEX: ML-2550,XEROX,USA,DUPLEX
JC97-01738A MEA UNIT-GEAR P/UP MP CARDINA: ML-2150,
JC97-01715A MEA UNIT-GUIDE FRONT, DUP: ML-2150,SEC,
JC97-01713A MEA UNIT-ROLLER FEED, DUP: ML-2150,SEC,
JC97-01401A MEA UNIT-TERMINAL:TR: ML-5000A,SAMSUNG,KO
JC75-00095A JC75-00095A MEC- BRUSH ANTISTATIC: ML-6060A,SEC,NTR
JC47-00009A MEP-CLUTCH FEED CARDINAL:, ML-2150,4.0W,
JC31-00024A MOTOR DC-BLDC CARDINAL: 50M8432030,1.7A
JC74-00011A MPR-PAD KNOCK UP MP: ML-6060A,CR+CORK,10*
JC92-01473A PBA MAIN-LCD PANEL: ML-2150,SEC,KOREA,LCD
JC92-01658A PBA MAIN-MAIN: ML-2550,SEC,USA,CARDINAL_P
JC92-01475A PBA MAIN-PTL1: ML-2150,SEC,KOREA,PTL1 B'D
JC92-01488A PBA MAIN-ZENER: ML-2150,SEC,KOREA,ZENER B
JC92-01336A PBA SUB-CASSETTE: ML-1650,KOREA/EXPORT,
JC92-01530A PBA SUB-CONNECTOR B'D: ML-2550,SEC,KOREA,
JC92-01510A PBA SUB-COVER JOINT: ML-2150,SEC,KOREA,CO
JC92-01514A PBA SUB-COVER OPEN: ML-2150,SEC,KOREA,COV
JC92-01511A PBA SUB-EMPTY SENSOR: ML-2150,SEC,KOREA,E
JC92-01512A PBA SUB-EXIT SENSOR: ML-2150,SEC,KOREA,EX
JC92-01516A PBA SUB-PTL2: ML-2150,SEC,KOREA,PTL2,-,
JC92-01528A PBA SUB-TONER_SENSOR: ML-2150,SEC,KOREA,T
JC72-20902A PEX-ROLLER F/UP(2): ML-5000A,TE
0604-001415 0604-001415 PHOTO-INTERRUPTER: TR,90%,150MW,DIP-4,BK
JC61-00686A PLATE-M-KNOCK UP MP: ML-2060,ABS,-,C8
JC72-00991A PMO-ACTUATOR EMPTY: ML-2060,PC,BLK,-,
JC72-00988A PMO-ACTUATOR EXIT: ML-2060,PC,BLK,-,-
JC72-00997A PMO-ACTUATOR FEED, DUP: ML-2060,POM,BLK,2
JC72-01002A PMO-ACTUATOR MP: ML-2060,PC,BLK,-,-,-
JC72-01310A PMO-ACTUATOR OUTFULL: ML-2150,ABS,BLK,V
JC72-00998A PMO-ACTUATOR REGISHUTTER: ML-2060,PET G/F
JC72-41191B PMO-BEARING SHAFT: ML-2150,POM,BLK,DE89
JC72-00382B PMO-BUSHING FEED: ML-1710,DELRIN8903,WHIT
JC72-40232A PMO-CAP AGITATOR: ML-80,PP,BLK,-
JC72-00463A PMO-CAP CONNECTOR L: ML-6060A,PC,VO,-
JC72-00465A PMO-CAP CONNECTOR U: ML-6060A,PC,VO,-
JC72-41292B PMO-CAP TR: ML-3560,POM,C75064,45.4*6.6,M
JC72-00999A PMO-DUMMY FRAME FUSER: ML-2060,PET G/F20%
JC72-41012A JC72-41012A PMO-GUIDE CLAW: ML-165,PEEK,BLK,-
JC72-00317A PMO-GUIDE DEVE L: ML-6060A,ABS,BLACK,V0
JC72-00318A PMO-GUIDE DEVE R: ML-6060A,ABS,BLACK,V0
JC72-41006A PMO-HOLDER EXIT ROLL: ML-165,PC,BLK,HB,-
JC72-41010A PMO-HOUSING TERMINAL: ML-165,ABS GF20%,BL
JC72-00994A PMO-HUB IN RETARD: ML-2060,POM,BLK,M90-
JC72-00993A PMO-HUB OUT RETARD: ML-2060,POM,BLK,M90
JC72-01004A PMO-IDLE KNOCK UP MP: ML-2060,POM,WHITE,-
JC72-01003A JC72-01003A PMO-IDLE PICK UP MP: ML-2060,POM,WHITE,
JC72-00825A PMO-IMPELLER_DRV: ML-6200,PC,BLK,V0,-
JC72-41007A PMO-ROLLER FD F: ML-165,POM,BLK,HB,-
JC72-40981A PMO-ROLLER UPPER DP: ML-165,POM,WHT,HB,-
JC72-01005A PMO-SIDE GUIDE MP(L): ML-2060,PC+ABS,C872
JC72-01006A PMO-SIDE GUIDE MP(R): ML-2060,PC+ABS,C872
JC72-00995A PMO-STACKER LOCKER : ML-2060,ABS,-,0810
JC72-00996A PMO-STACKER REAR: ML-2060,ABS,-,0810P,V
JC72-00973A PMO-STACKER_RX: ML-2150,ABS,LIGHT GRAY,
JC72-41004A PMO-STRIPE: ML-165,NYLON66,NAT,-
2001-000019 R-CARBON(S): 10OHM,5%,1/2W,AA,TP,2.4X6.4M
2001-000281 R-CARBON: 100OHM,5%,1/8W,AA,TP,1.8X3.2MM
2001-000502 R-CARBON: 20OHM,5%,1/4W,AA,TP,2.4X6.4MM
2007-000729 R-CHIP
2007-000123 R-CHIP: 1.5KOHM,5%,1/16W,DA,TP,1608
2007-000074 R-CHIP: 100OHM,5%,1/16W,DA,TP,1608
2007-000293 R-CHIP: 100OHM,5%,1/8W,DA,TP,3216
2007-000052 R-CHIP: 10KOHM,1%,1/16W,DA,TP,1608
2007-000090 R-CHIP: 10KOHM,5%,1/16W,DA,TP,1608
2007-000303 R-CHIP: 10KOHM,5%,1/8W,DA,TP,3216
2007-000309 R-CHIP: 10OHM,5%,1/16W,DA,TP,1608
2007-002901 R-CHIP: 12.1KOHM,1%,1/16W,DA,TP,1608
2007-000402 R-CHIP: 150OHM,5%,1/16W,DA,TP,1608
2007-000078 R-CHIP: 1KOHM,5%,1/16W,DA,TP,1608
2007-000109 R-CHIP: 1MOHM,5%,1/16W,DA,TP,1608
2007-000105 R-CHIP: 200KOHM,5%,1/16W,DA,TP,1608
2007-000106 R-CHIP: 220KOHM,5%,1/16W,DA,TP,1608
2007-000075 R-CHIP: 220OHM,5%,1/16W,DA,TP,1608
2007-000094 R-CHIP: 22KOHM,5%,1/16W,DA,TP,1608
2007-000071 R-CHIP: 22OHM,5%,1/16W,DA,TP,1608
2007-000082 R-CHIP: 3.3KOHM,5%,1/16W,DA,TP,1608
2007-000096 R-CHIP: 30KOHM,5%,1/16W,DA,TP,1608
2007-000076 R-CHIP: 330OHM,5%,1/16W,DA,TP,1608
2007-000134 R-CHIP: 33KOHM,5%,1/16W,DA,TP,1608
2007-000113 R-CHIP: 33OHM,5%,1/16W,DA,TP,1608
2007-000084 R-CHIP: 4.7KOHM,5%,1/16W,DA,TP,1608
2007-000077 R-CHIP: 470OHM,5%,1/16W,DA,TP,1608
2007-000965 R-CHIP: 5.1KOHM,5%,1/16W,DA,TP,1608
2007-000086 R-CHIP: 5.6KOHM,5%,1/16W,DA,TP,1608
2007-000120 R-CHIP: 680OHM,5%,1/16W,DA,TP,1608
2007-001134 R-CHIP: 68OHM,5%,1/16W,DA,TP,1608
2007-000121 R-CHIP: 820OHM,5%,1/16W,DA,TP,1608
2007-007445 R-CHIP: 9.09KOHM,1%,1/16W,DA,TP,1608
2011-000651 R-NETWORK: 10OHM,5%,1/16W,L,CHIP,8P,ST
2011-000002 R-NETWORK: 22OHM,5%,1/16W,L,CHIP,8P,ST
2005-000168 R-WIRE WOUND,NON: 0.22OHM,5%,2W,AA,BK,4X1
6044-000107 RING-C: ID2.5,OD6,T0.4,PASS,STS304
6044-000125 RING-E: ID4,OD9,T0.6,PASS,STSC
6044-000231 RING-E: ID5.0,OD11.0,T0.6,STS304
JC73-40915B RMO-RUBBER EXIT_DUP: ML-2150,EPDM,11.6
JC66-00668A ROLLER-EXIT_F/DOWN: ML-2150,SUM 6, EPDM
JC66-00597A ROLLER-HEAT: ML-2150,AL PIPE T1.8MM,26MM,
JC66-00442A ROLLER-M-IDLE, DUP: ML-2060,POM, SW01,8.0
JC66-00647A ROLLER-M_REGI IDLE L25: ML-2150,POM,12.1,
JC66-00648A ROLLER-M_REGI IDLE S25: ML-2150,POM,11.9,
JC66-00599A ROLLER-PRESSURE: ML-2150,STK 18, HTV SP
JC66-00540A ROLLER-TRANSFER: ML-2060,NBR SPONGE+SUM/N
JC73-00132A JC73-00132A RPR-FRICTION PAD MP: ML-2060,NBB,54*10*T1
JC73-10910A RPR-PAD CST: ML-165,CORK,25.8*24.6,NTR,-
JC73-00128A RUBBER-FEED: ML-2060,PNR,30,GRAY,SE
JC73-00127A RUBBER-PICK UP: ML-2060,PNR,30,GRAY,-
JC73-00129A JC73-00129A RUBBER-RETARD: ML-2060,PNR,30,GRAY,
6006-001193 SCREW-ASSY MACH: WSP,PH,+,M3,10,ZPC(YEL),
6001-000568 SCREW-MACHINE: PH,+,M3,L8,NI PLT,SM20C,-
6002-000175 SCREW-TAPPING: PWH,+,2,M3,L8,ZPC(YEL),SM2
6002-000440 SCREW-TAPPING: RWH,+,2,M3,L8,ZPC(BLK),SWR
6003-000282 6003-000282 SCREW-TAPTITE: BH,+,B,M3,L8,ZPC(BLK),SWCH
6003-000003 SCREW-TAPTITE: BH,+,B,M4,L10,CBLACK,SWRCH
6003-000196 SCREW-TAPTITE: PWH,+,B,M3,L10,NI PLT,SWRC
6003-000264 SCREW-TAPTITE: PWH,+,B,M3,L6,ZPC(YEL),SWR
6003-000267 SCREW-TAPTITE: PWH,+,S,M3,L8,ZPC(YEL),SWR
JC66-00592A SHAFT-FEED: ML-2060,SUM 24L,220,6,-,-
JC66-00591A SHAFT-HUB IN: ML-2060,SUM 24L,10,2,-,-
JC66-00444A SHAFT-IDLE ROLL, DUP: ML-2060,SUM24L,24,2
JC66-00439A SHAFT-M-COUPLING RETARD: ML-2060,PC+GF20%
JC66-00401A SHAFT-M-EXIT_DUPLEX: ML-2060,PC,-,-,-
JC66-00402A SHAFT-M-EXIT_F/UP: ML-2060,PC,-,-,-
JC66-00438A SHAFT-M-GEAR RETARD: ML-2060,PC+GF20%,-
JC66-00453A SHAFT-M-PICK UP MP: ML-2060,PC,-,-,-
JC66-00440A SHAFT-M-PICK UP: ML-2060,PC+GF20%,-,-
JC66-00446A SHAFT-REGI UPPER: ML-2060,SUM,6,-,-
JC66-00590A SHAFT-RETARD: ML-2060,SUM 24L,60,6,-,-
JC63-00297A SHEET GUIDE BOTTOM
JC63-00293A SHEET-COVER PICKUP: ML-2550,PVC,T0.2,-,
JC63-00132A SHEET-COVER TR: ML-2060,PVC,T0.2,-,-
JC63-00124A SHIELD-P_CONTROLLER: ML-2060,SECC,0.8,-
JC44-00053A SMPS-V2_HVPS: ML-2150,CARDINAL-V2,AC/DC,9
JC33-00012A JC33-00012A SOLENOID-MAIN: DLH-34L008-05,ML-2150,24V,
JC33-00013A SOLENOID-MP: DLH-34L008-04,ML-2150,24V,8O
JC61-00391A SPRING ETC-DUPLEX COVER: ML-9400W,SUS304W
JC61-00387A SPRING ETC-PAD: ML-9400W,SUS304WPB,7.55,-
JC61-00414A SPRING ETC-REMAIN: ML-9400W,SUS304WPB,0.4
JC61-00003A SPRING--CAM MP: ML-6100,SUS304-WPB,2.4,0.
JC61-70903A SPRING-ACTUATOR: ML-165,SWPB,P0.15,D7,L1.
6107-000014 SPRING-CS: PI0.55,D6.9,L14,SUS304-WPB,7
6107-001174 SPRING-CS: SUS 304 WPB,PI1.1,D22.9,L100
JC61-70965A SPRING-EMPTY: ML-6000,SUS304-WPB,PI0.25,D
6107-001155 SPRING-ES: SWP-WPB,PI0.55,L25,N29,-
JC61-70911A SPRING-EXIT ROLL FD: ML-165,SUS304 WPB,PI
JC61-70950A SPRING-EXTENSION: ML-5000A,SUS304WPB,PI0.
JC61-70932A SPRING-GUIDE DEVE: ML-5000A,SUS304 WPB,PI
JC61-70929A SPRING-HV LARGE: ML-5000A,SUS304 WPB,PI0.
JC61-70913A SPRING-KNOCK UP MP: ML-165,SUS304 WPB,PI0
JC61-70918A SPRING-LEVER: ML-165,SUS304 WPB,PI0.5,D4.
JC61-00056A SPRING-PR(7300): ML-7300,PIANO WIRE,1.0,6
JC61-70909A JC61-70909A SPRING-SAPERATION: ML-165,SUS304 WPB,PI0.
JC61-00047A SPRING-TR L HAWK: ML-6060A,SUS 304 WPB,
6107-001159 SPRING-TS: SUS304,PI0.45,D3.85,L20,W1
6107-001160 SPRING-TS: SUS304,PI0.45,D5.45,L19.8,
6107-001156 SPRING-TS: SUS304,PI0.6,D3.6,L22,W20,
6107-001158 SPRING-TS: SUS304-WPB,PI0.4,D6.7,-,
6107-001157 SPRING-TS: SWRS 82A,PI0.8,D11.5,N11.5
JC61-00667A JC61-00667A STOPPER-M-FAN80: ML-2060,ABS,-,BLK,-
JC61-00656A STOPPER-M-HINGE OPEN: ML-2060,ABS,-,-
3405-001069 SWITCH-MICRO: 125V,5A,30GF,SPDT
3404-000155 SWITCH-TACT: 12V,50MA,160+-50GF,6X6X3.5MM
3404-000116 SWITCH-TACT: 12V,50MA,160GF,6X6X3.6MM,SPS
JC65-00004A TERMINAL-P_DEVE:, SUS,-,T0.2,-
JC65-00006A TERMINAL-P_HV CARDINAL:, SUS,-,T0.2,
JC65-00007A TERMINAL-P_PTL 2:, SUS,-,T0.2,-
JC65-00001A TERMINAL-P_PTL :, SUS,-,T0.2,-
JC65-00002A TERMINAL-P_PTL L:, SUS,-,T0.2,-
JC65-00003A TERMINAL-P_PTL R:, SUS,-,T0.2,-
JC65-00005A TERMINAL-P_TR CARDINAL:, SUS,-,T0.2,
0501-000457 TR-SMALL SIGNAL
0501-000279 TR-SMALL SIGNAL: KSA1182,PNP,-35V,-30V,-5
0501-000338 TR-SMALL SIGNAL: KSC1623,NPN,60V,50V,150M
JC63-00128A TRAY-M-EXTEND MP: ML-2060,ABS,-,VO,
JC63-00129A TRAY-M-LINK MP(L): ML-2060,HIPS,-,HB,
JC63-00130A TRAY-M-LINK MP(R): ML-2060,HIPS,-,HB,
JC59-00019B UNIT-LSU_CARDINAL_25: ML-2550,-,600DPI,
6031-001255 WASHER-PLAIN: NYLON,CUTTING,ID5,OD9,T0.5,
JC64-00048A WINDOW-M-LCD: ML-2060,ACRYL,-,-,TRANS
Main Menu x
