Manufacturer
Samsung
Model Number
NP530U4BA01US
Description
Laptop Np530u4b-a01us
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
Samsung ADAPTOR |
| BA42-00365A | Samsung ANTENNA-WLAN |
| BA92-09690A | Samsung ASSY BOARD-CAMERA |
| BA92-09693A | Samsung ASSY BOARD-POWER |
| BA92-09689A | Samsung ASSY BOARD-TOP |
|
|
Samsung ASSY BOARD-USB |
| BA92-09841A | Samsung ASSY MOTHER BD-TOP |
| BA96-06049A | Samsung ASSY SPEAKER-LEFT |
| BA96-06050A | Samsung ASSY SPEAKER-RIGHT |
| BA81-15718A | Samsung BADGE-SAMSUNG |
| BA43-00339A | Samsung BATTERY |
| 3301-001721 | Samsung BEAD-SMD |
| 3301-001649 | Samsung BEAD-SMD |
| BA59-03220A | Samsung BOARD-TOUCHPAD |
| BA59-03219A | Samsung BOARD-TOUCHPAD |
| BA81-16327A | Samsung BRACKET-DC_JACK |
| BA61-01668A | Samsung BRACKET-LCD_L |
| BA61-01669A | Samsung BRACKET-LCD_R |
| BA61-01670A | Samsung BRACKET-ODD |
| 2402-001042 | Samsung C-AL, SMD |
| 2203-006741 | Samsung C-CER, CHIP |
| 2203-006399 | Samsung C-CER, CHIP |
| 2203-006377 | Samsung C-CER, CHIP |
| 2203-006348 | Samsung C-CER, CHIP |
| 2203-006260 | Samsung C-CER, CHIP |
| 2203-006166 | Samsung C-CER, CHIP |
| 2203-006090 | Samsung C-CER, CHIP |
| 2203-006048 | Samsung C-CER, CHIP |
| 2203-006000 | Samsung C-CER, CHIP |
| 2203-005344 | Samsung C-CER, CHIP |
| 2203-002720 | Samsung C-CER, CHIP |
| 2203-002050 | Samsung C-CER, CHIP |
| 2203-001140 | Samsung C-CER, CHIP |
| 2203-000627 | Samsung C-CER, CHIP |
| 2409-001129 | Samsung C-POLYMER , CHIP |
| BA39-01214A | Samsung CBF-HDD |
|
|
Samsung CBF-LCD_CAMERA |
|
|
Samsung CBF-POWER CORD |
| BA39-01205A | Samsung CBF-USB |
| 3709-001655 | Samsung CONNECTOR-CARD EDGE |
| 3709-001758 | Samsung CONNECTOR-CARD SLOT |
| 3709-001741 | Samsung CONNECTOR-CARD SLOT |
| 3709-001610 | Samsung CONNECTOR-CARD SLOT |
| 3708-002998 | Samsung CONNECTOR-FPC/FFC/PIC |
| 3708-002969 | Samsung CONNECTOR-FPC/FFC/PIC |
| 3708-002883 | Samsung CONNECTOR-FPC/FFC/PIC |
| 3708-002190 | Samsung CONNECTOR-FPC/FFC/PIC |
| 3708-002166 | Samsung CONNECTOR-FPC/FFC/PIC |
| 0404-001084 | Samsung DIODE-SCHOTTKY |
| 0404-001020 | Samsung DIODE-SCHOTTKY |
| 0407-000112 | Samsung DIODE-SWITCHING |
| 0401-000191 | Samsung DIODE-SWITCHING |
| 0401-000132 | Samsung DIODE-SWITCHING |
| BA61-01690A | Samsung DUMMY CARD-SD |
| BA59-03465A | Samsung DVD-SUPERMULTI |
| BA59-03160A | Samsung DVD-SUPERMULTI |
| BA59-02803A | Samsung DVD-SUPERMULTI |
| BA31-00124A | Samsung FAN-CPU |
| 0505-002598 | Samsung FET-SILICON |
| 0505-002386 | Samsung FET-SILICON |
| 0505-001883 | Samsung FET-SILICON |
| 0505-001089 | Samsung FET-SILICON |
| 0505-001064 | Samsung FET-SILICON |
| 0505-001016 | Samsung FET-SILICON |
| BA41-01905A | Samsung FFC-TP |
| BA41-01904A | Samsung FFC-TP_SUB |
| BA41-01912A | Samsung FPC |
| BA39-01211A | Samsung HARNESS POWER |
| BA39-01209A | Samsung HARNESS POWER-DC_IN_JACK |
|
|
Samsung HARNESS-HDD |
| BA59-03163E | Samsung HDD |
| BA59-03163D | Samsung HDD |
| BA59-03163C | Samsung HDD |
|
|
Samsung HDD |
| BA59-03163A | Samsung HDD |
| BA59-02924A | Samsung HDD |
| BA59-02473A | Samsung HDD |
| 3711-005753 | Samsung HEADER-BOARD TO BOARD |
| 3711-007864 | Samsung HEADER-BOARD TO CABLE |
| 3711-007754 | Samsung HEADER-BOARD TO CABLE |
| 3711-007753 | Samsung HEADER-BOARD TO CABLE |
| 3711-007692 | Samsung HEADER-BOARD TO CABLE |
| 3711-007549 | Samsung HEADER-BOARD TO CABLE |
| 3711-007005 | Samsung HEADER-BOARD TO CABLE |
| BA62-00672B | Samsung HEAT SINK-CPU |
| BA62-00672A | Samsung HEAT SINK-CPU |
| BA61-01659A | Samsung HINGE-L |
| BA61-01657A | Samsung HINGE-L |
| BA61-01660A | Samsung HINGE-R |
| BA61-01658A | Samsung HINGE-R |
| 1001-001760 | Samsung IC-ANALOG SWITCH |
| 1001-001675 | Samsung IC-ANALOG SWITCH |
| 1205-004168 | Samsung IC-CLOCK GENERATOR |
| 0801-002628 | Samsung IC-CMOS LOGIC |
| 1205-004291 | Samsung IC-CODEC |
| 1105-002167 | Samsung IC-DDR3 SDRAM |
| 1205-004159 | Samsung IC-ETHERNET CONTROLLER |
| 1107-001992 | Samsung IC-FLASH MEMORY |
| 0904-002559 | Samsung IC-MEMORY CONT. |
| 1107-001977 | Samsung IC-NOR FLASH |
| 1107-001915 | Samsung IC-NOR FLASH |
| 1203-006106 | Samsung IC-POSI.ADJUST REG. |
| 1203-006056 | Samsung IC-POSI.ADJUST REG. |
| 1203-005591 | Samsung IC-POSI.ADJUST REG. |
| 1203-007109 | Samsung IC-PWM CONTROLLER |
| 1203-005536 | Samsung IC-PWM CONTROLLER |
| 1203-005332 | Samsung IC-PWM CONTROLLER |
| 1209-001887 | Samsung IC-SENSOR |
| 1205-003683 | Samsung IC-SWITCH |
| 1202-001091 | Samsung IC-VOLTAGE COMP. |
| BA62-00694A | Samsung INSULATOR-GFX |
| BA81-08240A | Samsung INSULATOR-HDMI |
| BA62-00695A | Samsung INSULATOR-PCH |
| BA81-16535A | Samsung INSULATOR-TOUCHPAD |
| 3722-003347 | Samsung JACK-MODULAR |
| 3722-003474 | Samsung JACK-PHONE |
| 3722-003330 | Samsung JACK-USB |
| 3722-003302 | Samsung JACK-USB |
| BA68-05382A | Samsung LABEL ENERGY-WARRANTY |
| BA68-07510A | Samsung LABEL-FCC/IC_ID |
| BA68-06891A | Samsung LABEL-LOGO_I5_CPU |
| BA68-05474A | Samsung LABEL-LOGO_WIN7 |
| BA68-20039A | Samsung LABEL-PPID_E |
| BA68-07509A | Samsung LABEL-RAINBOW_PEAK |
| BA59-02954A | Samsung LCD PANEL-140HD |
| BA81-11683A | Samsung MAGNET-LCD |
| 3003-001158 | Samsung MIC-CONDENSOR |
| BA59-03275A | Samsung MODULE-CAMERA |
| BA59-02889A | Samsung MODULE-WLAN_BT |
| BA69-40003A | Samsung PACKING-HANDLE |
| 2007-009768 | Samsung R-CHIP |
| 2007-008693 | Samsung R-CHIP |
| 2007-008676 | Samsung R-CHIP |
| 2007-008576 | Samsung R-CHIP |
| 2007-008551 | Samsung R-CHIP |
| 2007-008438 | Samsung R-CHIP |
| 2007-008429 | Samsung R-CHIP |
| 2007-008330 | Samsung R-CHIP |
| 2007-008309 | Samsung R-CHIP |
| 2007-008304 | Samsung R-CHIP |
| 2007-008300 | Samsung R-CHIP |
| 2007-008299 | Samsung R-CHIP |
| 2007-008298 | Samsung R-CHIP |
| 2007-008294 | Samsung R-CHIP |
| 2007-008293 | Samsung R-CHIP |
| 2007-008223 | Samsung R-CHIP |
| 2007-008175 | Samsung R-CHIP |
| 2007-008106 | Samsung R-CHIP |
| 2007-008026 | Samsung R-CHIP |
| 2007-008015 | Samsung R-CHIP |
| 2007-007942 | Samsung R-CHIP |
| 2007-007878 | Samsung R-CHIP |
| 2007-007803 | Samsung R-CHIP |
| 2007-007797 | Samsung R-CHIP |
| 2007-007737 | Samsung R-CHIP |
| 2007-007735 | Samsung R-CHIP |
| 2007-007617 | Samsung R-CHIP |
| 2007-007585 | Samsung R-CHIP |
| 2007-007549 | Samsung R-CHIP |
| 2007-007520 | Samsung R-CHIP |
| 2007-007467 | Samsung R-CHIP |
| 2007-007456 | Samsung R-CHIP |
| 2007-007352 | Samsung R-CHIP |
| 2007-007302 | Samsung R-CHIP |
| 2007-002918 | Samsung R-CHIP |
| 2007-002901 | Samsung R-CHIP |
| 2007-002899 | Samsung R-CHIP |
| 2007-002425 | Samsung R-CHIP |
| 2007-001153 | Samsung R-CHIP |
| 2007-000969 | Samsung R-CHIP |
| 2007-000729 | Samsung R-CHIP |
| 2007-000695 | Samsung R-CHIP |
| 2007-000536 | Samsung R-CHIP |
| 2007-000503 | Samsung R-CHIP |
| 2007-000309 | Samsung R-CHIP |
| 2007-000287 | Samsung R-CHIP |
| 2007-000239 | Samsung R-CHIP |
| 2007-000111 | Samsung R-CHIP |
| BA81-17155A | Samsung RUBBER-FOOT |
| BA81-16915A | Samsung RUBBER-FRONT |
| BA67-00419A | Samsung RUBBER-MIC |
| 6001-002736 | Samsung SCREW-MACHINE |
| 6001-002712 | Samsung SCREW-MACHINE |
| 6001-001925 | Samsung SCREW-MACHINE |
| 6001-001650 | Samsung SCREW-MACHINE |
| 6001-001649 | Samsung SCREW-MACHINE |
| 6001-001570 | Samsung SCREW-MACHINE |
| 6001-001480 | Samsung SCREW-MACHINE |
| 3710-003544 | Samsung SOCKET-BOARD TO CABLE |
| 3710-003575 | Samsung SOCKET-INTERFACE |
| 0202-001498 | Samsung SOLDER-WIRE FLUX |
| BA81-09630A | Samsung SPONGE-PCH_PAD |
| 3404-001052 | Samsung SWITCH-TACT |
| 0203-001869 | Samsung TAPE-KAPTONE |
| 0501-000465 | Samsung TR-SMALL SIGNAL |
| BA75-04041A | Samsung UNIT-BEZEL_ODD |
| BA75-03724A | Samsung UNIT-BEZEL_ODD |
| BA75-03723A | Samsung UNIT-BRACKET_HDD |
| BA81-17073A | Samsung UNIT-COVER_LAN |
| BA75-03722A | Samsung UNIT-DOOR_HDD |
|
|
Samsung UNIT-HOUSING_BOTTOM |
|
|
Samsung UNIT-HOUSING_LCD-BACK |
| BA75-03718B | Samsung UNIT-HOUSING_LCD-FRONT |
|
|
Samsung UNIT-HOUSING_TOP |
| BA39-01052A | Samsung WIRE HARNESS-BATTERY |
