Manufacturer
Samsung
Model Number
NP900X3JS01US
Description
Notebook 9 Pro 15-inch
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ADAPTOR |
| BA42-00569A | ANTENNA |
| BA97-08721A | ASSEMBLY CASE FRONT-TOP |
| BA98-00782A | ASSEMBLY CASE REAR-BOTTOM |
| BA97-08519A | ASSEMBLY CASE-FRONT TOUCHPAD |
| BA98-00721A | ASSEMBLY KEY-POWER |
| BA96-07190B | ASSEMBLY LCD SUBOUT |
| BA96-07190A | ASSEMBLY LCD SUBOUT |
| BA92-17656A | ASSEMBLY MOTHER BD-TOP;AMOR2-13 BO |
| BA96-05929C | ASSEMBLY SPEAKER (LEFT) |
| BA96-05928C | ASSEMBLY SPEAKER (RIGHT) |
| BA92-16014A | BOARD ASSEMBLY USB-TOP |
|
|
BOARD ASSEMBLY USB-TOP |
| BA61-03057A | BRACKET-PORT L |
| BA61-03058A | BRACKET-PORT R |
|
|
CAP-KEYBOARD |
| BA39-01391A | CBF HARNESS-DC JACK |
| 3711-008188 | CONNECTOR-BATTERY |
| BA98-00720A | COVER ASSEMBLY-SD |
| BA39-01203B | D SUB CABLE-VGA DONGLE |
| BA39-01204E | DATA LINK CABLE-GIGABIT LAN DO |
| BA31-00161A | FAN |
| BA41-02488A | FPC-BRIDGE |
| BA41-02487A | FPC-BRIDGE |
| BA41-02499A | FPC-TP |
| BA59-04284A | HDD-SSD |
| BA59-04115A | HDD-SSD |
| 3722-003839 | JACK-PHONE |
|
|
POWER CORD-DT |
| BA67-00414A | RUBBER-CABLE |
| BA67-00903A | RUBBER-FOOT |
| BA67-00407A | RUBBER-GUIDE LCD |
| BA67-00918A | RUBBER-SUPPORT |
| 6001-003310 | SCREW-MACHINE |
| 6001-002749 | SCREW-MACHINE |
|
|
SCREW-MACHINE |
| 6001-001925 | SCREW-MACHINE |
| 6001-001650 | SCREW-MACHINE |
| 6002-001550 | SCREW-TAPPING |
| 3710-003994 | SOCKET-BOARD TO BOARD |
| 3710-003986 | SOCKET-BOARD TO CABLE |
| 3710-004000 | SOCKET-INTERFACE |
| 3710-003999 | SOCKET-INTERFACE |
| 3722-003428 | USB JACK |
