Manufacturer
Samsung
Model Number
NP900X3LK05US
Description
Note,np900x3l-exp,ini5 6200u,133l Fhdu,4
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ADAPTOR |
| BA42-00569A | ANTENNA |
| BA92-16014A | ASSEMBLY BD USB-TOP |
|
|
ASSEMBLY BD USB-TOP |
| BA97-08245A | ASSEMBLY CASE FRONT-TOP |
| BA98-00782A | ASSEMBLY CASE REAR-BOTTOM |
| BA97-08519A | ASSEMBLY CASE-FRONT_TOUCHPAD |
| BA98-00720A | ASSEMBLY COVER-SD |
| BA98-00721A | ASSEMBLY KEY-POWER |
| BA96-07031A | ASSEMBLY LCD SUBOUT |
| BA92-16001A | ASSEMBLY MOTHER BD-TOP |
| BA96-05929C | ASSEMBLY SPEAKER-LEFT |
| BA96-05928C | ASSEMBLY SPEAKER-RIGHT |
| BA64-00751A | BADGE-SAMSUNG |
| 3301-001721 | BEAD-SMD |
| 3301-001649 | BEAD-SMD |
| BA61-03057A | BRACKET-PORT_L |
| BA61-03058A | BRACKET-PORT_R |
| 2203-008158 | C-CER,CHIP |
| 2203-007486 | C-CER,CHIP |
| 2203-007456 | C-CER,CHIP |
| 2203-006741 | C-CER,CHIP |
| 2203-006399 | C-CER,CHIP |
| 2203-006260 | C-CER,CHIP |
| 2203-006166 | C-CER,CHIP |
| 2203-006048 | C-CER,CHIP |
| 2203-005344 | C-CER,CHIP |
| 2203-002720 | C-CER,CHIP |
| 2203-002050 | C-CER,CHIP |
| 2203-001683 | C-CER,CHIP |
| 2203-000715 | C-CER,CHIP |
| 2203-000627 | C-CER,CHIP |
| 2409-001129 | C-POLYMER ,CHIP |
|
|
CAP-KBD |
| BA39-01391A | CBF HARNESS-DC JACK |
|
|
CBF-POWER CORD |
| 3711-008188 | CONNECTOR-BATTERY |
| 3708-003000 | CONNECTOR-FPC/FFC/PIC |
| 3708-002933 | CONNECTOR-FPC/FFC/PIC |
| 3701-001801 | CONNECTOR-HDMI |
| 3301-001272 | CORE-FERRITEBEAD |
| 2801-005306 | CRYSTAL-SMD |
| BA39-01204D | DATA LINK CABLE-GIGABIT_LAN_DO |
| 0404-001084 | DIODE-SCHOTTKY |
| 0407-000112 | DIODE-SWITCHING |
| 0401-001168 | DIODE-SWITCHING |
| 0401-000132 | DIODE-SWITCHING |
| BA31-00161A | FAN |
| 0505-001049 | FET-GAAS |
| 0505-003299 | FET-SILICON |
| 0505-002775 | FET-SILICON |
| 0505-002562 | FET-SILICON |
| 0505-001883 | FET-SILICON |
| BA41-02488A | FPC-BRIDGE |
| BA41-02487A | FPC-BRIDGE |
| BA41-02499A | FPC-TP |
| BA59-04049A | HDD-SSD |
| 3711-007755 | HEADER-BOARD TO CABLE |
| 3711-007753 | HEADER-BOARD TO CABLE |
| BA62-00963A | HEAT SINK |
| 1203-007229 | IC-BACKLIGHT DRIVER |
| 0801-003538 | IC-CMOS LOGIC |
| 0801-002998 | IC-CMOS LOGIC |
| 0801-002628 | IC-CMOS LOGIC |
| 1203-008612 | IC-DC/DC CONVERTER |
| 1203-007885 | IC-DC/DC CONVERTER |
| 1105-002744 | IC-DDR3 SDRAM |
| 1209-001887 | IC-ETC SENSOR |
| 1205-005356 | IC-ETHERNET CONTROLLER |
| 0904-002929 | IC-I/O SUPPORT CHIP |
| 1205-004821 | IC-INTERFACE |
| 1201-003272 | IC-OP AMP |
| 1203-008464 | IC-PWM CONTROLLER |
| 1203-008443 | IC-PWM CONTROLLER |
| 1203-007109 | IC-PWM CONTROLLER |
| 1205-003683 | IC-SWITCH |
|
|
INCELL BATTERY PACK-P21G0N-01- |
| 2703-003170 | INDUCTOR-SMD |
| 2703-003169 | INDUCTOR-SMD |
| 3722-003839 | JACK-PHONE |
| 3722-003428 | JACK-USB |
| BA69-40072E | L |
| BA68-02744E | LABEL BAR CODE-BOX |
| BA68-01297A | LABEL CAUTION |
| BA68-08293A | LABEL ENERGY-STAR |
| BA68-40005L | LABEL-BARCODE |
| BA68-10191W | LABEL-BARCODE |
| BA68-11522A | LABEL-CPU_LOGO |
| BA68-20039A | LABEL-PPID_E |
| BA68-00386A | LABEL-SHIPPING |
| BA69-40254C | PACKING-PAD, OPTION |
| BA69-00052A | PACKING-PALLET |
| 2007-009872 | R-CHIP |
| 2007-009177 | R-CHIP |
| 2007-009165 | R-CHIP |
| 2007-009120 | R-CHIP |
| 2007-008791 | R-CHIP |
| 2007-008706 | R-CHIP |
| 2007-008697 | R-CHIP |
| 2007-008676 | R-CHIP |
| 2007-008593 | R-CHIP |
| 2007-008333 | R-CHIP |
| 2007-008330 | R-CHIP |
| 2007-008309 | R-CHIP |
| 2007-008304 | R-CHIP |
| 2007-008302 | R-CHIP |
| 2007-008299 | R-CHIP |
| 2007-008298 | R-CHIP |
| 2007-008294 | R-CHIP |
| 2007-008293 | R-CHIP |
| 2007-008167 | R-CHIP |
| 2007-008134 | R-CHIP |
| 2007-008032 | R-CHIP |
| 2007-008026 | R-CHIP |
| 2007-007942 | R-CHIP |
| 2007-007797 | R-CHIP |
| 2007-007767 | R-CHIP |
| 2007-007737 | R-CHIP |
| 2007-007617 | R-CHIP |
| 2007-007585 | R-CHIP |
| 2007-007520 | R-CHIP |
| 2007-007463 | R-CHIP |
| 2007-002899 | R-CHIP |
| 2007-002425 | R-CHIP |
| 2007-000969 | R-CHIP |
| 2007-000695 | R-CHIP |
| 2007-000111 | R-CHIP |
| BA67-00414A | RUBBER-CABLE |
| BA67-00903A | RUBBER-FOOT |
| BA67-00407A | RUBBER-GUIDE_LCD |
| BA67-00918A | RUBBER-SUPPORT |
| 6001-003263 | SCREW-MACHINE |
| 6001-002749 | SCREW-MACHINE |
|
|
SCREW-MACHINE |
| 6001-001925 | SCREW-MACHINE |
| 6002-001550 | SCREW-TAPPING |
| 3710-003994 | SOCKET-BOARD TO BOARD |
| 3710-003986 | SOCKET-BOARD TO CABLE |
| 3710-004000 | SOCKET-INTERFACE |
| 3710-003999 | SOCKET-INTERFACE |
| 0202-001791 | SOLDER-CREAM |
| 3404-001440 | SWITCH-TACT |
| 0203-002173 | TAPE-ATTACH MASKING |
| BA81-16125A | TAPE-SDCARD |
| 0501-000465 | TR-SMALL SIGNAL |
