Manufacturer
Samsung
Model Number
NSE6DG8550SRAA
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| DG96-01178A | |
| DG96-01097A | |
| DG94-06418A | |
| DG94-06388C | |
| DG94-05996A | |
| DG94-05928A | |
| 0201-000326 | ADHESIVE-RBR;HM-3500,LIGHT CLEAR GREY,35 |
| 0201-001970 | ADHESIVE-RBR;TK-1080N,TRANSPARENT YELLOW |
| 0201-003400 | ADHESIVE-SEALANT;DS9200,BLACK,1.5MPA.S,N |
| 0201-001528 | ADHESIVE-SIL;LDC2577D,Y/GRN,175CPS |
| 0201-001982 | ADHESIVE-SIL;TSE3854DS-W,WHITE,2.2,MIL-A |
| 0201-002023 | ADHESIVE-SL;SEALANT OK,TRP,NON-ACETIC |
| DG62-00153A | ADIABATIC DOOR-SIDE;NE59J7850WS,GLASS WO |
| DG62-00165A | ADIABATIC DOOR-SUB;NY58J9850WS,GLASS WOO |
| DG62-00008B | ADIABATIC DOOR-TOP;FX710BGS,GLASS WOOL,T |
| DG62-00154A | ADIABATIC DOOR-TOP;NE59J7850WS,GLASS WOO |
| DG62-00169A | ADIABATIC DOOR;GLASS WOOL,T20,NY9000J |
| DG62-00298A | ADIABATIC;GLASS WOOL,T25,W708,L282,KNAUF |
| DG94-03135A | APPLIANCE DOOR LOCK FRONT |
| DG94-03134A | APPLIANCE DOOR LOCK REAR |
| DG94-03469A | ASSEMBLY BASE PLATE-DRAWER;NE63T9***, NX60T9 |
| DG94-03534A | ASSEMBLY BRACKET HEATER;NE63T**,NX60T**,ELEC |
|
|
ASSEMBLY BRACKET LATCH |
| DG94-04258A | ASSEMBLY BRACKET LATCH |
|
|
ASSEMBLY BRACKET SUB |
| DG94-01210M | ASSEMBLY BRACKET SUB;NX9000T,AL,T0.3 |
| DG94-03717C | ASSEMBLY BRACKET-REAR;NE9100D, |
| DG94-06254A | ASSEMBLY BRACKET;NS*6D*,BRACKET COVER COATIN |
| DG94-03525A | ASSEMBLY CAVITY FRONT;NE63T**,NX60T**,NY63T* |
| DG94-06239A | ASSEMBLY COOKTOP CASE;NSE6D*8**0 |
| DG94-06410A | ASSEMBLY COOKTOP FRAME;NSE6DG8 |
| DG94-03530F | ASSEMBLY COVER ADIABATIC-TOP;N |
| DG94-03530E | ASSEMBLY COVER ADIABATIC-TOP;NE9100D,RADIANT |
| DG94-03621B | ASSEMBLY COVER AIR;NE63T8951, NE63T8911,EGI- |
| DG94-06253A | ASSEMBLY COVER AIR;NS*6D*,MATTE COATING |
| DG94-03517A | ASSEMBLY COVER BACK-MAIN;NE9850,ELEC FLEX(NE |
| DG94-03519A | ASSEMBLY COVER BACK;NE63T8751**,NY63T8751**, |
| DG94-03560A | ASSEMBLY COVER CASING-LOW |
| DG94-03559A | ASSEMBLY COVER CASING-UP |
| DG94-03591A | ASSEMBLY COVER FRONT-COATING;NE/NX9000T,DUAL |
| DG94-03592A | ASSEMBLY COVER FRONT-WELDING;NE/NX9000T,DUAL |
| DG94-03590A | ASSEMBLY COVER FRONT;NE/NX9000T,DUAL FLEX BE |
| DG94-03533A | ASSEMBLY COVER HEATER;NE63T**,NX60T**,ELEC M |
| DG98-02091A | ASSEMBLY CUSHION BOTTOM;NE/NX9000T,GAS / ELE |
| DG94-03588A | ASSEMBLY DOOR E-COATING;NE/NX9000T,DUAL FLEX |
| DG94-03589A | ASSEMBLY DOOR E-WELDING;NE/NX9000T,DUAL FLEX |
| DG94-01147D | ASSEMBLY HINGE UP |
| DG94-06292A | ASSEMBLY HOLDER-KNOB;NSE6D*8700**AA,RADIANT |
| DG94-06244A | ASSEMBLY KNOB SELECT;NSG6DG87* 85*,EBONY BLA |
| DG94-05990C | ASSEMBLY KNOB;NSE6D*8*****AA/C,RADIANT,DUAL |
| DG94-05990B | ASSEMBLY KNOB;NSE6D*8*****AA/C,RADIANT,SINGL |
| DG94-05990D | ASSEMBLY KNOB;NSE6D*8*****AA/C,RADIANT,TRIPP |
|
|
ASSEMBLY LAMP BULB |
| DG96-00779D | ASSEMBLY MOTOR;NE9100D,ELEC |
| DG94-03472A | ASSEMBLY PANEL OUTER COATING |
| DG94-03473A | ASSEMBLY PANEL OUTER LEFT |
| DG94-03474A | ASSEMBLY PANEL OUTER RIGHT |
|
|
ASSEMBLY PARTITION SWITCH |
| DG94-01643D | ASSEMBLY PARTITION;NX60A6751,NE63A6751,T-FS |
| DG92-01088B | ASSEMBLY PBA MODULE-DISPLAY;DISPLAY,NE/NX910 |
| DG94-06037B | ASSEMBLY PEDESTAL;NE9100D,5,3,1 SERIES |
| DG97-00167A | ASSEMBLY SCREW |
| DG97-00213A | ASSEMBLY SCREW;N*6*A****,T-PJT,M3X14 |
| DG97-00215A | ASSEMBLY SCREW;N*6*A****,T-PJT,M3X7 |
| DG97-00214A | ASSEMBLY SCREW;N*6*A****,T-PJT,M4X6 |
| DG97-00154A | ASSEMBLY SCREW;NA36K7750TS,SWRCH18A, FIBER W |
| DG97-00172A | ASSEMBLY SCREW;NX60T****,T-PJT,COVER PANEL S |
|
|
ASSEMBLY TERMINAL BLOCK |
| DG94-03532A | ASSEMBLY VENT |
| DG94-03531B | ASSEMBLY VENT-MAIN;NE63T**NX60T**,MATT EPOXY |
|
|
ASSEMBLY WIRE HARNESS-DC SIGNAL |
| DG96-00804A | ASSEMBLY WIRE HARNESS-DC SIGNAL;NX60T8751SS/ |
| DG96-01151A | ASSEMBLY WIRE HARNESS-DISPLAY;NSE6DG8700,240 |
|
|
ASSEMBLY WIRE RACK |
| DG94-00486A | ASSEMBLY-PARTITION LOWER;FE710DRS,CESP-C T0. |
| DG94-00485A | ASSEMBLY-PARTITION UPPER;FE710DRS,CESP-C T0. |
| DG94-03469E | ASSY BASE PLATE-DRAWER;NE9100D,DUAL DOOR |
| DG94-00761D | ASSY BRACKET LATCH;NE9100D, NE5000A,ALCO |
| DG94-03717A | ASSY BRACKET-REAR;NE63T**,NX60T**,ELEC M |
| DG94-06601A | ASSY COVER;NE/NX9100D,T0.4 |
| DG94-05864A | ASSY COVER;T-PJT(EXCEPT 6311,6111,6515) |
| DG94-06398A | ASSY DOOR-MAIN;NSG6D89**,DUAL DOOR |
| DG94-06391A | ASSY DOOR-UP;NSG6D89**,STS,DUAL DOOR UP |
| DG94-06390A | ASSY DOOR;NSG6D89**,STS,DUAL DOOR |
| DG94-06032E | ASSY DRAWER;NSE6DG8500SRAA,STS, SLIDER |
| DG94-06397A | ASSY HANDLE;NSG6D89**,AL,STS,DUAL DOOR |
| DG94-06342A | ASSY HINGE;NE/NX9100D,30 NEW S/I SOFT CL |
| DG94-06231B | ASSY HOLDER PCB;NS*6DG8750SRAA,RAD&GAS,D |
| DG98-02152A | ASSY PACKING TRAY;NX9850,TRAY RACK PACKI |
| DG92-01424C | ASSY PCB MAIN;OVEN_PF1_23 MAIN,NE/NX9100 |
|
|
ASSY SENSOR;NE63T**,NX60T**,NY63T**,T-PJ |
| DG94-02565E | ASSY SUPPORT HINGE;24 NEW S/I 30 DUAL DO |
| DG96-00997A | ASSY WIRE HARNESS-COOKTOP;NE63T8511S,240 |
| DG96-00813A | ASSY WIRE HARNESS-DC SIGNAL;NE63T8751SS/ |
| DG62-00148A | BAFFLE DOOR |
| DG62-00291A | BAFFLE DOOR-LOW;NX9000T,GI-SGCC,DUAL DOO |
| DG62-00294A | BAFFLE DOOR-UP;NX9000T,GI-SGCC,DUAL DOOR |
| DG69-00376A | BAG ACCESSORY;NE58K9850WS,LDPE,T0.08,L83 |
| 6902-003459 | BAG PE;HDPE,MAKER : G WORLD,T0.015,W250, |
| DG81-00480A | BAG PE;LDPE,T0.03,W150,L200,TRP,RECYCL |
| 6902-000336 | BAG ZIPPER |
| 6922-000009 | BAND PP |
| DG61-01876A | BASE DRAWER-LEFT;NE63T****,NX60T****,NY6 |
| DG61-01876E | BASE DRAWER-LEFT;NE9100D,ALCOAT-SA1C,T0. |
| DG61-01877B | BASE DRAWER-REAR;NE63T****,NX6 |
| DG61-01877A | BASE DRAWER-REAR;NE63T****,NX60T****,NY6 |
| DG61-01875A | BASE DRAWER-RIGHT;NE63T****,NX60T****,NY |
| DG61-01875E | BASE DRAWER-RIGHT;NE9100D,ALCOAT-SA1C,T0 |
| DG61-02070B | BASE DRAWER;NE63T****,NX60T*** |
| DG61-02070A | BASE DRAWER;NE63T****,NX60T****,NY60T*** |
| 3301-002113 | BEAD-SMD;470 OHM/100MHZ 470 OHM/100MHZ,2 |
|
|
BOLT-HEX |
| DG61-01968A | BRACKET BARRIER-REAR;NE63T****,NX60T**** |
| DG61-01968B | BRACKET BARRIER-REAR;NE9100D,A |
| DG61-02757B | BRACKET BARRIER;NE9100D,ALCOAT-SA1C,T0.4 |
| DG61-02757A | BRACKET BARRIER;NE9100D,GI-SGCC,T0.4,W71 |
| DG61-00803A | BRACKET BOTTOM-LEFT;NE58F9710WS,GI-SGCC, |
| DG61-00803B | BRACKET BOTTOM-LEFT;NE9100D,ALCOAT-SA1C, |
| DG61-00808A | BRACKET BOTTOM-RIGHT;NE58F9710WS,GI-SGCC |
| DG61-00808B | BRACKET BOTTOM-RIGHT;NE9100D,ALCOAT-SA1C |
| DG61-00779A | BRACKET BROIL;NE58F9710WS,ALCOAT-SA1C,T0 |
| DG61-01213A | BRACKET CASING;NV51K6650DS,CR-SPE,T0.6,N |
| DG61-01931A | BRACKET CAVITY-LEFT;NY63T8751**, NE63T87 |
| DG61-01932A | BRACKET CAVITY-RIGHT;NY63T8751**, NE63T8 |
| DG61-01952B | BRACKET COOK TOP;NE9100D,ALCOA |
| DG61-01952A | BRACKET COOK TOP;OVEN NE63T****,T PJT , |
| DG61-02076A | BRACKET COVER;NE63T****,NE63A****,GI-SGC |
| DG61-02076C | BRACKET COVER;NSI6DG9900,ALCOA |
| DG61-01959A | BRACKET DOOR-LEFT;NX9000T,CR-SPE,T0.8,W3 |
| DG61-00963B | BRACKET DOOR-MIDDLE;NE/NX9000T,CR-SPE,T0 |
| DG61-01958A | BRACKET DOOR-RIGHT;NX9000T,CR-SPE,T0.8,W |
| DG61-01960A | BRACKET DOOR-UP;NX9000T,CR-SPE,T1,W735,L |
| DG61-00983M | BRACKET DOOR;NX9000T,AL,T0.3,W666,L33 |
| DG61-02007A | BRACKET ELEC |
| DG61-02007B | BRACKET ELEC;NE9100D,ALCOAT-SA1C,T0.5,W4 |
| DG61-01540A | BRACKET GUIDE;NE59J7850WS,STS430,T1.2,W3 |
| DG61-01928A | BRACKET HEATER-BROIL;NE9850,ALCOAT-SA1C, |
| DG61-02841B | BRACKET HEATER-RADIANT;NE9100D,ALCOAT-SA |
| DG61-02746B | BRACKET HEATER-RADIANT;NE9100D,ALCOAT-SA |
| DG61-02745B | BRACKET HEATER-RADIANT;NE9100D,ALCOAT-SA |
| DG61-02745A | BRACKET HEATER-RADIANT;NE9100D,GI-SGCC,T |
| DG61-02746A | BRACKET HEATER-RADIANT;NE9100D,GI-SGCC,T |
| DG61-02841A | BRACKET HEATER-RADIANT;NZ9100D,GI-SGCC,T |
| DG61-01938A | BRACKET HEATER-SUB;NE63T**,NX60T**,GI-SG |
| DG61-01938B | BRACKET HEATER-SUB;NSI6DG9900, |
| DG61-00142E | BRACKET HEATER;NE9100D,ALCOAT-SA1C,T1.2, |
| DG61-01865A | BRACKET HINGE;NX9000T,GI-SGCC,T1.6,W144, |
| DG61-00965A | BRACKET HOLDER;NE59J7850WS,GI-SGCC,T0.5, |
| DG61-00894A | BRACKET HOLDER;VAPOR,CR-SPCC,T1.2 |
| DG61-01924A | BRACKET MOTOR-SUB;NE63T**,NX60T**,NY63T* |
| DG61-01924B | BRACKET MOTOR-SUB;NE9100D,ALCO |
| DG61-02766C | BRACKET MOTOR-UP;NSI6DG9900,AL |
| DG61-01051B | BRACKET PANEL;NX9000T, NE9000T,AL,T0.3,W |
| DG61-00783A | BRACKET STOPPER;NE58F9710WS,GI-SGCC,T1,W |
| DG61-02910A | BRACKET STOPPER;NE9100D,ALCOAT |
| DG61-02818B | BRACKET SUPPORTER-LEFT;NE9100D,ALCOAT-SA |
| DG61-02819B | BRACKET SUPPORTER-RIGHT;NE9100D,ALCOAT-S |
| DG61-01926A | BRACKET VENT-UP;NE63T**,NX60T**,ALCOAT-S |
|
|
BRACKET-GROUND;FTQ386LWUX,GI-SGCC,0.8,14 |
| DG61-00212B | BRACKET-GROUND;NSI6DG9900,ALCO |
| DG61-00142B | BRACKET-HEATER;NE63*******,GI-SGCC,T1.2, |
| DG61-00661A | BRACKET-LATCH REAR |
| DG61-00661B | BRACKET-LATCH REAR;NSI6DG9900,ALCOAT-SA1 |
| DG61-00732A | BRACKET-LATCH SUB |
| DG61-00732B | BRACKET-LATCH SUB;NSI6DG9900,ALCOAT-SA1C |
| DG61-02094A | BRACKET-LATCH;T-FS,GI-SGCC,T1,W80,L72.6 |
| DG61-01990A | BRACKET-LEG;NE9000T,GI-SGCC,T1.6,W185,L9 |
| DG61-00206A | BRACKET-MULTI CONNECTOR |
| DG61-00206B | BRACKET-MULTI CONNECTOR;NSI6DG |
| DG61-00651A | BRACKET-PARTITION SWITCH;IP3,GI-SGCC,T0. |
| DG61-00291A | BRACKET-SLIDER;FCQ321HSUX,GI-SGCC,T0.8,W |
| DG61-00227A | BRACKET-SUPPORT HINGE;FTQ386LWUX,CR-SPE, |
| DG64-00763A | BUTTON PUSH;NE59J7850WS,PPS+GF40%,BLACK |
| 3002-001139 | BUZZER-PIEZO |
| 2402-001268 | C-AL, SMD |
| 2402-001368 | C-AL, SMD |
| 2402-001517 | C-AL,SMD;47UF,20%,50V,TP,6.3X6.3X7.7MM, |
| 2401-006180 | C-AL;100UF,20%,500V,WT,BK,25.4X30MM,10MM |
| 2401-004553 | C-AL;820UF,20%,25V,TP,10X20MM,5MM,-40TO+ |
| 2203-000627 | C-CER, CHIP |
| 2203-002285 | C-CER, CHIP |
| 2203-006158 | C-CER, CHIP |
| 2203-007306 | C-CER, CHIP |
| 2203-007456 | C-CER, CHIP |
| 2203-007513 | C-CER, CHIP |
| 2203-007544 | C-CER, CHIP |
| 2203-008315 | C-CER, CHIP |
| 2203-010495 | C-CER,CHIP;2.2UF,10%,25V,X7R,TP,2012,T1. |
| 2203-010033 | C-CER,CHIP;220NF,10%,25V,X5R,TP,1005,T0. |
| 2203-010496 | C-CER,CHIP;4.7UF,10%,25V,X7R,TP,2012,T1. |
| 2201-002429 | C-CERAMIC,DISC;10NF,+80-20%,2000V,Y5U,TP |
| 2201-002688 | C-CERAMIC,DISC;2.2NF,20%,400VAC,Y5U,TP,1 |
| 2201-002709 | C-CERAMIC,DISC;33PF,5%,1000V,SL,TP,6.3X5 |
| 2201-002711 | C-CERAMIC,DISC;470PF,10%,400VAC,Y5P,TP,1 |
| 2201-002335 | C-CERAMIC,DISC;68PF,10%,2000V,SL,TP,8X5M |
| 2301-002481 | C-FILM,LEAD-MPPF |
| 2301-002484 | C-FILM,LEAD-MPPF;470NF,10%,275VAC,BK,18X |
| 2301-002011 | C-FILM,LEAD-PPF;2.2NF,5%,630V,TP,13X11X6 |
| 6502-001117 | CABLE CLAMP |
|
|
CAM-DOOR LATCH |
| DG67-00030C | CAP-SHAFT PARTITION;NE599N1PBSR,STAINLES |
| DG61-02751B | CASE BURNER;NE9100D,ALCOAT-SA1C,T0.4,L70 |
| DG61-01900A | CAVITY FRONT;1* NE63T8751*,NX60T8751*,NY |
| DG61-01909A | CAVITY MAIN;NE63T8751**, NY63T8751**,CR- |
| DG61-01911D | CAVITY UP;NE63T8511*,8311*,8111*,CR-SPE, |
| 0204-009273 | COATING AGENT;DS8802FL,50~60%,300CPS,TRA |
| DB27-00011A | COIL CHOKE |
| DA27-00062A | COIL CHOKE;18MH,6A,16MMX18MM,MN-ZN,4P,DI |
| 3708-003344 | CONNECTOR-FPC/FFC/PIC;15P,1.0MM,SMD-A,SN |
| 3708-003265 | CONNECTOR-FPC/FFC/PIC;20P,1MM,SMD-A,SN,Y |
| 3711-000261 | CONNECTOR-HEADER |
| 3711-000262 | CONNECTOR-HEADER |
| 3711-000357 | CONNECTOR-HEADER |
| 3712-001770 | CONNECTOR-TERMINAL;TAB,MALE,12,12.8MM/10 |
| 3712-001769 | CONNECTOR-TERMINAL;TAB,MALE,12,12.8MM/15 |
| DG63-00955C | COVER ADIABATIC-TOP;NE9100D,ALCOAT-SA1C, |
| DG63-00685A | COVER AIR;NE63T**,NX60T**,NY63T**,GI-SGC |
| DG63-00678B | COVER AIR;NE63T8951, NE63T8911,EGI-SECC, |
| DG63-00685B | COVER AIR;NSI6DG9900,ALCOAT-SA |
| DG63-00677C | COVER BACK |
| DG63-00677A | COVER BACK |
| DG63-00702A | COVER BACK-MAIN;NE63T**,NY63T**,GI-SGCD, |
| DG63-00702C | COVER BACK-MAIN;NSI6DG9900,ALC |
| DG63-00690A | COVER CASING-LOW;NE63T8751**, NY63T8751* |
| DG63-00692A | COVER CASING-UP;NE63T8751(NE9850),CR-SPE |
| DG63-00687A | COVER DOOR |
| DG63-00396A | COVER GLASS;NE59J7850WS,GI-SGCC,T0.5,- |
| DG63-00725B | COVER HEATER-TOP;NE5000A,GI-SGCC,T0.5 |
| DG63-00725D | COVER HEATER-TOP;NE9100D,ALCOA |
| DG63-00693A | COVER HEATER;NE63T**,NX60T**,ALCOAT-SA1C |
| DG63-00418A | COVER PANEL |
| DG63-00419A | COVER PANEL |
| DG63-00674A | COVER PCB-LCD;8951,8751,8911,8711 NY63T8 |
| DG63-00682A | COVER WIRE;NE63T****,NY63T****,GI-SGCC,T |
| 2801-000258 | CRYSTAL-SMD |
| DG69-00491A | CUSHION BOTTOM;NX/NE9000T,EPS,W827,L749, |
| DG69-00063A | CUSHION DOOR;FTQ386LWUX,EPS,W43.5,L50,H2 |
| DG69-00493A | CUSHION DRAWER;NX/NE9000T,EPS,W234,L52,H |
| DG69-00005A | CUSHION-TOP PLATE |
| 0402-001224 | DIODE-BRIDGE |
| 0402-001472 | DIODE-RECTIFIER |
| 0402-001741 | DIODE-RECTIFIER;S1M,1000V,1A,SMA,TP |
| 0404-001250 | DIODE-SCHOTTKY |
| 0401-001099 | DIODE-SWITCHING |
| 0406-001239 | DIODE-TVS |
| 0406-001689 | DIODE-TVS |
| 0406-001906 | DIODE-TVS;SMF200A,224V,SOD-123FL,200W,TP |
| 0403-000461 | DIODE-ZENER |
| 0403-001164 | DIODE-ZENER |
| DG64-00920A | DOOR E-MAIN;NX9000T,CR-SPE,T0.7,W840,L69 |
| DG64-00904A | DOOR E-UP;NX9000T,CR-SPE,T0.7,W820,L430, |
| DG94-06032A | DRAWER |
|
|
FAN CONVECTION-LOW |
|
|
FAN CONVECTION-UP |
| 0505-000110 | FET-SILICON |
| 0505-003755 | FET-SILICON;AOD2910E,N,100V,37A,23MOHM,7 |
| 0505-001943 | FET-SILICON;FDN342P,P,20V,2A,0.08OHM,0.5 |
| DG63-00148A | FILTER MESH;FTQ**, FCQ**,STS304,T0.23,#3 |
| DG60-00042A | FLANGE COVER REAR;NE63T**,NX60T**,NY63T* |
| DG60-00042B | FLANGE COVER REAR;NSI6DG9900,A |
| 0204-004665 | FLUX;KSP-70M-S,MIXTURE,NO,FLUX,13% |
| DG61-00966A | FRAME INNER GLASS;NE59J7850WS,GI-SGCC, |
| DG61-00479A | FRAME-PARTITION BACK;FE710DRS*,STS430,T0 |
| DG61-00478A | FRAME-PARTITION FRONT;FE710DRS*,STS430,T |
| 3601-001288 | FUSE-AXIAL LEAD;250V,2.5A,TIME-LAG,CERAM |
| DG63-00720B | GASKET;NE/NX9100D,GLASS FIBER,T12, |
| DG63-00784A | GASKET;NE63T8***, NX60T8****,GLASS FIBER |
| DG64-00947A | GLASS DOOR IN |
| DG64-00952A | GLASS DOOR SUB |
| DG64-00541C | GLASS-IN;NE59M6850**,GLASS,T4,W526,L161, |
| DG63-00107A | GROUND-TERMINAL BLOCK |
| DG61-01925A | GUIDE AIR VENT-UP;NE63T**,NX60T**,ALCOAT |
| DG61-01896A | GUIDE AIR-LOW;OVEN NE63T****,T PJT , ELE |
| DG61-00480A | GUIDE-PARTITION;FE710DRS,TEFLON-PTFE,T6, |
| 3711-002046 | HEADER-BOARD TO CABLE |
| 3711-009393 | HEADER-BOARD TO CABLE;BOX,24P,2R,2.0MM,S |
| 3711-009394 | HEADER-BOARD TO CABLE;BOX,26P,2R,2.0MM,S |
| 3711-009395 | HEADER-BOARD TO CABLE;BOX,28P,2R,2.0MM,S |
| 3711-009166 | HEADER-BOARD TO CABLE;BOX,5P,1R,2.0MM,SM |
| 3711-009169 | HEADER-BOARD TO CABLE;BOX,5P,1R,2.0MM,SM |
| 3711-009233 | HEADER-BOARD TO CABLE;BOX,7P,1R,2.0MM,SM |
| 3711-008881 | HEADER-BOARD TO CABLE;BOX,9P,1R,2.5MM,PI |
| 3711-008909 | HEADER-BOARD TO CABLE;TP,SMD-S,1R,12P,2. |
|
|
HEATER MICA-WARMING |
|
|
HEATER RADIANT-DUAL |
|
|
HEATER RADIANT-SINGLE |
|
|
HEATER RADIANT-TRIPLE |
| DG47-00071C | HEATER SHEATH-BOTTOM |
|
|
HEATER SHEATH-CONVECTION |
|
|
HEATER SHEATH-GRILL |
| DG61-00968A | HOLDER DOOR LOCK-REAR;NE59J7850WS,CR-SPE |
| DG61-02792A | HOLDER KNOB;NSE6DG8700SRAA,PC,T1.9,EBONY |
| DG61-01538A | HOLDER LOCK-FRONT;NE59J7850WS,GI-SGCC,T2 |
| DG61-01539A | HOLDER LOCK-REAR;NE59J7850WS,GI-SGCC,T2, |
| DG61-01919A | HOLDER PCB-MAIN;NE,NX(8751**,8711**),NY8 |
| 1202-001090 | IC VOLTAGE COMP. |
| 1001-001942 | IC-ANALOG SWITCH |
| 1205-004505 | IC-BUS SWITCH;TSSOP,14P,7V,180MW,-40TO+8 |
| 1203-009429 | IC-DC/DC CONVERTER;SYU812C1,SOT23-6,6P,3 |
| 1103-001183 | IC-EEPROM |
| 1003-002158 | IC-LED DRIVER;TLC59116,TSSOP,28P,9.80MM, |
| 0903-002266 | IC-MICROCONTROLLER;A34M418YLN-01,LQFP,12 |
| 0903-002203 | IC-MICROCONTROLLER;HART-M320,MQFP,100P,2 |
| 1201-000166 | IC-OP AMP |
| 1201-001125 | IC-OP AMP |
| 1203-006759 | IC-POSI.ADJUST REG. |
| 1203-000294 | IC-POSI.FIXED REG. |
| 1203-002835 | IC-POSI.FIXED REG. |
| 1203-009642 | IC-PWM CONTROLLER;SC1551C-H084-TL,24P,SO |
| 1203-001211 | IC-VOL. DETECTOR |
| 1203-006245 | IC-VOL. DETECTOR |
| 2703-004724 | INDUCTOR-SMD |
| DE68-04077A | LABEL BOX;ALL SAMSUNG-KS,PRACTI,MGP,PAPE |
| DG68-00102B | LABEL CAUTION-DOOR |
| DG68-00101B | LABEL CAUTION-DOOR;30 OVEN,SEA,TETRON SI |
| DG68-01034A | LABEL INSTRUCTION;NE59M6850SS,PET,W100,L |
| DG68-00785A | LABEL INSTRUCTION;NX58K7850SS,PET,80,18, |
| 6812-000145 | LABEL INTEGRATION QR;PET,LAMINATE COATED |
| DG68-00279C | LABEL RATING;30 OVEN,SEA/SECA,TETRON,W13 |
| DG68-00100B | LABEL WARNING;30 OVEN,SEA,SECA,PET,W150, |
| DG68-00424A | LABEL-DOOR;30 OVEN,PAPER,W200,L120,200*1 |
| DG68-00099A | LABEL-POWER |
| DG47-00069A | LAMP-ETC;SP-2157-BLPS,D12.5X47.1MM,BK,1. |
| DG66-00072A | LATCH DOOR;T-FS,CR-SPCC,ZN PLATING,T2.3 |
| DG07-01012A | LCD;57.09X30.1MM,-20TO+85C,3.3V,-30TO+85 |
| 0601-001986 | LED |
| DG61-01956A | LEG LEVELING;T-PJT NE63T****,NX60T****,N |
|
|
LEG-LEVELING |
| DG66-00056A | LEVER LOCK-FRONT;NE59J7850WS,GI-SGCC,PRE |
| DG66-00057A | LEVER LOCK-REAR;NE59J7850WS,GI-SGCC,PRES |
| DG66-00026A | LEVER-PARTITION SWITCH;IP3,PBT+GF15%,B44 |
| DG64-00768A | LOCKER;NX58K9850SS,GI-SGCC,PRESS+ZN-NI C |
| DG68-00493A | MANUAL INSTALL;FE*,NE*,FX*,NX*,ENGLISH,S |
| DG68-01085A | MANUAL INSTRUCTION;NE5000N,USA/CANADA,EN |
|
|
MOTOR AC CONVECTION |
|
|
MOTOR AC CONVECTION |
| DG31-00025B | MOTOR AC DRIVE |
| DG31-00026D | MOTOR AC FAN-BLOWER;SMB-U485F, |
|
|
NUT-HEXAGON CAP |
|
|
NUT-HEXAGON CAP |
| DG69-00054A | PACKING ANGLE-FRONT;NE59J76**,PAPER,T7,W |
| DG69-00508A | PACKING ANGLE;NE/NX9000T,PAPER,W45,L10 |
| DG69-00166D | PACKING ANGLE;NX7000J,PAPER,T8,W65,L749 |
| DG69-00166H | PACKING ANGLE;NX9000T,PAPER,T7,W50,L740, |
| DG69-00509A | PACKING CASE ACCESSORY;NE/NX9000T,CB,SW1 |
| DG69-00506A | PACKING CASE BOTTOM;NE/NX9000T,CB,SW2,L8 |
| DG69-00188A | PACKING CASE;NE-F900A-PJT,CB,DW3,L769,W8 |
| DG69-00185A | PAD CUSHION;NE-F900A-PJT,EPS,50X,150,35, |
| DG69-00163B | PAD CUSHION;NE5000A, NX5000A,EPS,W50,L50 |
| DG69-00618A | PAD PACKING;NX/NE9000T,CB,SW1,SET,- |
| DG63-00241A | PAD SHEET;NX583G0VBSR,LDPE,T0.05,W200,L1 |
| DG69-00102B | PAD-RACK FLAT;FE710DRS*,PAPER,W100,L630, |
| DG69-00102A | PAD-RACK FLAT;FTQ**, FCQ**,PAPER,W70,L44 |
| DG64-00915A | PANEL-SIDE;NE63T****,NX60T****,NY60T**** |
| DG67-00048A | PARTITION-LOWER;FE710DRS*,CR-SPE,T0.6 |
| DG67-00047A | PARTITION-UPPER;FE710DRS*,CR-SPE,T0.6,W5 |
| 0604-001405 | PHOTO-COUPLER;TR,200-400%,200MW,SOP,TP |
| DE60-60030A | PIN-STAPLE |
| DG02-01003A | POWDER-CERAMIC;ATAG,ENAMEL,DARK BLUE GRA |
| DG02-01003B | POWDER-CERAMIC;ATAG,ENAMEL,DARK BLUE GRA |
| DG02-01001D | POWDER-CERAMIC;ESP PD650,ENAMEL,BLUE/WHI |
| 0106-001192 | POWDER-EPOXY;H-BK0605-S9,POLIESTER RESIN |
| 2007-000238 | R-CHIP |
| 2007-000279 | R-CHIP |
| 2007-000286 | R-CHIP |
| 2007-000293 | R-CHIP |
| 2007-000297 | R-CHIP |
| 2007-000308 | R-CHIP |
| 2007-000312 | R-CHIP |
| 2007-000352 | R-CHIP |
| 2007-000394 | R-CHIP |
| 2007-000441 | R-CHIP |
| 2007-000465 | R-CHIP |
| 2007-000476 | R-CHIP |
| 2007-000490 | R-CHIP |
| 2007-000508 | R-CHIP |
| 2007-000530 | R-CHIP |
| 2007-000537 | R-CHIP |
| 2007-000670 | R-CHIP |
| 2007-000677 | R-CHIP |
| 2007-000700 | R-CHIP |
| 2007-000762 | R-CHIP |
| 2007-000944 | R-CHIP |
| 2007-000945 | R-CHIP |
| 2007-001011 | R-CHIP |
| 2007-001015 | R-CHIP |
| 2007-001162 | R-CHIP |
| 2007-001190 | R-CHIP |
| 2007-001297 | R-CHIP |
| 2007-007336 | R-CHIP |
| 2007-007942 | R-CHIP |
| 2007-008175 | R-CHIP |
| 2007-008269 | R-CHIP |
| 2007-008485 | R-CHIP |
| 2007-008779 | R-CHIP |
| 2007-008791 | R-CHIP |
| 2007-009922 | R-CHIP |
| 2007-010245 | R-CHIP;0.01OHM,1%,2W,TP,6432 |
| 2007-000641 | R-CHIP;270OHM,1%,1/4W,TP,3216 |
| 2007-000764 | R-CHIP;330OHM,1%,1/4W,TP,3216 |
| 2007-001132 | R-CHIP;68OHM,1%,1/4W,TP,3216 |
|
|
RACK WIRE;NE59N6630SS,NE5000N,MSWR,W62 |
|
|
REGULATOR ENERGY;PER001-02D,18A,D-CUT,DU |
|
|
REGULATOR ENERGY;PER001-13D,15A,D-CUT,TR |
| DG44-01012A | REGULATOR ENERGY;PER002-01D,6.0A,D-CUT,S |
| 3501-001306 | RELAY-MINIATURE;12VDC,3000MA,1FORMA,10MS |
|
|
RELAY-POWER |
| 3501-001323 | RELAY-POWER;12V,30000MA,1FORMA,10MS,5MS, |
| 2802-001211 | RESONATOR-CERAMIC |
| DG67-00219A | RUBBER DAMPER;NE63T8111,NE63T8311,SILICO |
| DG67-00227A | RUBBER RING;BEST MODEL,SILICON RUBBER,T1 |
|
|
RUBBER-CUSHION |
| 6502-001149 | SADDLE;TIC-WSD21.5,W30.5,H33.3,T3.5,NYLO |
| 6001-000618 | SCREW-MACHINE |
| 6001-001122 | SCREW-MACHINE |
| 6001-002267 | SCREW-MACHINE |
|
|
SCREW-MACHINE |
| 6001-003299 | SCREW-MACHINE;TH,+,WP,M5,L16,ZPC(BLK),SW |
|
|
SCREW-SPECIAL |
| 6009-002193 | SCREW-SPECIAL;HH,+,M5,L25,ZPC(WHT),SWRCH |
| 6002-000413 | SCREW-TAPPING |
| 6002-000432 | SCREW-TAPPING |
| 6002-000440 | SCREW-TAPPING |
|
|
SCREW-TAPPING |
|
|
SCREW-TAPPING |
| DE60-00003A | SCREW-TAPPING |
| DE60-10193A | SCREW-TAPPING |
| 6002-001425 | SCREW-TAPPING;TH,+,2S,M4,L12,ZPC(BLK),SW |
|
|
SCREW-TAPTYPE |
|
|
SENSOR TEMP |
|
|
SENSOR-THERMISTOR |
| DG66-00027B | SHAFT-PARTITION SWITCH;FLEX, IP3,STS304, |
| DG63-00039B | SHEET-PARTITION;FE710DRS,AL,W605,L450,AL |
| DG63-00721A | SHIELD DRAWER;NX60T5***,NE63T5***,GI-SGC |
|
|
SLIDER-INNER |
|
|
SLIDER-OUTER |
| DG94-03528N | SMG PART |
| DG94-03527N | SMG PART |
| DG94-03525J | SMG PART |
| DG63-00721E | SMG PART |
| DG62-00302N | SMG PART |
| DG61-01900J | SMG PART |
| 2007-007310 | SMG PART |
| 0106-001605 | SMG PART |
| 0106-001577 | SMG PART |
| 0203-002310 | SMG PART |
| 1205-006575 | SMG PART |
| 2007-007107 | SMG PART |
| 2007-007131 | SMG PART |
| 2007-007132 | SMG PART |
| 2007-007136 | SMG PART |
| 2007-007139 | SMG PART |
| 2007-007142 | SMG PART |
| 2007-007306 | SMG PART |
| 2007-007309 | SMG PART |
| 2007-007311 | SMG PART |
| 2007-007312 | SMG PART |
| 2007-007317 | SMG PART |
| 2007-007318 | SMG PART |
| 2007-007334 | SMG PART |
| 2007-007405 | SMG PART |
| 2007-007573 | SMG PART |
| 2007-007589 | SMG PART |
| 2007-007590 | SMG PART |
| 2007-007671 | SMG PART |
| 2007-007698 | SMG PART |
| 2007-007766 | SMG PART |
| 2007-007861 | SMG PART |
| 2007-007946 | SMG PART |
| 2007-008117 | SMG PART |
| 2007-008263 | SMG PART |
| 2203-000233 | SMG PART |
| 2203-000278 | SMG PART |
| 2203-000386 | SMG PART |
| 2203-000438 | SMG PART |
| 2203-000489 | SMG PART |
| 2203-000585 | SMG PART |
| 2203-006842 | SMG PART |
| 2203-007392 | SMG PART |
| 2203-007795 | SMG PART |
| 2203-007809 | SMG PART |
| 4709-003216 | SMG PART |
| 6021-002125 | SMG PART |
| 6041-001084 | SMG PART |
| 6041-001085 | SMG PART |
| 6902-004215 | SMG PART |
| DB68-08717A | SMG PART |
| DE60-20061A | SMG PART |
| DE92-04799A | SMG PART |
| DE92-04801A | SMG PART |
| DE92-04802A | SMG PART |
| DG01-00246A | SMG PART |
| DG01-00247A | SMG PART |
| DG01-00248A | SMG PART |
| DG01-00249A | SMG PART |
| DG01-00295A | SMG PART |
| DG01-00296A | SMG PART |
| DG01-00300A | SMG PART |
| DG01-00307A | SMG PART |
| DG41-00063A | SMG PART |
| DG41-00064A | SMG PART |
| DG61-01868A | SMG PART |
| DG61-01869A | SMG PART |
| DG61-01971C | SMG PART |
| DG61-01993B | SMG PART |
| DG61-01994C | SMG PART |
| DG61-02739A | SMG PART |
| DG61-02741A | SMG PART |
| DG61-02742A | SMG PART |
| DG61-02743A | SMG PART |
| DG61-02744A | SMG PART |
| DG61-02747A | SMG PART |
| DG61-02748A | SMG PART |
| DG61-02751A | SMG PART |
| DG61-02766B | SMG PART |
| DG61-02769A | SMG PART |
| DG61-02774B | SMG PART |
| DG61-02793A | SMG PART |
| DG61-02797A | SMG PART |
| DG61-02816B | SMG PART |
| DG61-02817B | SMG PART |
| DG61-02818A | SMG PART |
| DG61-02819A | SMG PART |
| DG61-02840B | SMG PART |
| DG61-02865A | SMG PART |
| DG61-02866A | SMG PART |
| DG61-02867A | SMG PART |
| DG61-02874A | SMG PART |
| DG62-00304D | SMG PART |
| DG63-00932B | SMG PART |
| DG63-00946A | SMG PART |
| DG63-00955A | SMG PART |
| DG63-00956A | SMG PART |
| DG63-00972A | SMG PART |
| DG64-00906A | SMG PART |
| DG64-00907A | SMG PART |
| DG64-00908A | SMG PART |
| DG64-00910A | SMG PART |
| DG64-00911A | SMG PART |
| DG64-00921A | SMG PART |
| DG64-01038B | SMG PART |
| DG64-01265A | SMG PART |
| DG64-01266A | SMG PART |
| DG64-01267A | SMG PART |
| DG64-01272A | SMG PART |
| DG64-01292A | SMG PART |
| DG64-01294A | SMG PART |
| DG64-01316A | SMG PART |
| DG64-01322A | SMG PART |
| DG64-01323A | SMG PART |
| DG64-01324A | SMG PART |
| DG66-00071B | SMG PART |
| DG66-00100A | SMG PART |
| DG67-00312A | SMG PART |
| DG67-00313A | SMG PART |
| DG68-01625A | SMG PART |
| DG68-01635A | SMG PART |
| DG69-00782A | SMG PART |
| DG69-00782B | SMG PART |
| DG69-00784A | SMG PART |
| DG69-00784B | SMG PART |
| DG69-00791A | SMG PART |
| DG69-00809A | SMG PART |
| DG90-01482A | SMG PART |
| DG92-01412A | SMG PART |
| DG92-01421B | SMG PART |
| DG94-03523C | SMG PART |
| DG94-03689D | SMG PART |
| DG94-03706B | SMG PART |
| DG94-05991A | SMG PART |
| DG94-05998A | SMG PART |
| DG94-06034A | SMG PART |
| DG94-06034B | SMG PART |
| DG94-06226B | SMG PART |
| DG94-06235A | SMG PART |
| DG94-06240A | SMG PART |
| DG94-06241A | SMG PART |
| DG94-06379A | SMG PART |
| DG94-06381A | SMG PART |
| DG94-06382A | SMG PART |
| DG94-06393A | SMG PART |
| DG94-06394A | SMG PART |
| DG94-06395A | SMG PART |
| DG94-06396A | SMG PART |
| DG94-06399A | SMG PART |
| DG94-06400A | SMG PART |
| DG94-06401A | SMG PART |
| DG94-06402A | SMG PART |
| DG94-06403A | SMG PART |
| DG94-06404A | SMG PART |
| DG94-06408A | SMG PART |
| DG94-06409A | SMG PART |
| DG94-06417A | SMG PART |
| DG98-02576A | SMG PART |
| DG98-02576B | SMG PART |
| DG98-02578A | SMG PART |
| DG98-02578B | SMG PART |
| 0202-001338 | SOLDER-BAR |
| 0202-001976 | SOLDER-CREAM;LST-309M-K21 (PWM-118),D20~ |
| 0202-001463 | SOLDER-WIRE |
| 0204-005225 | SOLVENT;IT-700,R-OH,100%,0.786 |
|
|
SPACER-SIDE PANEL |
| DG60-00041A | SPACER;NE63T**,NX60T**,NY63T**,GI-SGCC,T |
| DG61-00659A | SPRING ETC-LEVER;FLEX,STAINLESS-STS304,D |
| DG61-00258A | SPRING ETC-RING;BT62FQBPST,STAINLESS-STS |
| DA61-09988A | SPRING-RIGHT;FDSR,STS304 |
| 3502-001075 | SSR;DC12V,0.3A,600V,-30TO+85C,0.05A,AC75 |
| 3502-001087 | SSR;DC12V,2A,9.6-25MV,-30TO+80C,0.028A,A |
| DG61-02811A | STOPPER-KNOB;NS*6D*8*00**AA,POM,T1.8,W15 |
| DG61-01874A | SUPPORT CAVITY-LEFT;NE63T**,NX60T**,NY63 |
| DG61-01908A | SUPPORT CAVITY-RIGHT;NE63T**,NX60T**,NY6 |
| DG61-01957A | SUPPORT FRAME;T-PJT NE63T****,NX60T****, |
|
|
SUPPORT HEATER |
|
|
SUPPORT-WARMING HEATER |
| 4715-001217 | SURGE ABSORBER;3600V,20%,3000A,AXIAL |
|
|
SWITCH-DOOR PLUNGER |
|
|
SWITCH-MICRO |
| DG34-00046A | SWITCH;DC5V,0.5MA,32 POSITIONS, 16 PULSE |
| DA02-00092A | TAPE ETC-OPP;BLUE,OPP,T0.08,W45,L50M,COL |
| DE02-00029B | TAPE FILAMENT |
| DE02-00027A | TAPE OPP |
| 0203-000444 | TAPE-AL FOIL |
| 0203-001825 | TAPE-DOUBLE FACE |
| 0203-001109 | TAPE-OPP MASKING |
| 0203-007184 | TAPE-SINGLE FACE;PO,T0.07,W50,L100M,CLEA |
| 1404-001481 | THERMISTOR-NTC , 5OHM,7A,3100K,25MWC,20MM, |
| 1404-001544 | THERMISTOR-NTC;10KOHM,1%,3435K,3.7MWC,TP |
| 1404-001872 | THERMISTOR-PTC |
|
|
THERMOSTAT |
| 0506-000175 | TR-ARRAY |
| 0504-000001 | TR-DIGITAL |
| 0504-001008 | TR-DIGITAL |
| 0504-001064 | TR-DIGITAL |
| 0504-001080 | TR-DIGITAL |
| 0502-001250 | TR-POWER |
| 0502-001266 | TR-POWER |
| 0501-000465 | TR-SMALL SIGNAL |
| DA26-00062A | TRANS SWITCHING;AC85-265V,3550MA,200MA,1 |
| DG63-00700A | TRAY OVEN |
| DG64-00983A | TRIM-PEDESTAL;NX60T5***,NE63T5***,GI-SGC |
| DG62-00021A | TUBE-GLASS;FTQ386,GLASS FIBER,4.1,60MM,3 |
| 1405-001239 | VARISTOR;680V,560VDC,6000A,17X10MM,TP,11 |
| DE60-40026A | WASHER PLAIN |
| DE81-01901A | WASHER PLAIN;TRIO PLUS,FIBER-WASHER,P1 |
| DG67-00238A | WIRE-PROTECTOR;NZ30A3060US,PA6 |
| DG67-00314A | WIRE-PROTECTOR;NZ9100D,PA66,T2,101F,-, |
|
|
WIRE-STEEL |
| DG61-01875B | |
| DG61-01876B | |
| DG90-01543A | |
| DG94-06445A |
