Model Image
Manufacturer

Samsung

Model Number

SCX-4500W

Description

Monochrome Laser Multifunction Printer

Interactive Exploded View

Parts List

Part Number Description
JC66-01541A ACTUATOR-EMPTY;SCX-4500,PC NH-1023P,BLK
JC66-01533A ACTUATOR-EXIT;SCX-4500,PC+GF20%,V0,BLK
JC66-01542A ACTUATOR-FEED;SCX-4500,PC NH-1023P,V0,BL
6902-000455 BAG CONDUCTIVE;LDPE,T0.07,W200,L450,BLK,
3301-000319 BEAD-SMD;11OHM,2X1.25X0.9MM,TP
3301-000317 BEAD-SMD;120OHM,2012,TP,-,-
3301-001594 BEAD-SMD;90OHM,2.0*1.2*1.3MM,TP,-,-
6602-001637 6602-001637 BELT-TIMING GEAR;POLY URETHANE,T0.98,L73
JC61-01640A BRACKET MOTOR-P-SCAN;SCX-4200,SECC,1.00,
JC61-01969A BRACKET-CIS;SCX-4500,PC/ABS,2.0,33.6,260
JC61-01967A BRACKET-FEED;SCX-4500,SECC,1.0,81.5,24.7
JC61-01968A BRACKET-GEAR;SCX-4500,SECC+SWCH-1018A+NI
JC61-01281A BRACKET-P-BAR_PICK_UP;ML-1610,SECC,1.00,
JC61-02114A BRACKET-REAR;SCX-4500,SECC,1.0,81.5,27.1
JC61-00888A JC61-00888A BUSH-M-HR L_R2;SCX-4920N,PPS,?25.3,?29.6
JC61-00887A JC61-00887A BUSH-M-HR R_R2;SCX-4920N,PPS,?25.3,?29.6
JC61-00588A JC61-00588A BUSH-M-TR L;ML-1710,POM,?6.1,?8,BLK
JC66-10901A JC66-10901A BUSH-PRESSURE R;ML-165,PPS(RBA313N),14,7
JC72-00382B BUSH;ML-1710,POM(DERLIN 8903),WHITE
JC64-00332A BUTTON-CASSETTE OPEN;SCX-4500,ABS,2.5*16
3002-000185 BUZZER-MAGNETIC;85DB,5V,40MA,2.4KHZ,BK
2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3
2402-001049 C-AL,SMD;10UF,20%,16V,GP,TP,3.3X3.3X5.4
2402-000209 C-AL,SMD;22UF,20%,16V,WT,TP,5.3X5.3MM
2203-000426 C-CER,CHIP;0.018NF,5%,50V,C0G,1608
2203-000627 C-CER,CHIP;0.022NF,5%,50V,C0G,TP,1005
2203-000998 C-CER,CHIP;0.047NF,5%,50V,C0G,1608
2203-001071 C-CER,CHIP;0.056NF,5%,50V,C0G,TP,1608
2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,1608
2203-007236 C-CER,CHIP;10000NF,10%,50V,X7R,TP,3225
2203-006348 C-CER,CHIP;1000NF,10%,25V,X5R,TP,1608,0.
2203-002709 C-CER,CHIP;100NF,+80-20%,16V,Y5V,1005
2203-005249 C-CER,CHIP;100NF,10%,50V,X7R,TP,1608
2203-000257 C-CER,CHIP;10NF,10%,50V,X7R,TP,1608
2203-000440 C-CER,CHIP;1NF,10,50V,X7R,TP,1608
2203-002392 C-CER,CHIP;220NF,+80-20%,50V,Y5V,2012
2203-002398 C-CER,CHIP;22NF,10%,50V,X7R,1608
2203-000888 C-CER,CHIP;4.7NF,10%,50V,X7R,TP,1608
2203-006818 C-CER,CHIP;47000NF,20%,6.3V,X5R,3216
2503-001051 C-NETWORK;100NFX4,20%,16V,2012
6501-000004 CABLE TIE;DA-80,T1,W2.5,L80,NTR,NYLON66
JC39-00969A CBF IF-CROSS CABLE;SCX-4500W,8,UL10991,1
3903-000085 3903-000085 CBF-POWER CORD;US,BP3/YES,3P_LUG,125/125
JB61-00232A CLIP-P-BELT;SF-457,SUS,0.2,NTR,HALF HARD
3708-001371 CONNECTOR-FPC/FFC/PIC;18P,1MM,STRAIGHT,S
3708-001436 CONNECTOR-FPC/FFC/PIC;4P,1MM,SMD-S,SN,N
3711-006437 CONNECTOR-HEADER;BOX,15P,1R,1.5MM,STRAIG
0609-001305 CONTACT IMAGE SENSOR;216MM,10368DOT,6.3M
JC63-01432A COVER-CASSETTE;SCX-4500,ABS,2.5,260,24.8
JC63-01434A COVER-DOOR STACKER;SCX-4500,ABS,1.2,122,
JC63-01444A COVER-DUMMY EXTRA;SCX-4500,PET+GF30%
JC63-01385A COVER-DUMMY REAR;SCX-4500,ABS,3,45,226.6
JC63-01382F COVER-FRONT;SCX-4500W,ABS,3,331.6,90.5,H
JC63-01430A COVER-FUSER DUMMY;SCX-4500,PET+GF30%
JC63-01431A COVER-FUSER;SCX-4500,PET+GF30%,2.0,289.0
JC63-01372A COVER-HVPS;SCX-4500,HIPS,1.7,208.6,84.2,
JC63-01446A COVER-LAMP;SCX-4500,PET+GF30%
JC63-01383B COVER-LEFT;ML-1630W,ABS(HG-0760),3,95,36
JC63-01436A COVER-REAR;SCX-4500,ABS,3,313.1,89.7,HB,
JC63-01384A COVER-RIGHT;SCX-4500,ABS,3,360,95,HB,SEC
JC63-01332A COVER-SCAN LOWER;SCX-4500,ABS,2.2,377,32
JC63-01333F COVER-SCAN OPE;SCX-4500W,ABS+PMMA,2.5,38
JC63-01330A COVER-SCAN PLATEN;SCX-4500,ABS+PMMA,3.0,
JC63-01334A COVER-SCAN REAR;SCX-4500,ABS,2.2,320,18,
JC63-01331A COVER-SCAN UPPER;SCX-4500,ABS,2.5,384,33
0402-001189 DIODE-RECTIFIER;M4,400V,1A,TS-1,TP
0404-000112 DIODE-SCHOTTKY;RB420D,40V,100MA,SOT-23,T
0407-000122 DIODE-SWITCHING;KDS226,80V,100MA,SOT-23,
0401-000116 DIODE-SWITCHING;MMSD914T1,100V,200MA,SOD
0403-000287 DIODE-ZENER;MMBZ5251B,20.9-23.1V,225MW,S
JC96-04715A DRIVE MAIN;SCX-4500,SEC,-,-,-
JC96-04724A ELA ETC-SHIELD PCB;SCX-4500,SEC,-,-,-
JC96-04540A ELA HOU-FUSER;SCX-4500,SEC,-,110V,-,-,-
JC96-05114A ELA UNIT-CIS;SCX-4500W,SEC,-,-,-,-,-,-,-
JC96-04645A ELA UNIT-FRAME LOWER;SCX-4500,SEC,-,-,-,
JC96-05110A ELA UNIT-FRAME;SCX-4500W,SEC,-,-,-,-
JC96-04812A ELA UNIT-INLET;SCX-4500,SEC,-,-,-
JC96-04623A ELA UNIT-LSU;SCX-4500,-,-,16PPM,600DPI,S
JC96-04532A ELA UNIT-SCAN DRIVE;SCX-4500,SEC,-,-,-,-
JC96-04530B ELA UNIT-SCAN LOWER;SCX-4500W,SEC,-,-,-,
JC96-04533F ELA UNIT-SCAN OPE;SCX-4500W,SEC,-,-,-,-
JC96-05113A ELA UNIT-SCANNER;SCX-4500W,SEC,-,-,-,-
JC96-04622A ELA UNIT-SOLENOID;SCX-4500,SEC,-,-,-,-
JC31-00089A FAN;24,70MA,0.3MMH20,15M^3/MI
JC63-01739A FELT-FUSER;SCX-4500,FELT,1,42,30
JC01-00022A FILM-LOCKER;SCX-4500,PET,0.05,10,15
JC61-40001A FOOT-ML80;ML-80,NBR,GRAY
JC61-02113A FRAME-BASE LOWER;SCX-4500,ABS(VE-0860P),
JC61-02107A FRAME-BASE UPPER;SCX-4500,ABS+GF5%,HB,2.
JC61-02081A FRAME-CST;SCX-4500,ABS HB,HF0660I,HB,BLK
JC61-02137A FRAME-FUSER;SCX-4500,SECC,1.2,69.3,266.7
JC66-01434A GEAR-DEVE;SCX-4500,POM,0.8,14,BLACK,HELI
JC66-01436A GEAR-DRV FEED;SCX-4500,POM,0.8/0.6,19/19
JC66-01800A JC66-01800A GEAR-DRV FUSER IN;SCX-4500,PA6T,0.8,26,B
JC66-01441A GEAR-DRV FUSER OUT;SCX-4500,POM,0.7,59,N
JC66-01443A GEAR-DRV PICKUP;SCX-4500,POM,0.8/0.7,18/
JC66-01442A GEAR-DRV REGI;SCX-4500,POM,0.7/0.8,34/13
JC66-01435A GEAR-FEED;SCX-4500,POM,0.6,32,NTR,20.4,S
JC66-01254A JC66-01254A GEAR-FUSER;ML-2571N,PPS,0.8,45,37.6*14.5
JC66-00340A JC66-00340A GEAR-HUB CLUTCH;SCX-5100,POM,M0.8,Z13,NT
JC66-01450A GEAR-IDLE AGI;SCX-4500,POM,0.6,25,BLACK,
JC66-01201A GEAR-M_PULLEY;SCX-4200,POM,0.4,73,31.874
JC66-01430A GEAR-OPC;SCX-4500,POM,0.8,25,BLACK,HELIC
JC66-01437A GEAR-PICKUP IN;SCX-4500,POM,0.8,35,NTR,2
JC66-01438A GEAR-PICKUP OUT;SCX-4500,POM,0.8,35,NTR,
JG66-40003A GEAR-PINION;SF4000,POM,1,Z16,WHT
JC66-01432A GEAR-RDCN 1;SCX-4500,POM,0.8/0.6,14/15,N
JC66-01446A GEAR-RDCN FEED A;SCX-4500,POM,0.5/0.8,47
JC66-01447A GEAR-RDCN FEED B;SCX-4500,POM,0.8/0.7,29
JC66-01445A GEAR-RDCN FUSER;SCX-4500,POM,0.5/0.7,72/
JC66-01444A GEAR-RDCN OPC;SCX-4500,POM,0.5/0.5,89/53
JC66-01562A GEAR-RDCN;SCX-4500,POM,0.8,27/15
JC66-01439A GEAR-REGI;SCX-4500,POM,0.8,19,NTR,16.80,
JC66-01449A GEAR-SUPPLY;SCX-4500,POM,0.6,20,BLACK,SP
JB01-00002A GLASS-PLATEN;247*356,2.85,CLEAR
JC63-01437A GROUND-MAIN;SCX-4500,SUS304-CSP,0.2
JC63-01414A GROUND-P DRIVE;SCX-4500,SUS304-CSP,0.2
JC63-01417A GROUND-P FUSER;SCX-4500,SUS304-CSP,0.2
JC63-01416A GROUND-P HVPS;SCX-4500,SUS304-CSP,0.2
JC63-01413A GROUND-P SAW;SCX-4500,SUS304-CSP,0.2
JC63-01415A GROUND-P THV;SCX-4500,SUS304-CSP,0.2
JC61-02111A GUIDE-CASSETTE LOCK;SCX-4500,POM,2.5,17.
JC61-02110A GUIDE-CASSETTE RAIL;SCX-4500,POM M90-44,
JC61-02184A GUIDE-CLAW PI;SCX-4321,PPS+GF40%, PI
JC61-02580A GUIDE-CLAW;ML-2240,PTFE,14,14,11,PATH
JC61-02129A GUIDE-EXIT;SCX-4500,PET+GF30%
JC61-01980A GUIDE-FEED LOWER;SCX-4500,PC+ABS HB,2.5,
JC61-01979A GUIDE-FEED UPPER;SCX-4500,ABS HB,2.5,69,
JC61-02450A GUIDE-INPUT;SCX-4500,PET+GF30%,BLK,V0
JC61-02127A GUIDE-KNOCKUP L;SCX-4500,POM(M90-44),35.
JC61-02128A GUIDE-KNOCKUP R;SCX-4500,POM(M90-44),35.
JC61-02126A GUIDE-REAR;SCX-4500,ABS HB,2.5,30,60,BLK
JC61-02125A GUIDE-SIDE L;SCX-4500,ABS HB,2.5,120.5,9
JC61-02124A GUIDE-SIDE R;SCX-4500,ABS HB,2.5,127.0,9
JC39-00685A HARNESS-INLET;SCX-4500,HARNESS,UL1617/10
JC39-00959A HARNESS-WLAN;SCX-4500W,UL1061/UL2547,5P/
3711-000862 HEADER-BOARD TO CABLE;BOX,3P,1R,1.25MM,S
3711-003411 HEADER-BOARD TO CABLE;BOX,5P,1R,2MM,STRA
JC61-02010A HOLDER-ACTUATOR;SCX-4500,PBT GP2150+GF 1
JC61-02012A HOLDER-LAMP;SCX-4500,SECC,0.8
JC61-02008A HOLDER-LED MAIN;SCX-4500,ABS,3.0,106,46
JC61-01548A HOLDER-M-CAM;CLP-300,POM (DE8903),18.5,2
JC61-02076A HOLDER-PAD;SCX-4500,PC,2.0,42,23,BLK
JC61-02009A HOLDER-SWITCH;SCX-4500,HIPS,2.0,56,38.6,
JC61-00909A HOUSING-M-PICK UP_R2;SCX-4920N,PC+ABS,12
JC61-02079A HOUSING-PICKUP B;SCX-4500,PC+ABS,37.6,BL
JC61-02109A HOUSING-TERMINAL;SCX-4500,HIPS(VE-1870U)
JC44-00146A HVPS;24V,21.6V~27.6V,MAX 5KV,MAX-2KV
JC09-00003A IC MICOM;CP6688AM,SCX-4500,32,5,24MHZ,8B
0803-003263 IC-CMOS LOGIC;74LCX07,HEX BUFFER,SOIC,14
0801-002403 IC-CMOS LOGIC;74LCX08,AND GATE,TSSOP,14P
0801-002446 IC-CMOS LOGIC;74LCX14,SCHMITT INVERTER,T
0801-002326 IC-CMOS LOGIC;74LCX32,OR GATE,TSSOP,14,1
1203-003739 IC-DC/DC CONVERTER;MVPG31,DFN,12P,4X3MM,
1105-001876 IC-DDR2 SDRAM;K4T51163QG-HCE6,DDR2 SDRAM
1003-001561 IC-LED DRIVER;PT6961,SOP,32P,300MIL,-,40
1107-001590 IC-NOR FLASH;S29GL064M,64MBIT,8MX8/4MX16
1203-001455 IC-POSI.FIXED REG.;1117,DPAK,3P,265MIL,P
1203-002454 IC-POSI.FIXED REG.;1117,TO-252,3P,257MIL
1203-002986 IC-POSI.FIXED REG.;7812,3P,6.6X6.1MM,PLA
1205-002762 IC-TRANSCEIVER;BCM5241A1KMLG,MLP,32P,5X5
0904-002093 IC-USC;ISP1761BE,32BIT,LQFP,128P,20X14MM
1202-000164 IC-VOLTAGE COMP.;393,SOP,8P,150MIL,DUAL,
JC99-02108A JC99-02108A INA-STACKER;ML-1630,SEC,-,-,-,-,-
JC70-00064A IPR-PIN ROLLER EXIT;SUS304,SF-5100,L23,P
JC70-10232A IPR-PLATE SAW;ML-80,SUS304 CSP 1/2H,T0.1
3722-002376 JACK-MODULAR;8P/8C,STANDARD,Y,ANLGE,YEL/
3722-002303 JACK-USB;4P/1C,AU30U,BLK,ANGLE,B TYPE
JB68-00916A LABEL RATING-BLANK;SF-340,SEC,TETRON,0.0
JC68-01584A LABEL(P)-BLANK 90*25;CLP-510,SEE,ART 100
JC68-10932A LABEL(P)-BLANK(ML);ML-85,ART,G100,WHT,CO
JB68-00644A LABEL(P)-SHADING;COMMON,YOOPO PAPER,T0.2
JB68-00073A LABEL(R)-BAR CODE;SF-3000,PY,T0.5,6.5,34
JC68-00573A LABEL(R)-BARCODE;ML-4500,PET,T0.05,20MM,
JC68-01996A LABEL-FUNCTION;SCX-4500,SEC,YUPO PAPER 1
4713-001226 LAMP-HALOGEN;115V,1300W
0601-001226 LED;SMD(TOP VIEW),RED,1.2X0.8MM,660NM,1.
JC67-00231A LENS-LED INDICATOR;SCX-4500,PMMA CLEAR,L
JC66-01573A LEVER-CASSETTE GUIDE;SCX-4500,POM(M90-44
JC66-01544A LEVER-CASSETTE LOCK;SCX-4500,POM (M90-44
JC66-01545A LEVER-HANDLE UPPER;SCX-4500,ABS+GF5%,2.0
JC66-01470A LEVER-PICKUP;SCX-4500,POM(M90-44),1.2,7.
JC66-01575A LINK-RAIL UPPER;ML-1630,PC+ABS,110.5*31.
JC66-01564A LINK-UPPER;SCX-4500,ACETAL,102.0,13,21.5
JC97-02933A MEA UNIT-CASSETTE;SCX-4500,SEC,KOREA,-,-
JC97-03055F MEA UNIT-COVER FRONT;SCX-4500W,SEC,-,-,-
JC97-02929A MEA UNIT-COVER PLATEN;SCX-4500,SEC,-,-,-
JC97-03130A MEA UNIT-COVER REAR;SCX-4500,SEC,-,-,-,-
JC97-02990A MEA UNIT-FEED LOWER;SCX-4500,SEC,-,-,-
JC97-02939A MEA UNIT-FEED UPPER;SCX-4500,SEC,-,-,-
JC97-02957A MEA UNIT-GEAR PICK UP;SCX-4500,SEC,-,-,-
JC97-02937A MEA UNIT-HOLDER PICKUP;SCX-4500,SEC
JC97-02938A MEA UNIT-PICKUP;SCX-4500,SEC,-,PICK UP,-
JC97-02982A JC97-02982A MEA UNIT-ROLLER PICKUP;SCX-4500,SEC,-,-,
JC97-02930A MEA UNIT-SCAN UPPER;SCX-4500,SEC,-,-,-,-
JC97-03065F MEA-SCAN OPE;SCX-4500W,SEC,-,-,-,-
JC97-03066A MEA-SCAN_PLATEN;SCX-4500,SEC,-,-,-,-
JC75-00049A MEC-TERMINAL;SF-5100,SAMSUNG
JC31-00079A MOTOR BLDC;1900RPM,789GF.CM,0.9,1.0KGF.C
JC31-00080A JC31-00080A MOTOR STEP;2T357278Q/SP-35RC-800S,SCX-45
JC69-00987A JC69-00987A PAD-FRICTION;ML-2571N,CB,10.2,29,8.5,GR
JB92-01316A PBA SUB-LED;SCX-1470,SEC,-,FR-1,1LAYER,2
JC92-02025A PBA SUB-WLAN;SCX-4600W,SEC,SEC,WLAN,FR-4
JC92-01903A PBA-INDICATOR JOINT;SCX-4500,SEC,SEC,IND
JC92-02010A PBA-MAIN;SCX-4500W,SEC,SEC,MAIN,-,-,-,89
JC92-02023A PBA-OPE;SCX-4600W,SEC,SEC,OPE,FR-4,-,-,5
JC72-20902B PEX-ROLLER F/UP(2);SCX-4500,TEFLON,BLK
0604-001415 0604-001415 PHOTO-INTERRUPTER;TR,90%,150MW,DIP-4,BK
JC61-02108A PLATE-GUIDE DEVE;SCX-4500,PC+ABS,1.5,11,
JC61-02080A PLATE-KNOCKUP;SCX-4500,ABS HB,2.5,90.3,2
JC72-41191B PMO-BEARING SHAFT;ML-2150,POM,BLK,DE8903
JC72-00102A JC72-00102A PMO-BUSHING_TR(L);SF-5100,POM (CH-15),BL
JC72-01234A PMO-DEVE CAP TONER;CLP-500,PP,H550,BLACK
CALL_1-800-SAMSUNG PMO-GEAR_EXIT_DRV16;SF-5100,POM(DE8903),
JC72-00444A PMO-HOLDER COLLIMATOR;ML-1710,PC,TRANSPA
2007-008433 R-CHIP;0.33OHM,1%,1W,TP,6432
2007-008453 R-CHIP;1.24KOHM,1%,1/16W,TP,1005
2007-000123 R-CHIP;1.5KOHM,5%,1/10W,TP,1608
2007-000074 R-CHIP;100OHM,5%,1/10W,TP,1608
2007-000090 R-CHIP;10KOHM,5%,1/10W,TP,1608
2007-000309 R-CHIP;10OHM,5%,1/10W,TP,1608
2007-007521 R-CHIP;14.7KOHM,1%,1/10W,TP,1608
2007-008567 R-CHIP;15.4KOHM,1%,1/10W,TP,1608
2007-000402 R-CHIP;150OHM,5%,1/10W,TP,1608
2007-001306 R-CHIP;150OHM,5%,1/16W,TP,1005
2007-000475 R-CHIP;1MOHM,1%,1/10W,TP,1608
2007-002425 R-CHIP;1OHM,5%,1/10W,TP,1608
2007-000124 R-CHIP;2.2KOHM,5%,1/10W,TP,1608
2007-007382 R-CHIP;20MOHM,5%,1/10W,TP,1608
2007-000071 R-CHIP;22OHM,5%,1/10W,TP,1608
2007-007525 R-CHIP;3.4KOHM,1%,1/10W,TP,1608
2007-000729 R-CHIP;300OHM,5%,1/10W,TP,1608
2007-007008 R-CHIP;300OHM,5%,1/16W,TP,1005
2007-000730 R-CHIP;300OHM,5%,1/4W,TP,3216
2007-000096 R-CHIP;30KOHM,5%,1/10W,TP,1608
2007-000076 R-CHIP;330OHM,5%,1/10W,TP,1608
2007-000839 R-CHIP;39OHM,5%,1/10W,TP,1608
2007-000084 R-CHIP;4.7KOHM,5%,1/10W,TP,1608
2007-000107 R-CHIP;470KOHM,5%,1/10W,TP,1608
2007-000097 R-CHIP;47KOHM,5%,1/10W,TP,1608
2007-008298 R-CHIP;49.9OHM,1%,1/16W,TP,1005
2007-000965 R-CHIP;5.1KOHM,5%,1/10W,TP,1608
2007-000144 R-CHIP;5.1KOHM,5%,1/16W,TP,1005
2007-001010 R-CHIP;51KOHM,5%,1/10W,TP,1608
2007-001045 R-CHIP;56OHM,5%,1/4W,TP,3216
2007-001134 R-CHIP;68OHM,5%,1/10W,TP,1608
2007-001139 R-CHIP;7.5KOHM,1%,1/10W,TP,1608
2007-001157 R-CHIP;750OHM,5%,1/10W,TP,1608
2007-000121 R-CHIP;820OHM,5%,1/10W,TP,1608
2011-001482 R-NETWORK;1KOHM,5%,1/16W,L,CHIP-V,8P,TP,
2011-001262 R-NETWORK;22OHM,5%,1/16W,L,CHIP,8P,TP,2.
2011-001261 R-NETWORK;33OHM,5%,1/16W,L,CHIP,8P,TP,2.
6044-000125 RING-E;ID4,OD9,T0.6,STSC
JC66-00526A JC66-00526A ROLLER-FEED ROLLER 1;ML-1510,SUM24L+NI+E
JC66-01543A ROLLER-FEED;SCX-4500,EPDM+SUM22+NI,24,GR
JC66-01531A ROLLER-HEAT;SCX-4500,STH032+855411 COAT,
JC66-01312B ROLLER-IDLE;SCX-4500,PFA,7,L11,BLK
JC66-01510A ROLLER-IDLE;SCX-4500,POM(M90-44),13,13.5
JC66-00380A ROLLER-M-EXIT F/UP;ML-1710,PC(GE EXL-911
JC66-01509A ROLLER-PICKUP IDLE;SCX-4500,POM(DELRIN-8
JC66-00600A ROLLER-PRESSURE;ML-1710,SUM24L+LSR+PFA,2
JC66-01218A JC66-01218A ROLLER-TRANSFER;SCX-4200,NBR+ECO,15,218M
JC73-00141A JC73-00141A RPR-PAD CASSETTE;ML-1510,URETHANE SPONGE
JC73-00255A RUBBER-EXIT F/UP;SCX-4500,EPDM,12 X 14.5
6001-000130 SCREW-MACHINE;BH,+,M3,L6,ZPC(WHT),SWRCH1
6003-000282 6003-000282 SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW
6003-000269 6003-000269 SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SW
6003-000301 SCREW-TAPTYPE;BH,+,S,M4,L6,ZPC(WHT),SWRC
6002-000308 SCREW-TAPTYPE;PH,+,-,B,M2.6,L6,ZPC(WHT),
6006-001078 SCREW-TAPTYPE;PH,+,WSP,B,M3,L10,ZPC(WHT)
6003-000264 SCREW-TAPTYPE;PWH,+,-,B,M3,L6,ZPC(WHT),S
6003-000196 SCREW-TAPTYPE;PWH,+,B,M3,L10,NI PLT,SWRC
JC62-00464A SEAL-LSU REAR;SCX-4500,POLYURETHANE FOAM
JC62-00417A SEAL-LSU;SCX-4500,POLYURETHANE FOAM,BLK,
JC66-01448A SHAFT-CIS;SCX-4500,SUM22,382,6
JC66-00720A SHAFT-P-CORE;ML-1750,SECC 1.2T,203
JC66-00829A JC66-00829A SHAFT-P-PICK_UP;ML-1610,SECC,264,T1.2
JC63-00290A SHEET-HOLDER PAD;ML-1750,PC,0.125,100,18
JC63-02006A SHEET-MENU;SCX-4500W,PC,0.254,101,56,BLK
JC63-01468A SHEET-SCAN DIFFUSION;SCX-4500,PET,0.125,
JC63-01713A SHEET-SCAN OPE;SCX-4500,PET,0.125,400,60
JC63-01712A SHEET-SCAN PLATEN;SCX-4500,PET,0.125,400
JC63-01411A SHEET-SMPS;SCX-4500,PC,0.254,230,163
JC63-00209A JC63-00209A SHEET-WHITE SPONGE;SCX-4216F,POLYURETHAN
JC63-01421A SHIELD-MAIN;SCX-4500,SECC,0.6,159.7,117.
JC63-01420A SHIELD-SMPS;SCX-4500,SECC,0.6,266.0,188.
JC66-01580A SLIDER-CIS;CLX-2160,RTP 899X93924,0.7,11
JC44-00147A SMPS-V1;ML-1630,SWAN-V1,FLYBACK,53W,110,
JC33-00023A SOLENOID-PICKUP;SCX-4500,DC5V,22.6*20.8*
JC72-01418A SPONGE-LEFT;SCX-4500,POLYURETHANE FOAM,5
JC72-01419A SPONGE-RIGHT;SCX-4500,POLYURETHANE FOAM,
JC72-01231A JC72-01231A SPONGE-ROLLER PICK_UP;ML-1510,IR60%+NR30
JC61-00064A SPRING ETC-CLAW;ML-5200A,SUS 304 WPB,F0.
JC61-00025A SPRING ETC-CS-CHARGE APOLLO;SF-5100,SUS
JC61-70932A SPRING ETC-GUIDE DEVE;ML-5000A,D4.3,L16.
JG61-70531A SPRING ETC-LOCKER,PLATE;SF6000,SUS304WPB
JC61-00056A SPRING ETC-PR(7300);ML-7300,PIANO WIRE,1
JC61-70940A SPRING ETC-TR(12);ML-5500,0.5,5,13,SUS30
JC61-70958A SPRING ETC-TR;ML-5000A,SUS304 WPB,PI0.55
6107-001137 SPRING-CS;SUS304 WPB,PI0.4,D9.4,L11.5,ID
6107-001167 SPRING-CS;SUS304-WPB,PI0.25,D3.25,L9.6,I
6107-001348 SPRING-CS;SUS304-WPB,PI0.26,D5.76,L6.93,
6107-001373 SPRING-CS;SUS304-WPB,PI0.45,D4.95,L11,ID
6107-001346 SPRING-CS;SUS304-WPB,PI0.5,D4.5,L11.0,ID
6107-001349 SPRING-CS;SUS304-WPB,PI0.6,L27.0,ID11.0,
6107-001350 SPRING-CS;SUS304-WPB,PI0.6,L41,ID7.2,OD8
6107-001194 SPRING-CS;SWP-B,BLK,PI0.9,D6.95,L20,ID6.
6107-001347 SPRING-ETC;SUS304,PI0.4,D1.8,L23.0,ID1.4
6107-001277 SPRING-ETC;SUS304,PI0.6,D2.1,L24.9,ID1.5
6107-001164 6107-001164 SPRING-TS;SUS304-WPB,PI0.15,D3.95,L12,ID
6107-001165 SPRING-TS;SUS304-WPB,PI0.2,D4,ID3.8,OD4.
6107-001351 SPRING-TS;SWP,PI2.1,D13,L9.6,ID10.9,OD15
6107-001170 SPRING-TS;SWP-B,PI0.9,D6.0,ID5.2,OD7.0
JC61-02123A STACKER-RX;SCX-4500,SAN,2.5,172.16,120,C
JC61-02484A STOPPER-ADJUSTER;CLP-350N,ABS,3.0,13.2,1
JC61-01714A STOPPER-PICK_UP L;ML-2571N,POM,D17,20,NA
JC61-01713A STOPPER-PICK_UP R;ML-2571N,POM,D17,20,BL
JC61-02178A STUD-HINGE;SCX-4500,SWCH-1018A,31.8
0203-002250 TAPE DOUBLE FACE;PET, 3M 9448,T0.12,W180
JC65-00019A TERMINAL-CRUM;SCX-5530FN,SUS304WPB,PI 0.
JC65-00024A TERMINAL-HV;SCX-4500,SUS304 1/2H,T0.2
0506-001069 TR-ARRAY;MBT3904DW1T1,NPN,DUAL,150MW,SOT
0501-000279 TR-SMALL SIGNAL;KSA1182-Y,PNP,150MW,SOT-
0501-000457 TR-SMALL SIGNAL;MMBT2222A/KST2222A,NPN,3
2103-000342 VR-SEMI;2KOHM,30%,1/10W,SIDE
6031-001602 WASHER-PLAIN;POLY,ID3.9,OD8.5,T0.5,BLK
6031-000023 WASHER-PLAIN;POLY,ID5.9,OD10.0,T0.5,BLK
JC64-00317A WINDOW-INDICATOR;SCX-4500,PMMA,2.0,306,1
Main Menu x
