Model Image
Manufacturer

Samsung

Model Number

SCX-4835FR

Description

Monochrome Laser Multifunction Printer

Interactive Exploded View

Parts List

Part Number Description
JC66-02767A ACTUATOR-ARM_MP;ML-3700ND,POM,5,14.2,4,W
JC66-02762A JC66-02762A ACTUATOR-EMPTY;ML-3710,POM,3.0,43.1,31.2
JC66-02766A JC66-02766A ACTUATOR-EMPTY_MP;ML-3710ND,PC,65.9,50.7
JC66-02774A ACTUATOR-EXIT;ML-3700ND,NYLON,2.0T,46.7,
JC66-01766A ACTUATOR-FEED;CLX-6200FX,PC,2,BLACK
JC66-02764A ACTUATOR-FEED;ML-3710,PC+GF,3.0,17.5,20.
JC66-01762A JC66-01762A ACTUATOR-REGI;CLX-6200FX,POM,2,BLACK
JC66-02763A ACTUATOR-REGI;ML-3710,PC+GF,3.0,30.6,21.
JC97-03947A JC97-03947A ADF-PICK UP ROLLER;SCX-5637FR,SEE
JC97-03945A JC97-03945A ADF-PICK_UP;SCX-5637FR,SEE
JC97-03946A JC97-03946A ADF-ROLLER;SCX-5637FR,SEE
JC70-00561B ADJUST-MP_LEFT;ML-3710,ABS,119.2,57.4,IC
JC70-00562B ADJUST-MP_RIGHT;ML-3710,ABS,120.2,57.4,I
JC66-20901A AUTO CLOSE-TIMING BELT;B32S2M280,CR+FG+N
4301-001042 4301-001042 BATTERY-LI;3V,220MAH,CR2032,20X3.2MM,CON
3301-001495 BEAD-SMD;120OHM,2012,2500MA,TP,115OHM/10
6601-001725 6601-001725 BEARING-BALL;SB6704ZZ,ID20,OD27,T4.0
6602-001588 BELT-TIMING GEAR;32S2M152,CR+GF+NF,T3.2,
JC67-00055A BRUSH-ANTISTATIC 531P;SF-531P,AL+THUNDER
JC61-00424A BUSH-4;ML-9400W,BEARING,?4,NTR
JC61-01686A BUSH-4D_FE;SCX-6345N,SBF2118,?4,?5.93,3.
JC61-00423A BUSH-6_D;ML-9400W,BEARING,?6,NTR
JC61-04093A JC61-04093A BUSH-HR;ML-3700,PPS,17.4,19.9,DARK BLUE
JC61-00585A BUSH-M-FEED IDLE;ML-1710,POM AT-15CF,?3.
JC61-00665A BUSH-M-FEED, DUP;ML-2150,POM, SW01,4.0,7
JC61-00588A JC61-00588A BUSH-M-TR L;ML-1710,POM,?6.1,?8,BLK
JC61-00750A JC61-00750A BUSH-M_ADF CLUTCH;SCX-6320F,PPS,7,11.85,
JC61-04095A JC61-04095A BUSH-PR_2ND;ML-3700,PPS(RFKB-9),5.1,BLAC
JC61-02468A BUSH-TR_L;ML-2851ND,STEEL SINTERED
JC72-00382B BUSH;ML-1710,POM(DERLIN 8903),WHITE
3002-001139 BUZZER-PIEZO;80DB,9V,2KHZ,BK
2402-001086 C-AL,SMD;100UF,20%,16V,WT,TP,6.6X6.6X5.3
2402-001049 C-AL,SMD;10UF,20%,16V,GP,TP,3.3X3.3X5.4
2402-001178 C-AL,SMD;10UF,20%,16V,WT,TP,4.3X4.3X5.8M
2402-001254 C-AL,SMD;10UF,20%,50V,WT,TP,6.3X5.2MM
2402-000209 C-AL,SMD;22UF,20%,16V,WT,TP,5.3X5.3MM
2402-001106 C-AL,SMD;33UF,20%,50V,WT,TP,8.3X8.3X6.3M
2402-000008 C-AL,SMD;47UF,20%,16V,GP,TP,6.6X6.6X5.4
2402-001155 C-AL,SMD;47UF,20%,16V,WT,TP,6.3X5.2MM
2203-000384 C-CER,CHIP;0.015NF,5%,50V,C0G,TP,1608,0.
2203-000426 C-CER,CHIP;0.018NF,5%,50V,C0G,1608
2203-000041 C-CER,CHIP;0.01NF,0.25PF,50V,C0G,TP,1608
2203-000626 C-CER,CHIP;0.022NF,5%,50V,C0G,1608
2203-000627 C-CER,CHIP;0.022NF,5%,50V,C0G,TP,1005
2203-000681 C-CER,CHIP;0.027NF,5%,50V,C0G,1608
2203-001071 C-CER,CHIP;0.056NF,5%,50V,C0G,TP,1608
2203-000783 C-CER,CHIP;0.33NF,5%,50V,C0G,1608
2203-007236 C-CER,CHIP;10000NF,10%,50V,X7R,TP,3225
2203-005819 C-CER,CHIP;1000NF,+80-20%,16V,Y5V,TP,160
2203-006348 C-CER,CHIP;1000NF,10%,25V,X5R,TP,1608,0.
2203-006960 C-CER,CHIP;1000NF,10%,50V,X7R,TP,2012
2203-002709 C-CER,CHIP;100NF,+80-20%,16V,Y5V,1005
2203-006166 C-CER,CHIP;100NF,10%,25V,X5R,TP,1005
2203-005249 C-CER,CHIP;100NF,10%,50V,X7R,TP,1608
2203-006468 C-CER,CHIP;10NF,10%,250V,X7R,-,2012
2203-000257 C-CER,CHIP;10NF,10%,50V,X7R,TP,1608
2203-005221 C-CER,CHIP;15NF,10%,50V,X7R,1608
2203-000440 C-CER,CHIP;1NF,10,50V,X7R,TP,1608
2203-000491 C-CER,CHIP;2.2NF,10%,50V,X7R,1608
2203-006320 C-CER,CHIP;2200NF,10%,16V,X7R,TP,2012
2203-002392 C-CER,CHIP;220NF,+80-20%,50V,Y5V,2012
2203-002398 C-CER,CHIP;22NF,10%,50V,X7R,1608
2203-005757 C-CER,CHIP;33NF,10%,200V,X7R,TP,3216
2203-005758 C-CER,CHIP;47NF,10%,200V,X7R,TP,3216
2203-000975 C-CER,CHIP;47NF,10%,25V,X7R,TP,1608,-
2201-002371 C-CERAMIC,DISC;0.47NF,10%,400V,Y5P,TP,8.
2305-000385 C-FILM,LEAD-PEF;470NF,10%,250V,BK,18X6X1
6502-001131 CABLE CLAMP;DACS-2N,6.2*2.8,NYLON66
6502-001130 CABLE CLAMP;DACS-3N,14*5,NYLON66,BLACK
6502-000132 CABLE CLAMP;DAWS-1NE,ID11,L21.0,NTR,NYLO
JC96-06088B CARTRIDGE SUB-GEAR_OPC LEFT;ML-3700,SEC
JC90-01034A CASSETTE-GUIDE LEFT;ML-3710,SEE
JC90-01033A CASSETTE-GUIDE RIGHT;ML-3710,SEE
JC90-01063A JC90-01063A CASSETTE-RETARD;ML-3710ND,URETHANE
JC90-01032A JC90-01032A CASSETTE-ROLLER RETARD;ML-3710,SEE
JC90-01065A CASSETTE;ML-3712
JF39-50094B CBF LINE CORD;MINI FAX,IVR
3903-000085 3903-000085 CBF-POWER CORD;US,BP3/YES,3P_LUG,125/125
JB61-00232A CLIP-P-BELT;SF-457,SUS,0.2,NTR,HALF HARD
JC47-00033A JC47-00033A CLUTCH-ELECTRIC;ML-3200ND,DC24V,125MA,Z2
JC47-00034A JC47-00034A CLUTCH-ELECTRIC;ML-3710ND,DC24V,125MA,Z3
JC66-00977A JC66-00977A CLUTCH-P_ONE WAY;SCX-6345N/XRX,OWC612GXR
JF27-60051A COIL FILTER;CF5400,60UH,50MOHM,18T
JC61-02220A COLLAR-SWING;ML-2851ND/XAA,POM,7,14.4,WH
3708-001252 CONNECTOR-FPC/FFC/PIC;16P,1MM,STRAIGHT,S
3708-001455 CONNECTOR-FPC/FFC/PIC;30P,0.5MM,SMD-A,AU
3708-001058 CONNECTOR-FPC/FFC/PIC;30P,1MM,STRAIGHT,S
3711-006574 CONNECTOR-HEADER;BOX,2P,1R,1.5MM,STRAIGH
3711-006573 CONNECTOR-HEADER;BOX,3P,1R,1.5MM,STRAIGH
0609-001408 CONTACT IMAGE SENSOR;217MM,10368DOT,0.5M
JC63-02917A JC63-02917A COVER-CASSETTE;ML-3710,ABS,3.0,21.4,71
JC63-02924A COVER-DADF_FRONT;SCX-5637FR,ABS,2,78.3,1
JC63-02925A COVER-DADF_REAR;SCX-5637FR,ABS,2.5,80.7,
JC95-01439A COVER-FRONT;SCX-4835FD,XAA
JC63-01926A COVER-H_FAX_BOARD;SCX-4828FN,PC+ABS,1.5T
JC95-01417A COVER-LEFT;SCX-4835FD,XAA
JC63-01927A COVER-L_FAX_BOARD;SCX-4828FN,PC+ABS,1.5T
JC63-02937A COVER-MIDDLE;SCX-4833FD,ABS,3T,287.55,32
JC95-01324A COVER-MIDDLE;SCX-4833FD,SEE
JC95-01303A COVER-REAR;MAGPIE
JC95-01416A COVER-RIGHT;SCX-4835FD,XAA
2801-003960 CRYSTAL-UNIT;28.224MHZ,50PPM,28-AAA,18PF
JC97-03880A DADF-COVER OPEN;SCX-5637FR,SEE
JC97-03038C JC97-03038C DADF-HINGE;SCX-5133F,SEC/XEROX,DOM/EXP,W
JC97-03882A DADF-LOWER;SCX-5637FR,SEE
JC97-03881A DADF-PLATEN;SCX-5637FR,SEE
JC97-03884A DADF-STACKER;SCX-5637FR,SEE
JC97-03883A DADF-UPPER;SCX-5637FR,SEE
JC97-03885A DADF;SCX-5637FR,SEE
0402-000128 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
0402-001189 DIODE-RECTIFIER;M4,400V,1A,TS-1,TP
0404-000112 DIODE-SCHOTTKY;RB420D,40V,100MA,SOT-23,T
0401-000005 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T
0407-000122 DIODE-SWITCHING;KDS226,80V,100MA,SOT-23,
0401-000116 DIODE-SWITCHING;MMSD914T1,100V,200MA,SOD
0403-000287 DIODE-ZENER;MMBZ5251B,20.9-23.1V,225MW,S
JC93-00208A DRIVE-DADF;CLX-6250FX,SEE
JC93-00329A DRIVE-FEED;ML-3710ND,SEC,DRIVE FEED ASSY
JC93-00326A DRIVE;ML-3710ND,SEC,DRIVE MAIN ASSY
JC90-01031A JC90-01031A DUPLEX;ML-3310D,SEE
JC96-05013A ELA UNIT-SCAN DRIVE;CLX-3170,-,-,-,-,-
JC96-04732A ELA UNIT-SWING;ML-2851ND,SEC,-,220V,-,-
JC96-01672A ELA UNIT-TERMINAL TR L;ML-6060A,SEC,-,-,
JC31-00146A FAN;50*50*20,24V
JC31-00108A FAN;SCX-5135ND
0505-001326 FET-SILICON;SI2308DS,N,60V,2A,0.22OHM,1.
JC61-01367A JC61-01367A FIXER-M_E RING 4PI;SCX-6345N/XRX,POM,T1.
JC39-01478A JC39-01478A FLAT CABLE;ML-3710,20,360MM,1.0MM,WHITE,
JC39-01489A FLAT CABLE;SCX-5637FR,16P,670MM,1.0MM,WH
JC39-01500A FLAT CABLE;SCX-5737FW,30P,110MM,1.0MM,WH
JC61-40001A FOOT-ML80;ML-80,NBR,GRAY
JC61-02752A FRAME-DUPLEX PATH_EX;ML-2851ND,HIPS,BLAC
JC93-00334A JC93-00334A FRAME-REAR;ML-3710,SEC,WORLD
JC93-00324A FRAME-ROLLER DECURL;ML-3700
JC93-00324B FRAME-ROLLER DECURL;ML-3700,BLACK(SIDE)
JC91-01023A JC91-01023A FUSER;ML-3700,SEC,WORLD,110V
JB66-00104A GEAR-ADF IDLE 34;SCX-1110F,POM,0.6,34,20
JC66-02805B GEAR-DEVE;ML-3700,POM,0.6,19,5.8,13.572,
JC66-01639A GEAR-DUPLEX DR 28;ML-2851ND/XAA,POM,0.6,
JC66-00038A GEAR-EXIT F/DOWN;ML-4500,POM,0.8,GREEN
JC66-01757A GEAR-EXIT;CLX-6200FX,POM,M0.5,Z51,F26.5,
JC66-01753A GEAR-FEED IDLE B;CLX-6200FX,POM,M0.5,Z47
JC66-01754A GEAR-FEED IDLE C;CLX-6200FX,POM,M0.5,Z19
JC66-01755A GEAR-FEED IDLE D;CLX-6200FX,POM,M0.5,Z23
JC66-01756A GEAR-FEED;CLX-6200FX,POM,M0.5,Z51,F26.5,
JC66-02775B JC66-02775B GEAR-FUSER;ML-3700ND,PPS,1,36,38.0
JC66-00340A JC66-00340A GEAR-HUB CLUTCH;SCX-5100,POM,M0.8,Z13,NT
JC66-01918A GEAR-IDLE PICK UP;CLX-3170FN,POM,0.5,20,
JC66-02075A GEAR-JOINT;ML-2855ND,POM,0.5,23,BLACK,12
JC66-01201A GEAR-M_PULLEY;SCX-4200,POM,0.4,73,31.874
JC66-02800B GEAR-OPC L;ML-3700,POM,0.6,39,17.4,26.17
JB66-00105A GEAR-PICK UP 26;SCX-1110F,POM,0.6,26,15.
JB66-00102A GEAR-PICK UP IDEL 38;SCX-1110F,POM,0.6,3
JC66-01759A GEAR-PICKUP IDLE LOW;CLX-6200FX,POM,M0.5
JC66-01760A GEAR-PICKUP IDLE UP;CLX-6200FX,POM,M0.5,
JC66-01758A GEAR-PICKUP IDLE;CLX-6200FX,POM,M1.0/M0.
JC66-01761A GEAR-PICKUP;CLX-6200FX,POM,M1,Z25,F27.0,
JG66-40003A GEAR-PINION;SF4000,POM,1,Z16,WHT
JC66-00387A GEAR-RACK_PINION;ML-1710,POM,0.7,WHT
JC66-01651A GEAR-RDCN 23/23;ML-2851ND/XAA,POM,0.6/0.
JC66-01635A GEAR-SWING DR 19;ML-2851ND/XAA,POM,0.6,1
JC63-01664A GROUND-BRUSH;CLX-6200FX,C5210P,0.2,7.0,4
JC63-01663A GROUND-DADF UPPER;CLX-6200FX,C5210P,0.2,
JC63-01661A GROUND-DADF;CLX-6200FX,C5210P,0.2,12.3,4
JC63-01662A GROUND-FEED EXIT;CLX-6200FX,C5210P,0.2,4
JC63-01660A GROUND-PLATEN;CLX-6200FX,C5210P,0.2,10.0
JC61-04139A GUIDE-DOCU_L;SCX-5637FR,ABS,2,82,128.56,
JC61-04138A GUIDE-DOCU_R;SCX-5637FR,ABS,2,82,128.56,
JC61-01410A JC61-01410A GUIDE-M_PICKUP DOC;SCX-6345N/XRX,PC+ABS,
JC61-04058A GUIDE-UPPER_MP;ML-3710ND,ABS,47.4,261.8,
JC39-01482A HARNESS-AC INLET-1;ML-3710,3PIN,100MM/11
JC39-01467A HARNESS-AIR TEMP;ML-3710,2 PIN,500MM,BLA
JC39-00892A HARNESS-DADF GND;CLX-6240FX,UL1007,125MM
JC39-01455A HARNESS-DADF JOINT;SCX-5637FR,20P,20P,30
JC39-00852A HARNESS-DADF MOTOR;CLX-6240FX,UL10272,4P
JC39-00855A HARNESS-DADF REGI SOL;CLX-6240FX,UL10272
JC39-00853A HARNESS-DADF SENSOR 1;CLX-6240FX,UL10272
JC39-00854A HARNESS-DADF SENSOR 2;CLX-6240FX,UL10272
JC39-01493A JC39-01493A HARNESS-DADF;SCX-5637FR,12P,11P,150MM,BL
JC39-01468A HARNESS-EXIT;ML-3710,3 PIN,300MM,BLACK/G
JC39-01486A HARNESS-FUSER BIAS;ML-3710,1 PIN,425MM,W
JC39-01488A HARNESS-FUSER CON;ML-3710,2 PIN,110MM,90
JC39-01487A HARNESS-FUSER JOINT;ML-3710,1 PIN,90MM,W
JC39-01479A JC39-01479A HARNESS-FUSER THERM;ML-3710,4 PIN,200MM,
JC39-01466A HARNESS-MOTOR CLUTCH;ML-3710,14 PIN,600M
JC39-01470A HARNESS-MP SENSOR & CLUTCH;ML-3710,5 PIN
JC39-01473A HARNESS-MP;ML-3710,3 PIN,75MM,BLACK/GRAY
JC39-01469A HARNESS-REARCOVER&BINFULL SENSOR;ML-3710
JC39-01472A HARNESS-SMPS(SIGNAL);ML-3710,5 PIN,275MM
3711-000270 HEADER-BOARD TO CABLE;1WALL,5P,1R,3.96MM
3711-006435 HEADER-BOARD TO CABLE;BOX,10P,1R,1.5MM,S
3711-006436 HEADER-BOARD TO CABLE;BOX,11P,1R,1.5MM,S
3711-006501 HEADER-BOARD TO CABLE;BOX,12P,1R,1.5MM,S
3711-003408 HEADER-BOARD TO CABLE;BOX,2P,1R,2MM,STRA
3711-006432 HEADER-BOARD TO CABLE;BOX,5P,1R,1.5MM,ST
3711-006433 HEADER-BOARD TO CABLE;BOX,6P,1R,1.5MM,ST
JC61-00696A HINGE-M-FRAME;SCX-4216F,POM,WHITE
JC61-00697A HINGE-M-PRESSURE;SCX-4216F,PC(LF1025),NT
JC61-04067A HOLDER-EXIT SENSOR;ML-3710,ABS,2,45.5,44
JC61-04085A HOLDER-JAM;ML-3700ND,PC
JC61-01172A HOLDER-M-EXIT F/DOWN;ML-1610,PC,T2.0,W18
JC61-02233A HOLDER-REGI;MLL-2851ND,POM,25,12,BLACK,S
JC61-04327A JC61-04327A HOLDER-ROLLER;ML-3710ND,ABS,2,66,39,HB
JC61-04068A JC61-04068A HOLDER-TR;ML-3700,ABS,2,24.4,9,ICE GREEN
JC44-00197A HVPS;24V,21.6V~27.6V,MAX 5KV,MAX-2KV,600
JC13-00049A IC ASIC-CHORUS4;ML-4200ND,540,1.1V, 1.8V
JC13-00020A IC ASIC-ENGINE CONTROL;LPEC1,CLP-500,128
JC13-00042B IC ASIC-NCRUM2;S3CC921,ML-1650,8,2.7V-3.
1001-000170 IC-ANALOG SWITCH;MC14051BD,SPDT CMOS,SOP
1201-000105 IC-AUDIO AMP;34119,SOP,8P,150MIL,SINGLE,
0801-002446 IC-CMOS LOGIC;74LCX14,SCHMITT INVERTER,T
0801-002628 IC-CMOS LOGIC;7SZ08,2-INPUT AND GATE,SC-
1205-002478 IC-DAA;CX20493-21/FAX,QFN,28P,5X5MM,PLAS
1205-002654 IC-MODEM;CX86710-12,TQFP,64P,7X7MM,PLAST
1107-001893 IC-NOR FLASH;W25Q64BVSSIG,64MBIT,X1,SOIC
1203-001455 IC-POSI.FIXED REG.;1117,DPAK,3P,265MIL,P
1203-002986 IC-POSI.FIXED REG.;7812,3P,6.6X6.1MM,PLA
1203-002159 IC-POWER PRESCALER;2026,SOP,8P,153MIL,PL
1203-005024 IC-PWM CONTROLLER;ISL88550AIRZ,TQFN,28P,
1202-000164 IC-VOLTAGE COMP.;393,SOP,8P,150MIL,DUAL,
JB70-00236A ICT-HINGE SHAFT(4IN1);SCX-1150F,SWCH,32.
JB70-00168A ICT-PIN ADF;SCX-1110F,STS303,L10.0,D2.0
JC64-00609A INDICATOR-PAPER;ML-3710,ABS,3.0,85.9
JB70-00148A IPR-HOLDER GLASS;SCX-1110/XRX,SUS304,12*
JF70-10616A IPR-WASHER SPRING CU;CF3400,SUS301-CSP,T
3722-002345 JACK-MODULAR;6P/4C,INVERTED,N,ANGLE,N,GR
3722-001051 JACK-USB;4P/1C,AU,BLK,ANGLE,A TYPE
3722-002303 JACK-USB;4P/1C,AU30U,BLK,ANGLE,B TYPE
JB68-00916A LABEL RATING-BLANK;SF-340,SEC,TETRON,0.0
JC68-01584A LABEL(P)-BLANK 90*25;CLP-510,SEE,ART 100
JC68-00780A LABEL(P)-CAUTION PRINTING;COMMON,WHITE P
JB68-00073A LABEL(R)-BAR CODE;SF-3000,PY,T0.5,6.5,34
JC68-00573A LABEL(R)-BARCODE;ML-4500,PET,T0.05,20MM,
4713-001566 4713-001566 LAMP-HALOGEN;110V,850W
JC66-00958A LATCH-M_ARM FRT;SCX-6345N/XRX,POM,T1.5,3
JC07-00012A LCD;VHF12642FL3W,ML-5050ND,128X64 DOTS,7
0601-001226 LED;SMD(TOP VIEW),RED,1.2X0.8MM,660NM,1.
JC66-02761A LEVER-ALIGN_DUPLEX;ML-3710ND,ABS,1.8,15.
JC66-02770A LEVER-COUPLING;ML-3710,PC,3.0,184.4,126.
JC66-02795A LEVER-LINK_JAM_L;ML-3700ND,SECC,1.6T,WHI
JC66-02796A LEVER-LINK_JAM_R;ML-3700ND,SECC,1.6T,WHI
JC66-02768A LEVER-OPC HOLDER_L;ML-3710,POM,3.0,16.3,
JC66-02769A LEVER-OPC HOLDER_R;ML-3710,POM,3.0,16.3,
JC66-02086B JC66-02086B LINK-COVER_MP;ML-3710,ABS,62.3,2.0,WAVE
JC97-03857A LSU;ML-3200,SEC,SINGLE,A4(LTR),600,S1,78
JC97-03069A JC97-03069A MEA UNIT-DADF RUBBER;CLX-6240FX,-,-,-,-,
JC97-03060A MEA UNIT-STOPPER;CLX-6240FX,-,-,-,-,-
JC97-03085A MEA-GEAR FEED;CLX-6240FX,-,-,-,-,-
JC97-03220A JC97-03220A MEA-UNIT_HINGE;CLX-6200FX,SEC,-,CLAMPPIN
JC75-00095A JC75-00095A MEC-BRUSH ANTISTATIC;ML-6060A,SEC,NTR
JC31-00144A MOTOR BLDC;DC 24V,2.0A,25W,ML-3700,TYPE2
JC31-00080A JC31-00080A MOTOR STEP;2T357278Q/SP-35RC-800S,SCX-45
JC31-00096A MOTOR STEP;STP-42D1079,SCX-5135ND,0.8A,2
JC90-01041A JC90-01041A MP-PICK UP;ML-3700,SEC
JC97-03893F OPE;SCX-4835FR,XAA
JC92-01746A PBA SUB-MODEM;SCX-5530FN,-,-,-,-,-,-,114
JC92-01954A JC92-01954A PBA-DADF;CLX-6240FX,SEC,-,-,-,-,-,65MM*4
JC92-02353A PBA-JOINT;SCX-5637FR,SEC,DUPLEX ADF PBA,
JC92-02350C PBA-MAIN;SCX-4833FR,SEC,MAIN,215X118MM
JC92-02366A JC92-02366A PBA-OPE;SCX-5637FR,SEC,OPE,365X72MM,FR-1
0604-001393 0604-001393 PHOTO-INTERRUPTER;TR,75MW,BGA,TR
0604-001415 0604-001415 PHOTO-INTERRUPTER;TR,90%,150MW,DIP-4,BK
JC61-02236A PLATE-EARTH-TRANSFER;ML-2851ND,SECC,1.0,
JC61-00914A PLATE-P-PUSH BUSHING;SCX-4920N,SECC,0.8,
JC61-00604A JC61-00604A PLATE-P-SAW;ML-1400,SUS304-CSP,0.15,15.1
JC97-03891A PLATEN-LOWER;SCX-4833FR,SEE
JC97-03888A PLATEN-UPPER;SCX-4833FR,SEE
JB72-00821A PMO-ADF COLAR;SCX-1110F,POM,NTR
JC72-41191B PMO-BEARING SHAFT;ML-2150,POM,BLK,DE8903
JC72-41191A PMO-BEARING SHAFT;ML-6000,POM,WHT,M90-44
JB72-00819A PMO-BUSH;SCX-1110F,POM,NTR
JC72-41364A PMO-BUSHING_P/U,MP;ML-6100,POM,BLACK,CF-
JG72-40960A PMO-CAP TONER;SF6000,PP,OD22,W6,BLK
JC72-00983A PMO-LOCKER CST;ML-1710,POM(DELIN 900P),W
JB72-00845A PMO-PICK UP CLUTCH SUB;SCX-1110F,POM(DE8
JC72-00984A JC72-00984A PMO-PLATE GUIDE DEVE_L;ML-1710,POM(M90-4
JC72-00985A JC72-00985A PMO-PLATE GUIDE DEVE_R;ML-1710,POM(M90-4
JC72-00744A PMO-SHAFT PICK UP;SCX-5150,ABS,BLK,HB
JB72-00822A PMO-SLEEVE ADF;SCX-1110F,POM,BLK
JB72-00823A PMO-SLEEVE PICK UP;SCX-1110F,POM,BLK
JC72-01343A JC72-01343A PMO-SUB_M_STACKER;ML-1520,PC,39*25.5*3.5
JC66-00899A PULLEY-18_DUP;ML-3560,POM,HB,WHITE,?4.1
JC66-00900A PULLEY-M-18-DUMMY_DUP;ML-3560,POM,HB,WHI
2007-008433 R-CHIP;0.33OHM,1%,1W,TP,6432
2007-000033 R-CHIP;0OHM,5%,1/4W,TP,3216
2007-000123 R-CHIP;1.5KOHM,5%,1/10W,TP,1608
2007-000079 R-CHIP;1.8KOHM,5%,1/10W,TP,1608
2007-008006 R-CHIP;10.7KOHM,1%,1/10W,TP,1608
2007-000102 R-CHIP;100KOHM,5%,1/10W,TP,1608
2007-000074 R-CHIP;100OHM,5%,1/10W,TP,1608
2007-000052 R-CHIP;10KOHM,1%,1/10W,TP,1608
2007-000090 R-CHIP;10KOHM,5%,1/10W,TP,1608
2007-000305 R-CHIP;10MOHM,5%,1/10W,TP,1608
2007-000309 R-CHIP;10OHM,5%,1/10W,TP,1608
2007-007297 R-CHIP;110OHM,1%,1/10W,TP,1608
2007-000116 R-CHIP;120OHM,5%,1/10W,TP,1608
2007-007521 R-CHIP;14.7KOHM,1%,1/10W,TP,1608
2007-008567 R-CHIP;15.4KOHM,1%,1/10W,TP,1608
2007-000402 R-CHIP;150OHM,5%,1/10W,TP,1608
2007-001306 R-CHIP;150OHM,5%,1/16W,TP,1005
2007-000403 R-CHIP;150OHM,5%,1/4W,TP,3216
2007-000092 R-CHIP;15KOHM,5%,1/10W,TP,1608
2007-000132 R-CHIP;180KOHM,5%,1/10W,TP,1608
2007-000078 R-CHIP;1KOHM,5%,1/10W,TP,1608
2007-000109 R-CHIP;1MOHM,5%,1/10W,TP,1608
2007-000481 R-CHIP;1MOHM,5%,1/4W,TP,3216
2007-002425 R-CHIP;1OHM,5%,1/10W,TP,1608
2007-008697 R-CHIP;2.49KOHM,1%,1/16W,TP,1005
2007-000066 R-CHIP;20KOHM,1%,1/10W,TP,1608
2007-000093 R-CHIP;20KOHM,5%,1/10W,TP,1608
2007-007382 R-CHIP;20MOHM,5%,1/10W,TP,1608
2007-000106 R-CHIP;220KOHM,5%,1/10W,TP,1608
2007-000094 R-CHIP;22KOHM,5%,1/10W,TP,1608
2007-000071 R-CHIP;22OHM,5%,1/10W,TP,1608
2007-008510 R-CHIP;237KOHM,1%,1/4W,TP,3216
2007-000616 R-CHIP;24KOHM,5%,1/10W,TP,1608
2007-000660 R-CHIP;27OHM,5%,1/4W,TP,3216
2007-000082 R-CHIP;3.3KOHM,5%,1/10W,TP,1608
2007-007525 R-CHIP;3.4KOHM,1%,1/10W,TP,1608
2007-007008 R-CHIP;300OHM,5%,1/16W,TP,1005
2007-000730 R-CHIP;300OHM,5%,1/4W,TP,3216
2007-000096 R-CHIP;30KOHM,5%,1/10W,TP,1608
2007-000740 R-CHIP;30KOHM,5%,1/4W,TP,3216
2007-000133 R-CHIP;330KOHM,5%,1/10W,TP,1608
2007-000076 R-CHIP;330OHM,5%,1/10W,TP,1608
2007-000134 R-CHIP;33KOHM,5%,1/10W,TP,1608
2007-000113 R-CHIP;33OHM,5%,1/10W,TP,1608
2007-000839 R-CHIP;39OHM,5%,1/10W,TP,1608
2007-000083 R-CHIP;3KOHM,5%,1/10W,TP,1608
2007-000084 R-CHIP;4.7KOHM,5%,1/10W,TP,1608
2007-000882 R-CHIP;4.7OHM,5%,1/10W,TP,1608
2007-009964 R-CHIP;44.2OHM,1%,1/16W,TP,1005
2007-000107 R-CHIP;470KOHM,5%,1/10W,TP,1608
2007-000097 R-CHIP;47KOHM,5%,1/10W,TP,1608
2007-000965 R-CHIP;5.1KOHM,5%,1/10W,TP,1608
2007-000144 R-CHIP;5.1KOHM,5%,1/16W,TP,1005
2007-001014 R-CHIP;51OHM,5%,1/10W,TP,1608
2007-008133 R-CHIP;56.2KOHM,1%,1/10W,TP,1608
2007-000119 R-CHIP;560OHM,5%,1/10W,TP,1608
2007-001044 R-CHIP;56OHM,5%,1/10W,TP,1608
2007-001045 R-CHIP;56OHM,5%,1/4W,TP,3216
2007-008473 R-CHIP;59KOHM,1%,1/10W,TP,1608
2007-002760 R-CHIP;6.8MOHM,5%,1/4W,TP,3216
2007-001116 R-CHIP;680OHM,1%,1/10W,TP,1608
2007-000120 R-CHIP;680OHM,5%,1/10W,TP,1608
2007-001134 R-CHIP;68OHM,5%,1/10W,TP,1608
2007-001139 R-CHIP;7.5KOHM,1%,1/10W,TP,1608
2007-000088 R-CHIP;7.5KOHM,5%,1/10W,TP,1608
2007-001164 R-CHIP;75OHM,1%,1/10W,TP,1608
2007-000121 R-CHIP;820OHM,5%,1/10W,TP,1608
2011-001262 R-NETWORK;22OHM,5%,1/16W,L,CHIP,8P,TP,2.
2011-001261 R-NETWORK;33OHM,5%,1/16W,L,CHIP,8P,TP,2.
2011-001094 R-NETWORK;39OHM,5%,1/16W,L,CHIP,8P,TP,3.
2011-001402 R-NETWORK;56OHM,5%,1/16W,L,CHIP,8P,TP,2.
3501-000203 RELAY-MINIATURE;5V,200MW,1000MA,1FORMC,6
6044-000159 RING-C;ID3,OD7,T0.6,PASS,STSC
6044-000001 RING-CS;ID2.8,OD8,T0.25,BLACK,SK-5
6044-000125 RING-E;ID4,OD9,T0.6,STSC
6044-000231 RING-E;ID5.0,OD11.0,T0.6,PASS,STS304
JB73-00052A JB73-00052A RMO-ADF RUBBER;SCX-1110F,SILICON RUBBER,
JC66-01824A JC66-01824A ROLLER-EXIT;CLX-6240FX,SUM22L+NI, EPDM,1
JC66-02834A JC66-02834A ROLLER-FEED REGI;ML-3710ND,SUM22+EPDM,14
JC66-01823A ROLLER-FEED;CLX-6240FX,SUM22L+NI , EPDM,
JC66-02797A JC66-02797A ROLLER-FEED;ML-37010ND,SUM22+EPDM,11.9,G
JC66-01657A JC66-01657A ROLLER-FEED_DUP2;ML-2851ND,SUM22L+NBR,11
JC96-04983A JC96-04983A ROLLER-FEED_DUP;ML-3560,SUM22+NBR,OD11.3
JC66-02846A JC66-02846A ROLLER-HEAT;ML-3700,AL3304+MP531,24.75,T
JC66-02798A ROLLER-IDLE;ML-3710ND,POM,14,WHITE,GUIDE
JC66-01312A ROLLER-IDLE;SCX-4521F,PFA,7,L11,WHITE
JC66-00461A JC66-00461A ROLLER-M-ADF IDLE;SCX-4114F,POM,BLK
JC66-00934A ROLLER-M-EXIT FR;ML-1610,TEFLON,6.5,L22.
JC66-00824A ROLLER-M-EXIT MAIN;ML-1610,POM,8.5,L23.6
JC66-00896A ROLLER-M-IDLE_ DUP;ML-3560,POM,OD9.6,14.
JC66-02939A JC66-02939A ROLLER-MAT_ RETARD;ML-3710ND,OD 16,ID 10
JC66-01822A ROLLER-MIDDLE;CLX-6240FX,SUM22L+NI, EPDM
JC66-01022A JC66-01022A ROLLER-M_IDLE SCF;SCX-6345N/XRX,POM,OD14
JC66-01663A JC66-01663A ROLLER-PRESSURE;ML-2851ND,LSR+PFA,20,237
JC66-01664A JC66-01664A ROLLER-PRESSURE_2ND;ML-2851ND,LSR+PFA,12
JC66-02955A ROLLER-SILICON_EXIT;ML-3700,SILICON,13.4
JC66-02842A JC66-02842A ROLLER-TRANSFER;ML-3700,NBR+ECO,6,218,BL
JC73-00141A JC73-00141A RPR-PAD CASSETTE;ML-1510,URETHANE SPONGE
JC73-00263A JC73-00263A RUBBER-EXIT F DOWN;CLP-310,EPDM,10,14.2,
JC73-00340A JC73-00340A RUBBER-PICK UP;ML-3700ND,EPDM+IR,27,ID 2
6001-000130 SCREW-MACHINE;BH,+,M3,L6,ZPC(WHT),SWRCH1
6002-000440 SCREW-TAPPING;PWH,+,2,M3,L8,ZPC(BLK),SWR
6003-000261 SCREW-TAPTYPE;BH,+,-,B,M3,L6,ZPC(WHT),SW
6003-000282 6003-000282 SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW
6003-000269 6003-000269 SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SW
6003-001474 SCREW-TAPTYPE;BH,+,B,M3,L30,ZPC(WHT),SWR
6003-000301 SCREW-TAPTYPE;BH,+,S,M4,L6,ZPC(WHT),SWRC
6006-001078 SCREW-TAPTYPE;PH,+,WSP,B,M3,L10,ZPC(WHT)
6003-000264 SCREW-TAPTYPE;PWH,+,-,B,M3,L6,ZPC(WHT),S
6003-000196 SCREW-TAPTYPE;PWH,+,B,M3,L10,NI PLT,SWRC
JC66-01846A SHAFT-DUP_ROLLER;ML-2851ND,SUM24L+NI,L48
JC66-00527A SHAFT-FEED IDLE;ML-1510,SUM24L+NI,223,8
JC66-02772A SHAFT-FEED REGI;ML-3710ND,POM,35.5,8,NAT
JC66-00444A SHAFT-IDLE ROLL, DUP;ML-2150,SUM24L,25,2
JC70-20901A JC70-20901A SHAFT;ML-5000A,SUS304,17.2,1.9,PI1.9
JC63-02984A JC63-02984A SHEET-CASSETTE;ML-3710,PC,0.125,47,10.8,
JC63-02956A SHEET-DUPLEX PATH;ML-3710,PET+TAPE NITTO
JC63-00186A SHEET-GUIDE ADF;SCX-6320F,PET,0.125,37,2
JC63-03074A SHEET-MP;ML-3710ND,PET,0.125,72,30,BLACK
JC63-03039A SHEET-OPE;SCX-5637FR,PC,0.5,456.4,83.21,
JC63-01776A SHEET-PATH;CLX-6240FX,PET,0.188,12.0,30,
JC63-02933A JC63-02933A SHEET-RETARD;ML-3710,PET,0.125,30,11.6,B
JC63-00209A JC63-00209A SHEET-WHITE SPONGE;SCX-4216F,POLYURETHAN
JC44-00095D JC44-00095D SMPS-V1;ML-3200,PSPN TYPE2 V1,FLYBACK,77
JC33-00030A JC33-00030A SOLENOID-DADF;DLH-34L130-01,CLX-6240FX,D
JC33-00031A SOLENOID-LIFTING;DAH-10H080-01,CLX-6240F
3001-002262 SPEAKER;0.3W,8OHM,81DB,400HZ,50X16.4MM
JC72-01444A SPONGE-GUIDE CHANGE DUP;ML-2851ND/XAA,PO
JB61-70904A SPRING ETC-CLUTCH;AMUNDSEN,SWRS82A,D11.4
JC61-00025A SPRING ETC-CS-CHARGE APOLLO;SF-5100,SUS
JC61-70932A SPRING ETC-GUIDE DEVE;ML-5000A,D4.3,L16.
JG61-70531A SPRING ETC-LOCKER,PLATE;SF6000,SUS304WPB
JC61-00387A SPRING ETC-PAD;ML-9400W,SUS304WPB,PI0.5,
JC61-02489A JC61-02489A SPRING ETC-PICKUP;CLX-6240FX,SUS304 WPB,
JC61-70935A SPRING ETC-SEPERATE P/UP;ML-5000A,SUS304
JB61-00076A JB61-00076A SPRING ETC-TORSION DOC (CC2-F);SCX-1110F
JC61-70958A SPRING ETC-TR;ML-5000A,SUS304 WPB,PI0.55
6107-001370 SPRING-CS;STS304WPB,NO FIN,PI0.45,D4.45,
6107-001137 SPRING-CS;SUS304 WPB,PI0.4,D9.4,L11.5,ID
6107-002776 SPRING-CS;SUS304,0.4,16,5.0,5.8
6107-002883 SPRING-CS;SUS304,0.4,5.35,10.75,RIGHT
6107-002824 SPRING-CS;SUS304,D5.5,L12,6.75,8.5
6107-001163 SPRING-CS;SUS304-WPB,PI0.4,D3.9,L13,ID3.
6107-001287 SPRING-CS;SUS304-WPB,PI0.6,D6.5,L25,ID5.
6107-001246 SPRING-CS;SWP B,PI0.9,D5.8,L15.5,ID4.9,O
6107-002779 6107-002779 SPRING-CS;SWP,ZINC,0.9,17.9,56.3,17,18.8
6107-001194 SPRING-CS;SWP-B,BLK,PI0.9,D6.95,L20,ID6.
6107-001354 SPRING-CS;SWP-B,END CLOSE,PI2,L33,ID7,OD
6107-002780 SPRING-ES;SUS304,PI0.24,L11.1,ID3.5,OD4
6107-002817 SPRING-ETC;SUS304,0.35,0.29,3.2,3.78
6107-002846 SPRING-ETC;SUS304,0.55,4.75,RIGHT
6107-002818 SPRING-ETC;SUS304,1.0,21.45
6107-001188 SPRING-ETC;SUS304,ANNEALING,PI0.46,D1.84
6107-002781 SPRING-TS;SUS304,1.0,4.75,LEFT,17,4,132
6107-002828 SPRING-TS;SUS304,3.8,4.1,3.95,20,RIGHT,7
6107-001164 6107-001164 SPRING-TS;SUS304-WPB,PI0.15,D3.95,L12,ID
6107-001156 SPRING-TS;SWP-B,PI0.6,W20,ID3.5
6107-001171 SPRING-TS;SWRS82A,0.75X0.5,D14.2,ID13.7,
6107-001537 SPRING-TS;SWRS82A,D0.8,L8.9,ID8.3,OD9.9
JC61-04098A STACKER-BIN_FULL;MAGPIE,PC,2,48.54,35.2,
JC61-04057A STOPPER-MP;ML-3710ND,POM,5,23.9,WHT
3404-001222 SWITCH-TACT;12VDC,50MA,160GF,6X6X5.0MM,S
0203-001100 TAPE-OPP MASKING;OPP/W75/CLR,T0.075,W75,
JC65-00051A TERMINAL-GND-DUPLEX;ML-3710ND,C5191W,2HO
JC65-00050A TERMINAL-PR_FUSER;ML-3700,SUS304,0.5PI
JC65-00047A TERMINAL-TR;ML-3700,SUS304,0.5PI
1404-001417 1404-001417 THERMISTOR-NTC ASSY;10KOHM,3435K,3MW/C
1404-001640 1404-001640 THERMISTOR-NTC ASSY;7KOHM,3370K,0.3MW/C,
1401-001069 THYRISTOR-SIDAC;TISP4350H3/P3100EC,275V,
0506-001069 TR-ARRAY;MBT3904DW1T1,NPN,DUAL,150MW,SOT
0502-001258 TR-POWER;FJT44,NPN,SOT-223,TP,40-200
0501-000632 TR-SMALL SIGNAL;2SB1197K,PNP,200MW,SOT-2
0501-000479 TR-SMALL SIGNAL;KST42,NPN,350MW,SOT-23,T
0501-000457 TR-SMALL SIGNAL;MMBT2222A/KST2222A,NPN,3
0501-000462 TR-SMALL SIGNAL;MMBT2907A,PNP,350MW,SOT-
2602-000061 TRANS-PULSE;30UH,0.225/0.325OHM,1:1.5,9.
2602-000062 TRANS-PULSE;450UH,0.25/0.25OHM,1:1,12.8X
JC63-02901A TRAY-EXTENSION_MP;MAGPIE,ABS,2.0,118.9,2
1405-000170 VARISTOR;82V,1200A,9X4.1MM,TP
6031-001255 WASHER-PLAIN;NYLON,CUTTING,ID5,OD9,T0.5,
6031-000023 WASHER-PLAIN;POLY,ID5.9,OD10.0,T0.5,BLK
Main Menu x
