Manufacturer
Samsung
Model Number
SCX-6345NJ
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 6902-000288 | BAG PE;LDPE,T0.05,W250,L450,TRP,8,2,10.5 |
| JB72-00764A | BAND;SCX-1110/XRX,POM,WHT |
| 3301-000344 | BEAD-RADIAL;200OHM,3.5X0.6X6.5MM,7000MA, |
| 3301-000317 | BEAD-SMD;120OHM,2012,TP,-,- |
| 6601-001385 | BEARING-BALL;679ZZ,ID9.0,OD14,L4.5,SRL |
| 6601-001346 | BEARING-BALL;6809 2Z,ID45,OD58,L7,GCR5,0 |
|
|
BEARING-BALL;688ZZ,ID8,OD16,L5,SUJ2 |
| JC66-10205A | BEARING-PRESSURE R;ML-80,PPS |
| 6602-001090 | BELT-TIMING GEAR;FIBER GLASS,T3.2,942.85 |
| 6602-001092 | BELT-TIMING GEAR;RUBBER,T1.36,40S2M338,3 |
| JC69-00878A | BOX(P)-MAIN_BOT;CB,DC3,A-1,207,577,799,B |
| JC67-00055A | BRUSH-ANTISTATIC 531P;SF-531P,AL+THUNDER |
| JC67-00196A | BRUSH-ANTISTATIC SCAN;SCX-6345N,AL+SUS F |
| JC67-00210A | BRUSH-ANTISTATICFUSER;SCX-6345N,AL,0.2,2 |
| JC67-00125A | BRUSH-EXIT;SCX-6345N/XRX,AL0.4T, SUS FIB |
| JC61-01694A | BUSH-46D;SCX-6345N,BRONZE POWDER,?4.6,?6 |
| JC61-00424A | BUSH-4;ML-9400W,BEARING,?4,NTR |
| JC61-01686A | BUSH-4D_FE;SCX-6345N,SBF2118,?4,?5.93,3. |
| JC61-00884A | BUSH-6_D(L);SCX-6320F,BRONZE POWDER(KAB- |
| JC61-00423A | BUSH-6_D;ML-9400W,BEARING,?6,NTR |
| JC61-00426A | BUSH-8/5;ML-9400W,BEARING,?8,OD12.0,L6.0 |
| JC61-01428A | BUSH-DRY;SCX-6345N/XRX,BRONZE SINTERED(K |
| JC61-01439A | BUSH-M H/R JF;SCX-6345N/XRX,PPS,?39.95,? |
|
|
BUSH-M_ADF CLUTCH;SCX-6320F,PPS,7,11.85, |
| 3002-000185 | BUZZER-MAGNETIC;85DB,5V,40MA,2.4KHZ,BK |
| 2402-001042 | C-AL,SMD;100UF,20%,16V,GP,TP,6.6X6.6X5.4 |
| 2402-001049 | C-AL,SMD;10UF,20%,16V,GP,TP,3.3X3.3X5.4 |
| 2402-001178 | C-AL,SMD;10UF,20%,16V,WT,TP,4.3X4.3X5.8M |
| 2402-000117 | C-AL,SMD;10UF,20%,35V,GP,TP,5.3X5.3X5.4 |
| 2402-000209 | C-AL,SMD;22UF,20%,16V,WT,TP,5.3X5.3MM |
| 2402-001106 | C-AL,SMD;33UF,20%,50V,WT,TP,8.3X8.3X6.3M |
| 2402-000008 | C-AL,SMD;47UF,20%,16V,GP,TP,6.6X6.6X5.4 |
| 2401-000207 | C-AL;100UF,20%,50V,WT,TP,8X12,5 |
| 2401-002300 | C-AL;47UF,20%,50V,GP,TP,6.3X11,5MM |
| 2203-005105 | C-CER,CHIP;.68NF,5%,50V,C0G,TP,1608 |
| 2203-000384 | C-CER,CHIP;0.015NF,5%,50V,C0G,TP,1608,0. |
| 2203-000426 | C-CER,CHIP;0.018NF,5%,50V,C0G,1608 |
| 2203-000041 | C-CER,CHIP;0.01NF,0.25PF,50V,C0G,TP,1608 |
| 2203-000626 | C-CER,CHIP;0.022NF,5%,50V,C0G,1608 |
| 2203-000681 | C-CER,CHIP;0.027NF,5%,50V,C0G,1608 |
| 2203-001607 | C-CER,CHIP;0.22NF,5%,50V,NP0,1608 |
| 2203-000783 | C-CER,CHIP;0.33NF,5%,50V,C0G,1608 |
| 2203-001656 | C-CER,CHIP;0.47NF,5%,50V,NP0,1608 |
| 2203-006676 | C-CER,CHIP;10000NF,+80-20%,10V,Y5V,TP,20 |
| 2203-005819 | C-CER,CHIP;1000NF,+80-20%,16V,Y5V,TP,160 |
| 2203-005617 | C-CER,CHIP;1000NF,+80-20%,50V,Y5V,TP,201 |
| 2203-000192 | C-CER,CHIP;100NF,+80-20%,50V,Y5V,TP,2012 |
| 2203-005249 | C-CER,CHIP;100NF,10%,50V,X7R,TP,1608 |
| 2203-000206 | C-CER,CHIP;100NF,10%,50V,X7R,TP,2012 |
| 2203-000257 | C-CER,CHIP;10NF,10%,50V,X7R,TP,1608 |
| 2203-000440 | C-CER,CHIP;1NF,10,50V,X7R,TP,1608 |
| 2203-000491 | C-CER,CHIP;2.2NF,10%,50V,X7R,1608 |
| 2203-002392 | C-CER,CHIP;220NF,+80-20%,50V,Y5V,2012 |
| 2203-000975 | C-CER,CHIP;47NF,10%,25V,X7R,TP,1608,- |
| 2404-000284 | C-TA,CHIP;10UF,20%,16V,-,TP,3528 |
| 6502-000132 | CABLE CLAMP;DAWS-1NE,ID11,L21.0,NTR,NYLO |
| 6502-001093 | CABLE CLAMP;DAWS-3NE,ID11*L34.8,NYLON66, |
| 6501-000004 | CABLE TIE;DA-80,T1,W2.5,L80,NTR,NYLON66 |
| 6501-000115 | CABLE TIE;DA100,T1,W2.5,L102,NTR,NYLON66 |
| JC67-00284A | CAP-TONER L;SCX-6555N,PP,1.0,33,6,BLK |
| JC39-00187A | CBF HARNESS-ADF ROLLER GND;SCX-5100,WIRE |
| JC39-00342A | CBF HARNESS-AIR_TEMP;SCX-6320F,CBF,UL106 |
| JC39-00466A | CBF HARNESS-COVER_EXT;SCX-6345N,CBF,UL10 |
| JC39-00332A | CBF HARNESS-COVER_OPEN;SCX-6320F,CBF,UL1 |
| JC39-00476A | CBF HARNESS-DEVE;SCX-6345N,CBF,UL1061,7, |
| JC39-00331A | CBF HARNESS-DOC_WIDTH;SCX-6320F,CBF,UL10 |
| JC39-00329A | CBF HARNESS-EXIT_OPEN;SCX-6320F,CBF,UL10 |
| JC39-00509A | CBF HARNESS-GND ZENER;SCX-4521F,UL1007,1 |
| JC39-00511A | CBF HARNESS-HDD;SCX-6345N,FLAT,UL2651,44 |
| JC39-00545A | CBF HARNESS-HVPS(3P);SCX-6345N,CBF,UL323 |
| JC39-00544A | CBF HARNESS-HVPS(8P);SCX-6345N,CBF,UL323 |
| JC39-00330A | CBF HARNESS-LENGTH_SEN;SCX-6320F,CBF,UL1 |
| JC39-00473A | CBF HARNESS-LIMIT_EMT;SCX-6345N,CBF,UL10 |
| JB39-00103A | CBF HARNESS-LIU GND;SCX-1110F,WIRE,UL100 |
| JC39-00241A | CBF HARNESS-MOTOR;ML-1710,CBF,UL 1061,4, |
| JC39-00470A | CBF HARNESS-MOTOR_STP;SCX-6345N,CBF,UL10 |
| JC39-00554A | CBF HARNESS-NEAR_SEN;SCX-6345N,CBF,UL106 |
| JC39-00550A | CBF HARNESS-OPE;SCX-6345N,CBF,UL1061,14, |
| JC39-00552A | CBF HARNESS-OPE_KEY;SCX-6345N,CBF,UL1061 |
| JC39-00553A | CBF HARNESS-OPE_SUB;SCX-6345N,CBF,UL1061 |
| JC39-00512A | CBF HARNESS-REGI;SCX-6345N,CBF,UL1061,14 |
| JC39-00328A | CBF HARNESS-REGI_SEN;SCX-6320F,CBF,UL106 |
| JC39-00344A | CBF HARNESS-SENSOR_IF;SCX-6320F,CBF,UL10 |
| JC39-40511A | CBF HARNESS;ML-80,JUMPER,AWG22,52MM,SILV |
|
|
CBF IF-USB;ML-6100,4,UL2725,1800 +/- 50, |
| JF39-50094B | CBF LINE CORD;MINI FAX,IVR |
| JC39-00556A | CBF SIGNAL-CCD;SCX-6345N,24P,FFC,600MM,A |
| 3903-000296 | CBF-POWER CORD;DT,US,EP3,IEC320 C13,125/ |
| JC66-00972A | CLUTCH-2.5K Z24;SCX-6345N/XRX,POM+METAL, |
|
|
CLUTCH-5K Z32;SCX-6345N/XRX,POM+METAL,5K |
|
|
CLUTCH-P_ONE WAY;SCX-6345N/XRX,OWC612GXR |
| JB27-00004A | COIL CHOKE-DIP;DR 8X11(470UH),MJC-1450,4 |
| 3701-001143 | CONNECTOR-DSUB;15P,3R,FEMALE,ANGLE,AUF |
| 3708-001637 | CONNECTOR-FPC/FFC/PIC;24P,1MM,STRAIGHT,S |
| 3708-001455 | CONNECTOR-FPC/FFC/PIC;30P,0.5MM,SMD-A,AU |
| 3711-000280 | CONNECTOR-HEADER;1WALL,6P,1R,2.5MM,STRAI |
| 3711-006075 | CONNECTOR-HEADER;BOX,44P,2R,2MM,STRAIGHT |
| 3301-001413 | CORE-FERRITE;AD,33X12X7MM,1500,2800GAUSS |
| JC67-00126A | COUPLER-TORQUELIMITER;SCX-6345N/XRX,OTLV |
| JC63-00765B | COVER-CONNECTOR;SCX-6345N,ABS,5.3,55.0,7 |
| JC63-00727B | COVER-EXIT BOTTOM;SCX-6345N/XRX,PC/ABS,2 |
| JC63-00728B | COVER-EXIT BRACKET;SCX-6345N/XRX,HIPS,2. |
| JC63-00731B | COVER-EXIT REAR;SCX-6345N/XRX,HIPS,2.5,3 |
| JC63-00196B | COVER-EXIT;SCX-6322DN,ABS,2.5T,42.29,237 |
| JC63-00200B | COVER-FRONT;SCX-6322DN,HIPS,95.22,243.5, |
| JC63-00195B | COVER-OPEN;SCX-6322DN,HIPS,3.0T,255.9,HB |
| JC63-00307A | COVER-P GEAR;SCX-6320F,SECC,1.2T,110,83. |
| JC63-01211A | COVER-PANEL_FRONT;SCX-6345N,ABS,2.5,500, |
| JC63-00201B | COVER-REAR;SCX-6322DN,HIPS,2.5T,63.6,243 |
| JC63-00775B | COVER-SIDE;SCX-6345N/XRX,ABS,3,392.1,378 |
| 2801-000111 | CRYSTAL-SMD;0.032768MHZ,20PPM,28-AAW,12. |
| 2801-000199 | CRYSTAL-UNIT;20MHZ,50PPM,28-AAA,16PF,50O |
| JC69-00882A | CUSHION-BLOCK;SCX-6345N/XRX,EPS,290,133, |
| JC69-00881A | CUSHION-SUPPORT;SCX-6345N/XRX,EPS,150,14 |
| 0402-001189 | DIODE-RECTIFIER;M4,400V,1A,TS-1,TP |
| 0402-001212 | DIODE-RECTIFIER;SS26,60V,2A,SMB,TP |
| 0404-000112 | DIODE-SCHOTTKY;RB420D,40V,100MA,SOT-23,T |
| 0407-000123 | DIODE-SWITCHING;DAN202K,80V,100MA,SOT-23 |
| 0407-000122 | DIODE-SWITCHING;KDS226,80V,100MA,SOT-23, |
| 0401-000116 | DIODE-SWITCHING;MMSD914T1,100V,200MA,SOD |
| JC67-00127A | DUCT-M_FAN LSU;SCX-6345N/XRX,ABS ,T1.5,W |
| JC96-03747A | ELA HOU-BASE PLATE R;SCX-6345N/XRX,XEROX |
| JC96-03734B | ELA HOU-BASE RIGHT;SCX-6345N/XRX,SEC,-,- |
|
|
ELA HOU-CCDM;SCX-6345N,-,-,MONO 45 CPM,C |
| JC96-03554B | ELA HOU-COVER PLATEN;SCX-6345N,SEC,SEC,- |
| JC96-02127A | ELA HOU-CST SENSOR HAWK16;ML-7250,XEROX, |
| JC96-03534A | ELA HOU-CVR OPN;SCX-6345N/XRX,-,-,CVR OP |
| JC96-03555A | ELA HOU-DADF MOTOR;SCX-6345N/XRX,XEROX,- |
| JC96-03579B | ELA HOU-DADF SUB;SCX-6345N,SEC,SEC,-,-,- |
| JC96-03553B | ELA HOU-DADF;SCX-6345N,SEC,SEC,-,-,- |
| JC96-03537A | ELA HOU-DRIVE FUSER;SCX-6345N/XRX,XEROX, |
|
|
ELA HOU-DRIVE MAIN;SCX-6345N/XRX,XEROX,- |
| JC96-03556A | ELA HOU-DUPLEX MOTOR;SCX-6345N/XRX,XEROX |
| JC96-03532A | ELA HOU-DUPLEX;SCX-6345N/XRX,-,-,DUPLEX, |
| JC96-05166A | ELA HOU-EXIT;SCX-6345N,SEC,-,-,- |
| JC96-03752A | ELA HOU-FAN DUCT;SCX-6345N,XEROX,-,-,-,- |
| JC96-03552B | ELA HOU-FRAME MAIN;SCX-6345N/XRX,SEC,-,- |
| JC96-03526B | ELA HOU-FRAME_TOP;SCX-6345N/XRX,SEC,-,FR |
|
|
ELA HOU-FUSER;SCX-6345N/XRX,XEROX,-,FUSE |
|
|
ELA HOU-MP PICK UP;SCX-6345N/XRX,-,-,MP |
| JC96-03557B | ELA HOU-MP;SCX-6345N,SEC,-,-,- |
| JC96-03659C | ELA HOU-NPC3_HIGH;SCX-6345N,IBM,NPC3 HIG |
| JC96-03753C | ELA HOU-OPE COVER;SCX-6345N,SEC,SEC,-,-, |
| JC96-03558A | ELA HOU-PICK UP;SCX-6345N/XRX,XEROX,KORE |
| JC96-03748B | ELA HOU-PLATE UPPER;SCX-6345N/XRX,SEC,-, |
| JC96-03550B | ELA HOU-PLATEN;SCX-6345N,SEC,SEC,-,-,- |
| JC96-03548B | ELA HOU-SCAN LOWER;SCX-6345N,SEC,SEC,-,- |
| JC96-03547A | ELA HOU-SCAN MOTOR;SCX-6345N/XRX,XEROX,- |
| JC96-03527B | ELA HOU-SCANNER;SCX-6345N,SEC,SEC,-,-,- |
|
|
ELA HOU-SIDE DUPLEX;SCX-6345N,SEC,-,-,- |
| JC96-03735A | ELA HOU-SIZE SENSOR;SCX-6345N/XRX,XEROX, |
| JC96-03749A | ELA HOU-SOLENOID DP;SCX-6345N/XRX,XEROX, |
| JC96-03903A | ELA HOU-SUB_DOC_WIDTH;SCX-6320F,XEROX,-, |
| JC96-03535A | ELA HOU-TERMINAL;SCX-6345N/XRX,-,-,TERMI |
| JC96-03736A | ELA HOU-UPPER DP;SCX-6345N/XRX,XEROX,-,- |
| JC96-04056A | ELA HOU-VARISTOR;SCX-6345N,XEROX,-,-,- |
| JC96-04028A | ELA UNIT-HDD;SCX-6345N,XEROX,-,-,-,-,-,- |
| JC96-04047A | ELA UNIT-LSU LD;SCX-6345N,-,-,DUAL,14 PI |
| JC96-04669A | ELA UNIT-SERIAL;SCX-6345N,IBM,EXPORT,JSC |
| JC96-04947A | ELA UNIT-SHIELD SMPS;SCX-6555N,-,-,-,-,- |
| JC31-00012C | FAN-DC INVERTER;AD0624HS-A76GL(,SCX-6345 |
| JC31-00012B | FAN-DC LSU;AD0624HS-A70GL(R1),SCX-6345N, |
| JC31-00025B | FAN-DC;AD0624MS-A70GL,SCX-6345N/XRX,PBT+ |
| JC31-00071A | FAN-DC;SCX-6345N |
| 0505-001350 | FET-SILICON;NDT2955,P,-60V,-2.5V,0.3OHM, |
| 0505-001326 | FET-SILICON;SI2308DS,N,60V,2A,0.22OHM,1. |
| 2901-001178 | FILTER-EMI SMD;25V,2A,100000PF,2X1.25X1M |
|
|
FIXER-M_E RING 4PI;SCX-6345N/XRX,POM,T1. |
| JC61-40001A | FOOT-ML80;ML-80,NBR,GRAY |
| JG61-40001A | FOOT-SF4000;SF4000,CR RUBBER,W14XL14,BLK |
|
|
FRAME-ACTUATOR;SCX-6345N,SEC |
| JC61-01411B | FRAME-CASSETTE;SCX-6345N,HIPS,HB,VIOLET |
| JC61-01351B | FRAME-MP LOWER;SCX-6345N,ABS,HB,VIOLET S |
| JC61-01352B | FRAME-MP TOP;SCX-6345N,ABS,HB,VIOLET SMO |
| JB66-00104A | GEAR-ADF IDLE 34;SCX-1110F,POM,0.6,34,20 |
| JC66-00320A | GEAR-AUGER;SCX-5100,POM M90-44,0.6,24,14 |
| JC66-00565A | GEAR-DADF24(A);SCX-6320F,POM M90-44,1,Z2 |
| JC66-00565B | GEAR-DADF24(A);SCX-6345N,POM SW-01,1,Z24 |
| JC66-00571A | GEAR-DADF_EXIT31;SCX-6320F,POM M90-44,0. |
|
|
GEAR-DADF_SCAN31;SCX-6320F,POM M90-44,0. |
| JB66-00083A | GEAR-IDLE;SCX-1110/XRX,POM M90-44,0.5,31 |
| JC66-01011A | GEAR-M DRV Z2228;SCX-6345N/XRX,NYLON66,A |
| JC66-00989A | GEAR-M_AGI IDLE;SCX-6345N/XRX,POM,1,31/5 |
| JC66-00986A | GEAR-M_AGITATOR;SCX-6345N/XRX,POM,1,61,H |
| JC66-00950B | GEAR-M_CHARGE ROLL;SCX-6555N,POM,0.5,Z20 |
| JC66-00991A | GEAR-M_DUPLEX IDLE;SCX-6345N/XRX,POM,1,3 |
| JC66-00996A | GEAR-M_EXIT IDLE A;SCX-6345N/XRX,POM,A:1 |
| JC66-00997A | GEAR-M_EXIT IDLE C;SCX-6345N/XRX,POM,A:1 |
| JC66-01018A | GEAR-M_EXIT LOWER;SCX-6345N/XRX,POM,0.8, |
| JC66-01017A | GEAR-M_EXIT UPPER;SCX-6345N/XRX,POM,0.8, |
| JC66-01012A | GEAR-M_EXIT;SCX-6345N/XRX,POM,1,15,W10,B |
| JC66-00974A | GEAR-M_FORWARD;SCX-6345N/XRX,POM,1,31,H9 |
| JC66-00995A | GEAR-M_FUSER IDLE A;SCX-6345N/XRX,POM,A: |
| JC66-00940A | GEAR-M_IDLE PU;SCX-6345N/XRX,POM,0.7,22, |
| JC66-00955A | GEAR-M_LIFT COUPLING;SCX-6345N/XRX,POM,1 |
| JC66-00954A | GEAR-M_LIFTING;SCX-6345N/XRX,POM,1.5,46, |
| JC66-00985A | GEAR-M_MIXER;SCX-6345N/XRX,POM,1,27,D34. |
| JC66-00936A | GEAR-M_MP FEED;SCX-6345N/XRX,POM,1,24,H2 |
| JC66-00988A | GEAR-M_MP IDLE A;SCX-6345N/XRX,POM,A:1,B |
| JC66-00990A | GEAR-M_MP IDLE B;SCX-6345N/XRX,POM,A:1,B |
| JC66-00941A | GEAR-M_ONE WAY;SCX-6345N/XRX,POM,0.7,21, |
| JC66-00982A | GEAR-M_OPC BASE;SCX-6345N/XRX,POM,0.5,79 |
| JC66-00987A | GEAR-M_PICKUP IDLE A;SCX-6345N/XRX,POM,A |
| JC66-00973A | GEAR-M_PICKUP IDLE B;SCX-6345N/XRX,POM,A |
| JC66-01020A | GEAR-M_PINION 24;SCX-6345N/XRX,POM,1,24, |
|
|
GEAR-M_PU JOINT;SCX-6345N/XRX,POM,0.7,21 |
| JC66-00983A | GEAR-M_REGI IDLE A;SCX-6345N/XRX,POM,A:0 |
| JC66-00984A | GEAR-M_REGI IDLE B;SCX-6345N/XRX,POM,A:1 |
| JC66-00975A | GEAR-M_RETARD;SCX-6345N/XRX,POM,0.6,57,H |
| JC66-00993A | GEAR-M_SUPPLY IDLE;SCX-6345N/XRX,POM,A:0 |
| JB66-00105A | GEAR-PICK UP 26;SCX-1110F,POM,0.6,26,15. |
| JB66-00102A | GEAR-PICK UP IDEL 38;SCX-1110F,POM,0.6,3 |
| JG66-40003A | GEAR-PINION;SF4000,POM,1,Z16,WHT |
| JC66-00530A | GEAR-REDUCTION73/37;SCX-6320F,POM M90-44 |
| JC66-00531A | GEAR-TIMING;SCX-6320F,POM M90-44,0.5,Z57 |
| JC01-00008A | GLASS-LSU;180.5*11.5,1.9 |
| JC01-00004A | GLASS-SCAN HEATING;388.0*253.0,3.2,SEMI- |
| JC74-00019A | GLASS;238.4*19*2.8,SCX-5100,GLASS,CLEAR |
| JC63-00802A | GROUND-P-OPC CONTACT;SCX-6345N/XRX,C5210 |
| JC63-00794A | GROUND-P-PAPER SIZE;SCX-6345N/XRX,PHOSPH |
| JC63-00833A | GROUND-P-SHAFT RETARD;SCX-6345N/XRX,PHOS |
| JC63-00428A | GROUND-S_REGI;SCX-6320F,STS 304 WTB,PI0. |
|
|
GUIDE-EXIT SUB;SCX-6555N,PPE+PS,T2,BLK |
| JC61-00737A | GUIDE-M_DUPLEX_INNER;SCX-6320F,HIPS,2.5T |
| JC61-00735A | GUIDE-M_DUPLEX_LOWER;SCX-6320F,HIPS,2.5T |
|
|
GUIDE-M_EXIT;SCX-6345N/XRX,PPE+PS,T2.5,2 |
| JC61-01297A | GUIDE-M_FEED IDLE MP;SCX-6345N/XRX,ABS , |
|
|
GUIDE-M_PICKUP DOC;SCX-6345N/XRX,PC+ABS, |
| JC61-01299A | GUIDE-M_UPPER PICK UP;SCX-6345N/XRX,PC A |
| JC61-01413A | GUIDE-P-SIDE LEFT;SCX-6345N/XRX,SECC,T1. |
| JC64-00224A | HANDLE-M-FUSER_JF;SCX-6345N/XRX,PC/STEEL |
| JC39-00541A | HARNESS-COVER_SW;SCX-6345N,CBF,UL1061,5, |
| JC39-00612A | HARNESS-DADF_CLUT;SCX-6345N,CBF,UL1061,6 |
| JC39-00646A | HARNESS-DEVE_RF;SCX-6345N,CBF,UL1061,14, |
| JC39-00474A | HARNESS-DUPLEX;SCX-6345N,CBF,UL1061,11,3 |
| JC39-00468A | HARNESS-DUPLX_MAN;SCX-6345N,CBF,UL1061,1 |
| JC39-00471A | HARNESS-EXIT;SCX-6345N,CBF,UL1061,8,3,2, |
| JC39-00551A | HARNESS-FUSER_AC;SCX-6345N,CBF,UL3122,1P |
| JC39-00546A | HARNESS-FUSER_FR;SCX-6345N,CBF,UL3122/UL |
| JC39-00618A | HARNESS-FUSER_FU;SCX-6345N,CBF,UL3122,2, |
| JC39-00463A | HARNESS-GATE_NEAR;SCX-6345N,CBF,UL1061,3 |
| JC39-00469A | HARNESS-HVPS_IH;SCX-6345N,CBF,UL1061,28, |
| JC39-00611A | HARNESS-IH_AC;SCX-6345N,CBF,UL1617,2,250 |
| JC39-00673A | HARNESS-JSCRIBE;SCX-6345N,CBF,UL1061,4P, |
| JC39-00555A | HARNESS-LSU;SCX-6345N,CBF,UL1061,18P(14P |
| JC39-00477A | HARNESS-MOTOR_SW;SCX-6345N,CBF,UL1061,2, |
| JC39-00610A | HARNESS-POWER_SW;SCX-6345N,CBF,UL1617/UL |
| JC39-00459A | HARNESS-SCAN;SCX-6345N,CBF,UL1061,22,125 |
| JC39-00557A | HARNESS-SCAN_IF;SCX-6345N,CBF,UL2835,16, |
| JC39-00462A | HARNESS-SCF_EMPTY;SCX-6345N,CBF,UL1061,8 |
| JC39-00472A | HARNESS-SCF_MAIN;SCX-6345N,CBF,UL1061,11 |
| JC39-00460A | HARNESS-SMPS;SCX-6345N,CBF,UL1061,28,325 |
| JC39-00543A | HARNESS-SPK_MP;SCX-6345N,CBF,UL1061,7,3, |
| JC39-00467A | HARNESS-TRAY_SIZE;SCX-6345N,CBF,UL1061,1 |
| JC39-00615A | HARNESS-VARISTOR;SCX-6345N,CBF,UL1007,2P |
| JC59-00026A | HDD-DISC_HARD;40G,0.37IN,0.37*3.94*2.75 |
| 3711-004487 | HEADER-BOARD TO BOARD;BOX,80P,2R,0.8MM,S |
| 3711-000255 | HEADER-BOARD TO CABLE;1WALL,5P,1R,2.5MM, |
| 3711-002812 | HEADER-BOARD TO CABLE;BOX,11P,1R,2MM,STR |
| 3711-002813 | HEADER-BOARD TO CABLE;BOX,12P,1R,2MM,STR |
| 3711-004909 | HEADER-BOARD TO CABLE;BOX,14P,2R,2MM,ANG |
| 3711-003035 | HEADER-BOARD TO CABLE;BOX,14P,2R,2MM,STR |
| 3711-003340 | HEADER-BOARD TO CABLE;BOX,16P,2R,2MM,STR |
| 3711-002000 | HEADER-BOARD TO CABLE;BOX,18P,2R,2MM,STR |
| 3711-002001 | HEADER-BOARD TO CABLE;BOX,20P,2R,2MM,STR |
| 3711-002002 | HEADER-BOARD TO CABLE;BOX,22P,2R,2MM,STR |
| 3711-003981 | HEADER-BOARD TO CABLE;BOX,28P,2R,2MM,STR |
| 3711-003408 | HEADER-BOARD TO CABLE;BOX,2P,1R,2MM,STRA |
| 3711-003968 | HEADER-BOARD TO CABLE;BOX,3P,1R,2.5MM,ST |
| 3711-003409 | HEADER-BOARD TO CABLE;BOX,3P,1R,2MM,STRA |
| 3711-003411 | HEADER-BOARD TO CABLE;BOX,5P,1R,2MM,STRA |
| 3711-002807 | HEADER-BOARD TO CABLE;BOX,6P,1R,2MM,STRA |
| 3711-002809 | HEADER-BOARD TO CABLE;BOX,8P,1R,2MM,STRA |
| JC61-00729A | HINGE-M-HOUSING;SCX-6320F,DELRIN 100P,WH |
| JC61-01422A | HOLDER-M_ACT READY;SCX-6345N/XRX,PC,T2,W |
| JC61-01335A | HOLDER-M_ACTUATOR DP;SCX-6345N/XRX,PC,T1 |
| JC61-01421A | HOLDER-M_ACT_FEED;SCX-6345N/XRX,PC,T2,W1 |
| JC61-01288A | HOLDER-M_IDLE ONE WAY;SCX-6345N/XRX,POM, |
| JC61-01406A | HOLDER-M_LIU;SCX-6345N/XRX,ABS,T2.5,W80, |
| JC61-01341B | HOUSING-BASE RIGHT;SCX-6345N/XRX,ABS,3.0 |
| JC61-01343A | HOUSING-M_SIZE SENSOR;SCX-6345N/XRX,ABS, |
| JC61-01752A | HOUSING-WTB;SCX-6345N/XRX,HIPS,W211.13,L |
| JC44-00103A | HVPS-JUNGFRAU;24V,21.6V~27.6V,MAX 5KV,MI |
| JC13-00032A | IC ASIC-CIP40;S4L9335X,SCX-6345N,28P,3.3 |
| JC13-00020A | IC ASIC-ENGINE CONTROL;LPEC1,CLP-500,128 |
| JC13-00028A | IC ASIC-SPGPV3;SPGPV3,ML-2550_VE,496PIN, |
| JC11-00019B | IC MASK ROM;SCX-6345N,TP,5MS,0,RF ID TAG |
| 1001-000170 | IC-ANALOG SWITCH;MC14051BD,SPDT CMOS,SOP |
| 1106-001457 | IC-ASYNC SRAM;K6F1008U2C,128KX8BIT,TSOP, |
| 1106-001228 | IC-ASYNC SRAM;K6R1016V1D,1MBIT,64KX16,TS |
| 1201-000105 | IC-AUDIO AMP;34119,SOP,8P,150MIL,SINGLE, |
| 0904-001987 | IC-BUS CONTROLLER;SII0680A,32BIT,LQPF,14 |
| 1205-002339 | IC-CLOCK GENERATOR;CY25811SC,SOIC,8P,150 |
| 0803-003263 | IC-CMOS LOGIC;74LCX07,HEX BUFFER,SOIC,14 |
| 0801-002446 | IC-CMOS LOGIC;74LCX14,SCHMITT INVERTER,T |
| 0801-002379 | IC-CMOS LOGIC;74LCX16245,TRANSCEIVER,TSS |
| 0801-002095 | IC-CMOS LOGIC;74LCX245,TRANSCEIVER,TSSOP |
| 0801-002326 | IC-CMOS LOGIC;74LCX32,OR GATE,TSSOP,14,1 |
| 0801-002449 | IC-CMOS LOGIC;74LVX4245,BUS TRANSCEIVER, |
| 0801-000794 | IC-CMOS LOGIC;7S08,AND GATE,SC-70,5P,2.0 |
| 1203-003739 | IC-DC/DC CONVERTER;MVPG31,DFN,12P,4X3MM, |
| 1105-001384 | IC-DRAM;K4S561632,256MBIT,4X4MX16,TSOP(I |
| 1105-001379 | IC-DRAM;K4S561632,256MBIT,4X4MX16,TSOP(I |
| 1105-001351 | IC-DRAM;K4S561632,SDR,256MBIT,16MX16BIT, |
| 1103-001321 | IC-EEPROM;24WC128,128KBIT,16KX8,SOP,8P,5 |
| 1107-001475 | IC-FLASH MEMORY;29LV320,32MBIT,4MX8/2MX1 |
| 1006-001151 | IC-LINE TRANSCEIVER;90LV019,SOP,14P,157M |
| 0903-001355 | IC-MICROCONTROLLER;S3C2510A,32BIT,BGA,41 |
| 0903-001411 | IC-MICROCONTROLLER;S3F443FX,LQFP,64P,12X |
| 0902-001613 | IC-MICROPROCESSOR;S3C44B0X01-EDR0,66MHZ, |
| 1003-001732 | IC-MOTOR DRIVER;A3953SLBTR,SOIC,16P,10.1 |
| 1003-001535 | IC-MOTOR DRIVER;A3977SLP,TSSOP,28P,9.6X4 |
| 1003-001848 | IC-MOTOR DRIVER;SLA7066M-LF2102,ZIP,21P, |
| 1107-001590 | IC-NOR FLASH;S29GL064M,64MBIT,8MX8/4MX16 |
| 1201-000167 | IC-OP AMP;358,SOP,TP,8P,150MIL,DUAL,100V |
| 1203-003700 | IC-POSI.ADJUST REG.;LD1117ADT-R,DPAK,3P, |
| 1203-001455 | IC-POSI.FIXED REG.;1117,DPAK,3P,265MIL,P |
| 1203-002454 | IC-POSI.FIXED REG.;1117,TO-252,3P,257MIL |
| 1203-000259 | IC-POSI.FIXED REG.;7818,TO-220IS,3P,-,PL |
| 1202-000164 | IC-VOLTAGE COMP.;393,SOP,8P,150MIL,DUAL, |
| JB70-00168A | ICT-PIN ADF;SCX-1110F,STS303,L10.0,D2.0 |
| JG70-40534A | ICT-SPRING CLUTCH;SF5500,STC-5,T0.3 |
| 2703-002539 | INDUCTOR-SMD;6.8UH,20%,6965 |
| JC70-00195A | IPR-BRACKET SENSOR;ML-7250,SECC,1.0T |
| JC70-00239A | IPR-CHANNEL BASE FRAME;SCX-5100,SECC,T1. |
| JC70-10232D | IPR-E-PLATE SAW(MCK2);SCX-6320F,SUS304CS |
| JC70-11028A | IPR-GROUND TOP;ML-6000,SUS304CSP3/4H,T0. |
| JC70-00218A | IPR-GUARD C/O S/W;SCX-5100,SUS301CSP,0.2 |
| JB70-00148A | IPR-HOLDER GLASS;SCX-1110/XRX,SUS304,12* |
| JC70-00064A | IPR-PIN ROLLER EXIT;SUS304,SF-5100,L23,P |
| JC70-00192A | IPR-PLATE SENSOR;ML-7250,SUS301,0.2T |
| JC70-00111A | IPR-SPRING MIRROR (A);ML-5200A,STSC301-C |
| JF70-10616A | IPR-WASHER SPRING CU;CF3400,SUS301-CSP,T |
| 3722-001319 | JACK-MODULAR;8P/8C,STANDARD,Y,ANGLE,INVE |
| 3722-002303 | JACK-USB;4P/1C,AU30U,BLK,ANGLE,B TYPE |
| JC72-00621A | JOINT-COUPLING_CONTAINER;POM,DELIN100P,1 |
| JC66-00976A | JOINT-M_RETARD;SCX-6345N/XRX,POM,T1.2,18 |
| JC64-00291A | KEY-CONTRAST;SCX-6345N,ABS,34.6*34.6*12. |
| JC64-00288A | KEY-HOOK;SCX-6345N,ABS HB,70*20*15,HB,DA |
| JC64-00287A | KEY-JOB_STATUS;SCX-6345N,ABS,16*22*9,HB, |
| JC64-00289A | KEY-STOP;SCX-6345N,HIPS HB,25*25*10,HB,S |
| JB68-00916A | LABEL RATING-BLANK;SF-340,SEC,TETRON,0.0 |
| JC68-01584A | LABEL(P)-BLANK 90*25;CLP-510,SEE,ART 100 |
| JC68-10932A | LABEL(P)-BLANK(ML);ML-85,ART,G100,WHT,CO |
| JC68-00780A | LABEL(P)-CAUTION PRINTING;COMMON,WHITE P |
| JB68-00073A | LABEL(R)-BAR CODE;SF-3000,PY,T0.5,6.5,34 |
| JC68-00573A | LABEL(R)-BARCODE;ML-4500,PET,T0.05,20MM, |
| JC68-01621A | LABEL(R)-MAX FILL;SCX-6345N/XRX,XEROX,PC |
| JC66-02071A | LATCH-BOX;CLX-6200FX,PP,1.8,81.7,68.4,WH |
| JC66-00958A | LATCH-M_ARM FRT;SCX-6345N/XRX,POM,T1.5,3 |
| JC07-00010A | LCD-DISPLAY+TOUCH;SP21H002-Z1A,SCX-6345N |
| 0601-001332 | LED;CBI,GRN,2.9MM,567NM |
| 0601-001619 | LED;CBI,RED/GRN,3MM,635/568NM,6.35X7X6MM |
| 0601-002131 | LED;ROUND,RED,5MM,633NM,5.0X8.6MM |
| 0601-001226 | LED;SMD(TOP VIEW),RED,1.2X0.8MM,660NM,1. |
| JC61-01391A | LEG-M LIMIT STACKING;SCX-6345N/XRX,PC,BL |
| JC61-01426A | LEG-M_ACT FEED BASE;SCX-6345N/XRX,POM,BL |
| JC61-01435A | LEG-M_ACT READY DP;SCX-6345N/XRX,PC,V0,B |
| JC61-01336A | LEG-M_ACTUATOR DUPLEX;SCX-6345N/XRX,PC,V |
| JC61-01408A | LEG-M_ACTUATOR REGI;SCX-6345N/XRX,POM,BL |
| JC67-00209A | LENS-STATUS;SCX-6345N,PMMA,MILKY WHITE,1 |
| JC66-00959A | LEVER-M_ARM FRICTION;SCX-6345N/XRX,POM M |
|
|
LOCKER-M_FRONT;SCX-6345N/XRX,POM,BLACK,H |
| JC64-00199A | LOCKER-M_REAR;SCX-6345N/XRX,POM,BLACK,HB |
|
|
LSU;SCX-6345N,SEC,SEE,45,600DPI,DUAL BEA |
| JC97-02702A | MEA UNIT-ACT FEED;SCX-6345N,XEROX,-,-,- |
| JC97-02704A | MEA UNIT-ACT READY;SCX-6345N,XEROX,GB,-, |
| JC97-02703A | MEA UNIT-ACT REGI;SCX-6345N,XEROX,GB,-,- |
| JC97-02272A | MEA UNIT-CARBON BRUSH;SCX-6345N/XRX,XERO |
|
|
MEA UNIT-CASSETTE;SCX-6345N/XRX,SEC,-,CA |
|
|
MEA UNIT-CLAW;SCX-6345N/XRX,XEROX |
| JC97-03568A | MEA UNIT-COVER FRONT NJ;SCX-6345NJ,SEC,- |
| JC97-01844C | MEA UNIT-COVER OPEN;SCX-6345N,SEC,SEC,-, |
| JC97-02374B | MEA UNIT-COVER REAR;SCX-6345N/XRX,SEC,-, |
| JC97-02258B | MEA UNIT-COVER TOP;SCX-6345N/XRX,SEC,-,C |
| JC97-02274B | MEA UNIT-COVER UPPER;SCX-6345N/XRX,SEC,- |
| JC97-02301A | MEA UNIT-DAMPER,L;SCX-6345N/XRX,XEROX,DA |
| JC97-02267B | MEA UNIT-DUMMY UPPER;SCX-6345N,SEC,SEC,- |
|
|
MEA UNIT-F DR;SCX-6345N/XRX,XEROX,-,F DR |
| JC97-02705A | MEA UNIT-FEED IDLE MP;SCX-6345N,XEROX,-, |
|
|
MEA UNIT-GEAR SUPPLY;SCX-6345N/XRX,XEROX |
|
|
MEA UNIT-GUIDE DUPLEX;SCX-6320F,XEROX,US |
| JC97-02293A | MEA UNIT-GUIDE SCAN;SCX-6345N/XRX,XEROX, |
| JC97-01847A | MEA UNIT-GUIDE_PICK_UP;SCX-6320F,XEROX,- |
|
|
MEA UNIT-HINGE JF;SCX-6345N/XRX,XEROX,-, |
|
|
MEA UNIT-HINGE;SCX-6345N/XRX,XEROX,-,HIN |
|
|
MEA UNIT-HOLDER ADF RUBBER;SCX-6320F,XER |
| JC97-02276A | MEA UNIT-HOLDER HDD;SCX-6345N/XRX,XEROX, |
|
|
MEA UNIT-HOLDER PAD;SCX-6345N/XRX,XEROX, |
| JC97-02836A | MEA UNIT-LIFTING GEAR;SCX-6345N,SEC,-,-, |
| JC97-02618A | MEA UNIT-MAGNET PLATE;SCX-6345N/XRX,XERO |
|
|
MEA UNIT-PICK UP_JF;SCX-6345N/XRX,XEROX, |
| JC97-02262A | MEA UNIT-REGI F;SCX-6345N/XRX,XEROX,-,RE |
| JC97-02261A | MEA UNIT-REGI R;SCX-6345N/XRX,XEROX,-,RE |
| JC97-02290A | MEA UNIT-RETARD;SCX-6345N/XRX,XEROX,-,RE |
|
|
MEA UNIT-ROLLER HEAT;SCX-6345N/XRX,XEROX |
| JC97-02283A | MEA UNIT-ROLLER PR;SCX-6345N/XRX,XEROX,- |
|
|
MEA UNIT-ROLLER PU;SCX-6345N/XRX,XEROX,- |
| JC97-02279A | MEA UNIT-SUPPORT PU;SCX-6345N/XRX,XEROX, |
| JC97-02278A | MEA UNIT-SUPPORT SCAN;SCX-6345N/XRX,XERO |
| JC97-02375A | MEA UNIT-TR SUB;SCX-6345N/XRX,XEROX,-,-, |
|
|
MEA UNIT-TR;SCX-6345N/XRX,XEROX,-,TR,-,- |
|
|
MEA UNIT-TRAY;SCX-6345N/XRX,SEC,-,TRAY,- |
| JC97-02266B | MEA UNIT-TX STACKER;SCX-6345N,SEC,SEC,-, |
| JC97-02687A | MEA-ACTUATOR_DUPLEX;SCX-6345N/XRX,XEROX, |
| JC97-02680A | MEA-BRACKET FUSER;SCX-6345N/XRX,XEROX,-, |
| JC97-02730A | MEA-GEAR REGI IDLE A;SCX-6345N,XEROX,-,- |
|
|
MEC-ADF ROLLER ASSY;SCX-1110F/XRX,XEROX, |
|
|
MEC-PICK UP ROLLER ASSY;SCX-1110F/XRX,XE |
| JC31-00038A | MOTOR DC-MAIN(BLDC);50M843A020,1925RPM,D |
| JC31-00066A | MOTOR DC;-,35000,-,24V,0.85A,-,3500HZ,MA |
| JC31-00015B | MOTOR DC;24V,SCX-6345N,WORM(POM) |
| JC31-00045A | MOTOR GEARED-P LIFT;2.1RPM,1.5N.M,1/1513 |
| JC31-00044A | MOTOR STEP-DADF;STP-42D 2077,SCX-6345N/X |
| JC31-00020B | MOTOR STEP-MAIN;M49SP-2K,SCX-5315F,1.18A |
| JC31-00043A | MOTOR STEP-SCAN;M42SP-4K,SCX-6345N/XRX,6 |
| JC31-00048B | MOTOR STEP;M42SP-4NK,SCX-6245N,0.6A,2158 |
| JC74-10901A | MPR-WASHER SUPPLY;POLY,ID4.1*OD11*T0.13, |
|
|
OTHER MECHA-M CPL OPC;SCX-6345N/XRX,POM, |
| JC67-00122A | OTHER MECHA-M GATE DP;SCX-6345N/XRX,PC+G |
|
|
PAD-MP(PLUS);EPU,SCX-5315F,0.9T,W31*L11. |
| JC92-01698A | PBA ETC-HDD;SCX-6345N,XEROX,USA,-,-,-,65 |
| JC92-01758A | PBA ETC-LCD_INVERTER;SCX-6345N,XEROX,24V |
| JC92-01690D | PBA MAIN-MFP;SCX-6345N,IBM,EXPORT,-,-,-, |
| JC92-01568A | PBA SUB-AIR_TMP;SCX-6320F,XEROX,USA,AIR |
| JC92-01336A | PBA SUB-CASSETTE;ML-1650,KOREA/EXPORT,-, |
|
|
PBA SUB-DADF;SCX-6345N,XEROX,USA,-,-,-,1 |
| JC92-01543A | PBA SUB-DIMM MODULE;CLP-500,KOREA,KOREA, |
| JC92-01564A | PBA SUB-EXIT_OPEN;SCX-6320F,XEROX,USA,EX |
|
|
PBA SUB-LENGTH;SCX-6320F,XEROX,USA,LENGT |
| JC92-01561A | PBA SUB-REGI;SCX-6320F,XEROX,USA,REGI SE |
| JC92-01695A | PBA SUB-SCAN_IF;SCX-6345N,XEROX,USA,-,-, |
| JC92-01725A | PBA SUB-SENSOR_IF;SCX-6345N,XEROX,USA,-, |
| JC92-01693B | PBA-OPE_KEY;SCX-6345N,SAMSUNG,USA,-,-,-, |
| JC92-01694B | PBA-OPE_KEY_SUB;SCX-6345N,SAMSUNG,USA,-, |
| JC92-01692C | PBA-OPE_MAIN;SCX-6345N,IBM,EXPORT,-,-,-, |
| JC92-01862A | PBA-RFID;SCX-6345N,-,-,-,-,-,-,25.1 X 63 |
| 0604-001227 | PHOTO-INTERRUPTER;TR,200MW,DIP-4,ST |
|
|
PHOTO-INTERRUPTER;TR,75MW,BGA,TR |
|
|
PHOTO-INTERRUPTER;TR,90%,150MW,DIP-4,BK |
| 6043-001028 | PIN-SPRING;W,OD2,L12,BLK,STS304 |
| JC61-01295A | PLATE-M_FEED UPPER;SCX-6345N/XRX,ABS ,T2 |
| JC61-00819A | PLATE-P-DUMMY PLATEN;SCX-6320F,SECC,T1.0 |
| JC61-01322A | PLATE-P-LEVER;SCX-6345N/XRX,SECC,T1.6,40 |
| JC61-01329A | PLATE-P-OPE;SCX-6345N/XRX,SECC,T0.8,274. |
| JC61-01635A | PLATE-P_LCD;SCX-6345N/XRX,SUS304,T0.3,23 |
| JC72-01248A | PMO-ACTUATOR DOC;SCX-6320F,ABS+GF10%,HB, |
| JC72-01263A | PMO-ACTUATOR DUPLEX;SCX-6320F,ABS+GF10%, |
|
|
PMO-ACTUATOR LENGTH;SCX-6322DN,ABS+GF10% |
| JC72-01249A | PMO-ACTUATOR SCAN;SCX-6320F,ABS+GF10%,HB |
| JB72-00821A | PMO-ADF COLAR;SCX-1110F,POM,NTR |
|
|
PMO-BUSHING_TR(L);SF-5100,POM (CH-15),BL |
| JC72-00743A | PMO-DEV/COUPLING;SCX-5100,DE8903,BLK |
| JC72-01255A | PMO-GATE DUPLEX;SCX-6320F,PC+GF10%,BLK |
| JF72-41354A | PMO-GEAR PINION;CF4500,POM,NTR+WHT(DELRI |
| JC72-00444A | PMO-HOLDER COLLIMATOR;ML-1710,PC,TRANSPA |
| JC72-00884A | PMO-HOLDER GEAR TR;SCX-5312F,PC+ABS,EMBE |
| JC72-00883A | PMO-HOLDER GND TR;SCX-5312F,PC+ABS,EMBER |
| JC72-00825A | PMO-IMPELLER_DRV;ML-6200,NYLON66,V0,BLK |
| JC72-00755A | PMO-LEVER SENSOR;SCX-5100,POM,HB,BLK |
| JC72-01300B | PMO-M_LOCKER DEVE;SCX-6345N,PC+ABS,ICE G |
| JB72-00845A | PMO-PICK UP CLUTCH SUB;SCX-1110F,POM(DE8 |
| JB72-00763A | PMO-PULLEY;SCX-1110/XRX,POM,WHT |
|
|
PMO-ROLL PINCH;SF5500,POM(DERLIN 500P),H |
| JC72-00906A | PMO-ROLLER IDLE SCAN;SF-830,POM,ROLLER I |
| JC72-00744A | PMO-SHAFT PICK UP;SCX-5150,ABS,BLK,HB |
| JB72-00822A | PMO-SLEEVE ADF;SCX-1110F,POM,BLK |
| JB72-00823A | PMO-SLEEVE PICK UP;SCX-1110F,POM,BLK |
| JC72-41396B | PMO-STOPPER EXIT;SF-5100,NYLON,HYTREL(72 |
| JC72-01254B | PMO-TX STACKER LOWER;SCX-6322DN,HIPS,273 |
| JC72-01253B | PMO-TX STACKER;SCX-6322DN,HIPS,322.0*200 |
| JC66-00971A | PULLEY-M_DUPLEX;SCX-6345N/XRX,POM,HB,BLA |
| 2001-000281 | R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM |
| 2001-000362 | R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3.2MM |
| 2007-000033 | R-CHIP;0OHM,5%,1/4W,TP,3216 |
| 2007-000122 | R-CHIP;1.2KOHM,5%,1/10W,TP,1608 |
| 2007-000123 | R-CHIP;1.5KOHM,5%,1/10W,TP,1608 |
| 2007-000079 | R-CHIP;1.8KOHM,5%,1/10W,TP,1608 |
| 2007-000102 | R-CHIP;100KOHM,5%,1/10W,TP,1608 |
| 2007-000287 | R-CHIP;100OHM,1%,1/10W,TP,1608 |
| 2007-000074 | R-CHIP;100OHM,5%,1/10W,TP,1608 |
| 2007-000293 | R-CHIP;100OHM,5%,1/4W,TP,3216 |
| 2007-000052 | R-CHIP;10KOHM,1%,1/10W,TP,1608 |
| 2007-000090 | R-CHIP;10KOHM,5%,1/10W,TP,1608 |
| 2007-000309 | R-CHIP;10OHM,5%,1/10W,TP,1608 |
| 2007-002901 | R-CHIP;12.1KOHM,1%,1/10W,TP,1608 |
| 2007-000103 | R-CHIP;120KOHM,5%,1/10W,TP,1608 |
| 2007-007613 | R-CHIP;121OHM,1%,1/10W,TP,1608 |
| 2007-000104 | R-CHIP;150KOHM,5%,1/10W,TP,1608 |
| 2007-000402 | R-CHIP;150OHM,5%,1/10W,TP,1608 |
| 2007-000403 | R-CHIP;150OHM,5%,1/4W,TP,3216 |
| 2007-000067 | R-CHIP;15KOHM,1%,1/10W,TP,1608 |
| 2007-000092 | R-CHIP;15KOHM,5%,1/10W,TP,1608 |
| 2007-008505 | R-CHIP;17.8KOHM,1%,1/10W,TP,1608 |
| 2007-000132 | R-CHIP;180KOHM,5%,1/10W,TP,1608 |
| 2007-000043 | R-CHIP;1KOHM,1%,1/10W,TP,1608 |
| 2007-000078 | R-CHIP;1KOHM,5%,1/10W,TP,1608 |
| 2007-000109 | R-CHIP;1MOHM,5%,1/10W,TP,1608 |
| 2007-000124 | R-CHIP;2.2KOHM,5%,1/10W,TP,1608 |
| 2007-007803 | R-CHIP;2.37KOHM,1%,1/10W,TP,1608 |
| 2007-007507 | R-CHIP;2.74KOHM,1%,1/10W,TP,1608 |
| 2007-000105 | R-CHIP;200KOHM,5%,1/10W,TP,1608 |
| 2007-000093 | R-CHIP;20KOHM,5%,1/10W,TP,1608 |
| 2007-000106 | R-CHIP;220KOHM,5%,1/10W,TP,1608 |
| 2007-000075 | R-CHIP;220OHM,5%,1/10W,TP,1608 |
| 2007-000094 | R-CHIP;22KOHM,5%,1/10W,TP,1608 |
| 2007-000071 | R-CHIP;22OHM,5%,1/10W,TP,1608 |
| 2007-000616 | R-CHIP;24KOHM,5%,1/10W,TP,1608 |
| 2007-000637 | R-CHIP;270KOHM,5%,1/10W,TP,1608 |
| 2007-000669 | R-CHIP;2KOHM,1%,1/10W,TP,1608 |
| 2007-007550 | R-CHIP;3.16KOHM,1%,1/10W,TP,1608 |
| 2007-000082 | R-CHIP;3.3KOHM,5%,1/10W,TP,1608 |
| 2007-007525 | R-CHIP;3.4KOHM,1%,1/10W,TP,1608 |
| 2007-000125 | R-CHIP;3.9KOHM,5%,1/10W,TP,1608 |
| 2007-000096 | R-CHIP;30KOHM,5%,1/10W,TP,1608 |
| 2007-000133 | R-CHIP;330KOHM,5%,1/10W,TP,1608 |
| 2007-000076 | R-CHIP;330OHM,5%,1/10W,TP,1608 |
| 2007-000134 | R-CHIP;33KOHM,5%,1/10W,TP,1608 |
| 2007-000113 | R-CHIP;33OHM,5%,1/10W,TP,1608 |
| 2007-000839 | R-CHIP;39OHM,5%,1/10W,TP,1608 |
| 2007-000083 | R-CHIP;3KOHM,5%,1/10W,TP,1608 |
| 2007-000084 | R-CHIP;4.7KOHM,5%,1/10W,TP,1608 |
| 2007-000875 | R-CHIP;4.7KOHM,5%,1/4W,TP,3216 |
| 2007-000107 | R-CHIP;470KOHM,5%,1/10W,TP,1608 |
| 2007-000097 | R-CHIP;47KOHM,5%,1/10W,TP,1608 |
| 2007-007226 | R-CHIP;49.9OHM,1%,1/10W,TP,1608 |
| 2007-000965 | R-CHIP;5.1KOHM,5%,1/10W,TP,1608 |
| 2007-000086 | R-CHIP;5.6KOHM,5%,1/10W,TP,1608 |
| 2007-007611 | R-CHIP;56.2OHM,1%,1/10W,TP,1608 |
| 2007-001044 | R-CHIP;56OHM,5%,1/10W,TP,1608 |
| 2007-001056 | R-CHIP;6.2KOHM,5%,1/10W,TP,1608 |
| 2007-000120 | R-CHIP;680OHM,5%,1/10W,TP,1608 |
| 2007-001134 | R-CHIP;68OHM,5%,1/10W,TP,1608 |
| 2007-001179 | R-CHIP;8.2KOHM,5%,1/10W,TP,1608 |
| 2007-000121 | R-CHIP;820OHM,5%,1/10W,TP,1608 |
| 2007-000101 | R-CHIP;82KOHM,5%,1/10W,TP,1608 |
| 2011-001011 | R-NETWORK;10KOHM,5%,1/16W,L,CHIP,8P,TP,3 |
| 2011-000651 | R-NETWORK;10OHM,5%,1/16W,L,CHIP,8P,TP,32 |
| 2011-000660 | R-NETWORK;1KOHM,5%,1/16W,L,CHIP-V,8P,TP, |
| 2011-000002 | R-NETWORK;22OHM,5%,1/16W,L,CHIP,8P,TP,32 |
| 2011-001094 | R-NETWORK;39OHM,5%,1/16W,L,CHIP,8P,TP,3. |
| 2005-000168 | R-WIRE WOUND,NON;0.22OHM,5%,2W,AA,BK,4X1 |
| 6044-000159 | RING-C;ID3,OD7,T0.6,PASS,STSC |
| 6044-000001 | RING-CS;ID2.8,OD8,T0.25,BLACK,SK-5 |
| 6044-000121 | RING-E;ID2,OD5,T0.4,PASS,STSC |
| 6044-000125 | RING-E;ID4,OD9,T0.6,STSC |
| 6044-000231 | RING-E;ID5.0,OD11.0,T0.6,PASS,STS304 |
|
|
RMO-ADF RUBBER;SCX-1110F,SILICON RUBBER, |
|
|
ROLLER-DR REGI;SCX-6345N/XRX,EPDM,SUM22+ |
| JC66-00970A | ROLLER-DUPLEX READY;SCX-6345N/XRX,SUM22+ |
| JC66-00969A | ROLLER-DUPLEX;SCX-6345N/XRX,SUM22+EPDM60 |
| JC66-00588A | ROLLER-EXIT;SCX-6320F,SUM24L+EPDM,D17.38 |
| JC66-01028A | ROLLER-IDLE REGI;SCX-6345N/XRX,SUM 22+NI |
| JC66-01019A | ROLLER-M EXIT DP IDLE;SCX-6345N/XRX,POM, |
|
|
ROLLER-M IDLE JF;SCX-6345N/XRX,POM+PFPE, |
| JC66-01026A | ROLLER-MP DRV;SCX-6345N/XRX,EPDM+SUM22,O |
|
|
ROLLER-M_IDLE SCF;SCX-6345N/XRX,POM,OD14 |
| JC66-00585A | ROLLER-SCAN;ML-2150,SUM24L+EPDM,D17.38,2 |
| JC66-00998A | ROLLER-TONER FEED;SCX-6345N/XRX,SUS+U_FO |
|
|
ROLLER-TRANSFER;SCX-6345N/XRX,EPDM,OD18. |
| JC72-20902A | ROLLER;ML-5000A,TEFLON,WHT |
|
|
RPR-PAD CASSETTE;ML-1510,URETHANE SPONGE |
| JC73-00079A | RPR-SEAL SIDE;SCX-5100,URETHANE FOAM,NTR |
| JC73-00215A | RUBBER-DAMPER HDD;SCX-6345N/XRX,EPDM,7.5 |
| JC73-00235A | RUBBER-GUIDE MP;SCX-6345N/XRX,NBB,38*28. |
| JC73-00253A | RUBBER-JOB_START;SCX-6345N,SILICON,12.7, |
| JC73-00252A | RUBBER-JOB_STATUS;SCX-6345N,SILICON,14.4 |
| JC73-00216A | RUBBER-ROLLER PU;SCX-6345N/XRX,EPDM+IR 3 |
| 6001-000130 | SCREW-MACHINE;BH,+,M3,L6,ZPC(WHT),SWRCH1 |
| 6006-001193 | SCREW-MACHINE;PH,+,WSP,M3,L10,ZPC(WHT),S |
| 6002-000440 | SCREW-TAPPING;PWH,+,2,M3,L8,ZPC(BLK),SWR |
| 6002-000175 | SCREW-TAPPING;PWH,+,2,M3,L8,ZPC(WHT),SM2 |
|
|
SCREW-TAPTYPE;BH,+,-,B,M3,L12,ZPC(BLK),S |
|
|
SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW |
|
|
SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SW |
| 6003-001474 | SCREW-TAPTYPE;BH,+,B,M3,L30,ZPC(WHT),SWR |
|
|
SCREW-TAPTYPE;BH,+,B,M4,L16,NI PLT,SWRCH |
| 6003-000301 | SCREW-TAPTYPE;BH,+,S,M4,L6,ZPC(WHT),SWRC |
|
|
SCREW-TAPTYPE;FH,+,B,M3,L8,ZPC(BLK),SWRC |
| 6006-001078 | SCREW-TAPTYPE;PH,+,WSP,B,M3,L10,ZPC(WHT) |
| 6003-000264 | SCREW-TAPTYPE;PWH,+,-,B,M3,L6,ZPC(WHT),S |
| 6003-000266 | SCREW-TAPTYPE;PWH,+,-,S,M3,L6,ZPC(WHT),S |
| 6003-000221 | SCREW-TAPTYPE;PWH,+,-,S,M4,L8,ZPC(WHT),S |
| 6003-000196 | SCREW-TAPTYPE;PWH,+,B,M3,L10,NI PLT,SWRC |
| JC62-00327A | SEAL-COVER FRONT;SCX-6345N/XRX,POLYURETH |
| JC62-00302A | SEAL-LSU;SCX-6345N,TAPE,0.2,161.3,205.3 |
| JC62-00301A | SEAL-LSU;SCX-6345N,URETHANE,10,20,20 |
| JC66-01152A | SHAFT-CLEANING PR;SCX-6345N/XRX,SUM22 NI |
| JC66-00661A | SHAFT-EXIT IDLE;SCX-6320F,SUM24L,PI 3.95 |
| JC70-40914A | SHAFT-ICT-PIN P/UP SHAFT;ML-5000A,SUM24L |
|
|
SHAFT-PLATE LEVER;SCX-6345N/XRX,SUM22 NI |
| JC66-00662A | SHAFT-REGI;SCX-6320F,SUM24L,47.5,PI 6.0 |
| JC66-00937A | SHAFT-RETARD S;SCX-6345N/XRX,SUM22 NI,22 |
| JC66-00939A | SHAFT;SCX-6345N/XRX,SUS303,L8,OD2,NTR |
| JC63-00074A | SHEET-DUMMY UPPER;SCX-5312F,PET SHEET,0. |
| JC63-00186A | SHEET-GUIDE ADF;SCX-6320F,PET,0.125,37,2 |
| JC63-00795A | SHEET-GUIDE FILM BASE;SCX-6345N/XRX,PET, |
|
|
SHEET-GUIDE RETARD;SCX-6345N/XRX,PET,0.1 |
| JC63-01043A | SHEET-LCD;SCX-6345N/XRX,PET SHEET,0.125, |
| JC63-01114A | SHEET-LSU;SCX-6345N,PVC,0.3,15,25 |
| JC63-01242A | SHEET-PANEL;SCX-6345N/XEU,PC SHEET,0.254 |
| JC63-00810A | SHEET-WHITE BAR;SCX-6345N/XRX,PET,0.075, |
| JC72-00751A | SHEET;SCX-5100,SPONGE+SHEET,217.5*357.5, |
|
|
SMPS-PSP_TYPE5_V1;SCX-4521F,*,AC/DC,100V |
| JC33-00008C | SOLENOID-DUPLEX JF;SCX-6345N/XRX,24V,45O |
| 6045-001009 | SPACER-ROUND;ID6,OD10,T1.0,NTR,NYLON66,L |
| 3001-001858 | SPEAKER;0.3W,8OHM,81DB,400HZ,50X16.4MM |
| JC72-01415A | SPONGE-DAMPER GATE;SCX-6555N,SHL55+3M909 |
| JC72-01416A | SPONGE-DAMPER SOL;SCX-6555N,SHL55+3M9096 |
| JC72-01444A | SPONGE-GUIDE CHANGE DUP;ML-2851ND/XAA,PO |
| JC72-01542A | SPONGE-SIDE FAN;SCX-6255N,PORON,2.0T,10, |
| JB61-70904A | SPRING ETC-CLUTCH;AMUNDSEN,SWRS82A,D11.4 |
| JC61-00062A | SPRING ETC-CLUTCH;ML-4500,SWP,7.8,21 |
| JC61-00396A | SPRING ETC-COIL CONTAINER;ML-9400W,SUS30 |
| JC61-01563A | SPRING ETC-DUP IDLE;SCX-6345N/XRX,SUS304 |
| JC61-70950A | SPRING ETC-EXTENSION;ML-5000A,SUS304WPB |
| JC61-70930A | SPRING ETC-HV SMALL;ML-5000A,PI0.3,L12.5 |
| JC61-00483A | SPRING ETC-KNOCKUP,MP;SCX-5100,SUS304-WP |
| JC61-00479A | SPRING ETC-LOCKER TORSION;SCX-5100,SUS30 |
| JC61-00387A | SPRING ETC-PAD;ML-9400W,SUS304WPB,PI0.5, |
|
|
SPRING ETC-PICKUP;SCX-5100,SUS304-WPB,PI |
| JC61-70203A | SPRING ETC-PLATE TR;SL-1050,SUS304CSP-3/ |
| JC61-70910A | SPRING ETC-RAIL;ML-165,SUS304 WPB,D5.4,L |
| JC61-70915A | SPRING ETC-SOLENOID DP;ML-165,SUS304-WPB |
| JC61-70959A | SPRING ETC-SPRING ETC FEED;ML-5000A,SUS3 |
|
|
SPRING ETC-TORSION DOC (CC2-F);SCX-1110F |
| JC61-00486A | SPRING ETC-TORSION;SCX-5100,SUS304WPB,0. |
| JC61-70967A | SPRING ETC-TR R;ML-5000A,SUS304 WPB,D4.5 |
| JC61-70906A | SPRING ETC-TR_R;ML-165,SUS304WPB,PI0.5,O |
| JC61-00548A | SPRING ETC-WHITE BAR;SCX-5312F,SUS304WPB |
| 6107-000117 | SPRING-CS;PI0.7,D12.4,L29,DEGRE,STS304-W |
| 6107-001135 | SPRING-CS;SUS304 WPB,PI0.3,L14,ID5.4,OD6 |
|
|
SPRING-CS;SUS304,PI0.5,D6.7,L17.5,ID6.2, |
| 6107-000014 | SPRING-CS;SUS304-WPB,PI0.55,D6.9,L14 |
| 6107-001219 | SPRING-CS;SWOSC-V,PI3.2,D12.4,L55.8,ID9. |
| 6107-001194 | SPRING-CS;SWP-B,BLK,PI0.9,D6.95,L20,ID6. |
| 6107-001291 | SPRING-ES;SUS304-WPB,NTR,PI0.12,D2.48,L8 |
|
|
SPRING-ES;SUS304-WPB,NTR,PI0.32,D3.88,L1 |
| 6107-001258 | SPRING-ES;SUS304-WPB,PI0.55,D4.25,L37.5, |
| 6107-001257 | SPRING-ES;SUS304-WPB,PI1.2,D10,L44.2,ID8 |
| 6107-001315 | SPRING-ES;SWP-B,PI0.3,D2.8,L40,ID2.5,OD3 |
| 6107-001259 | SPRING-ES;SWP-B,PI0.35,D4.25,L33.8,ID3.9 |
| 6107-001155 | SPRING-ES;SWP-B,PI0.55,L25,OD4.4 |
| 6107-001261 | SPRING-TS;SUS304-WPB,PI0.35,D5.15,L12/12 |
| 6107-001540 | SPRING-TS;SWP B,PI0.5,D3.55,L12.93/6.5,W |
|
|
STOPPER-M-FAN80;ML-2150,ABS HB,26.4,BLAC |
| JC61-00832B | STOPPER-M_KNOCK UP;CLP-510,HIPS HB,24,VI |
| 6103-000101 | SUPPORTER;DALS-10N,H10,NTR,NYLON66 |
| 3404-000165 | SWITCH-TACT;12V,50MA,160GF,6X6X5,SPST |
| 0203-001100 | TAPE-OPP MASKING;OPP/W75/CLR,T0.075,W75, |
| JC65-00012A | TERMINAL-S_IDLE;SCX-6345N/XRX,SUS304WPB, |
| JC02-00058A | TONER-JF;SCX-6345N,BLACK,8.5UM,-7~-19UQ/ |
| 0506-001069 | TR-ARRAY;MBT3904DW1T1,NPN,DUAL,150MW,SOT |
| 0502-000245 | TR-POWER;KSB1151-Y,PNP,1300MW,TO-126,160 |
| 0502-001048 | TR-POWER;KSD1691,NPN,1.3W,TO-126,BK,160 |
| 0501-000632 | TR-SMALL SIGNAL;2SB1197K,PNP,200MW,SOT-2 |
| 0504-000144 | TR-SMALL SIGNAL;2SC1008,NPN,800MW,TO-92, |
| 0501-000279 | TR-SMALL SIGNAL;KSA1182-Y,PNP,150MW,SOT- |
| 0501-000294 | TR-SMALL SIGNAL;KSA708-Y,PNP,800MW,TO-92 |
| 0501-000342 | TR-SMALL SIGNAL;KSC1623-Y,NPN,200MW,SOT- |
| 0501-000457 | TR-SMALL SIGNAL;MMBT2222A/KST2222A,NPN,3 |
| JC63-00447E | TRAY-M-ASF_FOLDER;ML-3051ND,HIPS,2.5,235 |
| 1405-000188 | VARISTOR;560V,2500A,14X8.5MM,TP |
| 6031-000023 | WASHER-PLAIN;POLY,ID5.9,OD10.0,T0.5,BLK |
| 6031-000019 | WASHER-PLAIN;POLY,ID6.1,OD8.5,T0.1,BLK |
| 6031-001584 | WASHER-PLAIN;POLYSLIDER,ID4,OD7,T0.5,BLA |
