Manufacturer
Samsung
Model Number
SCX4200
Description
Laser Multifunction Printer
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| JC70-00304A | ADJUST RACK-M-MANUAL: ML-1400,POM(M90-44) |
| JC70-00300A | ADJUST-M-CASSETTE_L: ML-1400,ABS,-,BL |
| JC70-00301A | ADJUST-M-CASSETTE_R: ML-1400,ABS,-,BL |
| JC70-00476B | ADJUST-M_MANUAL_L: SCX-4200,HIPS HB(HR-13 |
| JC70-00477B | ADJUST-M_MANUAL_R: SCX-4200,HIPS HB(HR-13 |
|
|
BEARING-PRESSURE/R: ML-165,PPS,5,14.8 |
| JC69-00932A | BOX(P)-MAIN: SCX-4200/XAA,DW,OFFSET4,321, |
| JC61-01640A | BRACKET MOTOR-P-SCAN: SCX-4200,SECC,T1.0, |
| JC61-01646A | BRACKET-M-CIS: SCX-4200,PC/ABS,2.0,28.67, |
| JC61-00602A | BRACKET-P-FEED: ML-1400,SECC,1,-,- |
| JC61-00598B | BRACKET-P-GEAR 1400: SCX-4200,SECC+SUM24L |
| JC61-00601A | BRACKET-P-INLET: ML-1400,SECC,1,128,23, |
| JC61-00585A | BUSH-M-FEED IDLE: ML-1400,POM(M90-44),- |
|
|
BUSH-M-HR L: ML-1400,PPS,-,-,V0 |
|
|
BUSH-M-HR R: ML-1400,PPS(RBA313N, CONDUCT |
| JC61-00586A | BUSH-M-PICK_UP L: ML-1400,POM(M90-44),- |
| JC61-00587A | BUSH-M-PICK_UP R: ML-1400,POM(M90-44),- |
|
|
BUSH-M-TR L: ML-1400,POM(M90-44),-,BL |
| 2402-001178 | C-AL,SMD: 10UF,20%,16V,WT,TP,4.3X4.3X5.8 |
| 2401-000426 | C-AL: 10UF,20%,16V,WT,4*5MM,5MM,TP |
| 2401-002300 | C-AL: 47UF,20%,50V,GP,6X11MM,5MM,TP |
| 2402-000008 | C-ALUMINUM,SMD: 47UF,+-20%,16V,6.6X6.6X5. |
| 2203-000426 | C-CERAMIC,CHIP |
| 2203-000783 | C-CERAMIC,CHIP |
| 2203-000998 | C-CERAMIC,CHIP |
| 2203-000206 | C-CERAMIC,CHIP: 100NF,10%,50V,X7R,2012, |
| 2203-000257 | C-CERAMIC,CHIP: 10NF,10%,50V,X7R,1608,T |
| 2203-000357 | C-CERAMIC,CHIP: 150PF,5%,50V,CH,1608,TP |
| 2203-000384 | C-CERAMIC,CHIP: 15PF,5%,50V,CH,1608,TP |
| 2203-000440 | C-CERAMIC,CHIP: 1NF,10%,50V,X7R,1608,TP |
| 2203-002392 | C-CERAMIC,CHIP: 220NF,+80-20%,50V,Y5V,TP, |
| 2203-001607 | C-CERAMIC,CHIP: 220PF,5%,50V,CH,1608,1.6M |
| 2203-002398 | C-CERAMIC,CHIP: 22NF,10%,50V,X7R,TP,1608, |
| 2203-000626 | C-CERAMIC,CHIP: 22PF,5%,50V,CH,1608,TP |
| 2203-001683 | C-CERAMIC,CHIP: 68PF,5%,50V,CH,1608,1.6MM |
| JC66-00377A | CAM-M-PICK_UP: ML-1400,POM(M90-44),-,NT |
| JC67-00155A | CAP-M-LCD: SCX-4200,PC,T2.0,41.0,86.2,CLE |
| JC67-00156A | CAP-M-LED: SCX-4200,PMMA,T1.0,14.6,14.1,M |
| JC67-00158A | CAP-M-LSU: SCX-4200,HIPS,1.5T,-,- |
| JC39-00576A | CBF HARNESS-CRUM2: SCX-4200,CBF,UL1061,5P |
| JC39-00240A | CBF HARNESS-ENGINE: ML-1710,CBF,UL1061,26 |
| JC39-00404A | CBF HARNESS-FUSER JOINT |
| JC39-00306A | CBF HARNESS-LCD: CLP-500,WIRE,UL2877,14-1 |
| JC39-00242A | CBF HARNESS-LSU: ML-1710,#26,UL 1061,11PI |
| JC39-00241A | CBF HARNESS-MOTOR: ML-1710,CBF,UL 1061,4P |
| JB39-40532A | CBF HARNESS-OPE: SF3000,CBF,UL1007,100,Y/ |
| JC39-00243A | CBF HARNESS-PTL: ML-1710,CBF,UL 1061,2P,1 |
|
|
CBF SIGNAL-CIS FFC: SCX-4100,12PIN,FFC,68 |
| JC39-40511A | CBF-HARNESS: ML-80,JUMPER,AWG22,52MM,SILV |
|
|
CBF-POWER CORD: DT,US,BP3/YES,I(IEC C13/C |
| JB61-00232A | CLIP-P-BELT: SF-457,SUS,0.2,NTR,HALF HARD |
| 3708-001408 | CONNECTOR-FPC/FFC/PIC: 12P,1MM,STRAIGHT,S |
| 3711-003968 | CONNECTOR-HEADER: BOX,3P,1R,2.5MM,STRAIGH |
| 0609-001287 | CONTACT IMAGE SENSOR: 216MM,5136DOT,1.5MS |
| 3301-000317 | CORE-FERRITE BEAD: AB,2X1.25X0.9MM,- |
| JC63-01009A | COVER-M-FRONT: SCX-4200,HIPS,T2.2,405.4,1 |
| JC63-01019A | COVER-M-FUSER: SCX-4200,PET+GF30%,T2.0,28 |
| JC63-01008A | COVER-M-MIDDLE: SCX-4200,HIPS,T2.2,393.6, |
| JC63-01010A | COVER-M-PANEL: SCX-4200,HIPS,T2.2,52.1,34 |
| JC63-01013A | COVER-M-PLATEN: SCX-4200,HIPS,T2.2,405.29 |
| JC63-01012A | COVER-M-REAR DOOR: SCX-4200,ABS,T2.2,270. |
| JC63-01011A | COVER-M-REAR: SCX-4200,HIPS,T2.2,367.4,19 |
| JC63-01014A | COVER-M-SCAN LOWER: SCX-4200,HIPS,T2.2,40 |
| JC63-01007A | COVER-M-SCAN UPPER: SCX-4200,HIPS,T2.2,40 |
| JC63-01018A | COVER-M-SIDE L: SCX-4200,HIPS,T2.2,301.52 |
| JC63-01017A | COVER-M-SIDE R: SCX-4200,HIPS,T2.2,301.52 |
| 0407-000122 | DIODE-ARRAY: 1SS226,80V,300MA,C2-3,SOT-23 |
| 0407-000101 | DIODE-ARRAY: DA204K,20V,100MA,C2-3,SOT-2 |
| 0402-000129 | DIODE-RECTIFIER: 1N4003,200V,1A,DO-41 |
| 0404-000112 | DIODE-SCHOTTKY: RB420D,25V,100MA,SOT-23,T |
| 0401-000005 | DIODE-SWITCHING: 1N4148,100V,200MA,500MW, |
| 0401-001090 | DIODE-SWITCHING: 1SS355,80V,225MA,SOD-323 |
| JC96-03808C | ELA HOU-FUSER: SCX-4200,SAMSUNG,110V, |
| JC96-03805A | ELA UNIT-COVER PLATEN: SCX-4200,SEC,-,- |
| JC96-03823A | ELA UNIT-DRIVE: SCX-4200,SAMSUNG,110V/2 |
| JC96-03821A | ELA UNIT-FRAME LOWER: SCX-4200,SAMSUNG, |
| JC96-03809A | ELA UNIT-OPE: SCX-4200,SEC,-,-,- |
| JC96-03834A | ELA UNIT-SCAN DRIVE: SCX-4200,SAMSUNG,1 |
| JC96-03806A | ELA UNIT-SCAN LOWER: SCX-4200,SEC,-,- |
| JC96-03833A | ELA UNIT-SCAN UPPER: SCX-4200,SEC,-,- |
| JC96-03822A | ELA UNIT-SCANNER: SCX-4200,-,-,- |
| JC96-03206A | ELA UNIT-SMPS V1 |
| 3103-001085 | FAN-DC: 24V,80MA,4800RPM,0.131MMH20 |
| JC31-00004A | FAN-DC_HAWK: ML-6060,24.0V,2800RPM,15M^3/ |
| JC61-00835A | FOOT-BACK: ML-1750,NBR,D13.6,10.5,- |
| JC61-00836A | FOOT-FRONT: ML-1750,NBR,D7,12,- |
| JC61-01651A | FRAME-M_BASE: SCX-4200,ABS(VE-0860P),-, |
| JC66-00381A | GEAR-AGITATOR: ML-1400,POM,0.6,22,-,- |
| JC66-00384A | GEAR-DEVE ROLLER: ML-1400,DELIN 500CL,0.8 |
|
|
GEAR-DRV FUSER IN: SCX-4200,PA6T,0.8,26,- |
|
|
GEAR-DRV FUSER OUT: SCX-4200,POM,0.8,53,- |
| JC66-00038A | GEAR-EXIT F/DOWN: ML-4500,POM,WHT,- |
| JC66-00393A | GEAR-FEED 1: ML-1400,POM(M90-44),-,NT |
| JC66-00394A | GEAR-FEED 2: ML-1400,POM(M90-44),-,NT |
|
|
GEAR-FUSER, Z37: ML-1710,HTN51G35HSL,0.8, |
|
|
GEAR-HUB CLUTCH: SCX-5100,POM,M0.8,Z13, |
|
|
GEAR-IDLE 23: ML-1400,POM(M90-44),0.8,23, |
| JC66-00382A | GEAR-IDLE 26/13: ML-1400,POM,0.6,26/13, |
| JC66-01201A | GEAR-M_PULLEY: SCX-4200,POM,0.4,73,-,31 |
| JC66-00386A | GEAR-OPC L: ML-1400,POM,0.6,30,6.3 / 10,- |
| JC66-00012A | GEAR-OPC R: SF-5100,POM(M90-44),BLK,M0.6, |
| JG66-40003A | GEAR-PINION: SF4000,POM,WHT,M1,Z16 |
| JC66-00387A | GEAR-RACK_PINION: ML-1400,POM(M90-44),- |
| JC66-00391A | GEAR-RDCN 113/33: ML-1400,POM(NW-02),11 |
|
|
GEAR-RDCN 25/15: SCX-4200,PA6T,FR52G30LX, |
|
|
GEAR-RDCN 57/18: ML-1400,POM(M90-44),57 |
| JC66-00392A | GEAR-RDCN 90/31: ML-1400,POM(M90-44),90 |
| JC66-00395A | GEAR-TRANSFER: ML-1400,POM(M90-44),-, |
| JB01-00002A | GLASS-PLATEN: 250*360,2.8,CLEAR |
| JC63-00458A | GROUND-P-TERMINAL DEVE: SCX-4920,SUS304,0 |
| JC61-00918B | GUIDE-M-EXTENSION L2: ML-2250,HIPS,150, |
| JC61-01641A | GUIDE-M-HANDLE: SCX-4200,HIPS, HB,T2.2,28 |
| JC61-00937A | GUIDE-M-KNOCK UP: ML-1750,POM,60,15,- |
| JC61-00594A | GUIDE-M-TR RIB: ML-1400,PC+ABS,-,BLK, |
| JC61-00718A | GUIDE-P-PAPER: ML-1710,SECC,0.8,24.9,262. |
| JC61-00607A | GUIDE-P-TR : ML-1400,SECC,0.5,241,95,- |
| JC39-00558A | HARNESS-FUSER: SCX-4200,UL3122 #18,UL 312 |
| JC39-00582A | HARNESS-OPE: SCX-4200,WIRE HARNESS,UL1061 |
| JC39-00560A | HARNESS-SWITCH: SCX-4200,CBF,UL 1061,4P,2 |
|
|
HOLDER-BEARING EXIT F/DOWN: SCX-4216F,POM |
| JC61-00580A | HOLDER-M-PAD: ML-1400,PC(NH-1023),-,- |
|
|
HOLDER-M-PLATE CLAW: ML-1400,PET+GF30%, |
| JC61-00582B | HOLDER-M_EXIT F/DOWN: SCX-4200,PC(LS-1250 |
| JC61-01643A | HOLDER-M_HARNESS: SCX-4200,ABS, HB,2.0,15 |
| JC61-00583A | HOLDER-PTL: ML-1400,ABS,-,BLK,- |
| JC61-00591A | HOUSING-M-PICK_UP: ML-1400,PC+ABS,-,N |
| JC61-00911A | HOUSING-M-TERMINAL R2: SCX-4920,ABS,58. |
| JC13-00021A | IC ASIC-CHORUS2: S3C46Q0X,SF-531P,208P,+1 |
| JB13-00004A | IC ASIC-OPE: SF-3100,HT48C5,SSOP,48P,16.1 |
| 1205-002339 | IC-CLOCK GENERATOR: CY25811SC,SOIC,8P,150 |
| 0801-002469 | IC-CMOS LOGIC: 74HC14,SCHMITT INVERTER,TS |
| 0801-002446 | IC-CMOS LOGIC: 74LCX14,SCHMITT INVERTER,T |
| 0801-000794 | IC-CMOS LOGIC: 7S08,AND GATE,SOP,5P,64MIL |
| 1105-001390 | IC-DRAM: K4S641632F,4X1MX16BIT,TSOP(II) |
| 1103-001183 | IC-EEPROM: 24C04,512X8BIT,SOP,8P,150MIL,- |
| 1107-001391 | IC-FLASH MEMORY: M29W800DB70N6,1MX8/512KX |
| 1003-001535 | IC-MOTOR DRIVER: A3977SLP,TSSOP,28P,9.6X4 |
| 1203-001455 | IC-POSI.FIXED REG.: 1117,DPAK,3P,265MIL,P |
| 1203-000242 | IC-POSI.FIXED REG.: 7812,TO-220,3P,PLAS |
| 0904-001989 | IC-USC: ISP1582BS,HVQFN56,56P,8X8X0.85M |
| 1202-000164 | IC-VOLTAGE COMP.: 393,SOP,8P,150MIL,DUAL, |
| 1203-002454 | IC-VOLTAGE REGULATOR: FAN1117A,TO-252,3P, |
| JC70-00307A | IPR-P-EARTH TRANSFER: ML-1400,SECC,1.0T |
| JC70-00312A | IPR-P-TERMINAL CON: ML-1400,SUS304-CSP, |
|
|
IPR-PLATE PAD: ML-1400,SUS304-CSP,0.1,- |
| JC70-00335A | IPR-P_GROUND_DRIVE2: ML-1400,SUS304-CSP,- |
| 3722-002303 | JACK-USB |
| JC64-00258A | KEY-M-COPIES: SCX-4200,HIPS,19,HB,DARKMAG |
| JC64-00257A | KEY-M-MENU: SCX-4200,ABS,HB,DARKMAGENT, |
| JC64-00255A | KEY-M-START: SCX-4200,HIPS,P.28,HB,SOFT B |
| JC64-00256A | KEY-M-STOP: SCX-4200,HIPS,P22,HB,SOFT ORA |
| JC68-01584A | LABEL(P)-BLANK 90*25: CLP-510,SEE,ART 100 |
| JB68-00644A | LABEL(P)-SHADING: SCX-1105,YOOPO PAPER ,T |
| 4713-001203 | LAMP-HALOGEN |
| JC07-00003A | LCD-DISPLAY(XEV): VHX1620BHRC9,SCX-5312F/ |
| 0601-000003 | LED: ROUND,RED/GRN,3.1MM,650/563 |
| BN94-01666B | LENS-PTL: ML-1400,PC,NTR,-,- |
| JC97-02436A | MEA UNIT-CASSETTE: SCX-4200,SEC,-,110/2 |
|
|
MEA UNIT-CLUTCH: ML-1710,SAMSUNG,-,-, |
| JC97-02435A | MEA UNIT-COVER FRONT: SCX-4200,SEC,-, |
| JC97-02433A | MEA UNIT-COVER MIDDLE: SCX-4200,SEC,-,- |
| JC97-02434A | MEA UNIT-COVER REAR: SCX-4200,SEC,-,- |
| JC97-02432A | MEA UNIT-COVER SIDE_R: SCX-4200,SEC,-,- |
| JC97-01792A | MEA UNIT-SHIELD ENGINE: ML-1710,SAMSUNG,- |
| JC97-01782A | MEA-CHARGE ROLLER: ML-1710,SEC,12*254,0.5 |
| JC75-00049A | MEC-TERMINAL: SF-5100,SAMSUNG,IVR |
| JC31-00028A | MOTOR STEP-HUMMINGBIRD: M49SP-2NK,ML-1710 |
| JC31-00049A | MOTOR STEP-SCAN: 2T357278Q,SCX-4200,0.2A, |
| JC92-02112A | PBA MAIN-CONTROLLER: SCX-4200,SEC,-,- |
|
|
PBA SUB-CRUM: SCX-4200,SEC,KOREA,CRUM,- |
| JC92-01760B | PBA SUB-PANEL: SCX-4200/XAA,SEC,AMERICA,- |
| JC92-01841A | PBA SUB-PTL: SF-560/EUE,SAMSUNG,-,-,- |
| JC92-01761A | PBA SUB-SWITCH: SCX-4200,SEC,-,-,33 |
|
|
PLATE-P-SAW: ML-1400,SUS304-CSP,0.15,16,2 |
| JC61-01652A | PLATE-P-TERMINAL CR: SCX-4200,SUS301-CSP |
| JC72-00974A | PMO-ACTUATOR CVR OPEN: ML-1400,ABS,BLK, |
| JC72-00975A | PMO-ACTUATOR EMPTY: ML-1400,ABS,BLK,-,H |
| JC72-00976A | PMO-ACTUATOR FEED: ML-1400,ABS,BLK,-,HB |
| JC72-00977A | PMO-ACTUATOR MANUAL: ML-1400,ABS,BLK,-, |
|
|
PMO-ACTUATOR_EXIT: ML-1400,PC(NH-1023),BL |
| JC72-00382B | PMO-BUSHING FEED: ML-1710,DELRIN8903,WHIT |
|
|
PMO-BUSHING_TR(L): SF-5100,POM ,BLK,- |
| JC72-00978A | PMO-COLLAR_SPRING: ML-1400,POM(M90-44),NT |
| JC72-00971A | PMO-EXTENSION SMALL: ML-1400,HIPS(HR-1360 |
|
|
PMO-GEAR PICK_UP A: ML-1400,POM(M90-44),N |
| JC72-00982A | PMO-IDLE PICK_UP: ML-1400,POM(M90-44),NTR |
| JC72-00825A | PMO-IMPELLER_DRV: ML-6200,PC,BLK,V0,- |
| JC72-00983A | PMO-LOCKER CST: ML-1400,POM,BLK,-,-,- |
| JC72-41082B | PMO-M-ROLLER EXIT_FR 500: ML-1710,POM, 50 |
| JC72-41081B | PMO-M-ROLLER EXIT_MAIN 5: ML-1710,POM, 50 |
|
|
PMO-PLATE GUIDE DEVE_L: ML-1400,POM(M90-4 |
|
|
PMO-PLATE GUIDE DEVE_R: ML-1400,POM(M90-4 |
| JC72-00972A | PMO-PLATE_LOCKER: ML-1400,POM(M90-44),WHT |
|
|
PMO-SUB_M_STACKER: ML-1520,PC,BLACK,40*30 |
| 2001-000911 | R-CARBON: 62OHM,5%,1/4W,AA,TP,2.4X6.4MM |
| 2007-000729 | R-CHIP |
| 2007-000033 | R-CHIP: 0OHM,5%,1/8W,DA,TP,3216 |
| 2007-000123 | R-CHIP: 1.5KOHM,5%,1/16W,DA,TP,1608 |
| 2007-000074 | R-CHIP: 100OHM,5%,1/16W,DA,TP,1608 |
| 2007-000293 | R-CHIP: 100OHM,5%,1/8W,DA,TP,3216 |
| 2007-000090 | R-CHIP: 10KOHM,5%,1/16W,DA,TP,1608 |
| 2007-000303 | R-CHIP: 10KOHM,5%,1/8W,DA,TP,3216 |
| 2007-002901 | R-CHIP: 12.1KOHM,1%,1/16W,DA,TP,1608 |
| 2007-000091 | R-CHIP: 12KOHM,5%,1/16W,DA,TP,1608 |
| 2007-007521 | R-CHIP: 14.7KOHM,1%,1/16W,DA,TP,1608 |
| 2007-000402 | R-CHIP: 150OHM,5%,1/16W,DA,TP,1608 |
| 2007-000078 | R-CHIP: 1KOHM,5%,1/16W,DA,TP,1608 |
| 2007-000475 | R-CHIP: 1MOHM,1%,1/16W,DA,TP,1608 |
| 2007-000105 | R-CHIP: 200KOHM,5%,1/16W,DA,TP,1608 |
| 2007-000094 | R-CHIP: 22KOHM,5%,1/16W,DA,TP,1608 |
| 2007-000071 | R-CHIP: 22OHM,5%,1/16W,DA,TP,1608 |
| 2007-000730 | R-CHIP: 300OHM,5%,1/8W,DA,TP,3216 |
| 2007-000096 | R-CHIP: 30KOHM,5%,1/16W,DA,TP,1608 |
| 2007-000076 | R-CHIP: 330OHM,5%,1/16W,DA,TP,1608 |
| 2007-000134 | R-CHIP: 33KOHM,5%,1/16W,DA,TP,1608 |
| 2007-000113 | R-CHIP: 33OHM,5%,1/16W,DA,TP,1608 |
| 2007-000084 | R-CHIP: 4.7KOHM,5%,1/16W,DA,TP,1608 |
| 2007-000107 | R-CHIP: 470KOHM,5%,1/16W,DA,TP,1608 |
| 2007-000097 | R-CHIP: 47KOHM,5%,1/16W,DA,TP,1608 |
| 2007-000965 | R-CHIP: 5.1KOHM,5%,1/16W,DA,TP,1608 |
| 2007-000120 | R-CHIP: 680OHM,5%,1/16W,DA,TP,1608 |
| 2007-001139 | R-CHIP: 7.5KOHM,1%,1/16W,DA,TP,1608 |
| 2005-000168 | R-WIRE WOUND,NON: 0.22OHM,5%,2W,AA,BK,4X1 |
| 6044-000159 | RING-C: ID3,OD7,T0.6,PASS,STSC |
| JC73-00017A | RMO-RUBBER_EXIT: SF-5100,EPDM,11.8X13.8X2 |
| JC66-01209A | ROLLER-EXIT F/DOWN: SCX-4200,SUM22+EPDM,1 |
| JC66-00598A | ROLLER-FEED : ML-1710,SUM24L+EPDN,3/14.5, |
|
|
ROLLER-FEED ROLLER 1: ML-1510,SUM24L+EPDM |
|
|
ROLLER-HEAT: ML-1710,AL + PFA COAT,20.3,2 |
| JC66-00380A | ROLLER-M-EXIT F/UP: ML-1400,PC(NH-1023),1 |
|
|
ROLLER-M-IDLE FEED: ML-1510,POM,13,13,- |
| JC66-00600A | ROLLER-PRESSURE: ML-1710,SPONGE+PFA,22,23 |
|
|
ROLLER-TRANSFER: SCX-4200,NBR+ECO,15,218M |
|
|
RPR-FRICTION PAD: ML-1510,NBB,1T 10*45,60 |
|
|
RPR-PAD CASSETTE: ML-1510,NBB,1T 10*45,52 |
| 6001-000130 | SCREW-MACHINE: BH,+,M3,L6,ZPC(WHT),SM20C, |
|
|
SCREW-TAPTITE: BH,+,B,M3,L8,ZPC(BLK),SWCH |
|
|
SCREW-TAPTITE: BH,+,S,M3,L6,ZPC(YEL),SWRC |
| 6003-000196 | SCREW-TAPTITE: PWH,+,B,M3,L10,NI PLT,SWRC |
| 6003-000264 | SCREW-TAPTITE: PWH,+,B,M3,L6,ZPC(YEL),SWR |
| JC66-00527A | SHAFT-FEED IDLE: ML-1510,SUM24L,225,8,- |
| JC66-00398A | SHAFT-FEED: ML-1400,POM+GF20%,-,-,- |
| JC66-00720A | SHAFT-P-CORE: ML-1750,SECC 1.6T,220,-,- |
| JC66-00399A | SHAFT-P-PICK_UP: ML-1400,SECC,-,-,0.8 |
| JC63-00290A | SHEET-HOLDER PAD: ML-1750,PC,0.178T,50,28 |
|
|
SHEET-WHITE SPONGE: SCX-4114F,PC SHEET+SP |
| JC44-00072A | SMPS-V1: SCX-4100,AC/DC,45.7W,100-120VA |
| JC33-00010A | SOLENOID-HB (MANUAL):, ML-1510,DC24V,- |
| JC33-00009A | SOLENOID-HB (PICK-UP):, ML-1510,DC24V, |
|
|
SPONGE-ROLLER PICK_UP: ML-1510,URETHAN FO |
| JC61-00064A | SPRING-CLAW: ML-5200A,SUS 304 WPB,0.2,D |
| 6107-001137 | SPRING-CS: SUS304 WPB,PI0.4,D9.4,L11.5, |
| 6107-001194 | SPRING-CS: SUS304-WPB,BLK,PI0.95,D7,L20,- |
| 6107-001167 | SPRING-CS: SUS304-WPB,PI0.25,D3.25,L9.6 |
| 6107-001163 | SPRING-CS: SUS304-WPB,PI0.4,D3.9,L13, |
| 6107-001166 | SPRING-CS: SUS304-WPB,PI0.65,D12.65,L55 |
| 6107-001168 | SPRING-CS: SWP-B,PI1,D4.9,L16,-,D3.9, |
| 6107-001047 | SPRING-ES: PI0.45,D2.75,L24.2,SUS304 |
|
|
SPRING-ETC: SUS304-WPB,PI0.45,D4.45,L12 |
| JC61-70911A | SPRING-EXIT ROLL FD: ML-165,SUS304 WPB,PI |
| JC61-70932A | SPRING-GUIDE DEVE: ML-5000A,SUS304 WPB,PI |
| JG61-70531A | SPRING-LOCKER,PLATE: SF6000,STS304WPB,PI0 |
| JC61-00047A | SPRING-TR L HAWK: ML-6060A,SUS 304 WPB, |
| JC61-70958A | SPRING-TR: ML-5000A,SUS304 WPB,PI0.5,D4.5 |
|
|
SPRING-TS: SUS304-WPB,PI0.15,D3.75,L12, |
| 6107-001165 | SPRING-TS: SUS304-WPB,PI0.2,D4,-,ID |
| 6107-001171 | SPRING-TS: SWP-A,0.8,D14.2,-,ID13.6 |
| 6107-001170 | SPRING-TS: SWP-B,PI0.8,D6,-,ID5.2,O |
| JC61-01644A | STACKER-M-LARGE: SCX-4200,HIPS,1.8,100,55 |
| JC61-01645A | STACKER-M-SMALL: SCX-4200,HIPS,1.7,50,33. |
| 3404-000165 | SWITCH-TACT: 12V,50MA,160GF+-50GF,6X6MM,S |
| 0504-000111 | TR-DIGITAL |
| 0501-000457 | TR-SMALL SIGNAL |
| 0501-000150 | TR-SMALL SIGNAL: 2SA1037AK,PNP,-50V,-50V, |
| 0501-000279 | TR-SMALL SIGNAL: KSA1182,PNP,-35V,-30V,-5 |
| JC59-00018C | UNIT-HUMMING_VE LSU: SCX-4100,-,600 DPI |
| 6031-000023 | WASHER-PLAIN:, ID5.9,OD10.0,T0.5,BLK,POL |
| 6031-000019 | WASHER-PLAIN:, ID6.1,OD8.5,T0.1,BLK,POLY |
