Manufacturer
Samsung
Model Number
SF-335T
Description
Fax Machine Compact, Thermal Printing
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| JB81-00297B | AS-OPE PBA;SF-335T,*,-,XEU,OPE PBA,SVC,T |
| 6902-000183 | BAG PE;LDPE,T0.05,W350,L400,TRP,28LANGUA |
| 3301-001051 | BEAD-SMD;1000OHM,1608,190MA,,,,0.9OHM |
| 3301-000369 | BEAD-SMD;2000OHM,3216,100,TP,-,-,1.5 |
| JB61-00139A | BRACKET-M_TX;SF-330,PC+GF10%,2.00,W82,L6 |
| JB61-00153A | BRACKET-P_LF RIGHT;SF-330,SECC,1.00,W103 |
| JB61-00151A | BUSH-M_FEED ROLLER;SF-330,POM (LUCEL CF6 |
| JB64-00030A | BUTTON-M_HOOK SWITCH;SF-330,HIPS,33.5X29 |
| 2401-000059 | C-AL;0.22UF,20%,50V,GP,-,5X11,5 |
| 2401-000042 | C-AL;100UF,20%,16V,GP,TP,6.3X7,5 |
| 2401-000207 | C-AL;100UF,20%,50V,WT,TP,8X12,5 |
| 2401-000414 | C-AL;10UF,20%,16V,GP,TP,4X7,5 |
| 2401-000603 | C-AL;1UF,20%,50V,GP,TP,5X11,2 |
| 2401-000962 | C-AL;22UF,20%,50V,GP,TP,5X11,5 |
| 2401-002075 | C-AL;4.7UF,20%,50V,GP,TP,5X11,5 |
| 2401-001775 | C-AL;470NF,20%,50V,GP,TP,4X7,5 |
| 2401-001698 | C-AL;470UF,20%,35V,WT,TP,10X20,5 |
| 2203-000426 | C-CER,CHIP;0.018NF,5%,50V,C0G,1608 |
| 2203-000626 | C-CER,CHIP;0.022NF,5%,50V,C0G,1608 |
| 2203-000851 | C-CER,CHIP;0.039NF,5%,50V,C0G,1608 |
| 2203-000998 | C-CER,CHIP;0.047NF,5%,50V,C0G,1608 |
| 2203-001656 | C-CER,CHIP;0.47NF,5%,50V,NP0,1608 |
| 2203-000476 | C-CER,CHIP;1000NF,+80-20%,16V,Y5V,2012 |
| 2203-000192 | C-CER,CHIP;100NF,+80-20%,50V,Y5V,TP,2012 |
| 2203-000206 | C-CER,CHIP;100NF,10%,50V,X7R,TP,2012 |
| 2203-000257 | C-CER,CHIP;10NF,10%,50V,X7R,TP,1608 |
| 2203-000440 | C-CER,CHIP;1NF,10,50V,X7R,TP,1608 |
| 2203-002398 | C-CER,CHIP;22NF,10%,50V,X7R,1608 |
| 2203-000888 | C-CER,CHIP;4.7NF,10%,50V,X7R,TP,1608 |
| 2203-000975 | C-CER,CHIP;47NF,10%,25V,X7R,TP,1608,- |
| 2203-000989 | C-CER,CHIP;47NF,10%,50V,X7R,2012 |
| 2203-001143 | C-CER,CHIP;68NF,10%,50V,X7R,2012 |
| 2301-001027 | C-FILM,LEAD-PEF;15NF,10%,250V,TP,9.5X12X |
| 2305-000583 | C-FILM,LEAD-PEF;470NF,10%,250V,TP,20X7X1 |
| 2404-000284 | C-TA,CHIP;10UF,20%,16V,-,TP,3528 |
| 6501-000004 | CABLE TIE;DA-80,T1,W2.5,L80,NTR,NYLON66 |
| JB39-00182A | CBF CURL CORD-CURL CORD;-,SF-330,4P,300M |
| JB39-00176A | CBF HARNESS-CIS LIU;SF-330,UL1061,#26,8, |
| JB39-00179A | CBF HARNESS-CR MOTOR-MAIN;SF-330,UL1007, |
| JB39-00026A | CBF HARNESS-HANDSET MODULAR;SF-3100,MODU |
| JG39-41019A | CBF HARNESS-LCD;SF4400,WIRE,UL2878,14,30 |
| JB39-00181A | CBF HARNESS-MAIN LIU FFC;SF-330,FLAT CAB |
| JB39-00175A | CBF HARNESS-OPE LIU;SF-330,UL1061,#26,7, |
| JB39-00020A | CBF HARNESS-OPE MIC;SF-3100,CBF,UL 1061 |
| JB39-00180A | CBF HARNESS-OPE-ENGINE;SF-330,UL1007,#18 |
| JB39-00177A | CBF HARNESS-SMPS-MAIN;SF-330,UL1007,#24, |
| JB39-00178A | CBF HARNESS-SS MOTOR MAIN;SF-330,UL1061, |
| JC39-40511A | CBF HARNESS;ML-80,JUMPER,AWG22,52MM,SILV |
| JF39-50094B | CBF LINE CORD;MINI FAX,IVR |
| 3903-000048 | CBF-POWER CORD;DT,US,EP2,IEC320 C7/C8(ME |
| JB66-00182A | CLUTCH-M_ARM EXIT 25;SF-330,POM,WHT |
| JB66-00183A | CLUTCH-M_ARM PICK UP 25;SF-330,POM,WHT |
| JB27-00001A | COIL CHOKE-DIP;MJC-1300/LEX,150UH,0.34OH |
| JF27-60051A | COIL FILTER;CF5400,60UH,50MOHM,18T |
| 3708-001455 | CONNECTOR-FPC/FFC/PIC;30P,0.5MM,SMD-A,AU |
| 3708-001058 | CONNECTOR-FPC/FFC/PIC;30P,1MM,STRAIGHT,S |
| 0609-001174 | CONTACT IMAGE SENSOR;215MM,1728DOT,5MS,5 |
| JB63-00042B | COVER-M-SIDE L (TAD);SF-330,ABS ,T1.5,W1 |
| JB63-00041B | COVER-M-SIDE R (TAD);SF-335T,ABS,T1.5,W1 |
| JB63-00043A | COVER-M_BASE;SF-330,ABS,T2.5,W361.5,L238 |
| JB63-00040A | COVER-M_DUST;SF-330,HIPS,T2.5,W243.4,L55 |
| JB63-00045D | COVER-M_OPE (335T_XEC);SF-335T/XEC,HIPS, |
| JB63-00048A | COVER-M_TOP;SF-330,ABS,T2.3,W361.6,L244. |
| 0402-000128 | DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP |
| 0402-001212 | DIODE-RECTIFIER;SS26,60V,2A,SMB,TP |
| 0404-000112 | DIODE-SCHOTTKY;RB420D,40V,100MA,SOT-23,T |
| 0401-000005 | DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T |
| 0407-000122 | DIODE-SWITCHING;KDS226,80V,100MA,SOT-23, |
| 0401-000116 | DIODE-SWITCHING;MMSD914T1,100V,200MA,SOD |
| 0403-000525 | DIODE-ZENER;1N4733A,5%,1000MW,DO-41,TP |
| JB96-01425A | ELA UNIT-BASE (TAD);SF-335T,SAMSUNG,UK,- |
| JB96-01410A | ELA UNIT-CIS;SF-330,SAMSUNG,UK,-,-,-,- |
| JB96-01407A | ELA UNIT-ENGINE HP;SF-330,SAMSUNG,UK,-,- |
| JB96-01415A | ELA UNIT-ENGINE;SF-330,SAMSUNG,UK,-,-,-, |
| JB96-01406C | ELA UNIT-HANDSET(T);SF-335T,SAMSUNG,UK,- |
| JB96-01422D | ELA UNIT-OPE (335T_XEC);SF-335T/XEC,SESA |
| JB96-01405A | ELA UNIT-SCAN MOTOR;SF-330,SAMSUNG,UK,-, |
| JB63-00053A | FELT-INK;SF-330,WOOL,T5,W13.3,L29.75 |
| JG61-40001A | FOOT-SF4000;SF4000,CR RUBBER,W14XL14,BLK |
| JB61-00141A | FRAME-M_UPPER;SF-330,HIPS,HB,BLK,T2.0,W2 |
| JB63-00077A | GASKET-SPEAKER;SF-330,SPONGE,T1.6,OD 52, |
| JB66-00006A | GEAR-IDLE;SF-3100,DUPONT DELIN 500,0.6,2 |
| JB66-00184A | GEAR-M_EXIT IDLE 18;SF-330,POM,0.8,Z18,P |
| JB66-00179A | GEAR-M_EXIT IDLE 35;SF-330,POM,0.6,Z35,P |
| JB66-00181A | GEAR-M_FEED ROLLER 29;SF-330,POM,0.6,Z29 |
| JB66-00186A | GEAR-M_LF IDLE 18/65;SF-330,POM,A:0.6,B: |
| JB66-00187A | GEAR-M_LF IDLE 47;SF-330,POM,0.6,Z47,PD2 |
| JB66-00173A | GEAR-M_PICK UP ROLLER 30;SF-330,POM,0.6, |
| JB66-00172A | GEAR-M_PICK UP ROLLER 35;SF-330,POM,0.6, |
| JB66-00185A | GEAR-M_SWING IDLE 25;SF-330,POM,0.6,Z25, |
| JG66-40003A | GEAR-PINION;SF4000,POM,1,Z16,WHT |
| JB66-00005A | GEAR-TRANS;SF-3100,A:0.6,B:0.6,30/16,21. |
| JB61-00138A | GUIDE-M_CIS L;SF-330,POM,T1.5,W44,L32.5, |
| JB61-00137A | GUIDE-M_CIS R;SF-330,POM,T1.5,W44,L32.5, |
| JB61-00140A | GUIDE-M_SWING;SF-330,POM,T1.2,W33,L10.4, |
| 3711-003408 | HEADER-BOARD TO CABLE;BOX,2P,1R,2MM,STRA |
| 3711-003409 | HEADER-BOARD TO CABLE;BOX,3P,1R,2MM,STRA |
| 3711-003411 | HEADER-BOARD TO CABLE;BOX,5P,1R,2MM,STRA |
| 3711-002807 | HEADER-BOARD TO CABLE;BOX,6P,1R,2MM,STRA |
| 3711-002809 | HEADER-BOARD TO CABLE;BOX,8P,1R,2MM,STRA |
| JB61-00152A | HOLDER-M_FRICTION;SF-330,POM,T2.0,W66,L4 |
|
|
HOLDER-M_RUBBER;SF-330,POM,T1.0,W39,L18, |
| JC13-00021A | IC ASIC-CHORUS2;S3C46Q0X,SF-531P,208P,+1 |
| JB13-00022A | IC ASIC-ERTE;SC901901DWR2,SF-330,20PIN,+ |
| JB13-00004A | IC ASIC-OPE;HT48C50-1-SPPF,SF-3100,48P,+ |
| JB13-00023A | IC ASIC-QUARTERHORSE;SC79213FNR2,SF-330, |
| JB13-00021A | IC ASIC-SIXSHOOTER;SC901900FTA,SF-330,64 |
| 1001-000170 | IC-ANALOG SWITCH;MC14051BD,SPDT CMOS,SOP |
| 1001-000171 | IC-ANALOG SWITCH;MC14053BD,SPDT CMOS,SOP |
| 1201-000105 | IC-AUDIO AMP;34119,SOP,8P,150MIL,SINGLE, |
| 1205-001771 | IC-CLOCK GENERATOR;FS781BZB,SOP,8P,150MI |
| 0801-000921 | IC-CMOS LOGIC;74HCT244,BUFFER/DRIVER,SOP |
| 1105-001464 | IC-DRAM;K4S641632,4MX16BIT,TSOP(II),54P, |
| 1205-002195 | IC-MODEM;FM214-VS,TQFP,128P,20X14MM,PLAS |
| 1201-000167 | IC-OP AMP;358,SOP,TP,8P,150MIL,DUAL,100V |
| 1203-001455 | IC-POSI.FIXED REG.;1117,DPAK,3P,265MIL,P |
| 1203-002454 | IC-POSI.FIXED REG.;1117,TO-252,3P,257MIL |
| JG70-40514A | ICT-SPRING COIL;SF5500,STSC304WPB,D0.4 |
| 2703-000125 | INDUCTOR-SMD;10UH,10%,2012 |
| 3722-000577 | JACK-MODULAR;4P/4C,STANDARD,N,ANGLE,N,WH |
| 3722-000255 | JACK-MODULAR;6P/4C,INVERTED,N,ANGLE,STAN |
| 3722-001431 | JACK-USB;4P/1C,AUF,WHT,STRAIGHT,B TYPE |
| JB64-00028A | KEY-M_ANSWER;SF-330,PMMA,18X15X12,HB,MIL |
| JB64-00023A | KEY-M_CARTRIDGE;SF-330,HIPS,34X16X14,HB, |
| JB64-00021A | KEY-M_COPY;SF-330,ABS,16X16X11,HB,GRAY |
| JB64-00024A | KEY-M_MENU;SF-330,HIPS,37X27.5X16.5,HB,C |
| JB64-00027A | KEY-M_SAVE;SF-330,PMMA,18X14X13,HB,MILKY |
| JB64-00022A | KEY-M_START;SF-330,ABS,17X17X9,HB,CLEAR |
| JB64-00026A | KEY-M_STOP;SF-330,ABS,16X16X9,HB,CLEAR R |
| JB64-00029A | KEY-M_TAD;SF-330,HIPS,37X14X15,HB,COOL W |
| JB64-00020A | KEY-M_TEL;SF-330,ABS,64X63X17.5,HB,COOL |
| JC68-10932A | LABEL(P)-BLANK(ML);ML-85,ART,G100,WHT,CO |
| JC68-00573A | LABEL(R)-BARCODE;ML-4500,PET,T0.05,20MM, |
| JB07-00002A | LCD-DISPLAY;VHX1610ANR,SF-330,16CHX1,73X |
| JB66-00180A | LEVER-M_FEED SENSOR;SF-330,ABS GF10%,1.5 |
| JB66-00168A | LEVER-M_SENSOR DOC;SF-330,ABS HB,1.6,24. |
| JB66-00169A | LEVER-M_SENSOR SCAN;SF-330,ABS HB,1.6,20 |
| JB97-01672A | MEA ETC-LEVER ACTUATOR;SF-330,SAMSUNG,UK |
| JB97-01207A | MEA ETC-ROLLER WHITE;SF-3100,SEUK,GB,MIL |
| JB97-01623A | MEA HOU-CHUTE;SF-330,SAMSUNG,UK,-,-,-,- |
| JB97-01622B | MEA HOU-COVER BASE (TAD);SF-330,SAMSUNG, |
| JB97-01626B | MEA HOU-COVER TOP (TAD);SF-335T,SAMSUNG, |
| JB97-01627A | MEA HOU-DOOR;SF-330,SAMSUNG,UK,-,-,-,- |
| JB97-01673A | MEA HOU-GUIDE EXTENSION;SF-330,SAMSUNG,U |
| JB97-01624A | MEA HOU-STACKER TX;SF-330,SAMSUNG,UK,-,- |
| JB97-01621A | MEA UNIT-ASF;SF-330,SAMSUNG,UK,-,-,-,- |
| JB97-01678A | MEA UNIT-BRACKET LF;SF-330,SAMSUNG,UK,-, |
| JB97-01631A | MEA UNIT-FEED ROLLER;SF-330,SAMSUNG,UK,- |
| JB97-01671A | MEA UNIT-FRAME MAIN;SF-330,SAMSUNG,UK,-, |
| JB97-01630A | MEA UNIT-FRICTION ROLLER;SF-330,SAMSUNG, |
| JB97-01628A | MEA UNIT-LEVER EXIT;SF-330,SAMSUNG,UK,-, |
|
|
MEA UNIT-ROLLER ADF;SF-330,SAMSUNG,UK,-, |
| JB97-01629A | MEA UNIT-ROLLER EXIT;SF-330,SAMSUNG,UK,- |
| JB97-01690A | MEA UNIT-SCAN UPPER;SF-330,SAMSUNG,UK,-, |
| JB75-00051A | MEC-ANTISTATIC BRUSH;SF-3100,SEUK,NTR |
| 3003-000103 | MIC-CONDENSOR;1.5V,0.5MA,-44DB,1KOHM |
| 3003-000120 | MIC-CONDENSOR;4.5V,0.8MA,-38DB,1KOHM |
| JB31-00026A | MOTOR STEP-LF;SP-42RD-110M,SF-330,1.3A,1 |
| JB31-00025A | MOTOR STEP-TX;SP-42RD-300L,SF-330,0.2A,2 |
| JF74-10234A | MPR-PAD;T1.0,W19.7,L23.7 |
| JB92-01218B | PBA MAIN-MAIN PBA TAD;SF-335T,XEU,UK,MAI |
| JB92-01218L | PBA MAIN-SF-335T/XIL;SF-335T,XEU,ENGLAND |
| JB92-01219N | PBA SUB-LIU PBA;CF-335T,KOR,SEC,LIU PBA, |
| JB92-01220B | PBA SUB;SF-335T,XEU,UK,OPE,PHANTOM Y,(BO |
| 0604-000142 | PHOTO-COUPLER;TR,-,200MW,DIP-4,ST |
| 0604-000118 | PHOTO-COUPLER;TR,20-300%,200MW,DIP-4,ST |
| 0604-001210 | PHOTO-INTERRUPTER;TR,200MW,DIP-4,ST |
| JB72-00137A | PMO-BUSHING WHITE;SF-3100,POM,VIOLET,94V |
| JF72-41293A | PMO-GEAR CLUTCH;SF1600,POM,NTR+WHT(DELRI |
| JB72-00127D | PMO-HANDSET LOWER (T);SF-335T,ABS,SOFT B |
| JB72-40237A | PMO-HOLDER WHEEL;MJ-63V,POM,WHT,V0 |
| JB72-00112B | PMO-KEY RESOLUTION;SF-330,HIPS,6X6X8.2,H |
| JB72-40933A | PMO-LEVER EXIT;AMUNDSEN,ABS,HB,BLK |
| GB72-40770A | PMO-MIC. ADAPTER;SAP-1000,RUBBER |
| JF72-10620A | PPR-JACK DUMMY;SF100SEI(I),PC,V2,IVR(C74 |
| 2007-000033 | R-CHIP;0OHM,5%,1/4W,TP,3216 |
| 2007-000029 | R-CHIP;0OHM,5%,1/8W,TP,2012 |
| 2007-000122 | R-CHIP;1.2KOHM,5%,1/10W,TP,1608 |
| 2007-000123 | R-CHIP;1.5KOHM,5%,1/10W,TP,1608 |
| 2007-000102 | R-CHIP;100KOHM,5%,1/10W,TP,1608 |
| 2007-000074 | R-CHIP;100OHM,5%,1/10W,TP,1608 |
| 2007-000090 | R-CHIP;10KOHM,5%,1/10W,TP,1608 |
| 2007-000305 | R-CHIP;10MOHM,5%,1/10W,TP,1608 |
| 2007-000103 | R-CHIP;120KOHM,5%,1/10W,TP,1608 |
| 2007-000091 | R-CHIP;12KOHM,5%,1/10W,TP,1608 |
| 2007-000104 | R-CHIP;150KOHM,5%,1/10W,TP,1608 |
| 2007-000092 | R-CHIP;15KOHM,5%,1/10W,TP,1608 |
| 2007-008505 | R-CHIP;17.8KOHM,1%,1/10W,TP,1608 |
| 2007-000078 | R-CHIP;1KOHM,5%,1/10W,TP,1608 |
| 2007-000109 | R-CHIP;1MOHM,5%,1/10W,TP,1608 |
| 2007-000124 | R-CHIP;2.2KOHM,5%,1/10W,TP,1608 |
| 2007-007507 | R-CHIP;2.74KOHM,1%,1/10W,TP,1608 |
| 2007-000093 | R-CHIP;20KOHM,5%,1/10W,TP,1608 |
| 2007-000094 | R-CHIP;22KOHM,5%,1/10W,TP,1608 |
| 2007-000637 | R-CHIP;270KOHM,5%,1/10W,TP,1608 |
|
|
R-CHIP;2KOHM,5%,1/10W,TP,1608 |
| 2007-000082 | R-CHIP;3.3KOHM,5%,1/10W,TP,1608 |
| 2007-000730 | R-CHIP;300OHM,5%,1/4W,TP,3216 |
| 2007-000096 | R-CHIP;30KOHM,5%,1/10W,TP,1608 |
| 2007-000133 | R-CHIP;330KOHM,5%,1/10W,TP,1608 |
| 2007-000134 | R-CHIP;33KOHM,5%,1/10W,TP,1608 |
| 2007-000113 | R-CHIP;33OHM,5%,1/10W,TP,1608 |
| 2007-000783 | R-CHIP;33OHM,5%,1/4W,TP,3216 |
| 2007-000083 | R-CHIP;3KOHM,5%,1/10W,TP,1608 |
| 2007-000084 | R-CHIP;4.7KOHM,5%,1/10W,TP,1608 |
| 2007-000107 | R-CHIP;470KOHM,5%,1/10W,TP,1608 |
| 2007-000077 | R-CHIP;470OHM,5%,1/10W,TP,1608 |
| 2007-000097 | R-CHIP;47KOHM,5%,1/10W,TP,1608 |
| 2007-000072 | R-CHIP;47OHM,5%,1/10W,TP,1608 |
| 2007-000086 | R-CHIP;5.6KOHM,5%,1/10W,TP,1608 |
| 2007-000119 | R-CHIP;560OHM,5%,1/10W,TP,1608 |
| 2007-000098 | R-CHIP;56KOHM,5%,1/10W,TP,1608 |
| 2007-001114 | R-CHIP;680KOHM,5%,1/10W,TP,1608 |
| 2007-000120 | R-CHIP;680OHM,5%,1/10W,TP,1608 |
| 2007-000100 | R-CHIP;68KOHM,5%,1/10W,TP,1608 |
| 2007-007238 | R-CHIP;8.25KOHM,1%,1/10W,TP,1608 |
| 2007-001179 | R-CHIP;8.2KOHM,5%,1/10W,TP,1608 |
| 2007-000121 | R-CHIP;820OHM,5%,1/10W,TP,1608 |
| 2003-000178 | R-METAL OXIDE;15KOHM,5%,1W,AA,TP,4.3X12M |
| 2004-000284 | R-METAL;12KOHM,1%,1/4W,AA,TP,2.4X6.4MM |
| 2011-001093 | R-NETWORK;100OHM,5%,1/16W,L,CHIP,8P,TP,3 |
| 2011-000585 | R-NETWORK;47OHM,5%,1/16W,L,CHIP,8P,TP,3. |
| 3501-000203 | RELAY-MINIATURE;5V,200MW,1000MA,1FORMC,6 |
| 2802-000185 | RESONATOR-CERAMIC;7.37MHZ,0.5%,TP,10.0X5 |
| 6044-000138 | RING-OP;ID17,OD35,T2,BLACK,SPONGE.R |
| JB73-00009A | RMO-PICK UP RUBBER;SF-3100,EPDM,15.5X21X |
| JF73-40501A | RMO-RUBBER MIC;NATURAL,SILICON RUBBER |
| JB66-00188A | ROLLER-M_FRICTION;SF-330,POM,OD4,26X4,WH |
|
|
RUBBER-ADF;SF-330,SILICONE,1.5,25.38X23X |
| JB73-00098A | RUBBER-CONTACT MAIN;SF-330,SILICONE,H9.2 |
| JB73-00099A | RUBBER-CONTACT SAVE;SF-330,SILICONE,H9.2 |
| JB73-00095A | RUBBER-EXIT ROLLER;SF-330,EPDM,5.5,7XOD1 |
| 6002-000175 | SCREW-TAPPING;PWH,+,2,M3,L8,ZPC(WHT),SM2 |
|
|
SCREW-TAPTYPE;BH,+,-,S,M3,L6,ZPC(WHT),SW |
| 6003-000196 | SCREW-TAPTYPE;PWH,+,B,M3,L10,NI PLT,SWRC |
| JB66-00166A | SHAFT-M_DRIVER ADF;SF-330,POM,L101.6,PI8 |
| JB66-00176A | SHAFT-M_PICK UP;SF-330,PC+ABS,W258.6,OD1 |
| JB66-00178A | SHAFT-M_RX EXIT;SF-330,PC+ABS,L247.3,D14 |
| JB63-00059A | SHEET-INSULATION LIU;SF-330,PVC SHEET,0. |
| JB63-00052D | SHEET-WINDOW LCD(XEC);SF-335T/XEC,PC,T0. |
| JB44-00027A | SMPS-SMPS/V1;SF-330,*,AC/DC,24.25W,100-1 |
| 3001-001293 | SPEAKER;0.3W,8OHM,81DB,400HZ,50X16.6MM |
| JB61-70938A | SPRING ETC-CIS(ATLAS);MJC-3700,PW2,0.6,5 |
| JB61-70922A | SPRING ETC-CLUTCH;MJC-810L,SUS304,ID4.1, |
| JB61-70907A | SPRING ETC-CS (EXIT);AMUNDSEN,SWPB,D3.71 |
| JB61-70919A | SPRING ETC-ES ACTUATOR;MUNICH,SUS304,D0. |
| JB61-00107A | SPRING ETC-LEVER SENSOR;SF-430,SUS304,0. |
| 6107-001136 | SPRING-CS;STS304 WPB,PI0.8,D16.9,L41.6,I |
| 6107-001137 | SPRING-CS;SUS304 WPB,PI0.4,D9.4,L11.5,ID |
| 6107-001147 | SPRING-ES;SUS304 WPB,PASS,PI0.2,D3.6,L23 |
| 6107-001138 | SPRING-ES;SUS304 WPB,PI0.5,D3.8,L15,ID3. |
| 6107-000011 | SPRING-ES;SUS304-WPB,PI0.2,D3.4,L13 |
| JB61-00142A | SUPPORT-M_ADF;SF-330,POM,T2.0,W38.6,L29. |
| 4715-001043 | SURGE ABSORBER;600V,20%,500A,TP |
| 0203-000007 | TAPE-FILAMENT;T0.15,L55M,TRP,FILAMENT |
| 0203-001100 | TAPE-OPP MASKING;OPP/W75/CLR,T0.075,W75, |
| 0506-001068 | TR-ARRAY;S1P2655A03-S0B0,NPN,7,1W,SOP-16 |
| 0501-000279 | TR-SMALL SIGNAL;KSA1182-Y,PNP,150MW,SOT- |
| 0501-000009 | TR-SMALL SIGNAL;KSC945-Y,NPN,250MW,TO-92 |
| 0501-000457 | TR-SMALL SIGNAL;MMBT2222A/KST2222A,NPN,3 |
| JG26-50001A | TRANS MATCHING;100-1016,SF6000,4P,EX19,6 |
| JB63-00065A | TRAY-M-STACKER TX1;SF-330,HIPS,T2.0,W120 |
| 1405-000170 | VARISTOR;82V,1200A,9X4.1MM,TP |
| 6031-001555 | WASHER-PLAIN;POLY,ID7,OD10.8,T0.2,BLACK |
