Manufacturer
Samsung
Model Number
TXN2775HF
Description
Crt Tv
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| AA64-02745E | BACK CABINET |
| AA94-12659A | BOARD |
| AA64-70117B | BRAND BADGE |
| 2401-003024 | C-AL; 220UF, 20%, 200V, |
| 2401-001676 | C-AL; 820UF, 20%, 250V, |
| AA27-00057A | COIL HORIZ. WIDTH; -, |
| AA27-00070A | COIL LINEARITY; -, 7UH |
| AA03-00253A | CRT |
| 0402-000546 | DIODE |
| 0402-001399 | DIODE |
| 0403-001330 | DIODE-ZENER; MTZJ30A, |
| AA96-00932L | FRONT CABINET |
| 1203-002512 | IC |
| AA09-00310A | IC MICOM; SDA 5525C, S |
| 1103-001213 | IC-EEPROM; 24WC16, 204 |
| 1201-001131 | IC-VIDEO AMP; 6111, SI |
| 1204-001972 | IC901 MSP3420GBB3V |
| 2701-000178 | INDUCTOR-AXIAL; 33UH, |
| AA94-12873M | MAIN PCB |
| AA94-13006F | MAIN PCB |
| AA95-03224L | MD201 FEATURE BOX |
| 1201-001385 | POWER-IC |
| 2003-000540 | R-METAL OXIDE (S); 1KO |
| AA95-02001U | SUB-PCB NTSC F- |
| AA96-00908P | TERMINAL PCB |
| 1404-001026 | THERMISTOR-PTC; 7OHM, |
|
|
TR-POWER |
| 0403-001327 | ZENER DIODE |
