Manufacturer
Samsung
Model Number
TXN3245FP
Description
Crt Tv
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 2401-002458 | C-AL; 220UF, 20%, 200V, |
| 2401-001397 | C-AL; 470UF, 20%, 25V, G |
| 2401-002288 | C-AL; 470UF, 20%, 25V, G |
| 2401-001676 | C-AL; 820UF, 20%, 250V, |
| 2401-000262 | CP819 |
| AA03-00357A | CRT |
| AA03-00253A | CRT |
| AA96-01793A | CRT PCB |
| 0402-001296 | DIODE-RECTIFIER |
| 0505-001723 | FET-SILICON; IRF630, N |
| AA26-00180A | FLYBACK TRANSFORMER |
| AA96-00902F | FRONT CABINET |
| 1203-002512 | IC |
| 1103-001213 | IC-EEPROM; 24WC16, 204 |
| 1203-001944 | IC-POSI.FIXED REG.; 7 |
| 1203-001225 | IC-POSI.FIXED REG.; 7 |
| 3722-001766 | JACK-PIN; 7P (9P), -, NI |
| 3722-001765 | JACK-PIN; 9P (9P), -, NI |
| 3722-001031 | JACK-RCA; 3P, 3.6MM, #1 |
|
|
LOC # Q401 (HORIZONTAL OUTPUT) |
| AA95-03224L | MD201 FEATURE BOX |
| AA97-14110A | MICRO |
| 32119-901-110 | Q901 |
| 2008-000251 | R-FUSIBLE (S); 0.27OHM |
| 2008-001148 | R-FUSIBLE; 3.3OHM, 5%, |
| 3704-001032 | SOCKET |
| AA40-00134A | TUNER |
