Manufacturer
Samsung
Model Number
UN55NU6950FXZA
Description
55-inch Class Led1080p Smart Hdtv
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ASSY BOARD P-FUNCTION;Y18 NU7300, 7100,C |
|
|
ASSY BOARD P-MAIN;NU709 SDC 3-IN-1 55INC |
| BN96-45669A | ASSY CHASSIS FRONT P;55UNU7100X,PC+ABS+E |
| BN96-45945A | ASSY COVER P-REAR;55UNU7090P,PC+ABS+ED20 |
|
|
ASSY HOLDER P-RING;65Q8C,ABS,BLACK,HB |
|
|
ASSY LED BAR P;55INCH_NU7100,ALUMINUM,NU |
| BN96-39045D | ASSY OPEN CELL;SDC,55INCH,QUALITY IMPROV |
|
|
ASSY SPEAKER P-FRONT;TV-SPK,UN5000M,6OHM |
|
|
ASSY STAND P-COVER TOP LEFT;55UNU7090P,P |
|
|
ASSY STAND P-COVER TOP RIGHT;55UNU7090P, |
|
|
BRACKET-STAND LINK;55UNU7100X,EGI-SECC,T |
| BN63-17752A | COVER-TERMINAL SIDE;55UNU7090P,HIPS,V-0, |
|
|
FFC CABLE;55NU7090,FOLD,L400,96P,- |
|
|
FFC CABLE;65KS7500,FOLD,L600,96P |
| BN39-01997C | HDMI CABLE;C49HG90,19,2000MM,BLK,HDMI A, |
| 1107-002374 | IC-EMMC;KLM4G1FEPD-B031,4GBYTE,BGA,153P, |
| 1107-002226 | IC-NOR FLASH;W25Q40CLSSIP,4MBIT,SOIC,8P, |
| BN39-02231D | LEAD CONNECTOR-SUB ASSY;43KU6400,UL21016 |
| BN39-02415A | LEAD CONNECTOR-SUB ASSY;55NU7090,UL21016 |
|
|
NETWORK-WLAN CLIENT;WDN221M,58X27X8.5MM |
|
|
POWER CORD-DT;USA,2P-F,125V,7A,BLK,L1500 |
|
|
PRODUCT LCD-SDC;CY-NN055HGLVDV/H,NU7090, |
|
|
REMOCON-TV;2018 TV,SAMSUNG,44KEY,3.0V,US |
|
|
SCREW-MACHINE;PWH,M3,L5.0,ZPC(WHT),SWR |
|
|
SCREW-TAPTYPE;BH,S,M4,L14,ZPC(BLK),SWR |
