Manufacturer
Samsung
Model Number
UN55NU7200FXZA
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ASSEMBLY BOARD P-FUNCTION |
| BN96-45669B | ASSEMBLY CHASSIS FRONT P |
|
|
ASSEMBLY HOLDER P-RING |
| BN96-45632A | ASSEMBLY SPEAKER P-FRONT |
| BN96-45797C | ASSEMBLY STAND P-COVER TOP LEF |
| BN96-45796C | ASSEMBLY STAND P-COVER TOP RIG |
|
|
ASSY LED BAR P;55INCH_NU7100,A |
|
|
ASSY PCB MAIN;LEDTV 7K,B VERSI |
| 6902-000341 | BAG PE |
| BH69-00418A | BAG PE-WRAPPING FILM |
| 6922-000013 | BAND PP |
|
|
BEAD-SMD |
| 3301-001364 | BEAD-SMD |
|
|
BRACKET-STAND LINK;55UNU7100X, |
| 2402-001268 | C-AL, SMD |
| 2203-008315 | C-CER, CHIP |
| 2203-008096 | C-CER, CHIP |
| 2203-007544 | C-CER, CHIP |
| 2203-007423 | C-CER, CHIP |
| 2203-007306 | C-CER, CHIP |
| 2203-007176 | C-CER, CHIP |
| 2203-006844 | C-CER, CHIP |
| 2203-006698 | C-CER, CHIP |
| 2203-006158 | C-CER, CHIP |
| 2203-006126 | C-CER, CHIP |
| 2203-006048 | C-CER, CHIP |
| 2203-005993 | C-CER, CHIP |
| 2203-005968 | C-CER, CHIP |
| 2203-005642 | C-CER, CHIP |
| 2203-005249 | C-CER, CHIP |
| 2203-005083 | C-CER, CHIP |
| 2203-002285 | C-CER, CHIP |
| 2409-001240 | C-ORGANIC, SMD |
| 3701-001967 | CONNECTOR-HDMI |
|
|
CONNECTOR-OPTICAL |
| BN96-45656A | COVER ASSEMBLY P-REAR |
| BN63-16652A | COVER-TERMINAL SIDE |
| 2801-004021 | CRYSTAL-SMD |
|
|
DC VSS-PD BOARD |
| 0404-001976 | DIODE-SCHOTTKY |
| 0404-001953 | DIODE-SCHOTTKY |
| 0404-001640 | DIODE-SCHOTTKY |
| 0404-001404 | DIODE-SCHOTTKY |
| 0401-001056 | DIODE-SWITCHING |
| 0406-001786 | DIODE-TVS |
| 0406-001778 | DIODE-TVS |
| 0406-001718 | DIODE-TVS |
| 0505-003397 | FET-SILICON |
| 0505-003391 | FET-SILICON |
| 0505-003205 | FET-SILICON |
| 0505-002893 | FET-SILICON |
| 0505-002660 | FET-SILICON |
| 0505-002598 | FET-SILICON |
| 0505-002560 | FET-SILICON |
| 0505-001844 | FET-SILICON |
|
|
FFC CABLE |
|
|
FFC CABLE |
|
|
FUSE-SURFACE MOUNT |
| BN63-00520A | GASKET |
|
|
GENDER CABLE |
|
|
GENDER CABLE |
| 3711-008859 | HEADER-BOARD TO CABLE |
| 3711-008131 | HEADER-BOARD TO CABLE |
| 3711-007803 | HEADER-BOARD TO CABLE |
| 1001-001545 | IC-ANALOG MULTIPLEX |
| 1201-004117 | IC-AUDIO AMP |
| 1203-009067 | IC-DC/DC CONVERTER |
| 1203-009060 | IC-DC/DC CONVERTER |
| 1203-008920 | IC-DC/DC CONVERTER |
| 1203-008777 | IC-DC/DC CONVERTER |
| 1203-008139 | IC-DC/DC CONVERTER;TPS56C20PWP |
| 1105-002926 | IC-DDR4 SDRAM;H9HCNNN4KUMLHR,L |
| 1105-002925 | IC-DDR4 SDRAM;H9HCNNN8KUMLHR,L |
| 1204-003752 | IC-DECODER |
| 1107-002623 | IC-EMMC;KLM4G1FETE-B041,4GBYTE |
| 1003-002947 | IC-LEVEL DRIVER |
| 1107-002226 | IC-NOR FLASH |
| 1201-000166 | IC-OP AMP |
| 1203-009057 | IC-POSI.ADJUST REG. |
| 1205-005749 | IC-SWITCH |
| 1205-004692 | IC-SWITCH |
| 1203-008392 | IC-VOL. DETECTOR |
| 1203-004363 | IC-VOL. DETECTOR |
| 2703-005376 | INDUCTOR-SMD |
| 2703-005193 | INDUCTOR-SMD |
| 2703-005191 | INDUCTOR-SMD |
| 2703-004724 | INDUCTOR-SMD |
| 2703-003937 | INDUCTOR-SMD |
| 2703-003862 | INDUCTOR-SMD |
| 2703-003747 | INDUCTOR-SMD |
| 3722-003199 | JACK-MODULAR |
| 3722-003873 | JACK-PHONE |
| 3722-003814 | JACK-PHONE |
| BN68-00513A | LABEL-E, PASS |
| BN39-02217D | LEAD CONNECTOR-POWER |
| BN39-02231D | LEAD CONNECTOR-SUB ASSEMBLY |
|
|
NETWORK-WLAN CLIENT |
|
|
POWER CORD-DT |
| BN95-04769D | PRODUCT LCD-CSOT;CY-NN055HGHV4 |
| 2007-009777 | R-CHIP |
| 2007-009322 | R-CHIP |
| 2007-008596 | R-CHIP |
| 2007-008298 | R-CHIP |
| 2007-008294 | R-CHIP |
| 2007-008015 | R-CHIP |
| 2007-007992 | R-CHIP |
| 2007-007767 | R-CHIP |
| 2007-007736 | R-CHIP |
| 2007-007733 | R-CHIP |
| 2007-007520 | R-CHIP |
| 2007-007305 | R-CHIP |
| 2007-002906 | R-CHIP |
| 2007-002899 | R-CHIP |
| 2007-001125 | R-CHIP |
| 2007-000979 | R-CHIP |
| 2007-000779 | R-CHIP |
| 2007-000772 | R-CHIP |
| 2007-000066 | R-CHIP |
| 2007-000052 | R-CHIP |
| 2011-001587 | R-NETWORK |
| 2011-001264 | R-NETWORK |
|
|
SCREW-MACHINE |
|
|
SCREW-TAPTYPE |
| 0203-001602 | TAPE-OPP MASKING |
| 0203-001598 | TAPE-SINGLE FACE |
| 0504-000126 | TR-DIGITAL |
| 0501-000445 | TR-SMALL SIGNAL |
|
|
TUNER-DTV AIR CABLE |
|
|
TV REMOTE CONTROL |
|
|
USB JACK |
| 1405-001382 | VARISTOR |
| 1405-001381 | VARISTOR |
| 1405-001306 | VARISTOR |
|
|
VARISTOR |
| 1405-001232 | VARISTOR |
