Manufacturer
Samsung
Model Number
UN60F7100AFXZA
Description
60-inch Class (60.0-inch Diag.) Led 7100 Series Tv
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ASSY BOARD P-5WAY SWITCH FUNCTION;UN60F7 |
|
|
ASSY BOARD P-RF-MODULE;BLUETOOTH MODULE, |
|
|
ASSY CABLE P-FFC;UN60F7100,FFC,1 H,427MM |
|
|
ASSY CABLE P;IR BLASTER,IR BLASTER CABL, |
|
|
ASSY COVER P-MIDDLE;UF7100 60,MABS HB CL |
| BN96-26363E | ASSY COVER P-REAR;UF7100 60/65,NORTH AME |
|
|
ASSY GUIDE P-STAND;UF7100 60,PC+G/F 20% |
|
|
ASSY HOLDER P-RING;11 LED-TV |
|
|
ASSY PCB MAIN;UF7K |
|
|
ASSY SPEAKER P;6OHM,10W,ENCLOSURE_F7K |
|
|
ASSY STAND P-BASE;UF6400 60/65,W/W,CHROM |
|
|
ASSY T CON;217*150*1.2T,13Y SHARP 240HZ |
| 3301-000314 | BEAD-SMD;120OHM,1608,TP,120OHM/100MHZ |
|
|
BEAD-SMD;26OHM,1608,TP |
| 3301-001404 | BEAD-SMD;30OHM,2012,TP,15.9OHM/30MHZ |
| 2203-003039 | C-CER,CHIP;0.008NF,0.25PF,50V,C0G,TP,100 |
| 2203-001851 | C-CER,CHIP;0.016NF,5%,50V,NP0,TP,1608 |
| 2203-000292 | C-CER,CHIP;0.01NF,5%,50V,C0G,TP,1608 |
| 2203-005642 | C-CER,CHIP;0.22NF,5%,50V,NP0,TP,1005 |
| 2203-007513 | C-CER,CHIP;10000NF,10%,10V,X5R,TP,1608,0 |
| 2203-007176 | C-CER,CHIP;10000NF,10%,16V,X5R,TP,2012,1 |
| 2203-007306 | C-CER,CHIP;10000NF,10%,25V,X5R,TP,2012,1 |
| 2203-006090 | C-CER,CHIP;10000NF,10%,6.3V,X5R,TP,2012 |
| 2203-006348 | C-CER,CHIP;1000NF,10%,25V,X5R,TP,1608,0. |
| 2203-006698 | C-CER,CHIP;1000NF,10%,25V,X7R,TP,1608,0. |
| 2203-006960 | C-CER,CHIP;1000NF,10%,50V,X7R,TP,2012 |
| 2203-006048 | C-CER,CHIP;100NF,10%,10V,X7R,TP,1005 |
| 2203-006158 | C-CER,CHIP;100NF,10%,16V,X7R,TP,1005,0.5 |
| 2203-002711 | C-CER,CHIP;100NF,10%,25V,X7R,TP,1608 |
| 2203-005249 | C-CER,CHIP;100NF,10%,50V,X7R,TP,1608 |
| 2203-002720 | C-CER,CHIP;10NF,10%,25V,X7R,TP,1005,0.5T |
| 2203-002285 | C-CER,CHIP;10NF,10%,50V,X7R,TP,1005 |
| 2203-000257 | C-CER,CHIP;10NF,10%,50V,X7R,TP,1608 |
| 2203-007233 | C-CER,CHIP;22000NF,10%,16V,X5R,TP,3216,1 |
| 2203-006706 | C-CER,CHIP;2200NF,10%,50V,X7R,TP,3225 |
| 2203-000575 | C-CER,CHIP;220NF,10%,25V,X7R,TP,2012 |
| 2203-000576 | C-CER,CHIP;220NF,10%,50V,X7R,TP,3216 |
| 2203-005344 | C-CER,CHIP;22NF,10%,25V,X7R,TP,1005,0.5T |
| 2203-002398 | C-CER,CHIP;22NF,10%,50V,X7R,TP,1608 |
| 2203-005968 | C-CER,CHIP;4.7NF,10%,50V,X7R,TP,1005,0.5 |
| 2203-006377 | C-CER,CHIP;4700NF,10%,25V,X5R,TP,2012 |
| 2203-006126 | C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 |
| 2203-002519 | C-CER,CHIP;5.6NF,10%,50V,X7R,TP,1005 |
| 2503-001051 | C-NETWORK;100NFX4,20%,16V,2012 |
|
|
CBF-POWER CORD;DT,UL/CSA,LP-11L,125V,7A, |
|
|
CONNECTOR-FPC/FFC/PIC;80P,0.5MM,SMD-A,AU |
| 3701-001861 | CONNECTOR-HDMI;19P,2ROW,FEMALE,SMD-A,AU |
| 3701-001856 | CONNECTOR-HDMI;19P,2ROW,FEMALE,SMD-S,AU |
| 3711-002050 | CONNECTOR-HEADER;BOX,10P,1R,1.25MM,SMD-A |
| 3707-001106 | CONNECTOR-OPTICAL;STRAIGHT W/L,SPDIF |
| 2801-000102 | CRYSTAL-SMD;12MHZ,30PPM,12PF,100OHM,TP |
| 2801-004775 | CRYSTAL-SMD;12MHZ,30PPM,16PF,30OHM,TP |
| 2801-003326 | CRYSTAL-SMD;24MHZ,30PPM,28-ABX,20PF,50OH |
| 2801-003954 | CRYSTAL-SMD;27MHZ,30PPM,28-AAN,16PF,50OH |
| 0404-001643 | DIODE-SCHOTTKY;B360A,60V,3000MA,SMA,TP |
| 0404-001404 | DIODE-SCHOTTKY;BAT721C,40V,200MA,SOT-23, |
| 0404-001482 | DIODE-SCHOTTKY;RB055LA-40,40V,3000MA,PMD |
| 0404-001640 | DIODE-SCHOTTKY;SS1060HEWS,60V,1000MA,SOD |
| 0404-001271 | DIODE-SCHOTTKY;SSA34,40V,3000MA,SMA,TP |
| 0404-001307 | DIODE-SCHOTTKY;SSC54,40V,5000MA,DO-214AB |
| 0401-001056 | DIODE-SWITCHING;MMBD4148SE,100V,200MA,SO |
| 0406-001271 | DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251 |
| 0406-001445 | DIODE-TVS;RCLAMP7512N,2.7/2.8/2.9,300W,S |
| 0406-001438 | DIODE-TVS;SMCJ14A,15.6/-/17.2V,1500W,DO- |
| 0505-001905 | FET-SILICON;2N7002,N,60V,300MA,7.5OHM,.3 |
| 0505-000274 | FET-SILICON;AO4435L,P30V11A,0.014OHM |
| 0505-002925 | FET-SILICON;AO4438,N,60V,8.2A,3.1W,SOT-8 |
| 0505-002937 | FET-SILICON;AO4854L,DUAL N,30V,8A,2W,SOT |
| 0505-002645 | FET-SILICON;AOD4184A,N,40V,50A,0.007OHM, |
| 0505-002598 | FET-SILICON;AP2317GN,P20V4.2A,0.052O |
| 0505-001844 | FET-SILICON;SI4435DDY-T1-GE3,P30V11. |
| 3711-008441 | HEADER-BOARD TO CABLE;BOX,24P,2R,2MM,ANG |
|
|
HEADER-BOARD TO CABLE;BOX,26P,2R,1.25MM, |
| 3711-008131 | HEADER-BOARD TO CABLE;BOX,4P,1R,2.5MM,AN |
| 3711-005925 | HEADER-BOARD TO CABLE;BOX,51P,1R,0.5MM,S |
| 3711-005499 | HEADER-BOARD TO CABLE;BOX,8P,1R,1.25MM,S |
| 3711-005601 | HEADER-BOARD TO CABLE;BOX,8P,1R,2MM,SMD- |
| AA61-20285C | HOLDER-BOX;CORAL,PP,BLACK,HB,17.5G |
| 1001-001545 | IC-ANALOG MULTIPLEX;TS3USB221ERSER,R-PQF |
| 0801-002701 | IC-CMOS LOGIC;74VHCT125A,BUFFER,TSSOP,14 |
| 0801-003292 | IC-CMOS LOGIC;7WB66,BUS SWITCH,MAB08A,8P |
| 1203-007502 | IC-DC/DC CONVERTER;AOZ3011PI,SO-8,8Z30,4 |
| 1203-007215 | IC-DC/DC CONVERTER;SN1109048RHL,QFN,14P, |
| 1105-002264 | IC-DDR2 SDRAM;K4T51163QJ-BCF8,DDR2,512MB |
| 1105-002194 | IC-DDR3 SDRAM;K4B1G1646G-BCH9,DDR3 SDRAM |
| 1105-002430 | IC-DDR3 SDRAM;K4B2G1646E-BCMA,DDR3 1866, |
| 1105-002338 | IC-DDR3 SDRAM;K4B4G1646B-HCMA,DDR3 1866, |
| 1204-003421 | IC-DECODER;SEMS30,PBGA,729Z30,21.6X21.6M |
| 1204-003301 | IC-DECODER;VPP1552,FPBGA,324P,15 X 15 MM |
| 1006-001509 | IC-DRIVER/RECEIVER;MAX3222ECPWR,TSSOP,20 |
| 1103-001487 | IC-EEPROM;AT24C256C-SSHL-T,256KBIT,32KX8 |
| 1003-002412 | IC-LEVEL DRIVER;MAX17079GTL+,TR,40P,6X6X |
| 1205-004222 | IC-MULTIPLIER;THV3056,64P,9X9X0.9MM,PLAS |
| 1107-002077 | IC-NAND FLASH;KLM4G1FE3B-B001,4GBYTE,32G |
| 1107-001915 | IC-NOR FLASH;32MBIT,X1,SOP,8P,5.25X5.25M |
| 1201-002980 | IC-OP AMP;MAX9650ATA+,TDFN-EP,TP,8P,3*3M |
| 1203-006138 | IC-POSI.ADJUST REG.;AP1117DGZ-13-89,TO-2 |
| 1203-007242 | IC-POSI.ADJUST REG.;G2992BP11U,SOP-8,8P, |
| 1203-006136 | IC-POSI.FIXED REG.;AP1117D-18-GZ-13-89,T |
| 1203-006135 | IC-POSI.FIXED REG.;AP1117D-33-GZ-13-89,T |
| 1203-006130 | IC-POSI.FIXED REG.;S-1172B25-U5T1G,SOT-8 |
| 1203-006109 | IC-POSI.FIXED REG.;S-1206B33-M3T1G,SOT-2 |
| 1203-006806 | IC-POWER SUPERVISOR;ISL45041IRZ-T,8P,3X3 |
| 1209-001761 | IC-SENSOR;LM75ADP,TSSOP,8P,3.1X3.1MM,PLA |
| 1205-004447 | IC-SWITCH;TPS2051CDBVR,SOT23-5,5P,3X1.65 |
| 1204-003324 | IC-VIDEO PROCESS;SDP1111,FCBGA,768P,31X3 |
| 1203-004364 | IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, |
| 1203-007728 | IC-VOL. DETECTOR;RT9831GQW,QW : WQFN-20L |
| 1203-004363 | IC-VOL. DETECTOR;SOT-23,3Z30,2.9X1.6MM,P |
| 1203-006780 | IC-VOL. REFERENCE;MAX9697ATI+,TQFN,28P,5 |
| 2703-003713 | INDUCTOR-SMD;1.5UH,20%,7366,0.015OHM,700 |
| 2703-002804 | INDUCTOR-SMD;10UH,20%,12X12MM,0.022OHM,6 |
| 2703-003488 | INDUCTOR-SMD;10UH,20%,6965,0.071OHM,3500 |
| 2703-000158 | INDUCTOR-SMD;1UH,10%,2012,.4OHM,50MA,45, |
| 2703-003932 | INDUCTOR-SMD;22UH,20%,8080,0.075OHM,2500 |
| 2703-003930 | INDUCTOR-SMD;4.7UH,20%,5050,0.072OHM,245 |
| 2703-003790 | INDUCTOR-SMD;4.7UH,20%,8080,0.025OHM,450 |
| 3722-003229 | JACK-MODULAR;8P/8C W/L,Y,STRAIGHT,N,AU,1 |
| 3722-003617 | JACK-PHONE;14P/2C,SN,BLK,STRAIGHT,3.6PI, |
| 3722-003226 | JACK-PHONE;7P/1C,SN,BLK |
|
|
JACK-PIN;5P+SCREW HOLE,NI+SN,G,Y/BLU/RED |
|
|
JACK-USB;4P/1C,NI,BLK,A |
| BN39-01784A | LEAD CONNECTOR;7.1K SHARP 60INCH L LED W |
| BN39-01785A | LEAD CONNECTOR;7.1K SHARP 60INCH R LED W |
|
|
LEAD CONNECTOR;UN55F7500,LEAD CONNECTOR, |
|
|
NETWORK;WIDT-30Q,INTERNAL WIFI,USB,IEEE8 |
| 2806-001308 | OSCILLATOR-VCXO;27MHZ,30PF,TP,3.3V,50M |
|
|
POWER SUPPLY PCB DC VSS-LED TV PD BD;L60X2P_DHS,L60X2P_DH |
|
|
PRODUCT LCD-SHARP;LK600D3HD5K,CY-LF600DS |
| 2007-008714 | R-CHIP;0.01OHM,1%,1W,TP,6432 |
| 2007-000039 | R-CHIP;0OHM,1%,1/10W,TP,1608 |
| 2007-000029 | R-CHIP;0OHM,5%,1/8W,TP,2012 |
| 2007-007463 | R-CHIP;1.1KOHM,1%,1/16W,TP,1005 |
| 2007-000123 | R-CHIP;1.5KOHM,5%,1/10W,TP,1608 |
| 2007-000256 | R-CHIP;1.6KOHM,1%,1/10W,TP,1608 |
| 2007-000079 | R-CHIP;1.8KOHM,5%,1/10W,TP,1608 |
| 2007-000060 | R-CHIP;100KOHM,1%,1/10W,TP,1608 |
| 2007-000052 | R-CHIP;10KOHM,1%,1/10W,TP,1608 |
| 2007-008426 | R-CHIP;12.4KOHM,1%,1/10W,TP,1608 |
| 2007-000336 | R-CHIP;120KOHM,1%,1/10W,TP,1608 |
| 2007-007352 | R-CHIP;130KOHM,1%,1/10W,TP,1608 |
| 2007-007768 | R-CHIP;13KOHM,1%,1/10W,TP,1608 |
| 2007-000040 | R-CHIP;150OHM,1%,1/10W,TP,1608 |
| 2007-000043 | R-CHIP;1KOHM,1%,1/10W,TP,1608 |
| 2007-000078 | R-CHIP;1KOHM,5%,1/10W,TP,1608 |
| 2007-007942 | R-CHIP;1MOHM,1%,1/16W,TP,1005 |
| 2007-000109 | R-CHIP;1MOHM,5%,1/10W,TP,1608 |
| 2007-002425 | R-CHIP;1OHM,5%,1/10W,TP,1608 |
| 2007-000491 | R-CHIP;2.2KOHM,1%,1/10W,TP,1608 |
| 2007-003015 | R-CHIP;2.2OHM,5%,1/16W,TP,1005 |
| 2007-000509 | R-CHIP;2.4KOHM,1%,1/10W,TP,1608 |
| 2007-007767 | R-CHIP;200OHM,1%,1/16W,TP,1005 |
| 2007-000066 | R-CHIP;20KOHM,1%,1/10W,TP,1608 |
| 2007-000570 | R-CHIP;220OHM,1%,1/10W,TP,1608 |
| 2007-008649 | R-CHIP;220OHM,1%,1/16W,TP,1005 |
| 2007-000583 | R-CHIP;22KOHM,1%,1/10W,TP,1608 |
| 2007-000606 | R-CHIP;240OHM,1%,1/10W,TP,1608 |
| 2007-000614 | R-CHIP;24KOHM,1%,1/10W,TP,1608 |
| 2007-000695 | R-CHIP;3.3OHM,5%,1/10W,TP,1608 |
| 2007-007008 | R-CHIP;300OHM,5%,1/16W,TP,1005 |
| 2007-000736 | R-CHIP;30KOHM,1%,1/10W,TP,1608 |
| 2007-000772 | R-CHIP;33KOHM,1%,1/10W,TP,1608 |
| 2007-000779 | R-CHIP;33OHM,1%,1/10W,TP,1608 |
| 2007-008294 | R-CHIP;33OHM,1%,1/16W,TP,1005 |
| 2007-000799 | R-CHIP;360OHM,5%,1/10W,TP,1608 |
| 2007-000803 | R-CHIP;36KOHM,1%,1/10W,TP,1608 |
| 2007-000842 | R-CHIP;3KOHM,1%,1/10W,TP,1608 |
| 2007-000857 | R-CHIP;4.3KOHM,1%,1/10W,TP,1608 |
| 2007-000869 | R-CHIP;4.7KOHM,1%,1/10W,TP,1608 |
| 2007-000084 | R-CHIP;4.7KOHM,5%,1/10W,TP,1608 |
| 2007-000910 | R-CHIP;43KOHM,1%,1/10W,TP,1608 |
| 2007-000913 | R-CHIP;43KOHM,5%,1/10W,TP,1608 |
| 2007-007722 | R-CHIP;43OHM,1%,1/10W,TP,1608 |
| 2007-008298 | R-CHIP;49.9OHM,1%,1/16W,TP,1005 |
| 2007-000962 | R-CHIP;5.1KOHM,1%,1/10W,TP,1608 |
| 2007-000979 | R-CHIP;5.6KOHM,1%,1/10W,TP,1608 |
| 2007-008807 | R-CHIP;53.6KOHM,1%,1/16W,TP,1005 |
| 2007-008133 | R-CHIP;56.2KOHM,1%,1/10W,TP,1608 |
| 2007-001042 | R-CHIP;56OHM,1%,1/10W,TP,1608 |
| 2007-001056 | R-CHIP;6.2KOHM,5%,1/10W,TP,1608 |
| 2007-001093 | R-CHIP;620OHM,5%,1/10W,TP,1608 |
| 2007-001096 | R-CHIP;62KOHM,1%,1/10W,TP,1608 |
| 2007-001116 | R-CHIP;680OHM,1%,1/10W,TP,1608 |
| 2007-001125 | R-CHIP;68KOHM,1%,1/10W,TP,1608 |
| 2007-001139 | R-CHIP;7.5KOHM,1%,1/10W,TP,1608 |
| 2007-001153 | R-CHIP;750OHM,1%,1/10W,TP,1608 |
| 2007-007723 | R-CHIP;75KOHM,1%,1/10W,TP,1608 |
| 2007-008015 | R-CHIP;75OHM,1%,1/16W,TP,1005 |
| 2007-001168 | R-CHIP;75OHM,5%,1/4W,TP,3216 |
| 2007-007238 | R-CHIP;8.25KOHM,1%,1/10W,TP,1608 |
| 2007-001199 | R-CHIP;820OHM,1%,1/10W,TP,1608 |
| 2007-001206 | R-CHIP;82KOHM,1%,1/10W,TP,1608 |
| 2007-000127 | R-CHIP;9.1KOHM,5%,1/10W,TP,1608 |
| 2007-007331 | R-CHIP;90.9KOHM,1%,1/10W,TP,1608 |
| 2007-007431 | R-CHIP;91KOHM,1%,1/10W,TP,1608 |
| 2011-001587 | R-NETWORK;100OHM,5%,1/16W,L,CHIP-V,4P,TP |
| 2011-001506 | R-NETWORK;10KOHM,5%,1/16W,L,CHIP,4P,TP,1 |
| 2011-001264 | R-NETWORK;10OHM,5%,1/16W,L,CHIP,8P,TP,2. |
| 2011-001449 | R-NETWORK;22OHM,5%,1/16W,L,4P,TP,1010 |
| 2011-001262 | R-NETWORK;22OHM,5%,1/16W,L,CHIP,8P,TP,2. |
| 2011-001261 | R-NETWORK;33OHM,5%,1/16W,L,CHIP,8P,TP,2. |
| 2011-001527 | R-NETWORK;4.7KOHM,5%,1/16W,L,CHIP,4P,TP, |
|
|
REMOCON-SMART TOUCH CONTROL;TM1360,14,80 |
|
|
SCREW-MACHINE;BH,+,M3,L4,ZPC(WHT),SWRCH1 |
|
|
SCREW-MACHINE;BH,+,M3,L6,ZPC(BLK),SWRCH1 |
|
|
SCREW-MACHINE;BH,+,M3,L6,ZPC(WHT),SWRCH1 |
|
|
SCREW-MACHINE;CH,+,M3,L4,ZPC(BLK),SWRCH1 |
|
|
SCREW-MACHINE;PWH,+,M3.0,L5.0,ZPC(WHT),S |
|
|
SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) |
|
|
SCREW-TAPTYPE;BH,+,B,M3,L6,ZPC(BLK),SWRC |
|
|
SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR |
|
|
SCREW-TAPTYPE;BH,S,M4,L10,ZPC(BLK),SWRCH |
|
|
SCREW-TAPTYPE;FH,+,B,M4,L8,ZPC(BLK),SWRC |
| BN02-00043B | TAPE ETC-SHEET FIXING;NNB 32/40/46/55,3M |
| 0502-001365 | TR-POWER;KTA1040D,1000MW,DPAK,TR,100 |
| 0502-001364 | TR-POWER;KTC3573,1,500MW,PLASTIC,TR,150 |
| 0502-001360 | TR-POWER;STC405D,NPN,15000MW,TO-252 |
| 0501-002080 | TR-SMALL SIGNAL;2SC2412K,NPN,200MW,SC-59 |
| 0501-000279 | TR-SMALL SIGNAL;KSA1182-Y,PNP,150MW,SOT- |
| 0501-000445 | TR-SMALL SIGNAL;KTC3875S-Y,NPN,150MW,SOT |
|
|
TUNER;DTVS20EIH035A,DTVS20EIH035A,VSB-HA |
|
|
VARISTOR;35V,20VDC,5A,1.0X0.5X0.6MM,TP,1 |
