Manufacturer
Samsung
Model Number
UN65H6203AFXZA
Description
65-inch Class 1080p Led Smart Hdtv
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ASSY BOARD P-FUNCTION;UN65H6203,CT5000-9 |
|
|
ASSY CABLE P-FFC;UN65H6203,FFC,1H,550MM, |
|
|
ASSY CABLE P;IR BLASTER,UL1185 28AWG,2.5 |
| BN96-33449A | ASSY COVER P-MIDDLE REAR;H6203,65,ZA,PC+ |
| BN96-33334A | ASSY COVER P-REAR;UH6203 55",ZA,UO,PCM,T |
|
|
ASSY GUIDE P-STAND;UE6000,60,UO,ZA,PC+G/ |
| CALL_1-800-SAMSUNG | ASSY OPEN CELL;T650HVN05.1,10BITS,65INCH |
|
|
ASSY PCB MAIN;H6203 |
|
|
ASSY SPEAKER P;6OHM,4PIN,10W,ENCLOSURE T |
|
|
ASSY STAND P-BASE;PD530 59,PMMA+ABS HB(B |
|
|
ASSY T CON P;T650HVX,DF650-XX,8 BITS,65 |
| BN61-07962B | BRACKET-STNAD LINK;UE6030 55",SECC,T1.6, |
|
|
BRACKET-WALL;UE5000 46",EGI-SECC PL,T1.2 |
|
|
CBF-POWER CORD;DT,UL/CSA,LP-11L,125V,7A, |
| 3701-001856 | CONNECTOR-HDMI;19P,FEMALE,AU,0.5MM,BLK,S |
| 3707-001106 | CONNECTOR-OPTICAL;STRAIGHT W/L,SPDIF |
| 2801-003773 | CRYSTAL-SMD;12MHZ,30PPM,28-AAN,20PF,50OH |
| BN73-00052C | FOOT RUBBER;LCD TV,SI,T2.0 DIA19,GRAY |
| 3711-008453 | HEADER-BOARD TO CABLE;BOX,18P,2R,2MM,ANG |
|
|
HEADER-BOARD TO CABLE;BOX,26P,2R,1.25MM, |
| 3711-008131 | HEADER-BOARD TO CABLE;BOX,4P,1R,2.5MM,AN |
| AA61-20285C | HOLDER-BOX;CORAL,PP,BLACK,HB,17.5G |
|
|
HOLDER-WIRE STAND;UB7000 46INCH,PA66 |
| 3722-003229 | JACK-MODULAR;8P/8C W/L,Y,STRAIGHT,N,AU,1 |
| 3722-003667 | JACK-PHONE;1P/7C,SN/NI,BLK,STRAIGHT,3.6P |
| 3722-003226 | JACK-PHONE;7P/1C,SN,BLK |
|
|
JACK-PIN;5P+SCREW HOLE,NI+SN,G,Y/BLU/RED |
| 3722-003248 | JACK-USB;4P/1C(W/L),NI/PD/AU/SN,BLK,STRA |
|
|
LEAD CONNECTOR;UN55H6203,FLAT CONNECTOR, |
|
|
NETWORK-WIFI MODULE;WIDT-30Q,INTERNAL WI |
|
|
POWER BOARD TV PD BD;L65H1_EHS,L65H1_EHS, |
|
|
PRODUCT LCD-AUO;T650HVN05.1,CY-DF650CGAV |
|
|
REMOCON;TM1250A,49,3.0V,TM1250A_AMERICA_ |
|
|
SCREW-MACHINE;BH,+,M3,L4,ZPC(WHT),SWRCH1 |
|
|
SCREW-MACHINE;BH,+,M3,L6,ZPC(BLK),SWRCH1 |
|
|
SCREW-MACHINE;BH,+,M3,L6,ZPC(WHT),SWRCH1 |
|
|
SCREW-MACHINE;PWH,+,M3.0,L5.0,ZPC(WHT),S |
|
|
SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR |
|
|
SCREW-TAPTYPE;FH,+,-,B,M3,L8,ZPC(BLK),SW |
|
|
SCREW-TAPTYPE;FH,+,B,M4,L10,ZPC(WHT),SWR |
| BN40-00279B | TUNER;GVTH-F78B/FNS,GVTH-F78B/FNS,ATSC H |
