Manufacturer
Samsung
Model Number
XE500C12K02US
Description
Note,xe500c12i-exp,cel N2840,116hd Ns,4g
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ADAPTOR |
| BA92-14400A | ASSEMBLY BD CAM-TOP |
| BA92-14224A | ASSEMBLY BD SUB-TOP |
| BA98-00562A | ASSEMBLY BRACKET-PORT_L |
| BA98-00423A | ASSEMBLY BRACKET-PORT_L |
| BA98-00563A | ASSEMBLY BRACKET-PORT_R |
| BA98-00422A | ASSEMBLY BRACKET-PORT_R |
|
|
ASSEMBLY CASE FRONT-TOP |
|
|
ASSEMBLY CASE LOWER-FRONT |
| BA97-07248A | ASSEMBLY CASE REAR-BOTTOM |
| BA98-00561A | ASSEMBLY CASE REAR-BOTTOM(WLAN |
| BA97-07245A | ASSEMBLY CASE UPPER-BACK |
|
|
ASSEMBLY CASE UPPER-BACK(WLAN) |
| BA98-00449A | ASSEMBLY HINGE-L |
| BA98-00225A | ASSEMBLY HINGE-L |
| BA98-00450A | ASSEMBLY HINGE-R |
| BA98-00226A | ASSEMBLY HINGE-R |
| BA92-15210A | ASSEMBLY MOTHER BD-TOP |
| BA98-00153A | ASSEMBLY RUBBER-FOOT |
| BA98-00469A | ASSEMBLY RUBBER-SCREW_COVER |
| BA96-06804A | ASSEMBLY SPEAKER-LEFT |
| BA96-06804B | ASSEMBLY SPEAKER-RIGHT |
|
|
ASSEMBLY SVC LCD-SILVER |
| 6902-001018 | BAG PE |
| 6902-000468 | BAG PE |
| BA43-00370A | BATTERY-LUCAS2-11R_2C, 4080MAH |
| 3301-001649 | BEAD-SMD |
| BA61-02671A | BRACKET-CORNER_L |
| BA61-02665A | BRACKET-CORNER_L |
| BA61-02670A | BRACKET-CORNER_R |
| 2203-008158 | C-CER,CHIP |
| 2203-007486 | C-CER,CHIP |
| 2203-007456 | C-CER,CHIP |
| 2203-006399 | C-CER,CHIP |
| 2203-006348 | C-CER,CHIP |
| 2203-006260 | C-CER,CHIP |
| 2203-006166 | C-CER,CHIP |
| 2203-005344 | C-CER,CHIP |
| 2203-002720 | C-CER,CHIP |
| 2203-001656 | C-CER,CHIP |
| 2203-000799 | C-CER,CHIP |
| 2203-000627 | C-CER,CHIP |
| 2409-001159 | C-ORGANIC,SMD |
| 2409-001129 | C-POLYMER ,CHIP |
| BA59-03975A | CAMERA MODULE-CAMERA |
| BA39-01366A | CBF-LCD |
| 3711-008188 | CONNECTOR-BATTERY |
| 3708-003000 | CONNECTOR-FPC/FFC/PIC |
| 3708-002933 | CONNECTOR-FPC/FFC/PIC |
| 3708-002882 | CONNECTOR-FPC/FFC/PIC |
| 3301-001272 | CORE-FERRITEBEAD |
| BA63-01407C | COVER-SD |
| 0401-000132 | DIODE-SWITCHING |
| 0406-001271 | DIODE-TVS |
| 0505-002775 | FET-SILICON |
| 0505-002598 | FET-SILICON |
| 0505-002562 | FET-SILICON |
| 0505-001883 | FET-SILICON |
| 0505-001089 | FET-SILICON |
| 0505-001064 | FET-SILICON |
| BA41-02328A | FFC-CAMERA |
| BA41-02456A | FFC-SUB B D |
| BA41-02327A | FFC-TOUCHPAD |
| BA41-02406A | FPC-BRIDGE |
| BA62-00949A | HEAT SINK-CPU |
| 0801-003185 | IC-CMOS LOGIC |
| 1205-004892 | IC-CODEC |
| 1203-008352 | IC-DC/DC CONVERTER |
| 1203-007109 | IC-PWM CONTROLLER |
| 1205-005116 | IC-SWITCH |
|
|
JACK-DC POWER |
| 3722-003807 | JACK-PHONE |
| 3722-003809 | JACK-USB |
| 3722-003808 | JACK-USB |
| BA69-40072E | L |
| BA68-02744E | LABEL BAR CODE-BOX |
| BA68-01297A | LABEL CAUTION |
| BA68-04365A | LABEL ENERGY-STAR |
| BA68-40005L | LABEL-BARCODE |
| BA68-10191W | LABEL-BARCODE |
| BA68-10654A | LABEL-CPU-LOGO |
| BA68-20039A | LABEL-PPID_E |
| BA68-00386A | LABEL-SHIPPING |
| BA69-40254C | PACKING-PAD, OPTION |
| BA69-00052A | PACKING-PALLET |
| 2007-011665 | R-CHIP |
| 2007-009872 | R-CHIP |
| 2007-009768 | R-CHIP |
| 2007-009177 | R-CHIP |
| 2007-008791 | R-CHIP |
| 2007-008706 | R-CHIP |
| 2007-008676 | R-CHIP |
| 2007-008551 | R-CHIP |
| 2007-008359 | R-CHIP |
| 2007-008333 | R-CHIP |
| 2007-008304 | R-CHIP |
| 2007-008294 | R-CHIP |
| 2007-008167 | R-CHIP |
| 2007-008106 | R-CHIP |
| 2007-008032 | R-CHIP |
| 2007-008015 | R-CHIP |
| 2007-007942 | R-CHIP |
| 2007-007767 | R-CHIP |
| 2007-007668 | R-CHIP |
| 2007-007617 | R-CHIP |
| 2007-007463 | R-CHIP |
| 2007-007456 | R-CHIP |
| 2007-007329 | R-CHIP |
| 2007-002899 | R-CHIP |
| 2007-000969 | R-CHIP |
| 2007-000695 | R-CHIP |
| 2007-000309 | R-CHIP |
| 2007-000111 | R-CHIP |
| 2007-000039 | R-CHIP |
| 6001-002749 | SCREW-MACHINE |
| 6001-002712 | SCREW-MACHINE |
| 6001-001925 | SCREW-MACHINE |
| 6001-001626 | SCREW-MACHINE |
| 6001-001022 | SCREW-MACHINE |
| 0202-001791 | SOLDER-CREAM |
| 0203-002173 | TAPE-ATTACH MASKING |
| 0203-001869 | TAPE-KAPTONE |
| 0501-000465 | TR-SMALL SIGNAL |
