Model Image
Manufacturer

Sony

Model Number

AVC3450

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
1-131-341-00 1-131-341-00 0.1UF 35V CAP
8-719-921-20 8-719-921-20 1S2076A
3-645-824-00 3-645-824-00 BRACKET GRIP
3-645-814-00 3-645-814-00 BRACKET L
3-645-813-00 3-645-813-00 BRACKET LAMP
3-645-812-00 3-645-812-00 BRACKET PWB
3-645-816-00 3-645-816-00 BRACKET Y
3-645-829-00 3-645-829-00 BUSHING HOLDER
1-526-540-22 1-526-540-22 C.R.T. SOCKET
3-645-862-00 3-645-862-00 CASE SHIELD
9-911-839-99 9-911-839-99 CUSHION
8-719-939-39 8-719-939-39 DIODE
8-719-900-95 8-719-900-95 DIODE
3-645-801-00 3-645-801-00 HAND STRAP
3-645-852-00 3-645-852-00 HOLDER VIDICON
1-507-109-00 1-507-109-00 IF TERM
X-3645-801-0 X-3645-801-0 LENS MOUNT ASSY
X-3645-814-0 X-3645-814-0 LENS MOUNT ASSY
A-7511-076-A A-7511-076-A MCB, CHF
A-7511-075-A A-7511-075-A MCB,HVF
A-7511-074-A A-7511-074-A MCB,LPF
A-7511-078-A A-7511-078-A MCB,SWF
A-7511-077-A A-7511-077-A MCB,VFF
1-213-187-00 1-213-187-00 METAL FILM
1-106-363-00 1-106-363-00 MYLAR0.0068UF 200V
3-645-808-00 3-645-808-00 NAME PLATE USA
3-645-802-00 3-645-802-00 PANEL FRONT
X-3645-802-0 X-3645-802-0 POLE ASSY
3-645-819-00 3-645-819-00 RING A ADJ
3-645-820-00 3-645-820-00 RING B ADJ
3-645-863-00 3-645-863-00 RING SRING
3-645-833-00 3-645-833-00 SCREEN
3-643-981-00 3-643-981-00 SHADE LAMP
3-645-821-00 3-645-821-00 SHIELD PLATE A
3-645-809-00 3-645-809-00 SHIELD PLATE C
3-645-869-00 3-645-869-00 SHUTTEN RING
3-645-835-00 3-645-835-00 SPRING B
3-645-864-00 3-645-864-00 SUPPORT BOBBIN
3-645-818-00 3-645-818-00 SUPPORT CRT
3-645-815-00 3-645-815-00 SUPPORT DY
A-7612-067-A A-7612-067-A SWITCH ASSY
X-3645-804-0 X-3645-804-0 TOP PANEL ASSY
1-407-721-00 1-407-721-00 TRANSFORMER
8-729-119-79 8-729-119-79 TRANSISTORS
1-224-253-99 1-224-253-99 VARIABLE RES 22KH-B
3-645-834-00 3-645-834-00 VF BASE
1-435-010-00 1-435-010-00 XMFR, HOR BLKG OSC.
