Model Image
Manufacturer

Sony

Model Number

BRCH700

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
3-863-696-11 3-863-696-11 +BSW M2
3-986-860-01 3-986-860-01 +PSW 2.6X22
3-986-877-01 3-986-877-01 +PSW2.6X6
A-8286-220-B A-8286-220-B ASSY, BASE CABINET
9-910-999-UU 9-910-999-UU ASSY, BASE PLATE
X-3704-752-2 X-3704-752-2 ASSY, EXP CHASSIS SUB
X-3704-748-5 X-3704-748-5 ASSY, INNER CABINET
1-400-260-11 1-400-260-11 BEAD, FERRITE
3-986-892-01 3-986-892-01 BEARING T
3-743-242-01 3-743-242-01 BEARING, BALL
3-990-660-01 3-990-660-01 BRACKET(A), CEILING
3-990-659-02 3-990-659-02 BRACKET(B), CEILING
3-986-887-02 3-986-887-02 CABINET, FRONT
3-986-889-01 3-986-889-01 CABINET, LOWER
3-986-888-01 3-986-888-01 CABINET, UPPER
1-831-325-11 1-831-325-11 CABLE, FLEXIBLE FLAT (22, 21)
1-831-330-11 1-831-330-11 CABLE, FLEXIBLE FLAT (30 CORE)
1-831-328-11 1-831-328-11 CABLE, FLEXIBLE FLAT (30 CORE)
1-831-327-11 1-831-327-11 CABLE, FLEXIBLE FLAT (30 CORE)
3-986-864-01 3-986-864-01 CAP, CLAMP
3-986-851-03 3-986-851-03 CAP, INNER
3-986-856-02 3-986-856-02 CAP, OUTER(L)
3-986-857-02 3-986-857-02 CAP, OUTER(R)
A-1153-348-A A-1153-348-A CHASSIS ASSY, CN (WITH MOUNT)
3-986-884-02 3-986-884-02 CHASSIS LENS
X-2582-628-1 X-2582-628-1 CHASSIS SUB ASSY, TILT
3-986-894-01 3-986-894-01 CLANP, HARNESS
1-456-165-12 1-456-165-12 COIL, CHOKE (SMD)
1-764-705-61 1-764-705-61 CONNECTOR, FFC/FPC (LIF) 6P
1-764-528-51 1-764-528-51 CONNECTOR, FFC/FPC (ZIF) 21P
1-764-529-51 1-764-529-51 CONNECTOR, FFC/FPC (ZIF) 22P
1-573-362-61 1-573-362-61 CONNECTOR, FFC/FPC (ZIF) 22P
1-764-530-51 1-764-530-51 CONNECTOR, FFC/FPC (ZIF) 23P
1-784-421-71 1-784-421-71 CONNECTOR, FFC/FPC (ZIF) 27P
1-750-361-51 1-750-361-51 CONNECTOR, FFC/FPC (ZIF) 30P
1-784-424-71 1-784-424-71 CONNECTOR, FFC/FPC (ZIF) 51P
1-764-516-51 1-764-516-51 CONNECTOR, FFC/FPC (ZIF) 6P
1-766-621-71 1-766-621-71 CONNECTOR, FFC/FPC 10P
1-766-866-51 1-766-866-51 CONNECTOR, FFC/FPC 6P
1-766-336-61 1-766-336-61 CONNECTOR, FFC/FPC 6P
1-766-644-61 1-766-644-61 CONNECTOR, FFC/FPC 8P
3-986-826-01 3-986-826-01 COVER (T), FFC
A-8286-259-B A-8286-259-B COVER ASSY, BASE REAR
3-854-280-01 3-854-280-01 CUSHION
A-1153-349-A A-1153-349-A DC ASSY (WITH MOUNT)
8-719-049-22 8-719-049-22 DIODE CL-200D-C-TS
3-986-849-01 3-986-849-01 FLANGELESS BALL BEARING
3-986-848-01 3-986-848-01 FLANGELESS BALL BEARING
3-986-847-01 3-986-847-01 FLANGELESS BALL BEARING
3-986-905-01 3-986-905-01 GEAR, ND 1
3-986-904-01 3-986-904-01 GEAR, ND 2
A-8286-221-A A-8286-221-A HARNESS ASSY, LVDS
3-986-895-01 3-986-895-01 HARNESS CAP T
2-178-771-01 2-178-771-01 HEAT SINK (CCD)
3-986-896-01 3-986-896-01 HOLDER (TILT), BEARING
3-986-850-01 3-986-850-01 HOLDER, MAIN IR
6-806-643-03 6-806-643-03 IC EPCS4SI8N(11)-BRCH700-V102
6-715-303-01 6-715-303-01 IC EPCS4SI8N(11)-BRCH700-V102
6-808-204-01 6-808-204-01 IC HD64F2328BVTE-BRCH700-V105
6-600-796-01 6-600-796-01 IC TSOP38240
J-6433-530-A J-6433-530-A JIGU, KANIME(TILT)
9-910-999-40 9-910-999-40 MORTOR, STEPPING
1-787-782-22 1-787-782-22 MOTOR, STEPPING
1-787-782-12 1-787-782-12 MOTOR, STEPPING
A-1149-410-A A-1149-410-A MOUNTED C.BOARD, AD-175
A-1172-922-A A-1172-922-A MOUNTED C.BOARD, AD-175G
A-1149-401-A A-1149-401-A MOUNTED C.BOARD, CC-96
A-1149-405-A A-1149-405-A MOUNTED C.BOARD, CN-2746
A-1149-411-A A-1149-411-A MOUNTED C.BOARD, DD-41
A-1149-403-A A-1149-403-A MOUNTED C.BOARD, DI-45
A-1149-414-A A-1149-414-A MOUNTED C.BOARD, DR-585
A-1551-552-A A-1551-552-A MOUNTED C.BOARD, DR-585(S)
A-1149-408-A A-1149-408-A MOUNTED C.BOARD, IR-38
A-1149-412-A A-1149-412-A MOUNTED C.BOARD, LED-446
A-1149-406-A A-1149-406-A MOUNTED C.BOARD, PS-711
A-1149-415-A A-1149-415-A MOUNTED C.BOARD, SE-821
A-1172-923-A A-1172-923-A MOUNTED C.BOARD, SE-821G
A-1149-413-A A-1149-413-A MOUNTED C.BOARD, TSI-56
A-1149-409-A A-1149-409-A MOUNTED C.BOARD, VC-2
A-1175-823-A A-1175-823-A MOUNTED C.BOARD, VC-2G
3-903-974-51 3-903-974-51 OPERATING INSTRUCTIONS
3-903-974-44 3-903-974-44 OPERATING INSTRUCTIONS
3-903-974-34 3-903-974-34 OPERATING INSTRUCTIONS
3-903-974-24 3-903-974-24 OPERATING INSTRUCTIONS
3-903-974-15 3-903-974-15 OPERATING INSTRUCTIONS
3-903-974-05 3-903-974-05 OPERATING INSTRUCTIONS
1-813-702-11 1-813-702-11 OSCILLATOR, CRYSTAL (VCXO)
1-813-701-11 1-813-701-11 OSCILLATOR, CRYSTAL (VCXO)
1-819-855-11 1-819-855-11 PIN (PWB USE STRAIGHT) 9P
3-986-902-01 3-986-902-01 PLATE, BASE
3-854-278-01 3-854-278-01 PLATE, MOTOR
A-1166-018-A A-1166-018-A PRISM ASSY (RP), H700
1-678-019-21 1-678-019-21 PWB, FP-234 FLEXIBLE
J-6433-570-A J-6433-570-A REVERSED STAND TOOL
3-990-630-01 3-990-630-01 ROPE, WIRE
7-621-775-70 7-621-775-70 SCREW +B2.6X14(EP-FE/ZNBK/CM2)
3-986-903-02 3-986-903-02 SENSOR SHUTTER P
3-986-893-03 3-986-893-03 SENSOR SHUTTER T
9-968-221-02 9-968-221-02 SERVICE MANUAL
9-968-220-01 9-968-220-01 SERVICE MANUAL
A-8286-219-A A-8286-219-A SHAFT ASSY, PAN
3-986-885-01 3-986-885-01 SHAFT R
4-535-761-01 4-535-761-01 SHEET, VIBRATION PROOF
3-863-160-01 3-863-160-01 SPACER2.6X17
3-986-891-01 3-986-891-01 SPRING, CLICK
3-990-384-01 3-990-384-01 SPRING, SHIELD
A-1153-347-A A-1153-347-A SY-335 ASSY (WITH MOUNT)
A-1551-558-A A-1551-558-A SY-355(S) ASSY (WITH MOUNT)
6-552-376-01 6-552-376-01 TR DRC9114T0K8
6-552-385-01 6-552-385-01 TR DRC9144E0K8
6-552-386-01 6-552-386-01 TR DRC9144E0L
6-552-338-01 6-552-338-01 TR DSA9001R0K8
6-551-780-01 6-551-780-01 TR UNR91A2G0LS0
6-551-797-01 6-551-797-01 TR UNR92A3G0LS0
6-551-800-01 6-551-800-01 TR UNR92A5G08S0
1-443-855-11 1-443-855-11 TRANSFORMER, DC-DC CONVERTER
8-729-041-23 8-729-041-23 TRANSISTOR NDS356AP
3-986-898-01 3-986-898-01 WASHER (T)
3-986-900-01 3-986-900-01 WASHER, P
3-990-382-01 3-990-382-01 WASHER, WAVE
3-986-845-01 3-986-845-01 WASHER, WAVE
