Model Image
Manufacturer

Sony

Model Number

CFM140

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
1-501-437-11 1-501-437-11 ANTENNA, TELESCOPIC
1-402-405-11 1-402-405-11 ANTENNA,FERRITE-BAR (MW)
3-362-959-01 3-362-959-01 ARM, IDLER
3-362-987-01 3-362-987-01 ARM,EH
3-348-377-01 3-348-377-01 ARM,P
3-391-588-01 3-391-588-01 BASE PLATE ASSY
3-394-725-01 3-394-725-01 BELT-Q (SQUARE) (RBR)
X-3599-123-3 X-3599-123-3 BLACK CASSETTE LID
3-391-546-01 3-391-546-01 BRACKET,ANT
3-391-529-01 3-391-529-01 BRACKET,REC
1-164-019-11 1-164-019-11 CAPACITOR,CERAMIC 10PF CH
1-137-015-11 1-137-015-11 CAPACITOR,FILM 0.0047MF
3-391-572-01 3-391-572-01 CHASSIS ASSY MAIN
1-557-287-11 1-557-287-11 CORD,POWER
3-394-735-01 3-394-735-01 CUSHION (LEFT)
3-391-521-01 3-391-521-01 DIAL WHEEL (B)
1-543-777-11 1-543-777-11 HEAD,MAGNETIC (ERASING)
1-543-410-11 1-543-410-11 HEAD,MAGNETIC (REC/PB)
3-362-986-01 3-362-986-01 HOLDER,HEAD
8-759-821-14 8-759-821-14 IC LA4160
3-362-965-01 3-362-965-01 IDLER, FF
3-391-523-01 3-391-523-01 KNOB DECK,POUSE
3-391-528-01 3-391-528-01 KNOB DECK,REC
3-391-524-01 3-391-524-01 KNOB DECK,STOP
3-362-968-01 3-362-968-01 LEVER, EJECT
3-933-845-01 3-933-845-01 LEVER, EJECT SLIDE
3-394-738-01 3-394-738-01 LEVER, PLAY BUTTON
3-348-368-01 3-348-368-01 LEVER, REC SAFETY
3-362-976-01 3-362-976-01 LEVER,CONTROL
3-933-802-01 3-933-802-01 LEVER,FF BUTTON
3-362-975-01 3-362-975-01 LEVER,SENSOR
X-3598-123-6 X-3598-123-6 LID ASSY, CASSETTE(WHITE)
3-363-230-01 3-363-230-01 LUG
3-362-982-01 3-362-982-01 PINCH ROLLER
X-3598-122-7 X-3598-122-7 PINK FRONT CABINET ASSY
X-3598-123-7 X-3598-123-7 PINK LID CASSETTE ASSY
3-348-322-01 3-348-322-01 PLATE,FUNCTION,SWITCH
3-391-516-01 3-391-516-01 POINTER
X-3363-611-1 X-3363-611-1 REEL ASSY
3-362-962-01 3-362-962-01 REEL ASSY, T
3-366-352-01 3-366-352-01 SCREW
7-621-772-30 7-621-772-30 SCREW
3-362-958-01 3-362-958-01 SCREW
3-362-972-01 3-362-972-01 SENSOR
1-544-151-11 1-544-151-11 SPEAKER
3-362-961-01 3-362-961-01 SPINDLE (BASE)
3-362-957-01 3-362-957-01 SPRING
3-363-228-01 3-363-228-01 SPRING (COIL)
3-362-985-01 3-362-985-01 SPRING (COIL)
3-362-983-01 3-362-983-01 SPRING (COIL)
3-362-977-01 3-362-977-01 SPRING (COIL)
3-362-971-01 3-362-971-01 SPRING (COIL)
3-362-970-01 3-362-970-01 SPRING (COIL)
3-362-956-01 3-362-956-01 SPRING (COIL)
3-362-955-01 3-362-955-01 SPRING (COIL)
3-362-954-01 3-362-954-01 SPRING (COIL)
3-362-945-01 3-362-945-01 SPRING (COIL)
3-933-820-01 3-933-820-01 SPRING PANEL P(COIL)
3-362-967-01 3-362-967-01 SPRING, CASSETTE (COIL)
3-362-978-01 3-362-978-01 SPRING, PLATE
3-597-529-01 3-597-529-01 SPRING,DIAL
3-362-944-01 3-362-944-01 STOPPER, REC
1-572-538-11 1-572-538-11 SWITCH,LEAF
1-450-232-11 1-450-232-11 TRANSFORMER,POWER 0.5KVA
3-362-980-01 3-362-980-01 WASHER
X-3598-122-4 X-3598-122-4 WHITE FRONT CABINET ASSY
