Model Image
Manufacturer

Sony

Model Number

CFSW50

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
8-729-178-63 8-729-178-63 2SC1674TP-M TRANSISTOR
1-136-172-00 1-136-172-00 50V 0.39MF FILM CAPACITOR
1-807-781-11 1-807-781-11 AA1A4M TRANSISTOR
1-402-271-11 1-402-271-11 ANTENNA,FERRITE-ROD
1-501-222-31 1-501-222-31 ANTENNA,TELESCOPIC
3-339-393-01 3-339-393-01 ARM,SW
3-325-664-01 3-325-664-01 BRACKET,MOTOR
3-339-399-01 3-339-399-01 BUTTON(A),PRESET
3-340-302-01 3-340-302-01 BUTTON,MEMORY
3-325-637-01 3-325-637-01 BUTTON,PAUSE
3-339-398-01 3-339-398-01 BUTTON,REC MUTE
1-141-362-31 1-141-362-31 CAP, VAR FILM TRIMMER
3-341-172-01 3-341-172-01 CASE (D.D.CON.), SHIELD
3-340-325-01 3-340-325-01 CHASSIS
X-4920-348-1 X-4920-348-1 CHASSIS (S)ASSY,MECHANICA
X-3325-604-1 X-3325-604-1 CHASSIS ASSY,SHEET METAL
3-325-642-01 3-325-642-01 CHASSIS,GRAPHIC EQUALIZER
1-426-277-11 1-426-277-11 COIL,FM RF
1-563-209-11 1-563-209-11 CONNECTOR, SMALL MICRO 9P
1-562-680-41 1-562-680-41 CONNECTOR,SMALL MICRO 2P
1-562-680-31 1-562-680-31 CONNECTOR,SMALL MICRO 2P
1-562-680-21 1-562-680-21 CONNECTOR,SMALL MICRO 2P
1-562-681-11 1-562-681-11 CONNECTOR,SMALL MICRO 4P
1-559-158-11 1-559-158-11 CORD,POWER
3-340-329-01 3-340-329-01 CUSHION (UPPER)
3-325-611-01 3-325-611-01 CUSHION,MICROPHONE
3-325-607-41 3-325-607-41 ESCUTCHEON,SPEAKER
3-325-607-01 3-325-607-01 ESCUTCHEON,SPEAKER(WHITE)
1-567-777-11 1-567-777-11 FILTER,CERAMIC
X-3339-323-1 X-3339-323-1 FRONT CABINET
1-500-126-11 1-500-126-11 HEAD,MAGNETIC (REC/PB)
3-343-004-01 3-343-004-01 HEAT SINK
X-3362-198-1 X-3362-198-1 HOLDER (R) ASSY (A), CASS
X-3339-380-1 X-3339-380-1 HOLDER (RIGHT)ASSY (B)CAS
1-563-976-11 1-563-976-11 HOUSING,CONNECTOR
8-759-140-88 8-759-140-88 IC UPD1715G-541-21
8-719-980-71 8-719-980-71 KIODE SVC342L-V
3-325-604-11 3-325-604-11 KNOB,GRAPHIC EQUALIZER(BL
1-807-864-21 1-807-864-21 KSR1002 TRANSISTOR
3-329-310-01 3-329-310-01 LABEL,MODEL NUMBER
4-930-482-01 4-930-482-01 LEVER (A),FF
4-930-454-01 4-930-454-01 LEVER (A),REW
4-934-511-01 4-934-511-01 LEVER (S),REC
4-930-458-01 4-930-458-01 LEVER,PAUSE
3-325-667-01 3-325-667-01 LEVER,PLAY
3-325-665-01 3-325-665-01 LEVER,STOP
3-341-130-01 3-341-130-01 LOWER CUSHION
3-325-682-01 3-325-682-01 LUG,PLATE, T 0.3
1-410-517-11 1-410-517-11 MICRO INDUCTOR
1-410-332-11 1-410-332-11 MICRO INDUCTOR
3-325-609-21 3-325-609-21 NET,SPEAKER(BLACK)
3-325-609-31 3-325-609-31 NET,SPEAKER(RED)
3-325-609-01 3-325-609-01 NET,SPEAKER(WHITE)
1-618-294-11 1-618-294-11 PCB,LED
1-618-290-11 1-618-290-11 PCB,MD
3-325-688-01 3-325-688-01 PETAINER,SWITCH LEVER
1-566-497-11 1-566-497-11 PIN,CONNECTOR
1-564-784-11 1-564-784-11 PIN,CONNECTOR 6P
X-3325-603-1 X-3325-603-1 PLATE ASSY,REC
3-352-386-01 3-352-386-01 PLATE(D),SHIELD
3-341-159-01 3-341-159-01 PLATE,SHIELD
1-564-777-41 1-564-777-41 PLUG, CONNECTOR (2.5MM) 2
1-566-690-11 1-566-690-11 PLUG, CONNECTOR (2.5MM) 2
1-506-783-11 1-506-783-11 PLUG, CONNECTOR (2.5MM) 9
3-325-610-01 3-325-610-01 POINTER
X-3325-633-1 X-3325-633-1 RED CABINET
3-341-155-01 3-341-155-01 REINFORCEMENT
3-325-644-01 3-325-644-01 REINFORCEMENT
1-241-036-21 1-241-036-21 RESISTOR,ADJ,CARBON
4-932-606-01 4-932-606-01 RETAINER (33)
3-325-698-01 3-325-698-01 RING,RETAINING
3-329-301-01 3-329-301-01 SCREW (2.6X3),TAPPING(S-T
3-343-251-01 3-343-251-01 SCREW(M2.6X2.5),+P PAN
3-325-654-01 3-325-654-01 SHAFT,EJECT LEVER
3-340-305-01 3-340-305-01 SPACER,SW
3-325-657-01 3-325-657-01 SPRING (S
3-325-655-01 3-325-655-01 SPRING (S
3-325-694-01 3-325-694-01 SPRING,TENSION
3-322-924-01 3-322-924-01 SPRING,TENSION (S
8-719-918-65 8-719-918-65 SR106D-4 DIODE
3-325-680-01 3-325-680-01 STOPPER,SPEAKER
1-554-627-00 1-554-627-00 SWITCH,LEAF
3-340-395-01 3-340-395-01 TERMINAL BOARD(B),BATTERY
3-340-315-01 3-340-315-01 TERMINAL BOARD,ANTENNA
3-325-615-01 3-325-615-01 TERMINAL BOARD,ANTENNA
3-340-313-01 3-340-313-01 TERMINAL,BATTERY
1-448-319-11 1-448-319-11 TRANSFORMER,DC/DC CONVERT
8-729-206-25 8-729-206-25 TRANSISTOR RN1207
3-341-128-01 3-341-128-01 UPPER CUSHION
1-567-769-11 1-567-769-11 VIBRATOR,CRYSTAL
3-701-437-51 3-701-437-51 WASHER
3-325-695-01 3-325-695-01 WASHER
3-681-678-00 3-681-678-00 WASHER,STOPPER
X-4920-923-1 X-4920-923-1 WHEEL (W) ASSY,CAPSTAN
