Model Image
Manufacturer

Sony

Model Number

CSM100BSS

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
A-8308-329-B A-8308-329-B ARM (L) BLOCK ASSY, FL
A-8308-328-B A-8308-328-B ARM (R) BLOCK ASSY, FL
X-4625-703-1 X-4625-703-1 ARM ASSY, HLG
X-4625-704-1 X-4625-704-1 ARM ASSY, HLG DRIVE
X-4625-705-1 X-4625-705-1 ARM ASSY, HLG SUB
A-8308-321-A A-8308-321-A ARM BLOCK ASSY, PINCH
4-669-214-01 4-669-214-01 ARM, CHUCK DETECTION
4-671-311-01 4-671-311-01 ARM, HLG DRIVE SUB
4-669-282-01 4-669-282-01 ARM, PINCH SUB
4-669-205-01 4-669-205-01 ARM, UD LOCK
4-676-529-01 4-676-529-01 BACK (FD), BOTTLE
A-8308-748-B A-8308-748-B BASE (LOWER) ASSY, Y
A-8346-914-A A-8346-914-A BASE ASSY, CARRIER
3-179-470-01 3-179-470-01 BEARING
4-676-577-01 4-676-577-01 BELT (351-3GT-9), Y MOTOR
4-676-574-01 4-676-574-01 BELT (MA3-1018), Y PULLEY
4-676-576-01 4-676-576-01 BELT(BASIC)(MA5-246), X P
X-4625-455-1 X-4625-455-1 BEZEL ASSY
4-676-299-01 4-676-299-01 BLOCK, Y BELT HOLDING
A-8308-741-C A-8308-741-C BOTTLE ASSY
A-8308-978-C A-8308-978-C BOX ASSY, GEAR
X-4626-158-1 X-4626-158-1 BRACKET (REAR-B) ASSY
4-676-535-01 4-676-535-01 BRACKET (X), DR-513
4-676-316-01 4-676-316-01 BRACKET (YR), Y CABLE
4-676-537-01 4-676-537-01 BRACKET, CB-117
4-676-487-01 4-676-487-01 BRACKET, CB-120
4-677-167-01 4-677-167-01 BRACKET, DR-513
4-676-379-01 4-676-379-01 BRACKET, PROTRUDE SENSOR
4-676-532-01 4-676-532-01 BRACKET, X BELT HOLDER
4-676-506-01 4-676-506-01 BRACKET, Y HARNESS
4-676-294-01 4-676-294-01 BRACKET, Y MOTOR
4-676-320-01 4-676-320-01 BRACKET, Y SENSOR
A-8308-343-A A-8308-343-A BRAKE (T) BLOCK ASSY, REE
2-363-801-01 2-363-801-01 BUSHING, BEARING
1-100-443-91 1-100-443-91 CAP, ELECT 47MF (
1-128-555-11 1-128-555-11 CAPACITOR, ELECT 470MF/63
A-8308-767-A A-8308-767-A CASTER ASSY
A-8346-953-C A-8346-953-C CB-117COMPLETE PC BOARD
A-8346-955-A A-8346-955-A CB-118 COMPLETE PC BOARD
A-8346-975-C A-8346-975-C CB-120 COMPLETE PC BOARD
A-8346-981-B A-8346-981-B CB-121 COMPLETE PC BOARD
A-8307-163-B A-8307-163-B CB-122 COMPLETE PC BOARD
A-8346-906-A A-8346-906-A CHASSIS (CAP) ASSY, AMPLI
X-4625-706-3 X-4625-706-3 CHASSIS ASSY, HLG
4-617-314-01 4-617-314-01 CLAMP
4-630-973-01 4-630-973-01 CLAMP, CORD
A-8308-332-A A-8308-332-A COASTER BLOCK ASSY, TB
1-419-362-21 1-419-362-21 COIL, CHOKE 11UH
1-409-530-11 1-409-530-11 COIL, CHOKE 15UH
1-419-823-11 1-419-823-11 COIL, CHOKE 33UH
1-815-570-11 1-815-570-11 CONNECTOR, BOARD TO BOARD
1-785-524-11 1-785-524-11 CONNECTOR, DYNAMIC
1-785-516-11 1-785-516-11 CONNECTOR, DYNAMIC (10P)
1-817-223-21 1-817-223-21 CONNECTOR, FFC/FPC (13P)
1-817-222-21 1-817-222-21 CONNECTOR, FFC/FPC (15P)
1-817-227-21 1-817-227-21 CONNECTOR, FFC/FPC (16P)
1-817-221-21 1-817-221-21 CONNECTOR, FFC/FPC (18P)
1-817-226-21 1-817-226-21 CONNECTOR, FFC/FPC (20P)
1-817-230-21 1-817-230-21 CONNECTOR, FFC/FPC (24P)
1-817-225-21 1-817-225-21 CONNECTOR, FFC/FPC (24P)
1-817-229-21 1-817-229-21 CONNECTOR, FFC/FPC (32P)
1-817-220-21 1-817-220-21 CONNECTOR, FFC/FPC (32P)
1-817-231-21 1-817-231-21 CONNECTOR, FFC/FPC (34P)
1-817-224-21 1-817-224-21 CONNECTOR, FFC/FPC (5P)
1-817-228-21 1-817-228-21 CONNECTOR, FFC/FPC (6P)
1-757-676-41 1-757-676-41 CORD 1.5M, CONNECTION
1-757-676-51 1-757-676-51 CORD 2.5M, CONNECTION
1-824-099-11 1-824-099-11 CORD, CONNECTION
1-827-630-11 1-827-630-11 CORD, CONNECTION(DISPLAY
1-827-629-11 1-827-629-11 CORD, CONNECTION(K/M EXTE
4-671-322-02 4-671-322-02 COVER (HLG MOTOR)
4-668-901-01 4-668-901-01 COVER (LB)
4-668-902-01 4-668-902-01 COVER (PINCH)
4-669-239-03 4-669-239-03 COVER, BOTTOM
4-676-820-01 4-676-820-01 COVER, DEBUG CONNECTOR
3-628-472-02 3-628-472-02 COVER,LED
A-8346-979-C A-8346-979-C CPU-361 COMPLETE PC BOARD
8-719-016-93 8-719-016-93 DIODE 02DZ3.0-TPH3
6-500-538-01 6-500-538-01 DIODE PTZFTE2515B
6-500-536-01 6-500-536-01 DIODE PTZFTE256.2A
A-8307-159-B A-8307-159-B DP-373 COMPLETE PC BOARD
A-8347-001-A A-8347-001-A DR-512 COMPLETE PC BOARD
A-8346-983-C A-8346-983-C DR-514 COMPLETE PC BOARD
1-763-954-11 1-763-954-11 FAN, DC
1-416-976-11 1-416-976-11 FERRITE, EMI (SMD)
1-824-875-11 1-824-875-11 FFC (C/R-MOTOR)
1-824-874-11 1-824-874-11 FFC (DRUM-MOTOR)
1-824-871-11 1-824-871-11 FFC (FL-TE)
1-824-876-11 1-824-876-11 FFC (FRONT-PANEL)
1-824-872-11 1-824-872-11 FFC (MS-BRD)
1-824-868-11 1-824-868-11 FFC (RELAY-BRD-A)
1-824-869-12 1-824-869-12 FFC (RELAY-BRD-B)
1-824-870-12 1-824-870-12 FFC (RELAY-BRD-C)
1-824-877-11 1-824-877-11 FFC (SERIAL-BRD)
1-824-865-11 1-824-865-11 FFC (TB-CHK-SEN)
1-824-864-11 1-824-864-11 FFC (TB-ULE-SEN)
1-824-866-12 1-824-866-12 FFC (TP-FWD/RVS)
1-824-867-11 1-824-867-11 FFC (TREEL-MOTOR)
3-628-511-02 3-628-511-02 FILTER
A-8351-095-A A-8351-095-A FL BLOCK ASSY
4-676-573-01 4-676-573-01 FLEX (X), RUNNER
4-676-572-01 4-676-572-01 FLEX (Y), RUNNER
2-990-549-01 2-990-549-01 FOOT, RUBBER
1-576-658-21 1-576-658-21 FUSE, CHIP
1-576-700-21 1-576-700-21 FUSE-LINKS (10A)
1-576-699-21 1-576-699-21 FUSE-LINKS (8A)
4-671-882-01 4-671-882-01 GASKET (A)
4-671-881-02 4-671-881-02 GASKET (NOAH)
3-629-331-01 3-629-331-01 GASKET,SHIELD(3X10)
3-629-800-01 3-629-800-01 GASKET,SHIELD(5X5)
3-608-503-01 3-608-503-01 GASKET,SHILD(L)
4-668-962-01 4-668-962-01 GEAR (C), FL
4-668-963-01 4-668-963-01 GEAR (D), FL
4-673-252-01 4-673-252-01 GEAR (HLG MOTOR) (1)
4-673-253-01 4-673-253-01 GEAR (HLG MOTOR) (2)
X-4625-454-1 X-4625-454-1 GEAR (LB) ASSY, WORM RELA
4-668-908-02 4-668-908-02 GEAR (MS), RELAY
4-668-904-01 4-668-904-01 GEAR (PINCH PRESS)
X-4625-453-1 X-4625-453-1 GEAR (RING-TG7) ASSY, REL
A-8308-339-D A-8308-339-D GEAR ASSY, RING
4-669-265-03 4-669-265-03 GEAR, CAM
4-668-979-01 4-668-979-01 GEAR, COMMUNICATION
4-669-215-01 4-669-215-01 GEAR, EJECT
4-669-030-01 4-669-030-01 GEAR, FL WORM
4-668-911-02 4-668-911-02 GEAR, PINCH CAM
3-628-768-01 3-628-768-01 GUIDE,MAGAZINE(3)
3-633-376-01 3-633-376-01 GUIDE,MAGAZINE(5)
1-962-133-11 1-962-133-11 HARNESS (HL-SEN)
1-962-479-11 1-962-479-11 HARNESS, SUB (AITDR1)
1-962-480-11 1-962-480-11 HARNESS, SUB (AITDR2)
1-962-495-11 1-962-495-11 HARNESS, SUB (CB-CB-CPU)
1-962-424-11 1-962-424-11 HARNESS, SUB (CB-CPU1)
1-962-425-11 1-962-425-11 HARNESS, SUB (CB-CPU2)
1-962-426-11 1-962-426-11 HARNESS, SUB (CB-DP)
1-962-427-11 1-962-427-11 HARNESS, SUB (CB-PS)
1-962-423-11 1-962-423-11 HARNESS, SUB (CB-PS)
1-962-503-11 1-962-503-11 HARNESS, SUB (CB-PS1)
1-962-451-11 1-962-451-11 HARNESS, SUB (CB-RC-FFC12
1-962-452-11 1-962-452-11 HARNESS, SUB (CB-RC-FFC14
1-962-449-11 1-962-449-11 HARNESS, SUB (CB-RC-X)
1-962-445-11 1-962-445-11 HARNESS, SUB (CB-RC-Y)
1-962-448-11 1-962-448-11 HARNESS, SUB (CB-SE-BELT)
1-962-428-31 1-962-428-31 HARNESS, SUB (CB-SE-CS)
1-962-428-11 1-962-428-11 HARNESS, SUB (CB-SE-CS)
1-962-447-11 1-962-447-11 HARNESS, SUB (CB-SE-X)
1-962-430-11 1-962-430-11 HARNESS, SUB (CB-TS1)
1-962-504-11 1-962-504-11 HARNESS, SUB (CB-USB)
1-962-434-11 1-962-434-11 HARNESS, SUB (CPU-CB)
1-962-429-11 1-962-429-11 HARNESS, SUB (CPU-DR)
1-962-481-11 1-962-481-11 HARNESS, SUB (DCAIT)
1-962-450-11 1-962-450-11 HARNESS, SUB (DR-RC-X)
1-962-446-11 1-962-446-11 HARNESS, SUB (DR-RC-Y)
1-962-459-11 1-962-459-11 HARNESS, SUB (DR-SE-SENS1
1-962-460-11 1-962-460-11 HARNESS, SUB (DR-SE-SENS2
1-962-458-11 1-962-458-11 HARNESS, SUB (DR-SE-TRANS
1-960-978-11 1-960-978-11 HARNESS, SUB (LCD)
1-962-417-11 1-962-417-11 HARNESS, SUB (LF-BR)
1-962-483-11 1-962-483-11 HARNESS, SUB (MB-BR-DRIVE
1-962-418-11 1-962-418-11 HARNESS, SUB (MB-BR-ROBOT
1-962-419-11 1-962-419-11 HARNESS, SUB (MB-C)
1-962-421-11 1-962-421-11 HARNESS, SUB (MB-CB)
1-962-468-11 1-962-468-11 HARNESS, SUB (MB-HUB DRIV
1-962-403-11 1-962-403-11 HARNESS, SUB (MB-MB)
1-962-461-11 1-962-461-11 HARNESS, SUB (MB-PS-DRIVE
1-962-464-11 1-962-464-11 HARNESS, SUB (MB-PS-IF)
1-962-420-11 1-962-420-11 HARNESS, SUB (MB-PS-ROBOT
1-962-465-31 1-962-465-31 HARNESS, SUB (MBIF-MBDR)
1-962-465-21 1-962-465-21 HARNESS, SUB (MBIF-MBDR)
1-962-465-11 1-962-465-11 HARNESS, SUB (MBIF-MBDR)
1-962-466-11 1-962-466-11 HARNESS, SUB (MBIF-MBIF-R
1-962-467-11 1-962-467-11 HARNESS, SUB (MBIF-TS)
1-962-462-31 1-962-462-31 HARNESS, SUB (MBPW-MBDR)
1-962-462-21 1-962-462-21 HARNESS, SUB (MBPW-MBDR)
1-962-462-11 1-962-462-11 HARNESS, SUB (MBPW-MBDR)
1-962-463-11 1-962-463-11 HARNESS, SUB (MBPW-MBIF)
1-962-422-11 1-962-422-11 HARNESS, SUB (PS-C)
1-962-433-11 1-962-433-11 HARNESS, SUB (PS-CB)
1-962-431-11 1-962-431-11 HARNESS, SUB (PS-CONNECT)
1-962-432-11 1-962-432-11 HARNESS, SUB (PS-DR)
1-962-409-11 1-962-409-11 HARNESS, SUB (PS-PAA-24)
1-962-405-11 1-962-405-11 HARNESS, SUB (PS-PAA-AC1)
1-962-406-11 1-962-406-11 HARNESS, SUB (PS-PAA-ACL)
1-962-407-11 1-962-407-11 HARNESS, SUB (PS-PAA-ACN)
1-962-408-11 1-962-408-11 HARNESS, SUB (PS-PAA-CTL)
1-962-410-11 1-962-410-11 HARNESS, SUB (PS-PAA-G)
1-962-505-11 1-962-505-11 HARNESS, SUB (RC-ENC-R)
1-962-453-11 1-962-453-11 HARNESS, SUB (RC-ENC-Z)
1-962-454-11 1-962-454-11 HARNESS, SUB (RC-SE-IN)
1-962-455-11 1-962-455-11 HARNESS, SUB (RC-SE-REF)
1-962-457-11 1-962-457-11 HARNESS, SUB (RC-SE-Z ORG
1-962-441-11 1-962-441-11 HARNESS, SUB (ROBOT-X1)
1-962-442-11 1-962-442-11 HARNESS, SUB (ROBOT-Y)
1-962-477-11 1-962-477-11 HARNESS, SUB (SCSI-FLAT)
1-962-436-11 1-962-436-11 HARNESS, SUB (SE-DSENS)
1-962-502-11 1-962-502-11 HARNESS, SUB (SE-MB)
1-962-501-21 1-962-501-21 HARNESS, SUB (SE-SE-PRT)
1-962-501-11 1-962-501-11 HARNESS, SUB (SE-SE-PRT)
1-962-437-21 1-962-437-21 HARNESS, SUB (SE-SEC.PRT)
1-962-437-11 1-962-437-11 HARNESS, SUB (SE-SEC.PRT)
1-962-435-11 1-962-435-11 HARNESS, SUB (SE-X ZONE)
1-962-438-31 1-962-438-31 HARNESS, SUB (SE.PRT)
1-962-438-21 1-962-438-21 HARNESS, SUB (SE.PRT)
1-962-438-11 1-962-438-11 HARNESS, SUB (SE.PRT)
1-962-482-31 1-962-482-31 HARNESS, SUB (SEC,PRT)
1-962-482-21 1-962-482-21 HARNESS, SUB (SEC,PRT)
1-962-482-11 1-962-482-11 HARNESS, SUB (SEC,PRT)
4-668-919-01 4-668-919-01 HOLDER (RING)
4-669-177-01 4-669-177-01 HOLDER, BELT
1-576-516-11 1-576-516-11 HOLDER, FUSE
4-676-926-01 4-676-926-01 HOLDER, HUB
4-669-671-01 4-669-671-01 HOLDER, MIC
4-676-531-01 4-676-531-01 HOLDER, X BELT
4-676-295-01 4-676-295-01 HOLDER, Y BELT
3-628-483-01 3-628-483-01 HOLDER,RAIL(T)
6-703-592-01 6-703-592-01 IC ADM3491
6-703-727-01 6-703-727-01 IC BA9743AFV-FE2
6-703-728-01 6-703-728-01 IC BU2500FV-FE2
6-703-649-01 6-703-649-01 IC CY7C1041CV33-15ZCT
6-802-638-01 6-802-638-01 IC HD64F2339EVFC25V
6-700-821-01 6-700-821-01 IC HY628100BLLG-70TR
6-703-219-01 6-703-219-01 IC ISPLSI2032VE-110LT44A
6-703-595-01 6-703-595-01 IC LB1948M-TE-L-E
6-703-596-01 6-703-596-01 IC M95128-WMN6T
6-703-653-01 6-703-653-01 IC MC10EP451FAG
8-749-015-77 8-749-015-77 IC RPI-441C1
8-759-548-78 8-759-548-78 IC SN74LV273ANSR
8-759-491-39 8-759-491-39 IC TC74VHCT374AF(EL)
6-703-850-01 6-703-850-01 IC TC7SET04FU(TE85R1)
6-703-851-01 6-703-851-01 IC TC7W53FK(TE85R1)
6-703-639-01 6-703-639-01 IC TK11140CSCL-G
6-701-871-11 6-701-871-11 IC TK72150MCL-G
6-703-600-01 6-703-600-01 IC UPC1909GS-E2-A
6-703-729-01 6-703-729-01 IC UPC358G2-E2-A
A-8347-023-B A-8347-023-B IF-923 COMPLETE PC BOARD
A-8307-144-A A-8307-144-A IFD-T7 COMPL
1-469-669-11 1-469-669-11 INDUCTOR (EMI FERRITE) (
4-672-506-01 4-672-506-01 INSULATING SHEET (RMIC)
4-672-980-01 4-672-980-01 INSULATING SHEET (SCSI)
A-8308-322-A A-8308-322-A LB BLOCK ASSY
8-719-976-06 8-719-976-06 LED BR5334S
X-4625-431-1 X-4625-431-1 LEVER (TP T) ASSY
X-4625-427-1 X-4625-427-1 LEVER ASSY, CAM
A-8308-740-C A-8308-740-C MAGAZINE ASSY
A-8346-961-D A-8346-961-D MB-1005 COMPLETE PC BOARD
A-8346-963-A A-8346-963-A MB-1006 COMPLETE PC BOARD
A-8346-965-A A-8346-965-A MB-1007 COMPLETE PC BOARD
A-8346-967-A A-8346-967-A MB-1008 COMPLETE PC BOARD
X-4625-707-1 X-4625-707-1 MOTOR ASSY, GEARD
A-8308-325-A A-8308-325-A MOTOR BLOCK ASSY, FL
A-8308-333-A A-8308-333-A MOTOR BLOCK ASSY, TB
1-763-893-11 1-763-893-11 MOTOR, DC
1-763-805-11 1-763-805-11 MOTOR, DC (CAPSTAN)
1-781-997-11 1-781-997-11 OSCILLATOR, CRYSTAL
1-795-837-21 1-795-837-21 OSCILLATOR, CRYSTAL (112M
1-795-836-21 1-795-836-21 OSCILLATOR, CRYSTAL (113M
1-795-835-21 1-795-835-21 OSCILLATOR, CRYSTAL (120M
1-795-834-21 1-795-834-21 OSCILLATOR, CRYSTAL (20MH
4-676-703-01 4-676-703-01 PANEL (12V), BLANK
4-676-704-01 4-676-704-01 PANEL (24V), BLANK
4-676-963-01 4-676-963-01 PANEL (DRIVE), BLANK
A-8346-948-A A-8346-948-A PANEL (IF) ASSY, BLANK
4-676-587-01 4-676-587-01 PANEL (IF), BLANK
A-8346-901-A A-8346-901-A PANEL ASSY, DP
1-580-055-91 1-580-055-91 PIN, CONNECTOR 2P
1-580-057-91 1-580-057-91 PIN, CONNECTOR 4P
1-580-789-91 1-580-789-91 PIN, CONNECTOR 6P
1-778-903-11 1-778-903-11 PIN, DY CONNECTOR (PC BOA
4-671-877-01 4-671-877-01 PIN, GROUND
3-628-508-02 3-628-508-02 PIN,ADJUSTMENT PHASE
4-676-292-01 4-676-292-01 PLATE (1), Y BELT FIXED
4-676-293-01 4-676-293-01 PLATE (2), Y BELT FIXED
4-668-920-01 4-668-920-01 PLATE (S), PARTITION
4-676-724-01 4-676-724-01 PLATE, DOOR FIXED
4-671-313-01 4-671-313-01 PLATE, HLG POSITIONING
4-671-312-02 4-671-312-02 PLATE, HLG SLIDE
4-669-206-01 4-669-206-01 PLATE, UD LOCK
A-8307-162-A A-8307-162-A PS-655 COMPLETE PC BOARD
A-8346-957-D A-8346-957-D PS-656 COMPLETE PC BOARD
A-8346-959-A A-8346-959-A PS-657 COMPLETE PC BOARD
A-8307-160-A A-8307-160-A PS-665 COMPLETE PC BOARD
4-669-203-01 4-669-203-01 PULLEY
4-676-351-01 4-676-351-01 PULLEY (P24), Y
4-676-536-04 4-676-536-04 RAIL (B), X
4-677-100-01 4-677-100-01 RAIL (BX) (SSR20XW1UU+620
4-669-218-01 4-669-218-01 RAIL (D), TB
4-669-217-01 4-669-217-01 RAIL (U), TB
4-676-581-01 4-676-581-01 RAIL (Y)(SSR20XW1UU+1), L
X-4625-432-3 X-4625-432-3 REEL ASSY, T
4-676-431-01 4-676-431-01 REFLECTOR
1-468-788-11 1-468-788-11 REGULATOR, SWITCHING
1-515-842-11 1-515-842-11 RELAY (24V)
4-676-723-01 4-676-723-01 RETAINER, DISPLAY PANEL
4-669-219-01 4-669-219-01 RETAINER, TB COASTER
A-8308-317-A A-8308-317-A REVOG (SW) BLOCK ASSY
A-8308-340-B A-8308-340-B RING (TG7) BLOCK ASSY
4-671-309-01 4-671-309-01 ROLLER (HLG PLATE STOPPER
4-671-840-01 4-671-840-01 RUBBER (E)
4-669-380-02 4-669-380-02 SCREW (+1P2.6X2.8)
4-669-380-01 4-669-380-01 SCREW (+1P2.6X2.8)
4-669-387-01 4-669-387-01 SCREW (+1PS M2.6X4)
4-669-377-01 4-669-377-01 SCREW (+B M3X4)
4-673-278-01 4-673-278-01 SCREW (+P 2X8) (SCOTTCH G
4-669-383-01 4-669-383-01 SCREW (+PS M2.6X8)
4-669-384-01 4-669-384-01 SCREW (+PS M2X3.5)
4-669-386-01 4-669-386-01 SCREW (+PS M2X4)
4-669-388-01 4-669-388-01 SCREW (+PSW M3X5)
4-669-382-01 4-669-382-01 SCREW (+PTPWH M2X4)
4-670-812-01 4-670-812-01 SCREW (+PTPWH M2X6) (ON S
4-669-106-01 4-669-106-01 SCREW (M2), SPECIAL HEAD
4-669-376-02 4-669-376-02 SCREW M2X4
4-669-381-01 4-669-381-01 SCREW(+PSW M3X4)(BLACK NI
4-669-378-02 4-669-378-02 SCREW, TOOTHED LOCK (M2X3
A-8346-969-B A-8346-969-B SE-716 COMPLETE PC BOARD
A-8346-973-A A-8346-973-A SE-717 COMPLETE PC BOARD
A-8307-167-B A-8307-167-B SE-721 COMPL
A-8307-168-B A-8307-168-B SE-722 COMPL
A-8307-169-B A-8307-169-B SE-723 COMPL
A-8307-170-B A-8307-170-B SE-725 COMPL
A-8307-171-B A-8307-171-B SE-726 COMPL
A-8307-165-B A-8307-165-B SE-727 COMPL
A-8307-166-A A-8307-166-A SE-728 COMPL
A-8307-172-B A-8307-172-B SE-729 COMPL
A-8307-173-B A-8307-173-B SE-730 COMPL
4-671-839-01 4-671-839-01 SEAL (T REEL)
A-8346-971-A A-8346-971-A SEC-57 COMPLETE PC BOARD
A-8346-908-A A-8346-908-A SENSOR ASSY, DOOR
A-8308-762-A A-8308-762-A SHAFT ASSY, SYNCHRO
4-668-980-01 4-668-980-01 SHAFT, COMMUNICATION GEAR
3-628-401-01 3-628-401-01 SHAFT,STANDARD Y
3-628-493-01 3-628-493-01 SHAFT,Y-END
4-671-329-01 4-671-329-01 SHEET (3), SPACER
4-675-781-01 4-675-781-01 SHEET (HLG CHASSIS)
4-674-722-01 4-674-722-01 SHEET (SHUTTER), DUST
4-671-325-02 4-671-325-02 SHEET, FFC STICK
4-676-318-01 4-676-318-01 SLIDER (LOWER), X
A-8308-747-A A-8308-747-A SLIDER (T) ASSY, X
4-671-317-01 4-671-317-01 SPACER (TB FRAME)
4-676-543-01 4-676-543-01 SPACER, MOTOR
3-628-490-01 3-628-490-01 SPACER,X RAIL
4-669-204-01 4-669-204-01 SPRING (ADJUSTMENT ARM),
4-671-318-01 4-671-318-01 SPRING (HLG ARM), TORSION
4-671-319-01 4-671-319-01 SPRING (HLG DRIVE ARM),TO
4-671-320-01 4-671-320-01 SPRING (HLG SUB ARM), TOR
4-669-002-01 4-669-002-01 SPRING (HOLDER TG7)
4-668-898-01 4-668-898-01 SPRING (PINCH ARM), COIL
4-673-842-01 4-673-842-01 SPRING (S) (2), COASTER L
4-669-072-02 4-669-072-02 SPRING (TP_FWD), TENSION
4-669-078-01 4-669-078-01 SPRING (TP_REW), TENSION
4-671-321-01 4-671-321-01 SPRING(HLG DRIVE ARM), TO
4-669-224-01 4-669-224-01 SPRING, CHUCK DETECTION A
4-671-838-01 4-671-838-01 SPRING, GROUND
4-676-323-01 4-676-323-01 SPRING, TENSION COIL
4-676-282-01 4-676-282-01 SPRING, TRAP TORSION
A-8308-745-A A-8308-745-A STOPPER (LOWER) ASSY, X
A-8308-746-A A-8308-746-A STOPPER (LOWER) ASSY, Y
4-676-547-02 4-676-547-02 STOPPER (LOWER), X END
A-8308-744-A A-8308-744-A STOPPER (UPPER) ASSY, X
4-677-257-01 4-677-257-01 STOPPER (UPPER), X END
1-962-007-11 1-962-007-11 SUB HARNESS (FL-CIN)
1-962-010-11 1-962-010-11 SUB HARNESS (TE-LB)
1-962-009-11 1-962-009-11 SUB HARNESS (TE-PINCH)
4-673-085-01 4-673-085-01 SUPPORT (HLG PLATE)
4-676-533-01 4-676-533-01 SUPPORT, Y
X-4625-447-2 X-4625-447-2 TP (FWD) ASSY
X-4625-448-1 X-4625-448-1 TP (REW) ASSY
1-435-584-11 1-435-584-11 TRANSFORMER, POWER
6-550-540-01 6-550-540-01 TRANSISTOR 2SB1121-ST-TD-
6-550-541-01 6-550-541-01 TRANSISTOR 2SC1623-T1B-A
6-550-544-01 6-550-544-01 TRANSISTOR 2SC4083FT106P
6-550-545-01 6-550-545-01 TRANSISTOR 2SC4617FTLQ
6-550-552-01 6-550-552-01 TRANSISTOR 2SC5551-TD-E
6-550-551-01 6-550-551-01 TRANSISTOR CPH3105-TL-E
6-550-548-01 6-550-548-01 TRANSISTOR DTA114EUAFT106
6-550-549-01 6-550-549-01 TRANSISTOR DTC114EUAFT106
6-550-550-01 6-550-550-01 TRANSISTOR DTC114TUAFT106
8-729-929-05 8-729-929-05 TRANSISTOR DTC123EE
6-550-378-01 6-550-378-01 TRANSISTOR ECH8301-TL-E
8-729-055-15 8-729-055-15 TRANSISTOR HN1B01FU-GR(TE
A-8308-331-A A-8308-331-A TRANSPOTER BLOCK ASSY
A-8308-742-A A-8308-742-A TRAP ASSY, LOWER
A-8308-743-A A-8308-743-A TRAP ASSY, UPPER
1-795-833-21 1-795-833-21 VIBRATOR, CRYSTAL (13.56M
7-688-000-32 7-688-000-32 WASHER
3-628-471-01 3-628-471-01 WINDOW,INDICATION
3-628-489-02 3-628-489-02 X JOINT
A-1055-525-A A-1055-525-A X MOTOR ASSY
A-8308-763-A A-8308-763-A X PULLEY ASSY
A-1055-524-A A-1055-524-A Y MOTOR ASSY
A-8308-764-A A-8308-764-A Y SLIDER ASSY
Main Menu x
