Manufacturer

Sony

Model Number

DFRC20

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
7-682-552-09 7-682-552-09 Sony +B 3.0X16.0 BLK
1-248-098-11 1-248-098-11 Sony 270 RESISTOR,METAL FILM C
J-6189-530-A J-6189-530-A Sony A/D PHASE ADJUSTMENT TOOL
8-759-923-64 8-759-923-64 Sony AM26LS32ACNS, IC
1-547-769-13 1-547-769-13 Sony ARRAY, FIBER I
3-645-097-02 3-645-097-02 Sony BEARING, BALL
3-187-578-01 3-187-578-01 Sony BLACK, FLOCKED PAPER (A)
3-187-579-01 3-187-579-01 Sony BLACK, FLOCKED PAPER (B)
3-187-574-01 3-187-574-01 Sony BLACK, FLOCKED PAPER (C)
3-187-580-01 3-187-580-01 Sony BLACK, FLOCKED PAPER (D)
3-187-581-01 3-187-581-01 Sony BLACK, FLOCKED PAPER (E)
3-187-575-01 3-187-575-01 Sony BLACK, FLOCKED PAPER (F)
3-187-576-01 3-187-576-01 Sony BLACK, FLOCKED PAPER (G)
3-187-577-01 3-187-577-01 Sony BLACK, FLOCKED PAPER (H)
7-683-412-05 7-683-412-05 Sony BOLT,HEXAGON 2.6X6
3-625-620-00 3-625-620-00 Sony BRACKET AC CONNECTOR
1-764-274-11 1-764-274-11 Sony CONNECTOR, COAXIAL (BNC T
1-580-340-21 1-580-340-21 Sony CONNECTOR, PC BOARD (PLUG
1-750-795-21 1-750-795-21 Sony CONNECTOR, PRINT PC BOARD
1-506-468-11 1-506-468-11 Sony CONNECTOR3P
3-188-243-02 3-188-243-02 Sony COVER, INTERCEPTOR
3-166-744-21 3-166-744-21 Sony FILTER
3-166-744-13 3-166-744-13 Sony FILTER
3-186-006-01 3-186-006-01 Sony FOOT, MG
J-6187-910-A J-6187-910-A Sony GUIDE ADJUSTMENT BLOCK
1-953-637-22 1-953-637-22 Sony HARNESS, SUB (ACW1)
1-954-813-12 1-954-813-12 Sony HARNESS, SUB (LED)
1-954-279-11 1-954-279-11 Sony HARNESS, SUB (WESTREX)
3-185-127-02 3-185-127-02 Sony HINGE, LONG
1-565-896-11 1-565-896-11 Sony HOUSING,CONNECTOR
8-741-132-10 8-741-132-10 Sony IC BX1321
8-759-519-33 8-759-519-33 Sony IC DS1230Y
8-759-291-11 8-759-291-11 Sony IC EPM7128-IF462-IC10/11-
8-759-291-12 8-759-291-12 Sony IC EPM7128-SV157-IC102-V1
8-759-291-09 8-759-291-09 Sony IC EPM7160-PU83-IC09-V1.0
8-759-274-60 8-759-274-60 Sony IC MB88344PF
8-759-926-82 8-759-926-82 Sony IC SN74HC574NS
8-759-155-16 8-759-155-16 Sony IC UPC79M12HF
1-251-148-11 1-251-148-11 Sony INLET, AC (3P)
3-185-197-02 3-185-197-02 Sony JOINT, W
J-6187-940-A J-6187-940-A Sony L SHAPED HEX. WRENCH (M2.
J-6187-950-A J-6187-950-A Sony L SHAPED HEX. WRENCH (M3)
8-719-030-05 8-719-030-05 Sony LED FH1011
1-547-866-11 1-547-866-11 Sony LENS, C MOUNT
1-412-521-31 1-412-521-31 Sony MICRO INDUCTOR 4.7UH
A-8263-431-A A-8263-431-A Sony MOUNTED C. BOARD CN-1082
A-8263-432-A A-8263-432-A Sony MOUNTED C. BOARD CN-1083
A-8274-857-A A-8274-857-A Sony MOUNTED C. BOARD LE-137
A-8274-843-C A-8274-843-C Sony PANEL (L) ASSY, FRONT
A-8274-843-B A-8274-843-B Sony PANEL (L) ASSY, FRONT
3-188-213-02 3-188-213-02 Sony PANEL (M), FRONT
3-188-212-02 3-188-212-02 Sony PANEL (R), FRONT
A-8274-855-B A-8274-855-B Sony PANEL ASSY, REAR
A-8274-855-A A-8274-855-A Sony PANEL ASSY, REAR
A-8274-860-A A-8274-860-A Sony PANEL ASSY, SV
3-703-358-02 3-703-358-02 Sony PARALLEL PIN 2X6 (S
1-566-479-11 1-566-479-11 Sony PIN, SOCKET 7P
1-506-479-11 1-506-479-11 Sony PIN,CONNECTOR 14P
1-564-104-00 1-564-104-00 Sony PIN,CONNECTOR 3P
3-185-072-03 3-185-072-03 Sony PLATE, INDICATION, ARM
3-188-231-02 3-188-231-02 Sony PLATE, INDICATOR
3-188-222-02 3-188-222-02 Sony PLATE, LIGHT INTERCEPTION
3-188-222-01 3-188-222-01 Sony PLATE, LIGHT INTERCEPTION
A-8274-842-A A-8274-842-A Sony PLATE, TOP ASSY
3-701-616-01 3-701-616-01 Sony POLY BAG
X-3167-483-3 X-3167-483-3 Sony PR SUB ASSY
3-185-040-01 3-185-040-01 Sony PULLEY (L)
3-185-065-01 3-185-065-01 Sony RETAINER, GUIDE
3-185-234-01 3-185-234-01 Sony RETAINER, MG
X-3167-725-1 X-3167-725-1 Sony ROLLER ASSY, BELT
3-185-108-01 3-185-108-01 Sony RUBBER FOOT
2-133-531-11 2-133-531-11 Sony SCREW, CONNECTOR
9-967-598-01 9-967-598-01 Sony SERVICE MANUAL
3-185-212-01 3-185-212-01 Sony SHEET (B), RADIATION
3-185-213-01 3-185-213-01 Sony SHEET (C), RADIATION
1-540-221-11 1-540-221-11 Sony SOCKET, IC (PCC PACKAGE)
3-185-109-42 3-185-109-42 Sony SPACER, LENS
3-185-109-32 3-185-109-32 Sony SPACER, LENS
3-185-109-22 3-185-109-22 Sony SPACER, LENS
3-185-109-12 3-185-109-12 Sony SPACER, LENS
3-185-109-02 3-185-109-02 Sony SPACER, LENS
3-185-180-02 3-185-180-02 Sony SPRING
3-187-570-01 3-187-570-01 Sony SPRING, FS
4-922-449-01 4-922-449-01 Sony SPRING,COMPRESSION
3-558-379-02 3-558-379-02 Sony SPRING,COMPRESSION
3-185-045-01 3-185-045-01 Sony SPROCKET (16)
7-624-198-11 7-624-198-11 Sony STOP RING 9, TYPE-C
3-188-228-01 3-188-228-01 Sony SUPPORT K
1-570-598-11 1-570-598-11 Sony SWITCH,DIP
1-413-984-11 1-413-984-11 Sony SWITCHING REGULATOR
1-413-983-11 1-413-983-11 Sony SWITCHING REGULATOR (AC)
J-6187-810-A J-6187-810-A Sony TENTION REGULATOR ADJUSTE
1-535-417-11 1-535-417-11 Sony TERMINAL
8-729-904-38 8-729-904-38 Sony TRANSISTOR 2SD1118
