Model Image
Manufacturer

Sony

Model Number

DSCW610

Description

Cyber-shot Digital Still Camera; Silver

Interactive Exploded View

Parts List

Part Number Description
A-1799-286-A A-1799-286-A BARRIER BLOCK ASSY (1380E)
1-487-523-21 1-487-523-21 BATTERY CHARGER BCCSN/BCCSNB
1-853-309-31 1-853-309-31 BATTERYPACK, LITHIUM ION(NP-BN)
X-2582-694-1 X-2582-694-1 BTH ASSY
X-2582-680-1 X-2582-680-1 CABINET (FRONT) ASSY (030D)
X-2582-681-1 X-2582-681-1 CABINET (FRONT) ASSY (030E)
X-2582-682-1 X-2582-682-1 CABINET (FRONT) ASSY (030F)
X-2582-683-1 X-2582-683-1 CABINET (FRONT) ASSY (030G)
X-2582-679-1 X-2582-679-1 CABINET (FRONT) ASSY (SILVER)
4-297-228-12 4-297-228-12 CABINET (L (030)), SIDE
4-297-228-11 4-297-228-11 CABINET (L (030)), SIDE
4-297-228-02 4-297-228-02 CABINET (L (030)), SIDE
4-297-229-01 4-297-229-01 CABINET (R (030)), SIDE
X-2582-685-1 X-2582-685-1 CABINET (REAR) ASSY (030D)
X-2582-686-1 X-2582-686-1 CABINET (REAR) ASSY (030E)
X-2582-687-1 X-2582-687-1 CABINET (REAR) ASSY (030F)
X-2583-221-2 X-2583-221-2 CABINET (REAR) ASSY (030FT)
X-2582-688-1 X-2582-688-1 CABINET (REAR) ASSY (030G)
X-2582-684-1 X-2582-684-1 CABINET (REAR) ASSY (SILVER)
X-2582-689-1 X-2582-689-1 CABINET (UPPER) ASSY (030C)
1-822-837-31 1-822-837-31 CARD CONNECTOR
A-1798-783-A A-1798-783-A CD774 BOARD COMPLETE2
1-460-478-11 1-460-478-11 CHOKE, COIL4.7UH (3015)
A-1799-285-A A-1799-285-A COMPLETE ASSY (1380E)
4-417-256-01 4-417-256-01 CUSHION (030), LCD
9-913-200-93 9-913-200-93 DEDICATED USB CABLE
1-489-930-11 1-489-930-11 FLASH UNIT
4-297-226-01 4-297-226-01 FRAME (030), MAIN
4-147-091-01 4-147-091-01 FRAME FOR DIGITAL CAMERA
1-576-843-31 1-576-843-31 FUSE MICRO (1608)
6-718-170-01 6-718-170-01 IC BD9757MWV-SBZE2
6-718-133-01 6-718-133-01 IC H9YA1GA1GHMYAR-2YMR-C
6-712-852-01 6-712-852-01 IC RP103K301D
4-415-046-02 4-415-046-02 INSULATING SHEET (030), LCD
4-408-895-01 4-408-895-01 INSULATING SHEET (030), SY
1-802-984-11 1-802-984-11 LCD MODULE (LMS270GF07)
4-297-227-41 4-297-227-41 LID (030), BT
4-297-227-31 4-297-227-31 LID (030), BT
4-297-227-21 4-297-227-21 LID (030), BT
4-297-227-11 4-297-227-11 LID (030), BT
4-297-227-01 4-297-227-01 LID (030), BT (SILVER)
4-297-230-41 4-297-230-41 LID (030), MC
4-297-230-31 4-297-230-31 LID (030), MC
4-297-230-21 4-297-230-21 LID (030), MC
4-297-230-11 4-297-230-11 LID (030), MC
4-297-230-01 4-297-230-01 LID (030), MC
4-410-124-12 4-410-124-12 MANUAL, INSTRUCTION
4-410-123-11 4-410-123-11 MANUAL, INSTRUCTION
4-410-123-02 4-410-123-02 MANUAL, INSTRUCTION
1-576-415-31 1-576-415-31 MICRO FUSE (1608)
A-1851-791-A A-1851-791-A MOUNTED C.BOARD, SW-584
A-1743-731-A A-1743-731-A NARUTO GEAR LUBRICATED ASSY
1-885-071-11 1-885-071-11 PWB, MA-480 FLEXIBLE
4-155-850-01 4-155-850-01 RING A (S) ORNAMENTAL
4-535-068-01 4-535-068-01 SCREW(M1.4), NEW TRU-STAR, P2
4-410-120-01 4-410-120-01 SHEET (030), MA RADIATION
4-297-232-01 4-297-232-01 SHEET (030), ST
A-1851-790-A A-1851-790-A ST-268 BOARD COMPLETE
A-1851-909-A A-1851-909-A SY-285 BOARD, COMPLETE (SERVIC
1-798-408-12 1-798-408-12 TACTILE SWITCH,
1-781-525-11 1-781-525-11 VIBRATOR, CRYSTAL (32.768KHZ)
4-168-182-02 4-168-182-02 WINDOW (670) LCD
A-1743-730-A A-1743-730-A WORM B LUBRICATED ASSY
4-470-899-01 4-470-899-01 WRIST STRAP (SILVER)
