Model Image
Manufacturer

Sony

Model Number

DSCWX5

Description

Cyber-shot Digital Still Camera; Silver

Interactive Exploded View

Parts List

Part Number Description
X-2548-763-1 X-2548-763-1 (FRONT) ASSY (350) (BLACK)
X-2548-764-1 X-2548-764-1 (FRONT) ASSY (350) (BROWN)
X-2548-765-1 X-2548-765-1 (FRONT) ASSY (350) (VIOLET)
8-753-350-20 8-753-350-20 ACX402CMN1
X-2548-389-1 X-2548-389-1 BARRIER ASSY (BE0053)
X-2548-390-1 X-2548-390-1 BARRIER ASSY (BE0054)
1-487-523-21 1-487-523-21 BATTERY CHARGER BCCSN/BCCSNB
4-195-636-22 4-195-636-22 BUTTON (350), RUBBER
4-195-636-11 4-195-636-11 BUTTON (350), RUBBER
4-195-636-02 4-195-636-02 BUTTON (350), RUBBER
4-195-636-01 4-195-636-01 BUTTON 350 RUBBER
X-2548-767-2 X-2548-767-2 CABINET (REAR) ASSY (BROWN)
X-2548-768-2 X-2548-768-2 CABINET (REAR) ASSY (VIOLET)
4-195-655-01 4-195-655-01 CABINET (UPPER (350)), INNER
X-2549-184-1 X-2549-184-1 CABINET(FRONT) ASSY(350)(GOLD)
X-2548-762-1 X-2548-762-1 CABINETFRONT ASSY SILVER
4-195-609-41 4-195-609-41 CAP (350)
4-195-609-31 4-195-609-31 CAP (350)
4-195-609-11 4-195-609-11 CAP (350)
4-195-609-01 4-195-609-01 CAP 350 SILVER
1-116-752-21 1-116-752-21 CAPACITOR CERAMIC(0.01MF)
A-1784-410-A A-1784-410-A CD 794 FLEXIBLE BOARD COMPLETE
4-194-686-01 4-194-686-01 CDROM CYBERSHOT APPLICATION
1-842-269-11 1-842-269-11 CONNECTOR, FPC (ZIF) 23P
4-195-662-01 4-195-662-01 CUSHION (350), ABSORBENT
4-195-653-01 4-195-653-01 CUSHION (350), LCD
4-260-658-01 4-260-658-01 CUSHION (T (350))
6-503-638-01 6-503-638-01 DI RKH0160AKU
4-195-651-01 4-195-651-01 FRAME (350), MAIN
1-487-600-21 1-487-600-21 GEAR BLOCKC, ZOOM MOTER(BE005)
4-194-687-01 4-194-687-01 HANDBOOK(PDF)
X-2548-769-1 X-2548-769-1 HOLDER ASSY (350)(SILVER), BT
X-2549-378-1 X-2549-378-1 HOLDER ASSY (BLACK) (JET), BT
X-2549-379-1 X-2549-379-1 HOLDER ASSY (BROWN) (JET), BT
X-2549-377-1 X-2549-377-1 HOLDER ASSY (GOLD) (JET), BT
X-2549-380-1 X-2549-380-1 HOLDER ASSY (VIOLET) (JET), BT
X-2549-381-1 X-2549-381-1 HOLDER ASSY SILVER
X-2548-771-1 X-2548-771-1 HOLDER ASSY(350)(BROWN), BT
X-2549-185-1 X-2549-185-1 HOLDER ASSY(350)(GOLD), BT
X-2548-772-1 X-2548-772-1 HOLDER ASSY(350)(VIOLET), BT
6-716-442-01 6-716-442-01 IC MM3404A29URE
6-715-742-01 6-715-742-01 IC R2J2007CNS
4-195-657-02 4-195-657-02 INSULATING SHEET (350), SY
4-195-646-41 4-195-646-41 LID (350), HDMI
4-195-646-31 4-195-646-31 LID (350), HDMI
4-195-646-21 4-195-646-21 LID (350), HDMI
4-195-646-11 4-195-646-11 LID (350), HDMI
4-195-646-01 4-195-646-01 LID 350 HDMI SILVER
4-195-648-01 4-195-648-01 LIGHT (350), MS GUIDE,
4-194-693-21 4-194-693-21 MANUAL, INSTRUCTION
4-194-691-11 4-194-691-11 MANUAL, INSTRUCTION
4-194-691-01 4-194-691-01 MANUAL, INSTRUCTION
A-1806-119-A A-1806-119-A MOUNTED C.BOARD, CD-794
A-1784-412-A A-1784-412-A MOUNTED C.BOARD, HC-015
A-1784-409-A A-1784-409-A MS445 BOARD COMPLETE
1-756-935-21 1-756-935-21 NP-BN1 RECHARGEABLE BATTERY
1-856-111-31 1-856-111-31 OPTICAL UNIT (BLACK)
1-856-111-11 1-856-111-11 OPTICAL UNIT (BROWN)
1-856-111-51 1-856-111-51 OPTICAL UNIT (GOLD)
1-856-111-41 1-856-111-41 OPTICAL UNIT (SILVER)
1-856-111-21 1-856-111-21 OPTICAL UNIT (VIOLET)
4-195-647-01 4-195-647-01 PLATE (350), CONNECTOR
4-195-659-01 4-195-659-01 PROP (350), SY
1-881-709-11 1-881-709-11 PWB, FP-1247
1-881-849-11 1-881-849-11 PWB, FP-1254
X-2548-759-1 X-2548-759-1 RELEASE ASSY (350) (BLACK)
X-2548-760-1 X-2548-760-1 RELEASE ASSY (350) (BROWN)
X-2549-180-1 X-2549-180-1 RELEASE ASSY (350) (GOLD)
X-2548-761-1 X-2548-761-1 RELEASE ASSY (350) (VIOLET)
X-2548-758-3 X-2548-758-3 RELEASE ASSY 350 SILVER
4-160-888-31 4-160-888-31 RING (A (BE0053)), ORNAMENTAL
4-160-888-41 4-160-888-41 RING (A (BE0054)), ORNAMENTAL
4-195-656-01 4-195-656-01 RUBBER (350), MICROPHONE
4-195-652-01 4-195-652-01 SCREW (350), TRIPOD
4-258-381-01 4-258-381-01 SHEET (350), CD COPPER LEAF
4-258-386-01 4-258-386-01 SHEET (350), CD ELECTROSTATIC
4-258-384-01 4-258-384-01 SHEET (350), COPPER LEAF
4-258-385-01 4-258-385-01 SHEET (350), ELECTROSTATIC
4-258-382-01 4-258-382-01 SHEET (350), LCD COPPER LEAF
4-258-377-01 4-258-377-01 SHEET (350), MICROPHONE BLIND
4-195-660-01 4-195-660-01 SHEET (350), PROTECTION
4-195-658-01 4-195-658-01 SHEET (350), PROTECTION
4-258-383-01 4-258-383-01 SHEET (350), SY HEAT INSULATING
4-195-899-01 4-195-899-01 SHEET (CD (350)), THERMAL
4-195-900-01 4-195-900-01 SHEET (SY (350)), THERMAL
4-264-596-01 4-264-596-01 SHEET, LENS LIGHT INTERCEPTION
4-258-379-01 4-258-379-01 SPACER (350), LCD FLEXIBLE
4-258-378-01 4-258-378-01 SPACER (350), SY
A-1792-908-A A-1792-908-A ST236 BOARD COMPLETE
4-470-899-11 4-470-899-11 STRAP, HAND
1-489-134-21 1-489-134-21 SWITCH BLOCK, CONTROL(SW61350)
A-1812-942-A A-1812-942-A SY269 BOARD COMPLETE
6-552-341-01 6-552-341-01 TR DRA3114T0L
6-552-355-01 6-552-355-01 TR DRC3144T0L
X-2548-391-2 X-2548-391-2 TUBE (A_) ASSY (BE0053)
X-2548-391-1 X-2548-391-1 TUBE (A_) ASSY (BE0053)
X-2548-392-2 X-2548-392-2 TUBE (A_) ASSY (BE0054)
X-2548-392-1 X-2548-392-1 TUBE (A_) ASSY (BE0054)
1-837-299-22 1-837-299-22 USB A/V CABLE FOR MULTIUSE
4-195-654-01 4-195-654-01 WINDOW LCD
4-470-899-01 4-470-899-01 WRIST STRAP (SILVER)
