Model Image
Manufacturer

Sony

Model Number

DSCWX50

Description

Cyber-shot Digital Still Camera; Silver

Interactive Exploded View

Parts List

Part Number Description
1-492-868-11 1-492-868-11 AC-UB10/UB10B AC-ADAPTOR
1-490-498-65 1-490-498-65 ADAPTOR, AC (AC-UB10C)
4-411-656-01 4-411-656-01 BASE (150), SHEET MICROPHONE
X-2583-249-2 X-2583-249-2 BTH (150) PINK ASSY
X-2583-248-2 X-2583-248-2 BTH (150) SILVER ASSY
X-2583-256-5 X-2583-256-5 CABINET REAR 150 BLACK ASSY
X-2583-256-4 X-2583-256-4 CABINET REAR 150 BLACK ASSY
X-2583-259-5 X-2583-259-5 CABINET REAR 150 BLUE ASSY
X-2583-259-4 X-2583-259-4 CABINET REAR 150 BLUE ASSY
X-2583-258-5 X-2583-258-5 CABINET REAR 150 GOLD ASSY
X-2583-258-3 X-2583-258-3 CABINET REAR 150 GOLD ASSY
X-2583-257-5 X-2583-257-5 CABINET REAR 150 PINK ASSY
X-2583-257-3 X-2583-257-3 CABINET REAR 150 PINK ASSY
X-2583-257-1 X-2583-257-1 CABINET REAR 150 PINK ASSY
X-2583-255-5 X-2583-255-5 CABINET REAR 150 SILVER ASSY
X-2583-255-3 X-2583-255-3 CABINET REAR 150 SILVER ASSY
X-2583-255-1 X-2583-255-1 CABINET REAR 150 SILVER ASSY (
1-116-875-91 1-116-875-91 CERAMIC CAP 1.0MF X5R 0603
1-842-602-11 1-842-602-11 CONNECTOR HDMI
1-843-212-11 1-843-212-11 CONNECTOR, MULTIPLE (SOCKET)
4-411-640-42 4-411-640-42 COVER (150), DC
4-411-640-32 4-411-640-32 COVER (150), DC
4-411-640-22 4-411-640-22 COVER (150), DC
4-411-640-12 4-411-640-12 COVER (150), DC
4-411-640-02 4-411-640-02 COVER (150), DC
A-1852-925-A A-1852-925-A COVER(150) BLACK BLOCK ASSY
A-1852-928-A A-1852-928-A COVER(150) BLUE BLOCK ASSY
A-1852-927-A A-1852-927-A COVER(150) GOLD BLOCK ASSY
A-1852-926-A A-1852-926-A COVER(150) PINK BLOCK ASSY
A-1852-924-A A-1852-924-A COVER(150) SILVER BLOCK ASSY
4-411-648-01 4-411-648-01 CUSHION (150), LCD
4-411-653-01 4-411-653-01 CUSHION (SY) (150)
A-1825-023-A A-1825-023-A FILTER BLOCK ASSY ASM
X-2583-260-1 X-2583-260-1 FRAME (150) ASSY, MAIN
A-1852-919-A A-1852-919-A FRONT (150) SILVER BLOCK ASSY
A-1852-920-A A-1852-920-A FRONT(150) BLACK BLOCK ASSY
A-1852-923-A A-1852-923-A FRONT(150) BLUE BLOCK ASSY
A-1852-922-A A-1852-922-A FRONT(150) GOLD BLOCK ASSY
A-1852-921-A A-1852-921-A FRONT(150) PINK BLOCK ASSY
1-576-843-31 1-576-843-31 FUSE MICRO (1608)
4-411-659-01 4-411-659-01 GASKET (F)
4-418-107-01 4-418-107-01 GASKET (USB)
8-826-002-51 8-826-002-51 GYRO SENSOR GSU-X370D/N-S
6-718-064-01 6-718-064-01 IC BD91407GW-E2
6-718-737-01 6-718-737-01 IC MAX8976EWA+T
6-716-846-01 6-716-846-01 IC MB44C022PW-G-ERE1
4-411-641-91 4-411-641-91 LID (150), BT
4-411-641-81 4-411-641-81 LID (150), BT
4-411-641-71 4-411-641-71 LID (150), BT
4-411-641-61 4-411-641-61 LID (150), BT
4-411-641-51 4-411-641-51 LID (150), BT
4-411-641-41 4-411-641-41 LID (150), BT
4-411-641-31 4-411-641-31 LID (150), BT
4-411-641-21 4-411-641-21 LID (150), BT
4-411-641-11 4-411-641-11 LID (150), BT
4-411-643-01 4-411-643-01 LID (150), PLATE (BT)
4-417-810-01 4-417-810-01 LID (150), SHAFT (BT)
4-266-403-01 4-266-403-01 LID (770), SHAFT (BT)
4-411-642-01 4-411-642-01 LOCK TSUMAMI (150) BT LID
8-848-872-51 8-848-872-51 LSV-1430A-LS (RED)
4-411-521-21 4-411-521-21 MANUAL, INSTRUCTION
4-411-520-11 4-411-520-11 MANUAL, INSTRUCTION
4-408-995-11 4-408-995-11 MANUAL, INSTRUCTION
4-408-995-04 4-408-995-04 MANUAL, INSTRUCTION
1-576-415-31 1-576-415-31 MICRO FUSE (1608)
1-839-666-11 1-839-666-11 MICRO USB CABLE
1-811-497-11 1-811-497-11 PANEL MODULE (PE3-ACM)
4-411-645-01 4-411-645-01 PLATE (H) (150)
4-411-646-01 4-411-646-01 PLATE (SP) (150)
4-411-644-01 4-411-644-01 PLATE, USB (150)
X-2583-251-4 X-2583-251-4 RELEASE (150) BLACK ASSY
X-2583-254-4 X-2583-254-4 RELEASE (150) BLUE ASSY
X-2583-254-3 X-2583-254-3 RELEASE (150) BLUE ASSY
X-2583-253-4 X-2583-253-4 RELEASE (150) GOLD ASSY
X-2583-253-3 X-2583-253-3 RELEASE (150) GOLD ASSY
X-2583-252-4 X-2583-252-4 RELEASE (150) PINK ASSY
X-2583-252-3 X-2583-252-3 RELEASE (150) PINK ASSY
X-2583-250-4 X-2583-250-4 RELEASE (150) SILVER ASSY
X-2583-250-3 X-2583-250-3 RELEASE (150) SILVER ASSY (SIL
4-411-649-01 4-411-649-01 RUBBER (150), MICROPHONE
4-535-068-21 4-535-068-21 SCREW(M1.4), NEW TRU-STAR, P2
4-424-250-01 4-424-250-01 SCREW(M1.4), NEW TRU-STAR, P2
4-412-769-31 4-412-769-31 SCREW(M1.4), NEW TRU-STAR, P2
4-424-201-01 4-424-201-01 SCREW(M1.4), NEW TRU-STAR, P2 EG
1-490-064-31 1-490-064-31 SENSOR 3 AXIAL ACCELERATION
1-490-064-11 1-490-064-11 SENSOR 3 AXIAL ACCELERATION
4-421-218-01 4-421-218-01 SHEET (150), ELECTROSTATIC LENS
4-411-658-02 4-411-658-02 SHEET (150), RADIATION
4-411-657-01 4-411-657-01 SHEET (LCD) (150), RADIATION
4-411-654-01 4-411-654-01 SHEET (MF)
4-411-650-01 4-411-650-01 SHEET (SY) (150)
4-426-460-01 4-426-460-01 SPACER BTH
4-426-459-01 4-426-459-01 SPACER MF
4-266-405-01 4-266-405-01 SPRING (770), BT LID OPEN
4-409-867-01 4-409-867-01 ST SHEET (770)
A-1854-924-A A-1854-924-A ST-269 BOARD, COMPLETE
1-490-033-11 1-490-033-11 SWITCH BLOCK, CONTROL (SW63150
1-490-033-51 1-490-033-51 SWITCH BLOCK, CONTROL(SW63150)
1-490-033-41 1-490-033-41 SWITCH BLOCK, CONTROL(SW63150)
1-490-033-31 1-490-033-31 SWITCH BLOCK, CONTROL(SW63150)
1-490-033-21 1-490-033-21 SWITCH BLOCK, CONTROL(SW63150)
A-1863-155-A A-1863-155-A SY-311/SY-321 BOARD, COMPLETE
1-781-525-11 1-781-525-11 VIBRATOR, CRYSTAL (32.768KHZ)
4-411-647-01 4-411-647-01 WINDOW (150), LCD
A-1889-550-A A-1889-550-A WINDOW BLOCK ASSY (SERVICE)
4-470-899-01 4-470-899-01 WRIST STRAP (SILVER)
