Model Image
Manufacturer

Sony

Model Number

DSLRA100

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
J-6082-604-A J-6082-604-A 1000MM COLLIMATOR (110V)
A-1498-934-A A-1498-934-A 208 FOCUS PLATE IN MIRROW BOX
2-688-376-01 2-688-376-01 209 SCREEN SI IN MIRROW BOX
2-693-425-01 2-693-425-01 ACTION (SP), F SNAP
1-797-601-11 1-797-601-11 ADAPTOR, COMPACT FLASH
J-6082-603-B J-6082-603-B ADJ. UNIT OF CCD PERSPEC II
J-6082-597-A J-6082-597-A AE MASTER LENS
J-6082-594-A J-6082-594-A AF CHART 1
J-6082-595-A J-6082-595-A AF CHART 2
J-6082-596-A J-6082-596-A AF CHART 3
J-6082-811-A J-6082-811-A AF MASTER LENS 2
A-1209-702-A A-1209-702-A AF MODULE UNIT
J-6082-599-A J-6082-599-A AF-Y, P ADJUSTER
2-891-466-01 2-891-466-01 AF/M SW INSULATION SHEETB
2-683-121-02 2-683-121-02 ALPHA100 APPLICATION SOFTWARE
A-1196-097-A A-1196-097-A APERTURE UNIT
2-891-464-01 2-891-464-01 AS SW INSULATION SHEETB
2-695-356-21 2-695-356-21 BALL, BEARING
NPFM500H NPFM500H BATTERY PACK
1-479-694-11 1-479-694-11 BLOCK LIGHT GUIDE PLATE (2.5)
3-217-621-01 3-217-621-01 BODY CAP (PROTECTION)
A-1196-094-A A-1196-094-A BOX UNIT, MIRROR
2-688-287-01 2-688-287-01 BUTTON (SP), FN
2-693-424-01 2-693-424-01 BUTTON (SP), RELEASE
2-688-119-11 2-688-119-11 BUTTON, AEL+/-
2-688-119-01 2-688-119-01 BUTTON, AEL+/-
2-688-125-11 2-688-125-11 BUTTON, FN
2-688-125-01 2-688-125-01 BUTTON, FN
2-688-679-01 2-688-679-01 BUTTON, LENS LOCK
2-688-195-12 2-688-195-12 BUTTON, PREVIEW
2-688-195-02 2-688-195-02 BUTTON, PREVIEW
2-688-120-02 2-688-120-02 BUTTON, RELEASE
2-688-380-11 2-688-380-11 CAP, RELEASE BUTTON
2-688-380-01 2-688-380-01 CAP, RELEASE BUTTON
A-1196-231-A A-1196-231-A CAPACITOR UNIT, MAIN
1-114-302-11 1-114-302-11 CAPACITOR, ELECT 240MF
1-114-223-91 1-114-223-91 CAPACITOR, TANTALUM 10MF(3216)
A-1196-111-A A-1196-111-A CASE (UPPER) UNIT, FLASH
J-6082-650-A J-6082-650-A CCD CLEANING JIG
J-6082-635-A J-6082-635-A CCD CLEANING JIG
J-6082-663-A J-6082-663-A CCD CLEANING JIG (NEW)
J-6082-651-A J-6082-651-A CCD CLEANING JIG POINT (10PCS)
A-1196-229-B A-1196-229-B CCD UNIT
2-688-193-01 2-688-193-01 CHAMBER, BATTERY
2-693-429-01 2-693-429-01 CHARGE (SP), MIRROR OVER
A-1196-096-A A-1196-096-A CHARGE UNIT, AF
1-489-761-21 1-489-761-21 CHARGER, BATTERY (BC-VM10)
2-688-198-01 2-688-198-01 CHASSIS (G), SUB
A-1204-883-A A-1204-883-A CHASSIS UNIT, CCD
2-688-199-01 2-688-199-01 CHASSIS, BOTTOM
J-6082-584-A J-6082-584-A CHRMA METER CL-200
2-688-127-01 2-688-127-01 CLAW, BATTERY LOCK
2-693-416-01 2-693-416-01 CLICK (SP), FN DIAL
J-6082-638-A J-6082-638-A CONNECTION CORD (JIG)
J-6082-573-B J-6082-573-B CONNECTOR RELEASE JIG2
1-820-334-11 1-820-334-11 CONNECTOR, BOARD TO BOARD 60P
1-820-337-51 1-820-337-51 CONNECTOR, FFC/FPC (ZIF) 28P
1-820-436-11 1-820-436-11 CONNECTOR, FPC (ZIF) 12P
1-820-437-11 1-820-437-11 CONNECTOR, FPC (ZIF) 14P
1-820-379-11 1-820-379-11 CONNECTOR, FPC (ZIF) 17P
1-820-380-11 1-820-380-11 CONNECTOR, FPC (ZIF) 25P
1-820-341-51 1-820-341-51 CONNECTOR, FPC (ZIF) 31P
1-820-338-11 1-820-338-11 CONNECTOR, FPC (ZIF) 33P
1-820-339-11 1-820-339-11 CONNECTOR, FPC (ZIF) 51P
1-833-010-11 1-833-010-11 CORD, CONNECTION (JIG)
A-1196-107-A A-1196-107-A COVER UNIT (SILVER), BATTERY
A-1196-116-A A-1196-116-A COVER UNIT (SILVER), CF CARD
A-1196-103-C A-1196-103-C COVER UNIT (SILVER), UPPER
A-1196-106-A A-1196-106-A COVER UNIT, BATTERY
A-1196-115-A A-1196-115-A COVER UNIT, CF CARD
A-1196-108-A A-1196-108-A COVER UNIT, REAR
A-1196-102-C A-1196-102-C COVER UNIT, UPPER
2-688-188-11 2-688-188-11 COVER, FRONT DECORATION
2-688-188-01 2-688-188-01 COVER, FRONT DECORATION
2-688-194-11 2-688-194-11 COVER, L DECORATION
2-688-189-11 2-688-189-11 COVER, LL SOKKAN ADJUSTMENT
2-688-189-01 2-688-189-01 COVER, LL SOKKAN ADJUSTMENT
2-688-676-11 2-688-676-11 COVER, RELEASE
2-688-676-02 2-688-676-02 COVER, RELEASE
2-688-767-11 2-688-767-11 COVER, SHOE
2-688-859-01 2-688-859-01 CUSHION (A), SUB MIRROR (SP)
2-688-375-01 2-688-375-01 CUSHION, DRIVING LEVER
2-688-131-01 2-688-131-01 CUSHION, LCD
J-6082-582-A J-6082-582-A D SHUTTER TESTER
2-688-133-01 2-688-133-01 DECORATION, FN DIAL
2-688-134-11 2-688-134-11 DECORATION, MODE DIAL
2-688-134-01 2-688-134-01 DECORATION, MODE DIAL
2-689-292-02 2-689-292-02 DETECT CONTACT(A), SLLK
2-689-293-01 2-689-293-01 DETECT CONTACT(B), SLLK
2-689-193-01 2-689-193-01 DETECT CONTACT, AF/M CHANGE
2-688-294-01 2-688-294-01 DETECT CONTACT, ANTI SHAKE (SW)
2-688-290-01 2-688-290-01 DETECT CONTACT, PU
2-688-123-01 2-688-123-01 DIAL, FN
2-688-117-01 2-688-117-01 DIAL, MODE
2-693-430-01 2-693-430-01 DRIVING (SP), MIRROR
J-6082-624-A J-6082-624-A DSLR CABLE W/CONNECTOR
2-688-773-01 2-688-773-01 EYE HOOD
2-688-203-01 2-688-203-01 EYELET, GRIP
2-688-204-01 2-688-204-01 EYELET, LEFT
J-6082-662-A J-6082-662-A FINISHED INSPECTION JIG
J-6082-642-A J-6082-642-A FLUORESCENT LAMP
J-6082-643-A J-6082-643-A FLUORESENT LIGHT STAND
A-1196-101-A A-1196-101-A FRAME UNIT, EYE PIECE
2-693-431-01 2-693-431-01 FUNCTION (SP), SUB MIRROR
2-689-305-01 2-689-305-01 GEAR, IRIS DECELERATION
2-689-182-01 2-689-182-01 GEAR, SHUTTER CHARGE
3-096-151-11 3-096-151-11 GRIP REPAIRMENT TAPE
A-1196-230-A A-1196-230-A GYRO UNIT
1-964-901-11 1-964-901-11 HARNESS (BL-001)
A-1204-881-A A-1204-881-A HOLDER UNIT, BL CONTACT
A-1196-114-B A-1196-114-B HOLDER UNIT, FRONT DIAL
A-1196-095-A A-1196-095-A HOLDER UNIT, MAIN MIRROR
A-1204-880-A A-1204-880-A HOLDER UNIT, SUB MIRROR
2-688-126-11 2-688-126-11 HOLDER, LCD
2-688-126-01 2-688-126-01 HOLDER, LCD
2-688-202-01 2-688-202-01 HOLDER, TERMINAL BOARD
2-688-379-01 2-688-379-01 HOLDER, WIRE ARRANGEMENT
9-910-999-TF 9-910-999-TF HOUSING, CONNECTOR 2P
J-6082-602-A J-6082-602-A HVL CABLE W CONNECTOR
6-709-673-01 6-709-673-01 IC EL7457CLZ-T7
6-709-659-01 6-709-659-01 IC LV8014T-TLM-E
6-807-096-01 6-807-096-01 IC M30620FCPGP-U5C-CX62100
6-709-690-01 6-709-690-01 IC MA07169
6-806-964-01 6-806-964-01 IC S29AL032D70BFI03-94
6-709-675-01 6-709-675-01 IC UPC5703K9-033-5FH-A
6-709-670-01 6-709-670-01 IC VSP02M21ZWVR
6-709-671-01 6-709-671-01 IC VSP2590ZWVR
6-709-665-01 6-709-665-01 IC XC221A1100MR
6-709-664-01 6-709-664-01 IC XC6213B502NR
2-689-105-21 2-689-105-21 INSTRUCTION(READ THIS FIRST)
2-689-105-11 2-689-105-11 INSTRUCTION(READ THIS FIRST)
2-681-186-81 2-681-186-81 INSTRUCTION(READ THIS FIRST)
2-681-186-71 2-681-186-71 INSTRUCTION(READ THIS FIRST)
2-681-186-61 2-681-186-61 INSTRUCTION(READ THIS FIRST)
2-681-186-51 2-681-186-51 INSTRUCTION(READ THIS FIRST)
2-681-186-41 2-681-186-41 INSTRUCTION(READ THIS FIRST)
2-681-186-21 2-681-186-21 INSTRUCTION(READ THIS FIRST)
2-681-186-01 2-681-186-01 INSTRUCTION(READ THIS FIRST)
2-681-187-71 2-681-187-71 INSTRUCTION(USER S GUIDE)
2-681-187-61 2-681-187-61 INSTRUCTION(USER S GUIDE)
2-681-187-41 2-681-187-41 INSTRUCTION(USER S GUIDE)
2-681-187-01 2-681-187-01 INSTRUCTION(USER S GUIDE)
2-891-463-02 2-891-463-02 INSULATING SHEET, (SIDE) SCREW
2-688-295-01 2-688-295-01 INSULATING SHEET, AF/M
2-688-288-01 2-688-288-01 INSULATING SHEET, FN DIAL
2-891-467-01 2-891-467-01 INSULATING SHEET, FN SIDE SCREW
2-688-381-01 2-688-381-01 INSULATING SHEET, MAIN SW
2-688-284-01 2-688-284-01 INSULATING SHEET, MODE DIAL
2-688-192-11 2-688-192-11 KNOB, AF/M SELECTION
2-688-192-01 2-688-192-01 KNOB, AF/M SELECTION
2-688-382-11 2-688-382-11 KNOB, ANTI SHAKE (SW)
2-688-382-01 2-688-382-01 KNOB, ANTI SHAKE (SW)
2-688-857-01 2-688-857-01 KNOB, DIOPTER ADJUST
2-688-121-11 2-688-121-11 KNOB, MAIN SW
2-688-121-01 2-688-121-01 KNOB, MAIN SW
2-689-006-01 2-689-006-01 LABEL, DIOPTER ADJUST
2-688-296-01 2-688-296-01 LABEL, MAIN CAUTION
2-684-655-01 2-684-655-01 LABEL, MODEL NUMBER
8-753-280-79 8-753-280-79 LCD901 LCD DISPLAY ACX542AKA-1
2-689-288-01 2-689-288-01 LEVER, COUPLER
2-689-290-01 2-689-290-01 LEVER, COUPLER JOINT
2-689-400-01 2-689-400-01 LEVER, MAIN MIRROR DRIVING
2-689-399-01 2-689-399-01 LEVER, MIRROR DRIVING
2-891-459-01 2-891-459-01 LID (SP), BATTERY
2-688-186-11 2-688-186-11 LID, DC JACK
J-6082-591-A J-6082-591-A LIGHT BALANCE FILTER LB200
J-6082-603-1 J-6082-603-1 LIGHT BOX
2-693-419-01 2-693-419-01 LOCK (SP), LENS
2-688-796-01 2-688-796-01 LUG (1), CCD CHASSIS
J-6082-583-A J-6082-583-A LUMINANCE METER LS-100
J-6082-585-A J-6082-585-A MACBETH COLOR CHECKER
J-6082-589-A J-6082-589-A MASTER LENS FOR SHAKE
2-693-433-01 2-693-433-01 MIRROR, MAIN
A-1197-323-A A-1197-323-A MOUNT, CCD CONECTING
A-1183-655-A A-1183-655-A MOUNTED C. BOARD, IS-001
A-1183-654-A A-1183-654-A MOUNTED, C.BOARD, AM-001
2-688-191-01 2-688-191-01 MOUNTING(CF), HINGE SHAFT
1-820-343-21 1-820-343-21 PIN, CONNECTOR (CF CARD)
2-689-300-01 2-689-300-01 PLATE (1), MOUNT LUG
2-689-301-01 2-689-301-01 PLATE (2), MOUNT LUG
A-1196-113-B A-1196-113-B PLATE UNIT, UPPER COVER BASE
2-689-389-01 2-689-389-01 PLATE(1), PENTA PROTECTION LUG
2-688-854-01 2-688-854-01 PLATE(2), PENTA PROTECTION LUG
2-689-194-01 2-689-194-01 PLATE, AF/M KNOB CLICK
2-688-293-01 2-688-293-01 PLATE, ANTI SHAKE (SW) CLICK
2-688-200-01 2-688-200-01 PLATE, EYELET REINFORCEMENT
2-688-124-01 2-688-124-01 PLATE, FN DIAL CLICK
2-688-372-01 2-688-372-01 PLATE, I/O FLEXIBLE LUG
2-688-132-01 2-688-132-01 PLATE, LCDGND
2-689-294-01 2-689-294-01 PLATE, LENS LOCK BUTTON HOLDING
2-688-799-01 2-688-799-01 PLATE, MAIN PC BOARD LUG
2-689-190-01 2-689-190-01 PLATE, MAIN SW KNOB CLICK
2-689-405-01 2-689-405-01 PLATE, MIRROR DRIVING
2-688-118-01 2-688-118-01 PLATE, MODE DIAL CLICK
2-688-785-01 2-688-785-01 PLATE, POWER (GND)
A-1196-245-A A-1196-245-A POWER UNIT
J-6082-593-A J-6082-593-A PRESET SIGNAL ADAPTOR
J-6082-592-A J-6082-592-A PRESET TESTER
9-913-200-33 9-913-200-33 PROTECTION TAPE, BLUE
1-870-959-11 1-870-959-11 PWB, FP-525
1-870-962-11 1-870-962-11 PWB, FP-528
1-870-963-11 1-870-963-11 PWB, FP-529
A-1196-110-A A-1196-110-A REFLECTION UNIT
1-480-041-11 1-480-041-11 REMOTE HOLDER
A-1204-884-A A-1204-884-A REMOTE UNIT
J-6082-637-A J-6082-637-A RESOLVING POWER CHART WIDE
2-689-073-01 2-689-073-01 RETAINER, BALL
2-688-772-01 2-688-772-01 RETAINER, CROSS BUTTON
2-689-307-01 2-689-307-01 RETAINER, IRIS (PI)
2-689-404-01 2-689-404-01 RETAINER, MAIN MIRROR HOLDER
2-689-312-02 2-689-312-02 RING, IRIS
2-689-315-01 2-689-315-01 ROLLER (C), RING
3-283-668-01 3-283-668-01 ROLLER A(SV), RING
2-688-780-01 2-688-780-01 RUBBER, BOTTOM
3-299-343-11 3-299-343-11 RUBBER, S GRIP
3-299-343-01 3-299-343-01 RUBBER, S GRIP
2-689-187-01 2-689-187-01 SCREW (A), PC BOARD HOLDING
2-689-188-01 2-689-188-01 SCREW (B), PC BOARD HOLDING
2-695-426-01 2-695-426-01 SCREW (M1.6)
2-695-425-21 2-695-425-21 SCREW (M1.6)
2-695-425-11 2-695-425-11 SCREW (M1.6)
2-695-425-01 2-695-425-01 SCREW (M1.6)
2-695-424-21 2-695-424-21 SCREW (M1.6)
2-695-423-81 2-695-423-81 SCREW (M1.6)
2-695-423-61 2-695-423-61 SCREW (M1.6)
2-695-423-51 2-695-423-51 SCREW (M1.6)
2-695-423-41 2-695-423-41 SCREW (M1.6)
2-695-423-31 2-695-423-31 SCREW (M1.6)
2-695-423-11 2-695-423-11 SCREW (M1.6)
2-695-423-01 2-695-423-01 SCREW (M1.6)
2-695-420-01 2-695-420-01 SCREW (M1.6), +P1 MAIN PAN
2-695-422-01 2-695-422-01 SCREW (M1.6), +Z
2-695-427-01 2-695-427-01 SCREW (M2)
2-695-421-11 2-695-421-11 SCREW (M2), +P1 MAIN PAN
2-695-421-01 2-695-421-01 SCREW (M2), +P1 MAIN PAN
2-695-437-11 2-695-437-11 SCREW (T1.4), +P2 TAPPING
2-695-437-01 2-695-437-01 SCREW (T1.4), +P2 TAPPING
2-695-438-01 2-695-438-01 SCREW (T1.4), HEAD PAN TAPPING
2-695-428-21 2-695-428-21 SCREW (T1.4), HEAD PAN TAPPING
2-695-428-01 2-695-428-01 SCREW (T1.4), HEAD PAN TAPPING
2-695-439-01 2-695-439-01 SCREW (T1.7), HEAD PAN TAPPING
2-695-431-21 2-695-431-21 SCREW (T1.7), HEAD PAN TAPPING
2-695-431-11 2-695-431-11 SCREW (T1.7), HEAD PAN TAPPING
2-695-431-01 2-695-431-01 SCREW (T1.7), HEAD PAN TAPPING
2-695-430-51 2-695-430-51 SCREW (T1.7), HEAD PAN TAPPING
2-695-430-41 2-695-430-41 SCREW (T1.7), HEAD PAN TAPPING
2-695-430-31 2-695-430-31 SCREW (T1.7), HEAD PAN TAPPING
2-695-430-21 2-695-430-21 SCREW (T1.7), HEAD PAN TAPPING
2-695-430-11 2-695-430-11 SCREW (T1.7), HEAD PAN TAPPING
2-695-429-71 2-695-429-71 SCREW (T1.7), HEAD PAN TAPPING
2-695-429-61 2-695-429-61 SCREW (T1.7), HEAD PAN TAPPING
2-695-429-51 2-695-429-51 SCREW (T1.7), HEAD PAN TAPPING
2-695-429-41 2-695-429-41 SCREW (T1.7), HEAD PAN TAPPING
2-695-429-01 2-695-429-01 SCREW (T1.7), HEAD PAN TAPPING
2-695-574-11 2-695-574-11 SCREW (T2), +P1 PAN TAPPNG
2-695-574-01 2-695-574-01 SCREW (T2), +P1 PAN TAPPNG
2-695-433-21 2-695-433-21 SCREW (T2), HEAD PAN TAPPING
2-695-433-11 2-695-433-11 SCREW (T2), HEAD PAN TAPPING
2-695-433-01 2-695-433-01 SCREW (T2), HEAD PAN TAPPING
2-689-181-01 2-689-181-01 SCREW, AF CHARGE PLATE
2-689-291-01 2-689-291-01 SCREW, COUPLER LEVER ADJUSTMENT
2-688-297-11 2-688-297-11 SCREW, DECORATION
2-688-297-01 2-688-297-01 SCREW, DECORATION
2-689-298-01 2-689-298-01 SCREW, SNAP SUPPORT
2-894-387-01 2-894-387-01 SEAL, BODY CAP
2-693-418-01 2-693-418-01 SHAFT (L), ROTARY
2-689-297-01 2-689-297-01 SHAFT (R), ROTARY
2-693-423-01 2-693-423-01 SHAFT, PC BOARD HOLDING
J-6082-590-A J-6082-590-A SHAKE OFFSET CHART II
2-688-850-01 2-688-850-01 SHEET (A), FUSE
2-688-851-01 2-688-851-01 SHEET (B), FUSE
2-688-786-01 2-688-786-01 SHEET, CCD FLEXIBLE RETAINER
2-688-383-03 2-688-383-03 SHEET, CF CARD (INDICATION)
3-094-283-01 3-094-283-01 SHEET, COVER FLEXIBLE RETAINER
1-798-037-11 1-798-037-11 SHEET, CROSS KEY (SW)
2-693-339-01 2-693-339-01 SHEET, FCPCONNECT ELEPREVENTION
2-693-432-01 2-693-432-01 SHEET, FLARE PREVENTION
2-688-292-01 2-688-292-01 SHEET, LCD WINDOW
3-209-491-01 3-209-491-01 SHEET, MAGNET CUSHION
2-688-373-01 2-688-373-01 SHEET1(S), HEAT TRANSMISSION
2-688-374-01 2-688-374-01 SHEET2(L), HEAT TRANSMISSION
A-1198-056-A A-1198-056-A SHOE UNIT, ACCESSORY
1-788-564-11 1-788-564-11 SHUTTER
1-479-591-11 1-479-591-11 SLANT SENSOR
3-198-884-01 3-198-884-01 SLLK SW INSULATION SHEET
3-113-946-01 3-113-946-01 SPACER, RELEASE BUTTON
2-689-008-01 2-689-008-01 SPACER, SLLK DETECT CONTACT
2-893-999-01 2-893-999-01 SPRING, BATTERY
4-163-840-01 4-163-840-01 ST STROBE GUARD SHEET B
2-689-330-01 2-689-330-01 STOPPER, ECCENTRIC PIN
2-688-782-02 2-688-782-02 STRAP (2187 STANDARD STRAP)
2-689-185-01 2-689-185-01 TABLE (A), PC BOARD HOLDING
1-798-256-11 1-798-256-11 TACTILE SWITCH
2-889-024-01 2-889-024-01 TAPE (B), FPC STICKING
3-299-345-01 3-299-345-01 TAPE (B), RUBBER DOUBLE STICK
3-299-346-01 3-299-346-01 TAPE (C), RUBBER DOUBLE STICK
2-693-346-01 2-693-346-01 TAPE, ACCESS LIGHT LEAK
2-688-286-01 2-688-286-01 TAPE, FN DIAL SCALE
2-693-338-01 2-693-338-01 TAPE, FN PLATE SUPPORT
3-106-765-01 3-106-765-01 TAPE, LCD DUST PROTECTION
2-689-360-01 2-689-360-01 TAPE, PREVIEW BUTTON FCP FIXED
2-693-428-01 2-693-428-01 TAPE, PV BUTTON ATTACH
2-688-289-01 2-688-289-01 TAPE, SALF WINDOW
2-693-417-01 2-693-417-01 TENSION(SP), COUPLER LEVER
2-693-422-01 2-693-422-01 TENSION(SP-C), SLIDER
1-694-796-51 1-694-796-51 TERMINAL BOARD, BATTERY
J-6082-644-A J-6082-644-A TUNGSTEN LAMP
J-6082-604-1 J-6082-604-1 TUNGSTEN LAMP (6V 30W)
1-834-311-41 1-834-311-41 USB CABLE
J-6082-588-A J-6082-588-A VIBRATION TESTER
1-834-312-21 1-834-312-21 VIDEO CORD WITH CONNECTOR
2-688-291-01 2-688-291-01 WINDOW, LCD
2-688-129-01 2-688-129-01 WINDOW, SELF
J-6082-600-A J-6082-600-A X-CABLE II
Main Menu x
