Model Image
Manufacturer

Sony

Model Number

DSLRA330

Description

10.2 Mp Digital Slr Camera Body Only

Interactive Exploded View

Parts List

Part Number Description
A-1552-209-A A-1552-209-A ALX-8520
4-143-355-01 4-143-355-01 APPLICATION SOFTWARE ALPHA
1-487-825-43 1-487-825-43 BATTERY CHARGER BCVH1
X-2349-053-1 X-2349-053-1 BD BATTERY HOLDER ASSY
4-143-901-01 4-143-901-01 BD BATTERY LOCK
4-143-902-01 4-143-902-01 BD BATTERY LOCK SPRING
4-143-885-01 4-143-885-01 BD BOTTOM FRAME
X-2349-052-1 X-2349-052-1 BD BT LID COVER ASSY
4-143-905-01 4-143-905-01 BD BT LOCK SHAFT
4-143-898-01 4-143-898-01 BD BT TERMINAL HOLDER
4-143-897-01 4-143-897-01 BD EYELET G
4-143-890-01 4-143-890-01 BD EYEPIECE CUSHION(852)
4-143-889-01 4-143-889-01 BD FUSE REPAIR CAUTION LABEL
4-143-887-01 4-143-887-01 BD GRIP L FRAME
4-143-994-01 4-143-994-01 BD LCD FLEXIBLE GUARD TAPE
X-2349-077-1 X-2349-077-1 BD MEDIA BASE ASSY (852)
4-143-981-11 4-143-981-11 BD MEDIA COVER
4-143-982-01 4-143-982-01 BD MEDIA SPRING
4-147-194-01 4-147-194-01 BD SG SHEET
4-143-893-01 4-143-893-01 BD SHADING SHEET U
X-2349-075-1 X-2349-075-1 BD SIDE FRAME L ASSY
4-143-878-01 4-143-878-01 BOTTOM LABEL (A)
4-143-880-01 4-143-880-01 BOTTOM LABEL (C)
1-877-509-21 1-877-509-21 BT-048 MOUNT FPC UNIT
1-836-701-11 1-836-701-11 CABLE, FLEXIBLE FLAT (RGS-001)
9-910-999-TF 9-910-999-TF CAPACITOR, ELECT 180MF
A-1708-602-A A-1708-602-A CCD ASSY (852)
J-6082-726-A J-6082-726-A CLEANING STICK II
X-2349-085-1 X-2349-085-1 CV EYE HOOD ASSY
X-2349-084-1 X-2349-084-1 CV EYE PIECE BASE ASSY
X-2349-066-1 X-2349-066-1 CV FRONT COVER ASSY(852)
X-2349-069-1 X-2349-069-1 CV GRIP COVER ASSY(852)
4-143-881-01 4-143-881-01 CV GRIP SOKKAN COVER (A)
4-143-996-01 4-143-996-01 CV LCD FLEXIBLE GUARD (B)
X-2349-080-4 X-2349-080-4 CV LCD HINGE ASSY
4-143-995-01 4-143-995-01 CV LCD HINGE COVER
4-143-991-01 4-143-991-01 CV LCD WINDOW(852)
X-2349-078-1 X-2349-078-1 CV P CAB (M) ASSY
X-2349-079-1 X-2349-079-1 CV P CAB(C) ASSY
X-2349-081-1 X-2349-081-1 CV REAR COVER ASSY(852)
4-144-015-02 4-144-015-02 CV REAR RUBBER PV12DSLR505
4-144-016-01 4-144-016-01 CV REAR RUBBER TAPE
X-2349-059-1 X-2349-059-1 CV SHOULDER COVER G ASSY 852BJ
X-2349-059-3 X-2349-059-3 CV SHOULDER COVER G ASSY 852BJ
X-2349-056-1 X-2349-056-1 CV SHOULDER COVER G ASSY(852)
X-2349-054-1 X-2349-054-1 CV STOROBO BASE ASSY(852)
J-6082-725-A J-6082-725-A DSLR CABLE W/CONNECTOR FH-50
4-143-888-01 4-143-888-01 EM JS SPACER
4-143-992-01 4-143-992-01 EM LCD UNIT CASE(852)
4-143-892-01 4-143-892-01 EM SH FLEXIBLE SPACER
6-808-671-01 6-808-671-01 IC 19A43FZXBG-0114(EL
6-714-057-01 6-714-057-01 IC BD4827FVE-TR
6-808-610-01 6-808-610-01 IC MA07171
6-808-779-01 6-808-779-01 IC MB44C017BBGF-G-ERE1
6-714-056-01 6-714-056-01 IC MB91F233LALGV-G-11-ERE1
6-713-966-01 6-713-966-01 IC QPDS-M906
6-713-979-01 6-713-979-01 IC S-1200B30-I6T2G
A-1719-801-A A-1719-801-A IC S29WS128P0SBFW000A-001
6-710-498-01 6-710-498-01 IC TPS62110RSARG4
1-820-344-21 1-820-344-21 JACK, DC
4-143-886-01 4-143-886-01 JB AM FRAME
1-802-585-11 1-802-585-11 LCD901 LCD MODULE (LS027A3DC01)
4-143-883-11 4-143-883-11 LOGO EMBLEM (A)
1-877-475-21 1-877-475-21 MA-455 MOUNT FPC UNIT
4-147-786-11 4-147-786-11 MANUAL, INSTRUCTION
4-147-786-91 4-147-786-91 MANUAL, INSTRUCTION
4-141-081-01 4-141-081-01 MB AF MASK PLATE
A-1709-452-A A-1709-452-A MB BL CONTACT HOLDER UNIT
A-1709-448-A A-1709-448-A MB CHARGE BASE PLATE A UNIT
X-2348-670-2 X-2348-670-2 MB CHARGE BASE PLATE B ASSY
A-1709-453-B A-1709-453-B MB MIRROR BOX SUB UNIT
A-1729-799-A A-1729-799-A MOUNTED C.BOARD, RG-054
1-814-071-21 1-814-071-21 QUARTZ CRYSTAL OSCILLATOR
4-147-784-91 4-147-784-91 QUICK START GUIDE
4-144-032-01 4-144-032-01 S ADJUSTMENT SCREW
4-144-031-01 4-144-031-01 S ADJUSTMENT WASHER 09
4-154-343-01 4-154-343-01 SH GUARD CUSHION
1-877-476-21 1-877-476-21 SH-032 MOUNT FPC UNIT
A-1717-483-A A-1717-483-A SHOULDER COVER L BLOCK ASSY
A-1717-485-A A-1717-485-A SHOULDER COVER L BLOCK ASSY
A-1717-485-B A-1717-485-B SHOULDER COVER L BLOCK ASSY
A-1731-074-A A-1731-074-A SI SCREEN (SERVICE)
A-1805-816-A A-1805-816-A SLIDER UNIT(852 SERVICE)
4-143-911-01 4-143-911-01 ST CASE U
4-143-916-01 4-143-916-01 ST FLEXIBLE GUARD SHEET (A)
4-143-917-01 4-143-917-01 ST FLEXIBLE GUARD SHEET (B)
4-143-913-03 4-143-913-03 ST PLUNGER COVER
4-143-914-01 4-143-914-01 ST POP UP ARM COVER
4-143-912-01 4-143-912-01 ST SHOE FRAME
4-156-186-01 4-156-186-01 ST SWITCH SPACER
4-143-919-01 4-143-919-01 ST UL GUARD CASE
1-487-106-11 1-487-106-11 SWITCH BLOCK, CONTROL(RS85200)
1-487-107-11 1-487-107-11 SWITCH BLOCK, CONTROL(TK85200)
1-487-107-31 1-487-107-31 SWITCH BLOCK, CONTROL(TK85200)
6-552-535-01 6-552-535-01 TR DMG964030R
6-552-398-01 6-552-398-01 TR FJ3303010L
A-1708-601-A A-1708-601-A UNIT, IS FLEXIBLE(852)
4-143-882-01 4-143-882-01 VM DIOPTER ADJUST DIAL
A-1718-181-A A-1718-181-A VM PENTA UNIT 852S
