Model Image
Manufacturer

Sony

Model Number

DVPNC615

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
3-074-745-01 3-074-745-01 BELT (LOADING)
1-828-145-21 1-828-145-21 CABLE, STEREO A/V
9-885-021-15 9-885-021-15 CAPACITOR CERAMIC 150MF/4
9-885-021-16 9-885-021-16 CAPACITOR CERAMIC 220MF/3
9-885-021-10 9-885-021-10 CAPACITOR CERAMIC 220MF/3
3-073-127-21 3-073-127-21 CASE, UPPER
A-6060-647-A A-6060-647-A CHUCK ASSY
3-074-747-01 3-074-747-01 CLAMP (FFC)
3-074-739-01 3-074-739-01 COLLAR (SWING)
3-073-858-21 3-073-858-21 COVER, TRAY (P)
8-719-058-80 8-719-058-80 D102
9-885-020-50 9-885-020-50 DIODE D1N60
8-719-068-60 8-719-068-60 DIODE HZ33BP-TK
9-885-020-49 9-885-020-49 DIODE S1WBA60
1-823-836-11 1-823-836-11 FCI-I
1-823-921-11 1-823-921-11 FMS-18
3-074-735-01 3-074-735-01 GEAR (IDLER)
3-074-744-01 3-074-744-01 GEAR (LOADING A)
3-074-741-01 3-074-741-01 GEAR (LOADING B)
6-702-300-01 6-702-300-01 IC TK11118CSCL-G
6-801-260-01 6-801-260-01 IC TMP86CK74AF-1640
8-759-662-86 8-759-662-86 IC101
A-6060-675-A A-6060-675-A MOUNTED C BOARD AV-62CM
A-6060-663-A A-6060-663-A MOUNTED C BOARD, AV-62CM(
3-074-737-01 3-074-737-01 PLATE (GUIDE)
1-468-642-13 1-468-642-13 POWER BLOCK
9-885-021-18 9-885-021-18 TERMINAL, EARTH SR-010270
9-885-020-62 9-885-020-62 TRANSISTOR 2SC2655
9-885-020-61 9-885-020-61 TRANSISTOR 2SD1768S
3-074-717-01 3-074-717-01 TRAY
A-6060-640-A A-6060-640-A UNIT ASSY, TD
