Manufacturer
Sony
Model Number
FW98BZ30L
Description
98-inch 4k Professional Display
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
BRACKET SIDE (CBN) A (UCF) |
|
|
BRACKET, VESA (CBN 5L) (UCF) |
|
|
C18 AC INLET (UCF) |
|
|
COMPL_BM5STY_TCB_B2B (UCF) |
|
|
CONNECTOR ASSY 20P (GTCON) (UCF) |
|
|
CONNECTOR ASSY 2P (GGPFC) (UCF) |
|
|
CONNECTOR ASSY 30P (PWR1) (UCF) |
|
|
CONNECTOR ASSY 30P (PWR2) (UCF) |
|
|
CONNECTOR ASSY 4P (SP) (UCF) |
|
|
CONNECTOR ASSY 4P (TW) (UCF) |
|
|
CONNECTOR ASSY 6P (PWR3) (UCF) |
|
|
COVER STD (5L CBN) A (UCF) |
|
|
COVER, BTM (CBN) A (UCF) |
|
|
COVER, TOP (CBN) (UCF) |
|
|
FLAT CLAMP(FFC) (UCF) |
|
|
FLEXIBLE FLAT CABLE 20P (UCF) |
|
|
FLEXIBLE FLAT CABLE 25P (UCF) |
|
|
FLEXIBLE FLAT CABLE 30P (UCF) |
|
|
FLEXIBLE FLAT CABLE 41P (UCF) |
|
|
FLEXIBLE FLAT CABLE 51P (UCF) |
|
|
FY23_HY1S_WW_EVSI MT (UCF) |
|
|
G110 - STATIC CONVERTER(TV) (UCF) |
|
|
G111B - STATIC CONVERTER(TV) (UCF) |
|
|
HANDLE (6L RIS) (UCF) |
|
|
LABEL, UP B2B (UCF) |
|
|
LOUDSPEAKER, FY22 TW16-19MM (UCF) |
|
|
POWER-SUPPLY CORD (UCF) |
|
|
REAR COVER L (5L CBN) A (UCF) |
|
|
REAR COVER R (5L CBN) A (UCF) |
|
|
REFERENCE GUIDE (UCF) |
|
|
REMOTE COMMANDER (RMT-TB400U) (UCF) |
|
|
SCREW M3X3.0 STEP (UCF) |
|
|
SCREW, +PSW M3X6 (UCF) |
|
|
SCREW, +PSW M3X8 (UCF) |
|
|
SCREW, ORNAMENTAL M8X12 (UCF) |
|
|
SETUP GUIDE (UCF) |
|
|
SHEET THERMAL(BM6SL M6L) (UCF) |
|
|
SHT, INSULATION (CBN 5L) L A (UCF) |
|
|
SHT, INSULATION (CBN 5L) S (UCF) |
|
|
SLIDE, CLAMP (UCF) |
|
|
SPACER(26) WF +C (UCF) |
|
|
SPEAKER BOX ASSY (FY20 W30XL-A) (UCF) |
|
|
SPEAKER BOX ASSY (FY20 W30XL-B) (UCF) |
|
|
TAPE, CONDUCTIVE(MLB) S (UCF) |
|
|
WLAN/BT MODULE(11AC) (UCF) |
