Manufacturer
Sony
Model Number
GV8
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
6.3V 6.8MF,CHIP TANTALUM |
|
|
ARM ASSY,PINCH SUB |
|
|
ARM ASSY,TG7 |
|
|
ARM BLOCK ASSY,PINCH |
|
|
ARM,ADJUSTMENT |
|
|
ARM,UL |
|
|
BATTERY,LITHIUM (CR2032) |
|
|
BRACKET,KB |
|
|
CABLE,EXTENSION(W/CONNECT |
|
|
CAPACITOR ELECT 33MF/25V(CHIP) |
|
|
CAPACITOR,CERAMIC 220PF |
|
|
CAPACITOR,CERAMIC 4.0PF S |
|
|
CAPACITOR,CHIP TANTALM 33 |
|
|
CAPACITOR,CHIP TANTALUM |
|
|
CAPASITOR,CERAMIC 390PF S |
|
|
CASE MAIN,IC SHIELD |
|
|
CCD-1HDL BLOCK |
|
|
CHIP INDUCTOR |
|
|
CHIP INDUCTOR 2.2UH (3225) |
|
|
COIL, CHOKE 47UH |
|
|
COIL,CHOKE 10UH |
|
|
CONNECTOR WITH FPC 16P |
|
|
CONNECTOR,BOARD TO BOARD |
|
|
CONNECTOR,FPC (ZIP) 26P |
|
|
DAMPER,OIL |
|
|
DIODE AU02A |
|
|
DIODE RD10M-B1 |
|
|
DIODE RD18M-B1 |
|
|
DISTRIBUTOR,ANTENA |
|
|
FRAME (REAR) |
|
|
GEAR (LEFT) ASSY,DRIVE |
|
|
GEAR B O |
|
|
GEAR,UL |
|
|
INDUCTOR, CHIP 39UH (4532 |
|
|
INDUCTOR,CHIP 0.12UH |
|
|
INSULATOR (A),TU |
|
|
INSULATOR (B),TU |
|
|
LABEL,MODEL NUMBER(USA) |
|
|
LEVER ASSY,THREADING |
|
|
MICRO INDUCTOR (SHIELD TYPE) |
|
|
NUT,PLATE |
|
|
PIN,CONNECTOR 4P |
|
|
RESISTOR, CHIP 1.5M |
|
|
RESISTOR, CHIP 2.2 1/10W(1608) |
|
|
RETAINER,TT |
|
|
ROLLER ASSY (U),GUIDE |
|
|
ROLLER,TG2 |
|
|
SCREW (M1.4X2)(STEP),HEAD |
|
|
SCREW (M2X2.2) |
|
|
SHEET,INSULATING,LOCK SHA |
|
|
SLEEVE,ACC KIT |
|
|
SLEEVE,TG2 |
|
|
SOCKET,CONNECTOR 11P |
|
|
SOCKET,CONNECTOR 15P |
|
|
SPRING (COIL) (ST) |
|
|
SPRING,COIL (LB) |
|
|
SPRING,COIL (RK) |
|
|
TC4528BFHB-TP1,IC |
|
|
TRANSISTOR 2SC4177-L5 |
|
|
TRANSISTOR EE-TP109 |
|
|
TRANSISTOR FMY1 |
|
|
TROUBLESHOOTING GUIDE 198 |
|
|
TUBE,FLUORECENT |
|
|
VIBRATOR,LITHIUM NIOBATE |
|
|
WASHER,FIBER |
|
|
WASHER,STOPPER |
