Model Image
Manufacturer

Sony

Model Number

HDRHC9

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
1-837-287-11 1-837-287-11 (USB CABLE 5P) CORD WITH CONNE
1-838-205-11 1-838-205-11 A/V CONNECTING CABLE
1-490-430-23 1-490-430-23 AC-L200 AC ADAPTOR
1-487-150-71 1-487-150-71 ADAPTOR, AC (AC-L200D)
2-666-807-21 2-666-807-21 AG SHEET (2.7)
X-2024-469-1 X-2024-469-1 ARM (T) ASSY, GL
X-2024-468-1 X-2024-468-1 ARM ASSY(S), GL
X-2024-460-1 X-2024-460-1 BASE ASSY, CAM
X-2176-782-1 X-2176-782-1 BASE ASSY, SLIDE
2-637-947-01 2-637-947-01 BASE, MOTOR HOLDER
A-1599-884-A A-1599-884-A BATTERY PACK ASSY (FH60CE)
1-756-615-61 1-756-615-61 BH8001 - HOLDER, BATTERY
3-095-875-01 3-095-875-01 BLIND, HINGE
A-1083-006-A A-1083-006-A BLOCK ASSY, S BRAKE
A-1083-002-A A-1083-002-A BLOCK ASSY,TG6
A-1083-005-A A-1083-005-A BLOCKASSY, RVS BRAKE
3-095-822-01 3-095-822-01 BRACKET (242), AD
3-095-795-01 3-095-795-01 BRACKET (242), SHOE
X-2177-013-1 X-2177-013-1 BRACKET ASSY, MS
3-095-825-01 3-095-825-01 BRACKET, BL
3-095-778-01 3-095-778-01 BRACKET, IR CHASSIS
1-756-134-15 1-756-134-15 BT801 - BATTERY, STORAGE, LITH
1-780-064-21 1-780-064-21 BT901 - BATTERY TERMINAL BOARD
X-2187-189-1 X-2187-189-1 BUTTON ASSY, AD
1-112-766-11 1-112-766-11 C901 - CAPACITOR, ELECT 70MF
X-2187-182-1 X-2187-182-1 CABINET (C) ASSY, P
3-095-755-01 3-095-755-01 CABINET (G)
X-2176-769-3 X-2176-769-3 CABINET (L) ASSY (242)
3-095-877-21 3-095-877-21 CABINET (M), P
X-2187-181-1 X-2187-181-1 CABINET (R) ASSY
X-2187-137-1 X-2187-137-1 CABINET ASSY, BOTTOM
X-2187-187-1 X-2187-187-1 CABINET ASSY, TOP
3-095-855-01 3-095-855-01 CABINET, VF
1-829-414-63 1-829-414-63 CABLE, CONNECTION COMPONENT VI
1-833-788-11 1-833-788-11 CABLE, FLEXIBLE FLAT (FFC-107)
3-095-754-01 3-095-754-01 CLAMP (ST), FLEXIBLE
2-668-087-01 2-668-087-01 CLAMP, FLEXIBLE
2-638-780-01 2-638-780-01 CLIP
1-818-890-11 1-818-890-11 CN901 - CONNECTOR, EXTERNAL (H
X-2024-465-1 X-2024-465-1 COASTER (S) ASSY
X-2067-285-1 X-2067-285-1 COASTER (T) ASSY
X-2103-406-3 X-2103-406-3 COMPARTMENT ASSY, CASSETTE
1-838-710-11 1-838-710-11 CORD SET, POWER SUPPLY
1-757-541-13 1-757-541-13 CORD, CONNECTION, I LINK CABLE
1-790-107-61 1-790-107-61 CORD, POWER - NEED AC ADAPTOR
3-095-747-01 3-095-747-01 COVER (DCIN), JACK
3-095-878-21 3-095-878-21 COVER (FRONT), HINGE
3-095-770-01 3-095-770-01 COVER (HDMI), JACK
3-095-748-01 3-095-748-01 COVER (MIC), JACK
3-095-879-01 3-095-879-01 COVER (REAR), HINGE
X-2187-138-1 X-2187-138-1 COVER ASSY, SHOE
2-637-942-01 2-637-942-01 COVER, CAPSTAN
2-638-819-01 2-638-819-01 CUSHION, LCD
2-672-277-01 2-672-277-01 CUSHION, TP
6-500-652-01 6-500-652-01 D901 - DIODE GL453SE0000F
A-1870-876-A A-1870-876-A DEVICE LENS LSV-1190A
8-719-024-69 8-719-024-69 DI MA3S132EG8S0
2-666-804-01 2-666-804-01 DIFFUSION SHEET (2.7)
3-282-264-71 3-282-264-71 ENJOY HANDYCAM
3-282-264-01 3-282-264-01 ENJOY HANDYCAM
3-095-753-01 3-095-753-01 ESCUTCHEON, MICROPHONE
1-788-558-11 1-788-558-11 FILTER BLOCK, OPTICAL
1-479-888-11 1-479-888-11 FLASH UNIT
2-589-376-01 2-589-376-01 FOOT (395), RUBBER
X-2176-772-1 X-2176-772-1 FRAME (L) ASSY (242), LENS
X-2176-774-1 X-2176-774-1 FRAME (R) ASSY (242), LENS
X-2176-765-1 X-2176-765-1 FRAME ASSY, MD
3-095-752-01 3-095-752-01 FRAME, HDMI
2-887-999-01 2-887-999-01 FRONT FRAME (2.7J)
3-288-870-01 3-288-870-01 GASKET (4-1.5)
2-342-705-01 2-342-705-01 GEAR (T), GL
X-2067-281-1 X-2067-281-1 GEAR ASSY, CAM
X-2067-280-1 X-2067-280-1 GEAR ASSY, MODE
2-342-620-01 2-342-620-01 GEAR, CONVERSION
2-342-621-01 2-342-621-01 GEAR, RELAY
2-342-691-01 2-342-691-01 GEAR,NO.1
2-342-615-01 2-342-615-01 GEAR,NO.2
3-095-873-01 3-095-873-01 GUARD, JK
2-664-672-01 2-664-672-01 GUIDE, LAMP
8-719-067-74 8-719-067-74 H901 - ELEMENT, HOLE HW-105A-C
3-287-511-01 3-287-511-01 HANDYCAM APPLICATION SOFTWARE
1-965-256-31 1-965-256-31 HARNESS (HN-045)
3-084-377-01 3-084-377-01 HEAD (SCREW M1.2)
3-095-786-01 3-095-786-01 HEAT SINK (CMOS) (242)
X-2108-475-1 X-2108-475-1 HINGE ASSY
2-637-945-01 2-637-945-01 HOLDER, MOTOR
3-063-515-41 3-063-515-41 HOOD, LENS
6-807-924-01 6-807-924-01 IC MB91195ABGL-G-251-ERE1
6-808-122-01 6-808-122-01 IC MB91195ABGL-G-257-ERE1
6-715-704-01 6-715-704-01 IC MB95005ABGL-G-128-ERE1
6-717-596-01 6-717-596-01 IC W9825Y2DB75I-ER25
2-638-818-01 2-638-818-01 ILLUMINATOR
1-815-792-11 1-815-792-11 J001 - CONNECTOR, DC-IN (7.2V)
1-691-737-42 1-691-737-42 J801 - JACK (SMALL TYPE) - MIC
1-479-063-21 1-479-063-21 KEY BLOCK, CONTROL (SB9000)
A-1228-786-A A-1228-786-A LCD901 - TP BLOCK ASSY (27ESHG
8-753-241-14 8-753-241-14 LCD902 - LCX076AKE-1; LCD
2-342-917-02 2-342-917-02 LED BASE
A-1217-971-A A-1217-971-A LENS BARRIER UNIT
3-095-749-01 3-095-749-01 LID, CPC
2-666-801-21 2-666-801-21 LIGHT GUIDE (2.7)
A-1154-545-A A-1154-545-A M901 - DRUM DEH-33E-R
X-2067-283-2 X-2067-283-2 M902 - LOADING MOTOR ASSY
1-787-561-11 1-787-561-11 M904 - MOTOR UNIT (GEARED MOTO
3-278-987-61 3-278-987-61 MANUAL, INSTRUCTION
3-278-987-51 3-278-987-51 MANUAL, INSTRUCTION
3-278-987-12 3-278-987-12 MANUAL, INSTRUCTION
3-278-987-01 3-278-987-01 MANUAL, INSTRUCTION
A-1883-414-A A-1883-414-A MD (N220) SUB ASSY (S) A
2-638-004-01 2-638-004-01 MIC COVER
1-542-658-11 1-542-658-11 MIC901 - MICROPHONE UNIT
1-818-576-11 1-818-576-11 MIC902 - PIN, CONNECTOR (WITH
A-1449-755-A A-1449-755-A MOUNTED C. BOARD, CK-177
A-1449-754-A A-1449-754-A MOUNTED C. BOARD, JK-333
A-1449-753-A A-1449-753-A MOUNTED C. BOARD, LD-221 (COMP
A-1449-756-A A-1449-756-A MOUNTED C. BOARD, PD-325
A-1454-387-A A-1454-387-A MOUNTED C. BOARD, VC500 COMPLE
A-1231-935-A A-1231-935-A MOUNTED C.BOARD BL-007
A-1237-309-A A-1237-309-A MOUNTED C.BOARD CM-077, COMPLE
A-1174-647-B A-1174-647-B MOUNTED C.BOARD FP-372
A-1231-940-A A-1231-940-A MOUNTED C.BOARD FP-643
A-1231-943-A A-1231-943-A MOUNTED C.BOARD FP-644
A-1231-941-A A-1231-941-A MOUNTED C.BOARD FP-645
A-1231-942-A A-1231-942-A MOUNTED C.BOARD FP-646
A-1231-934-A A-1231-934-A MOUNTED C.BOARD MS-361
A-1234-567-A A-1234-567-A MOUNTED C.BOARD ST-164
A-1231-933-A A-1231-933-A MOUNTED C.BOARD US-013
2-668-134-01 2-668-134-01 PANEL (CF), POLARIZATION
X-2187-188-1 X-2187-188-1 PANEL ASSY (2422), F
X-2176-780-2 X-2176-780-2 PANEL ASSY, BT INSTEAD OF X217
X-2024-478-1 X-2024-478-1 PENDULUM ASSY
3-095-871-01 3-095-871-01 PLATE (HINGE), GROUND
3-095-876-01 3-095-876-01 PLATE (P), GROUND
2-638-816-01 2-638-816-01 PLATE (TFT), DEFLECTION
3-095-872-01 3-095-872-01 PLATE, JK RETAINER
2-342-933-02 2-342-933-02 PLATE, TOP
2-342-731-01 2-342-731-01 POSITIONING, S
7-627-850-77 7-627-850-77 PRECISION +P 1.4X1.8
2-666-803-01 2-666-803-01 PRISM SHEET H (2.7)
2-666-802-01 2-666-802-01 PRISM SHEET V (2.7)
1-677-049-11 1-677-049-11 PWB, FP-228 FLEXIBLE (DEW SENS
1-871-763-21 1-871-763-21 PWB, FP-648 FLEXIBLE
1-871-764-11 1-871-764-11 PWB, FP-649 FLEXIBLE
1-871-765-21 1-871-765-21 PWB, FP-650 FLEXIBLE
1-871-766-11 1-871-766-11 PWB, FP-651 FLEXIBLE
1-871-767-11 1-871-767-11 PWB, FP-652 FLEXIBLE
1-871-770-11 1-871-770-11 PWB, FP-655 FLEXIBLE
1-871-771-11 1-871-771-11 PWB, FP-656 FLEXIBLE
1-871-772-21 1-871-772-21 PWB, FP-657 FLEXIBLE
1-871-773-21 1-871-773-21 PWB, FP-658 FLEXIBLE
1-871-774-12 1-871-774-12 PWB, FP-659 FLEXIBLE
6-550-672-01 6-550-672-01 Q901 - TRANSISTOR PT4850FJE00F
2-342-612-01 2-342-612-01 RAIL
2-894-347-01 2-894-347-01 REFLECTION SHEET(2.7J)
A-1132-279-A A-1132-279-A REGULATOR BLOCK ASSY, TENSION
3-079-366-11 3-079-366-11 RELEASE, REEL LOCK
3-095-837-01 3-095-837-01 RETAINER, BT TERMINAL
3-095-874-01 3-095-874-01 RETAINER, JK TERMINAL
2-342-625-01 2-342-625-01 RETAINER, LEVER EJ
3-095-824-01 3-095-824-01 RETAINER, MICROPHONE
3-095-779-01 3-095-779-01 RETAINER, ST
3-097-852-01 3-097-852-01 RETAINER, USB TERMINAL
2-698-010-01 2-698-010-01 RUBBER (1190), SEAL
1-786-448-22 1-786-448-22 S901 - SWITCH, PUSH (1 KEY) (C
3-895-822-71 3-895-822-71 SCREW (M1.2X2), SPECIAL,
2-546-417-01 2-546-417-01 SCREW (M1.4)
3-703-816-08 3-703-816-08 SCREW (M1.4X1.4), SPECIAL
3-075-097-11 3-075-097-11 SCREW (M1.4X1.4), SPECIAL
3-062-214-01 3-062-214-01 SCREW (M1.4X1.5)
3-703-816-13 3-703-816-13 SCREW (M1.4X2.0), SPECIAL HEAD
3-973-497-91 3-973-497-91 SCREW (M1.7), 0-NO. +P 2
2-635-562-31 2-635-562-31 SCREW(M1.7)
2-660-401-01 2-660-401-01 SCREW(M1.7),NEW TRU-STAR,
3-078-890-21 3-078-890-21 SCREW, TAPPING
3-078-890-01 3-078-890-01 SCREW, TAPPING
3-080-204-11 3-080-204-11 SCREW, TAPPING, P2
3-080-204-01 3-080-204-01 SCREW, TAPPING, P2
3-288-871-01 3-288-871-01 SHEET (BT), ELECTROSTATIC
3-095-859-01 3-095-859-01 SHEET (CAPACITOR), INSULATING
3-095-788-01 3-095-788-01 SHEET (CMOS) (C), RADIATION
3-095-789-01 3-095-789-01 SHEET (CMOS) (R), RADIATION
3-095-797-11 3-095-797-11 SHEET (CMOS), SHIELD
3-272-247-01 3-272-247-01 SHEET (ST HOLDER), ADHESIVE
3-095-751-11 3-095-751-11 SHEET (VC), INSULATING
3-288-872-01 3-288-872-01 SHEET (VC1), ELECTROSTATIC
2-541-585-01 2-541-585-01 SHEET, FLEXIBLE ADHESIVE
3-098-924-01 3-098-924-01 SHEET, MICROPHONE RETAINER
X-2024-463-2 X-2024-463-2 SLIDER ASSY, MODE
1-825-262-82 1-825-262-82 SP901 - LOUD SPEAKER (1.6CM)
2-664-671-01 2-664-671-01 SPACER, LCD
2-342-926-01 2-342-926-01 SPRING (ARM S), TENSION COIL
2-342-927-01 2-342-927-01 SPRING (ARM T), TENSION COIL
2-342-624-01 2-342-624-01 SPRING (PINCH LIMITTER),
2-342-906-01 2-342-906-01 SPRING (PINCH RETURN), TORSION
2-342-626-01 2-342-626-01 SPRING (RETURN TG6), EXTENSION
2-342-716-01 2-342-716-01 SPRING (T), TORSION COIL
2-342-759-01 2-342-759-01 SPRING, RVS BRAKE
2-342-902-01 2-342-902-01 SPRING, TENSION REGULATOR
A-1599-883-A A-1599-883-A SQX-3065(UC) NP-FH60; RECHARGE
1-479-895-31 1-479-895-31 SWITCH BLOCK, CONTROL (PS24200
1-479-004-31 1-479-004-31 SWITCH BLOCK, CONTROL(AD11800)
X-2067-290-1 X-2067-290-1 TABLE ASSY, S REEL
X-2067-291-1 X-2067-291-1 TABLE ASSY, T REEL
3-941-343-21 3-941-343-21 TAPE (A)
2-590-635-01 2-590-635-01 TAPE (AS 1/2)
2-319-256-01 2-319-256-01 TAPE AS (0409)
2-342-918-01 2-342-918-01 TG6 CATCHER
3-095-744-01 3-095-744-01 TRIPOD
3-315-414-31 3-315-414-31 WASHER
1-478-495-41 1-478-495-41 WIRELESS REMOTE CONTROL (RMT-8
2-342-689-01 2-342-689-01 WORM SHAFT (2J)
