Model Image
Manufacturer

Sony

Model Number

HP149A

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
9-930-022-20 9-930-022-20 BEARING CAPSTAN
1-249-437-11 1-249-437-11 CARBON 47KH 1/4W
8-729-601-00 8-729-601-00 CS6225F
1-107-929-11 1-107-929-11 ELECT CAP 3.3UF 25V
1-105-693-00 1-105-693-00 MYLAR0.47UF 50V
7-621-772-78 7-621-772-78 SCREW MACH +P2X14
7-621-772-38 7-621-772-38 SCREW MACH +T2X6
7-685-133-19 7-685-133-19 SCRSELF-TAP(+)P2.6X6
1-516-479-XX 1-516-479-XX SWITCH BIAS
8-729-140-96 8-729-140-96 TRANSISTOR
1-237-514-21 1-237-514-21 VARIABLE RES 150-
