Sony

Model Number

ICFCD543RM

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
8-820-161-02 8-820-161-02 605 OPTICAL PICKUP 03-11-04
3-238-568-11 3-238-568-11 BUTTON (OPEN)
X-3381-915-1 X-3381-915-1 CABINET (LOWER) ASSY
X-3381-654-1 X-3381-654-1 CABINET (LOWER) ASSY
X-3381-653-1 X-3381-653-1 CABINET (LOWER) ASSY
1-823-760-11 1-823-760-11 CABLE, FLEXIBLE FLAT
1-419-540-21 1-419-540-21 COIL, OSCILLATION (AM)
3-241-678-01 3-241-678-01 CUSHION (1041)
1-804-648-11 1-804-648-11 DISPLAY PANEL, LIQUID CRY
3-238-567-11 3-238-567-11 LID, CD
A-3178-334-A A-3178-334-A MOUNTED C.BOARD (HAND), R
A-3021-883-A A-3021-883-A MOUNTED C.BOARD ASSY, LCD
A-3021-777-A A-3021-777-A MOUNTED C.BOARD ASSY, LCD
A-3021-881-A A-3021-881-A MOUNTED C.BOARD ASSY, MAI
A-3021-773-A A-3021-773-A MOUNTED C.BOARD ASSY, MAI
3-011-879-01 3-011-879-01 MOUNTING SCREW (M5X80)
3-009-707-01 3-009-707-01 MOUNTING SPACER
X-3382-368-1 X-3382-368-1 PANEL (FRONT) ASSY
X-3382-365-1 X-3382-365-1 PANEL (FRONT) ASSY
9-873-658-03 9-873-658-03 SERVICE MANUAL
