Manufacturer
Sony
Model Number
KD55X75CH
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
(MAIN CBA( COMPL_BKR_UC (UC2) |
|
|
(POWER CBA) GL6 (CH) - STATIC CONVERTER (TV) (UC2) |
|
|
BACK LIGHT COVER (L BCH) A (UC2) (PANEL PART) |
|
|
BEZEL (L NCS) A (BM11) (UC2) (PANEL PART) |
|
|
BEZEL (L NCS) A (UC2) |
|
|
BRACKET, SIDE (RBY) A (UC2) |
|
|
CONNECTOR ASSY 30P (UC2) |
|
|
CONNECTOR ASSY 5P (UC2) (PANEL PART) |
|
|
DIFFUSER PLATE (L) (UC2) (PANEL PART) |
|
|
FLEXIBLE FLAT CABLE 20P (UC2) |
|
|
FLEXIBLE FLAT CABLE 51P (UC2) |
|
|
FLEXIBLE FLAT CABLE 60P (BM11) (UC2) (PANEL PART) |
|
|
FLEXIBLE FLAT CABLE 60P (UC2) |
|
|
GASKET (4X5 (7)), SOFT (UC2) (PANEL PART) |
|
|
GASKET, TCON CN (NCS) (UC2) (PANEL PART) |
|
|
HARNESS ASSY (UC2) |
|
|
HKR-L_CITIZEN MOUNT (UC2) |
|
|
LABEL, UNDER TERMINAL (CPN) (UC2) |
|
|
LIQUID CRYSTAL ELEMENT(C550D11 (UC2) |
|
|
MICROLENS ON PRISM (L) (UC2) (PANEL PART) |
|
|
MIDDLE CHASSIS BT (L BCH) A (UC2) (PANEL PART) |
|
|
MIDDLE CHASSIS L (L BCH) A (UC2) (PANEL PART) |
|
|
MIDDLE CHASSIS R (L BCH) A (UC2) (PANEL PART) |
|
|
MIDDLE CHASSIS TP (L BCH) A (UC2) (PANEL PART) |
|
|
MOUNTED PWB E-T-CON (55) (UC2) |
|
|
MOUNTED PWB LS BAR (GBR L) (UC2) |
|
|
P-MOD (YSAS055CNS01)(SERVICE) (UC2) |
|
|
POLARIZER F/CF (313050U900000G) (UC2) (PANEL PART) |
|
|
POLARIZER R/TFT (313050YV00000G) (UC2) (PANEL PART) |
|
|
REFLECTIVE SHEET (L) (UC2) (PANEL PART) |
|
|
SCREW, +PSW M3X6 (UC2) (PANEL PART) |
|
|
SHEET, THERMAL (CCB) (UC2) (PANEL PART) |
|
|
SHEET, THERMAL(BKR) (UC2) |
|
|
SOURCE DRIVER IC MT BOARD (33021000000191) (UC2) (PANEL PART) |
|
|
STAND, NECK (L RBY) A (UC2) |
|
|
TAPE, ADHESIVE 810A (UC2) (PANEL PART) |
|
|
TAPE, SEALING BC (L BCH) (UC2) (PANEL PART) |
|
|
WLAN/BT MODULE(11AC)/DHUK-SY22 (UC2) |
