Manufacturer
Sony
Model Number
KD65X725E
Description
65-inch Class 4k Tv
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
(MAIN CBA) COMPL_SVC_BB8_AR_PSU (AR4) |
|
|
(MAIN CBA) COMPL_SVC_BB8_AR_PSU (ECU) |
|
|
(MAIN CBA) COMPL_SVC_BB8_SA_PSU (LA8) |
|
|
(POWER CBA) GL72-STATIC CONVERTER(TV) (AR4,LA8,ECU) |
|
|
AC COVER(PDT 2L) (AR4,LA8,ECU) |
|
|
ADAPTOR, CONVERSION (LA8,ECU) |
|
|
AL BEZEL(B) (760.0260F.0001) (PANEL PART) (ECU,LA8,AR4) |
|
|
AL BEZEL(L) (760.0260D.0001) (PANEL PART) (ECU,LA8,AR4) |
|
|
AL BEZEL(R) (760.0260E.0001) (PANEL PART) (ECU,LA8,AR4) |
|
|
AL BEZEL(T) (760.0260G.0001) (PANEL PART) (ECU,LA8,AR4) |
|
|
BRACKET, SIDE (CPN 2L) (AR4,LA8,ECU) |
|
|
BRACKET, UNDER (FRE) (AR4,LA8,ECU) |
|
|
CARD, WIRELESS LAN (AR4) |
|
|
CARD, WIRELESS LAN (LA8,ECU) |
|
|
CLAMPER, CABLE (AR4,LA8,ECU) |
|
|
CONNECTOR ASSY 30P (AR4,LA8,ECU) |
|
|
CUSHION (PDT AC) (AR4,LA8,ECU) |
|
|
FFC (750.02604.0001) (PANEL PART) (ECU,LA8,AR4) |
|
|
FLEXIBLE FLAT CABLE 51P (AR4,LA8,ECU) |
|
|
FLEXIBLE FLAT CABLE 51P (AR4,LA8,ECU) |
|
|
FLEXIBLE FLAT CABLE 5P (AR4,LA8,ECU) |
|
|
FLEXIBLE FLAT CABLE 5P (AR4,LA8,ECU) |
|
|
HARNESS ASSY (AR4,LA8,ECU) |
|
|
HOLDER SIDE SW(PDT) (AR4,LA8,ECU) |
|
|
LABEL, SIDE TERMINAL (FRE) (AR4,LA8,ECU) |
|
|
LABEL, UNDER TERMINAL (CPN) (AR4,LA8,ECU) |
|
|
LCD PANEL(W65QWSEB) (AR4,LA8,ECU) |
|
|
LIQUID CRYSTAL ELEMENT (PANEL PART) (ECU,LA8,AR4) |
|
|
MOUNTED PWB E-T-CON (PANEL PART) (ECU,LA8,AR4) |
|
|
NECK, STAND (2L HDN) A (AR4,LA8,ECU) |
|
|
POLARIZER F/CF (66.C4U57.309) (PANEL PART) (ECU,LA8,AR4) |
|
|
POLARIZER R/TFT (66.T4U58.308) (PANEL PART) (ECU,LA8,AR4) |
|
|
POWER-SUPPLY CORD (WITH CONN.) (AR4) |
|
|
POWER-SUPPLY CORD (WITH CONN.) (AR4) |
|
|
POWER-SUPPLY CORD (WITH CONN.) (LA8,ECU) |
|
|
POWER-SUPPLY CORD (WITH CONN.) (LA8,ECU) |
|
|
PULLEY, STAND (HWI) (AR4,LA8,ECU) |
|
|
REAR COVER (2L_HDN) A (AR4,LA8,ECU) |
|
|
REMOTE COMMANDER(RMT-TX300B) (AR4,LA8,ECU) |
|
|
SCREW, M3*5 (086.7B564.05R0) (PANEL PART) (ECU,LA8,AR4) |
|
|
SHEET, INSULATION (PDT 2L) (AR4) |
|
|
SHEET, INUSLATION (PDT 2L) (AR4,LA8,ECU) |
|
|
SHEET, THERMAL(BM) (AR4,LA8,ECU) |
|
|
SOURCE DRIVER IC MT BOARD (46.S0966.162) (PANEL PART) (ECU,LA8,AR4) |
|
|
SP-BOX ASSY, W25(L)-E (AR4,LA8,ECU) |
|
|
SPACER(17)+C (AR4,LA8,ECU) |
|
|
STAND (2L HDN) A (AR4) |
|
|
STAND(2L HDN) A (LA8,ECU) |
|
|
STOPPER (A) (AR4,LA8,ECU) |
|
|
SWITCH UNIT(3M-P) (AR4,LA8,ECU) |
|
|
TAPE, LCM BOTTOM (740.0260N.0001) (PANEL PART) (ECU,LA8,AR4) |
|
|
TAPE, OC BOTTOM (740.0260M.0001) (PANEL PART) (ECU,LA8,AR4) |
|
|
TAPE, OC TOP (740.0260H.0001) (PANEL PART) (ECU,LA8,AR4) |
|
|
UNIVERSAL SIL-TU SUT-RT243ZP (AR4,LA8,ECU) |
